Kodak PIXPRO AZ652 User manual

KODAK PIXPRO AZ652
DIGITAL CAMERA
User Manual

ii
1
ii
1
Declaration of Conformity
Responsible Party: JK Imaging Ltd.
Address: JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
JK Imaging Europe, 71 Clarendon Road, Watford, WD17 1DS, UK
Company Website: kodakpixpro.com
INDUSTRY CANADA
This device complies with Canadian RSS210.
This device complies with Industry Canada license-exempt RSS standard (s).Operation
is subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Radiation Exposure Statement:
This product complies with the Canadian portable RF exposure limit set forth for an
uncontrolled environment and is safe for intended operation as described in this manual.
Additional RF exposure reduction can be achieved if the product can be kept as far as
possible from the user body or set the device to lower output power if such function is
available.
BEFORE YOU START

2
For Customers in Europe
This symbol [crossed-out wheel bin WEEE Annex IV] indicates separate collection
of electrical waste and electronic equipment in the European countries. Please do
not throw the equipment into domestic refuse. Please use the return and collection
systems available in your country for proper, safe disposal of this product.
“CE” mark indicates that this product complies with the European requirements
for safety, health, environment and customer protection. “CE” marked cameras are
intended for sales in Europe.
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the R&TTE Directive
2014/53/EU. The following test methods have been applied in order to prove
presumption of conformity with the essential requirements of the R&TTE Directive
2014/53/EU:
- EN 609501: 2006+A11:2009 +A1:2010 +A12:2011
Safety of Information Technology Equipment
- EN 50566: 2013
Product standard to demonstrate compliance of radio frequency ields from
handheld and body- mounted wireless communication devices used by the general
public (30 MHz — 6 GHz)
- EN 622092: 2010
Human exposure to radio frequency ields from handheld and bodymounted
wireless communication devices — Human models, instrumentation, and
procedures
Part 2: Procedure to determine the speciic absorption rate (SAR) for wireless
communication devices used in close proximity to the human body (frequency
range of 30 MHz to 6 GHz)

3
- EN 300 328 V1.9.1 : 2015
Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband
transmission systems; Data transmission equipment operating in the 2.4GHz ISM
band andusing wide band modulation techniques; Harmonized EN covering the
essential requirements of article
- EN 301 4891 V1.9.2: 2011
Electromagnetic compatibility and Radio Spectrum Matters (ERM); Electro
Magnetic Compatibility (EMC) standard for radio equipment and services; Part 1:
Common technical requirements.
- EN 301 48917 V2.2.1:2012
Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic
Compatibility (EMC) standard for radio equipment; Part 17: Speciic conditions for
Broadband Data Transmission Systems
Hereby, Sintai Optical (Shenzhen) Co., Ltd, declares that this PIXPRO AZ652 is
in compliance with the essential requirements and other relevant provisions of
Directive 2014/53/EU.
Manufacturer: Sintai Optical (Shenzhen) Co., Ltd
Address: Qiwei Ind Sec, 1st, 2nd,& 3RD Bldg, Lisonglang Village, Gongming Town,
Bao’an District, Shenzhen, Guangdong, China
Batteries: Please dispose of used batteries at designated collection centers.
Packaging: Please follow local regulations for the recycling of packaging.
For Customers in the U.S.A.
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.

4
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modiications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Radiation Exposure Statement:
This product complies with the FCC portable RF exposure limit set forth for an
uncontrolled environment and is safe for intended operation as described in this manual.
Additional RF exposure reduction can be achieved if the product can be kept as far as
possible from the user body or set the device to lower output power if such function is
available.

5
About this Manual
Thank you for purchasing this KODAK PIXPRO Digital Camera. Please read this manual
carefully and keep it in a safe place for future reference.
JK Imaging reserves all rights of this document. No part of this published manual may
be reproduced, transmitted, transcribed, stored in a retrieval system or translated
into any language or computer language, in any form, by any means, without the prior
written permission of JK Imaging.
All trademarks mentioned in this manual are used for identiication purposes only and
are properties of their respective owners.
This manual will instruct you on how to operate the KODAK PIXPRO Digital Camera. JK
Imaging has tried its utmost to ensure the correctness of the user manual contents,
but reserves the right to modify as necessary. All of these contents are subject to
change without prior notice.
Throughout this manual, the following symbols are used to help you locate
information quickly and easily:
Indicates useful information.
In the instructions below, the following symbols may be used throughout this manual
on how to operate the camera. This is to facilitate better understanding.
「Item properties」：The optional properties in the camera interface are indicated by
the symbol「」.

