KODAK FLIK HD9
SMART PROJECTOR
User Manual

2 | EN
INTRODUCTION
Thank you for purchasing the KODAK FLIK HD9 Smart Projector. This User Guide is
intended to provide you with guidelines to ensure that operation of this product is safe
and does not pose risk to the user. Any use that does not conform to the guidelines
described in this User Guide may void the limited warranty.
Please read all directions carefully before using the product and retain this guide
for reference. This product is intended for household use only. It is not intended for
commercial use.
This product is covered by a limited one-year warranty. Coverage is subject to limits
and exclusions. See warranty for details.

EN | 3
SPECIFICATIONS
Product type: Projector
Product length: 4.3”
Product width: 5.4”
Product height: 5.9”
Native resolution: 1920 x 1080p
Power input: 19 V, 3 A
Rated voltage: AC 100 – 240 V, 50 - 60 Hz
Power consumption: 57 W
Brightness: 200 ANSI lumens
Light source: LED
Light source life: 30,000 hours
Contrast ratio: 960:1
Aspect ratio: 16:9
Throw ratio: 1.22
Keystone correction: Keystone ± 45°
Projection screen size: 40” - 120”
Projection distance: 43.7” - 105.5” (1.11 m -
2.68 m)
Image input modes: HDMI input x 1, USB
input x 1
Speakers: Dual 3-watt speakers
Audio out: 3.5 mm
Connectivity: BLUETOOTH 5.0, Wi-Fi 2.4
GHz/5 GHz 802.11 a/b/g/n/ac
Color: Black or white
Power source required: Yes (plug-in power)
Installation required: No
Adult assembly required: No
Additional tools required: No
Country of origin: China
Warranty included: Yes
Warranty length: 1 year

4 | EN
PACKAGE CONTENTS
SAFETY PRECAUTIONS
• KODAK FLIK HD9 Smart Projector
• AC adapter
• Power cord
• Remote control
• User guide
• Do not attempt to disassemble this device for any reason.
• Do not store the projector in areas where it will be exposed to high temperatures,
humidity, or direct sunlight. Exposure to any or all of these could permanently
damage the projector.
• Never handle the projector with damp or wet hands. This could damage the projector
or create the risk of electric shock.
• Keep the projector out of the reach of children.
• Never point the projector at someone else’s face or look directly into the projector
light. The light is bright and could cause damage.
• Do not use products such as alcohol, gasoline, diluent, or any other organic solvent
when cleaning or attempting to clean this product.
• Do not use this device in an environment where it will be exposed to heavy dust or

EN | 5
humidity/moisture.
• Never drop or shake the projector, as this could cause it to malfunction or
permanently damage the inside parts.
• Do not use the projector while bathing or in a shower.
• Do not place or store the projector where it can fall or be pulled into a tub or sink.
• Do not place, drop, or submerge the projector in water or any other liquid.
• If the projector somehow falls into the water despite you taking all of the above
precautions, please do not reach into the water to retrieve it. Unplug it immediately
and then retrieve it.
• Take care that objects and liquids do not fall or spill onto the projector.
• Improper maintenance can result in injuries or damage to the device.
• Do not make any repairs to the device by yourself. Only have your device repaired by
an authorized service center.
• Power o the device and remove it from the power supply before cleaning the
exterior. Use a soft, dry cloth to clean the device.
⚠WARNING: This product contains chemicals known to the State of California to
cause cancer and birth defects or other reproductive harm.
For more information: www.P65Warnings.ca.gov

6 | EN
PRODUCT OVERVIEW
FRONT BACK
1
2
8
3 4 5 7
6

EN | 7
TOP BOTTOM
10 11
12
9
1. Lens
2. Air ventilation
3. DC IN port
4. USB port
5. HDMI port
6. Indicator
7. IR receiver
8. 3.5 mm AUX port
9. Power button
10. Manual focus wheel
11. Feet
12. Tripod port

8 | EN
REMOTE CONTROL VIEW
1. Power button
2. Mute button
3. OK button
4. Navigation buttons
5. Return button
6. GOOGLE assistant button
7. Home button
8. Volume +/- buttons
9. NETFLIX button
10. PRIME VIDEO button
11. On-screen settings button
12. Projector settings button
1
11
2
12
3
4
5
6
7
8
910

EN | 9
INSTALL BATTERIES INTO THE REMOTE CONTROL
SET UP THE PROJECTOR
1. Press down and slide o the
battery cover.
2. Insert the two (2) AAA batteries
into the battery compartment.
3. Place the battery cover back on
the remote control.
1. Place the projector in front of a suitable projection screen or wall.
2. Connect the AC adapter to the power cord.
3. Then, connect the power jack of the AC adapter to the projector.
4. Connect the wall plug of the power cord to a wall outlet. The LED indicator on the
back of the projector will light up red.
5. Press the Power button on the projector or remote control to turn on the device.
The LED indicator will then turn green.

