Kodak ESP - User manual

Networking Setup Guide
Guide de configuration réseau
Guía de configuración de red
Guia de configuração de rede
All-in-One Printers • Imprimantes tout-en-un
Impresoras multifunción • Impressoras Multifuncionais

2www.kodak.com/go/aiosupport
1 Setting Up a Wireless (Wi-Fi) Connection
Before you connect, you need:
•awirelessrouter.
• to determine whether your wireless router supports Wi-Fi Protected Setup (WPS).
NOTE: If you have specific questions about your router, see your router manufacturer’s documentation.
Connecting to a non-WPS wireless router
Record your network information in the spaces below, using the correct uppercase and lowercase letters.
Network Name (SSID): ____________________________________________________
Security String (case-sensitive): ____________________________________________
NOTE: If you already set up your printer, you need to press Home, then press to select Network
Settings, then WiFi Setup Wizard. Press OK after each selection.
1. Press to select Wireless, then press OK.
2. Press to select your network, then press OK.
If you don’t see your network in the list, or if you want to change your network, select Rescan for
Wireless Networks, then press OK.
If the name of your network is not listed, make sure your wireless router is turned on and within
range. If the name of your network is still not listed, go to www.kodak.com/go/inkjetnetworking.
3. If your network requires a password, use the LCD keyboard to enter your Security String. The
Security String is case-sensitive.
On the control panel (both types of keyboards), press , , or to select the letters and
numbers, using the correct uppercase and lowercase letters. Press OK after each character. When
you are done, select DONE, then press OK.

www.kodak.com/go/inkjetnetworking 3
Networking Setup Guide for KODAK All-in-One Printers
There are two types of keyboards. Follow the instructions for your keyboard.
4. When the confirmation message appears, press OK.
When the printer is successfully connected, the Wi-Fi status light is on.
If you are unable to connect your printer, go to www.kodak.com/go/inkjetnetworking.
5. Install the KODAK All-in-One Printer Software on your computer. Follow the on-screen instructions
to complete your setup.
NOTE: If you installed the software before connecting to your network, select Start > Programs >
Kodak > Kodak Printer Network Setup Utility and follow the on-screen instructions.
Connecting to a WPS wireless router
NOTE: If you already set up your printer, you need to press Home, then press to select Network
Settings, then WiFi Setup Wizard. Press OK after each selection.
1. Press to select Wireless, then press OK.
•To change from uppercase to
lowercase, select abc/123,
then press OK.
• To change from lowercase to
uppercase, select ABC/123,
then press OK.
•To enter punctuation or
symbols, select !@#, then press
OK.
Use the arrow
keys to select the
letters, numbers,
and symbols.
Press OK after
each selection.

Setting Up a Wireless (Wi-Fi) Connection
4www.kodak.com/go/aiosupport
2. With WPS Connect selected, press OK.
3. Select one of these two methods of connecting:
IMPORTANT: Before you press OK on the printer, make sure you know where the router's button is, or where
to enter the generated PIN.
4. When the confirmation message appears, press OK.
When the printer is successfully connected, the Wi-Fi status light should be on.
If you are unable to connect your printer, go to www.kodak.com/go/inkjetnetworking.
5. Install the KODAK All-in-One Printer Software on your computer. Follow the on-screen instructions to
complete your setup.
NOTE: If you installed the software before connecting to your network, select Start > Programs >
Kodak > Kodak Printer Network Setup Utility and follow the on-screen instructions.
Pressing a Button Entering a PIN
a. With Push Button Configuration selected, press OK.
b. Press or select the WPS button for your wireless router.
NOTE: You will have two minutes to press or select the
WPS button. It may be a button on the device or a
virtual button in the device’s software.
a. Press to select Generate WPS
PIN, then press OK.
b. In your wireless router’s software,
locate the PIN screen.
c. Enter the PIN you received from the
LCD into the PIN screen.

www.kodak.com/go/aiosupport 5
1 Setting Up an Ethernet Connection
Before you connect, you need to:
• Have a functional Ethernet network that includes a router, switch, or hub with an Ethernet port.
• Have a Category 5 (or higher) Ethernet cable.
• Temporarily disable your firewall until the printer is successfully installed and communicating.
Connecting to an Ethernet network
1. Connect the Ethernet cable into the Ethernet port on the back of the printer.
2. Connect the other end of the Ethernet cable into an available Ethernet port
on your router, switch, or hub.
3. Install the KODAK All-in-One Printer Software on your computer. Follow the
on-screen instructions to complete your setup.

Eastman Kodak Company
Rochester, NY 14650
© Eastman Kodak Company, 2010
Kodak is a trademark of Eastman Kodak Company.
Specifications subject to change without notice.
P/N 1K5951
July 2010
Printed in China
1K7343