6
7
SAFETY NOTES
Safety notes for this camera
Do not drop the camera or allow it to
hit solid objects.
Do not attempt to disassemble or
repair the camera.
Do not use or store the camera in dusty
places or on a beach to prevent dust
or sand from entering the camera,
causing possible damage to it.
Do not use or store the camera in a hot
environment or under direct sunlight.
Do not use or store the camera near a
powerful magnetic ield, for example
near a magnet or transformer.
Avoid touching the lens of the camera.
Do not expose the camera to direct
sunlight for a long period of time.
To prevent the camera from being
damaged by moisture, do not use
or store the camera in very humid
environments, such as in rain or near
bodies of water.
If water accidentally comes in contact
with the camera, turn the camera off,
remove the battery and the memory
card, and dry it within 24 hours.
When you take the camera from a
cold place to a warmer environment,
condensation may occur. Please wait
for a reasonable period of time before
you turn it on.
Before you remove the battery and
memory card, the camera should be
turned off.
When you clean the body of the
camera, do not use abrasive, alcohol-
based or organic cleaner.
Use a professional lens wiping cloth
and dedicated cleaner to wipe and
clean the lens.
Download your photos and remove the
memory card when you are going to
store the camera for a long period of
time.
If this camera is not in use for a long
time, please keep it in a dry and clean
condition.
Our company will not pay
compensation for any failure of
playback of pictures or videos caused
by improper operation.

7
6
7
Safety notes for battery
Please use a battery that is the same
type as the one included.
Please use the attached charger to
charge the battery.
If battery luid leaks inside the
camera, contact our customer service
department. If battery luid leaks onto
your skin, rinse your skin with clean
water and seek immediate medical
attention.
Disposal of used batteries should be
carried out in accordance with the
local (national or regional) regulations.
To prevent the battery from being
damaged, do not drop the battery or
allow it to hit solid objects or to be
scratched by the objects.
Do not let the battery come in contact
with metal objects (including coins)
to avoid short circuiting, discharging,
excessive heat, or possible leakage.
Do not attempt to disassemble the
battery.
Do not expose the battery to water.
Always keep the battery contacts dry.
Do not heat the battery or throw it into
a ire to avoid a possible explosion.
Do not store the battery in a hot
environment or in direct sunlight.
If the battery overheats during
charging or use, stop charging or use
immediately. Turn off the product,
remove the battery carefully, and wait
until it cools down.
When the camera is stored for a long
period of time, remove the battery
and keep it in a dry place that is not
accessible to infants and children.
In a colder environment, the
performance of the battery could be
noticeably reduced.
When you install the battery, install it
according to the positive and negative
markings on the battery compartment.
Never force it into the battery
compartment.

8
Safety notes for memory card
We suggest buying only well-known,
name brand memory cards to ensure
peak performance.
Format the memory card using the
camera before you use it or insert a
new one.
Do not drop the memory card or
allow it to hit solid objects to avoid
damaging it.
Do not attempt to disassemble or
repair the memory card.
Do not expose the memory card to
water. Always keep it dry.
Do not remove the memory card when
the camera is turned on. Otherwise,
the memory card could be damaged.
Do not directly edit the data on the
memory card. Copy the data to your
PC before you edit them.
When the camera is stored for a long
period of time, be sure to download
your photos and remove the memory
card. Store it in a dry environment.
Do not modify the name of the iles
or folders of the memory card using
your PC. Modifying the ile names may
cause the iles to not be recognized
on the camera or a possible error may
occur.
A photo taken with the camera
will be stored in the folder that is
automatically generated on the
memory card. Do not store photos
that are not taken using this camera in
these folders as the pictures cannot be
recognized during the playback.
When you insert a memory card, make
sure the notch of the card matches the
markings on the top of the card slot.

9
Other Safety Notes
Do not disconnect the power or turn the camera off during the update process. Doing
so may cause incorrect data to be written and the camera may not power on later.
Do not hang the neck strap of the camera around the neck of a child.
When using your camera on an airplane, observe the relevant rules speciied by the
airline.
Due to the limitations of manufacturing technology, the LCD may have a few dead
or bright pixels. These pixels do no effect the quality or performance of the camera,
photos or video.
Do not expose the LCD to water. In a humid environment, only wipe it with a soft and
dry cleaning cloth.
If the LCD is damaged and the liquid crystal comes into contact with your skin, wipe
your skin with a dry cloth immediately and rinse it with clean water. If liquid crystal
comes into contact with your eyes, wash them with clean water at least for 15 minutes
and seek immediate medical attention. If you accidentally swallow liquid crystal, rinse
your mouth immediately and seek medical attention.

10
11
BEFORE YOU START.............. 1
SAFETY NOTES ..................... 6
CONTENTS...........................10
GETTING READY...................14
Accessories Included......................14
Install Lens Cap and Neck Strap.....15
Part Names ......................................16
Installing Battery and Memory Card .19
Charging Battery .............................21
Vari-angle LCD.................................22
Turning Camera On and Off ...........23
Set your Language, Date/Time
after the irst power-on.............24
Set your Language, Date/Time.......24
Resetting your Language..........25
Resetting Date/Time .................26
MODE OVERVIEW ................27
LCD Display......................................27
Overview of the Screen Icons in
Shooting Mode .........................27
Overview of the Screen Icons in
Movie Mode...............................29
Overview of the Screen Icons in
Playback Mode..........................30
How to Take Pictures.......................31
Using the Mode Dial ........................32
Face Beautiier ..................35
Wi-Fi Mode .........................36
Scene Mode ....................43
Custom Settings .................49
BASIC OPERATION............... 51
Using EVF (Electronic View Finder) .51
Using the Zoom Function................52
Display Setting ................................53
CONTENTS

11
10
11
AF Area ............................................55
Macro Mode.....................................56
Self-timer Mode ..............................57
Flash Mode .....................................58
WB (White Balance) Mode ..............60
Continuous Shot Mode ...................62
Exposure Compensation Functions
Setting .............................................64
EV Adjustment...........................64
ISO Adjustment.........................65
Shutter Speed Adjustment.......65
Aperture Adjustment ................66
Using Quick Recording ...................66
i Button Function Menu...................67
Using the Lens Function Ring .........68
Zoom/AF Mode..........................68
Function Ring (Smart) Mode ....69
MF(Manual Focus) Mode...........70
PLAYBACK ............................ 71
Viewing Photos and Videos ............71
Thumbnail View...............................72
Using Zoom Playback (for still
pictures only)...................................73
Continuous Shot Group Playback ..74
Animation Panorama Play ...............75
Slideshow ........................................76
Photos and Video Deletion .............77
USING THE MENUS.............. 78
Shooting Menu................................78
Expo Metering...........................79
OIS (Optical Image
Stabilization) .............................79
Beautiier ...................................80
Select Scene .............................80
Shoot Setting1 .................................81
Image Size.................................82

12
Movie Size .................................83
Quality .......................................84
MF (Manual Focus) Assist .........85
AF Assist Beam..........................86
Digital Zoom..............................86
Shoot Setting 2................................87
Date Imprint ..............................88
Quick Review.............................88
Cont. AF.....................................89
Face Detection ..........................89
Custom Settings .......................90
Function Ring (Smart)...............91
Playback Menu ................................92
Menu ...................................92
Display Mode .......................93
Rotate ..................................93
Color ...................................94
HDR .....................................95
Touch-up .............................96
Resize .................................97
Playback Settings ...........................97
Protect.......................................98
Delete ........................................98
DPOF (Digital Print Order
Format) ......................................99
Trim............................................100
Play Slide Show.........................100
General Settings..............................101
Sound Settings..........................102
Power Saver...............................102
Language...................................103
World Time ................................103
Date & Time...............................103
LCD Brightness..........................103
File Settings.....................................104
Format ......................................105

13
Copy to Card.............................106
File Numbering..........................106
Reset Settings ...........................107
Version.......................................107
CONNECTION SETTINGS .. 108
Connecting to a Computer.............108
Setting the USB Mode ..............108
Transferring iles to your
computer...................................109
Connecting to a PictBridge
Compatible Printer..........................110
Setting the USB Mode ..............110
Connecting to your Printer.......111
Using the PictBridge Menu .............112
Print (with Date) ........................112
Print (without Date)...................113
Print Index .................................114
Print DPOF Images ....................115
Exit.............................................115
Video System ..................................116
Supported HDMI Connections .......117
Connecting HDMIReady TV.....117
HDMI CEC Control...........................118
Set Eye-Fi SD Card Connection
Mode................................................123
APPENDICES ...................... 124
Product Speciications....................124
Prompts and Warning Messages ....128
Troubleshooting ..............................133

14
15
14
15
GETTING READY
Your camera box should contain the camera model you purchased along with the
following accessories. If anything is missing or appears to be damaged, please contact
your retailer.(Based on sales in different countries or regions, the shape of the AC adapter
will vary. Please subject to the actual product will prevail.)
Accessories Included
Micro USB Cable
Warranty Card
AC Adapter Neck StrapRechargeable
Li-ion battery
Lens Cap With Strap
Quick Start Guide
Quick Start Guide
STOP
Service Card CDROM

14
15
14
15
Install Lens Cap and Neck Strap






16
17
Part Names
11
10
1
2
3
987654
1. Micro HDMI Port
2. Micro USB Port
3. Zoom Lever
4. Shutter Button
5. Strap Eyelet
6. Exposure Compensation Button
7. Continuous Shot Button
8. Power Button
9. AF Assist Beam/Self-timer Lamp
10. Flash Lamp
11. Lens

17
16
17
13
12 14
17
16
18
19
20212223
15
5
12. Microphone
13. Electronic View Finder (EVF)
14. EVF / LCD Switch Button
15. Indicator Lamp
16. Mode Dial
17. Fast Video Recording Button
18. Menu Button
19. Jog Dial
[ ] AF Button/Up Button
[ ] Delete Button/Self-timer
Button/Down Button
[ ] Macro Button/Left Button
[ ] Flash Button/Right Button
20. Display Button
21 . Playback Button
22. SET Button
23. i Button
Rolling the jog dial can be for fast selection instead of pressing the up/down/left/
right button.

18
19
18
2425262728
24. Vari-angle LCD
25. Diopter Adjustment Knob
26. Speaker
27. Lens Function Ring Lever
28. Lens Function Ring
29
30
29. Battery Cover
30. Tripod Socket

18
19
2. Insert the battery into the battery
compartment according to the
negative and positive directions as
illustrated in the picture. Push the
battery down until it locks in place.
1. Open the battery cover.
2
1
Installing Battery and Memory Card
Battery Lock Knob