10 | EN
ADJUSTING FOCUS
PAIR THE REMOTE CONTROL
If the image on the screen appears fuzzy or unfocused when you turn the projector on,
use the focus wheel on the top to correct the image. Move the wheel left or right until
the image appears sharp and clear.
NOTE: For best performance, the projector must be located a minimum distance of 3.5
feet (1 meter) from the screen.
Power on the projector and the remote control should automatically pair with the
projector.
For manual pairing, press and hold the Volume – and OK buttons simultaneously for ive
(5) seconds. The LED light on the remote control will begin to lash. When the pairing
is complete, the LED light on the remote control will remain on without lashing. You
should now see a blue checkmark on your screen. Remember to always point your
remote control towards the projector and not the screen.

EN | 11
SET UP ANDROID TV ON THE PROJECTOR
There are two methods for setting up ANDROID TV on your projector:
Method 1: Set Up with an ANDROID Phone
1. When your projector says, “Quickly set up your projector with your ANDROID
phone?” use the remote control to choose “Continue” or “Yes.”
2. Open the GOOGLE app on your ANDROID phone.
3. Type or say, “Set up my device.”
4. Follow the instructions on your phone until you get a code. Enter the code on the
projector.
5. On your phone, tap the name of the projector when it shows up.
6. To inish the setup, follow the instructions on your projector.
Method 2: Set Up with the Remote Control
1. When your projector says, “Quickly set up your projector with your ANDROID
phone?” use the remote control to choose “Skip.”
2. Next, open the ANDROID TV™ settings by going to the Settings icon on the
ANDROID TV™ homepage using the remote control.
3. Then, go to Network and select your Wi-Fi® Network.
4. Enter your password and wait for the projector to connect to your network.
5. Then go to Account and select Add Account.
6. Enter your email address and conirm.
7. Enter your password and conirm.
If successfully logged in, your email address will appear under the Account option.
You will now be able to enjoy your ANDROID TV™ apps.

12 | EN
SELECT YOUR LANGUAGE
ANDROID TV SETTING
When starting up the projector for the irst time,
you will be guided to a page to select your
desired language. Use up or down buttons
to select your language and press the OK
button to conirm your selection.
BLUETOOTH Pairing
To connect your BLUETOOTH speakers/headphones, select Settings, then go to
Remotes & Accessories, next go to Add Accessory, and inally select the device to be
connected.
Press the Home button on the remote control to go to the ANDROID TV™ homepage.
NOTE: This projector does not support DOLBY AUDIO.
ANDROID TV Remote App
You can control your ANDROID TV™ system by downloading the remote app. Make sure
your device is connected to the same Wi-Fi network as the projector and BLUETOOTH is

EN | 13
activated.
ANDROID devices:
Download the ANDROID TV™ Remote app from the GOOGLE Play store, open the app,
and choose “HAKO mini” from the Remote tab. Then, select “Connect” and enter the
veriication code that displays on the projector screen.
iOS devices:
Download the ANDROID TV™ app from the App store, open the app to allow it to use
the local network for setup, and choose “HAKO mini” from the Remote tab. Then, select
“Connect” and enter the veriication code that displays on the projector screen.
MIRROR OR STREAM VIDEO FROM YOUR IOS
DEVICES TO THE PROJECTOR
First, you’ll need to install AirPlay on your projector. Install the AirScreen app from
GOOGLE Play to enable AirPlay on your projector. Once completed, follow these steps
to mirror or stream video from your iOS device.
Screen Mirroring from iPhone or iPad:
1. Make sure that your iOS device and projector are on the same Wi-Fi® network. Your
phone’s hotspot is also acceptable.
2. Swipe down on your phone home screen to display the control console and tap
the AirPlay icon.
3. Select the device you want to cast to.
Screen Mirroring from MAC:
1. Make sure that your MAC and projector are on the same Wi-Fi® network. Your

14 | EN
phone’s hotspot is also acceptable.
2. Click the AirPlay icon on the MAC and select your projector to start mirroring. The
AirPlay icon in the menu bar will turn blue when AirPlay is active.
3. To stop mirroring, click the AirPlay icon again and then select “Turn AirPlay O”.
NOTE: For MacBook Air, MacBook Pro, and iMac, the AirPlay icon will only be displayed
in the menu bar when AirPlay mirroring is available.
Streaming Video from iPhone or iPad:
1. Make sure that your iOS device and projector are on the same Wi-Fi® network. Your
phone’s hotspot is also acceptable.
2. Open the streaming apps you want to cast on the projector and select a video to
play.
3. Click the AirPlay or cast icons in the top right corner to cast to the projector.
NOTE: Be aware that copyrighted content from HULU, NETFLIX, and other similar
services CANNOT be mirrored or screencast. To view copyrighted content from these
services, download and use the oicial apps directly through the projector.
GOOGLE ASSISTANT
With GOOGLE Assistant, you can navigate through the apps and streaming services
using your voice.
1. Press the GOOGLE Assistant button to activate GOOGLE’s voice-powered virtual
assistant.
2. On the projection screen, an introduction will appear. Follow the steps to inish setup.
Once the Assistant is set up, press the GOOGLE Assistant button to ask your
question or to give a command.

EN | 15
PROJECTION SETTINGS
Press the Projector Settings button on the remote control and select “Settings”.
Then, select “Projection Settings” to get options like projection mode, keystone
correction, etc. Press the Home button at any time to exit back to the ANDROID TV™
homepage.
Projection Mode
Select between front projection, front ceiling projection, rear front projection, or rear
ceiling projection.
• Front: The projector is placed on a table in front of the screen. This is the most
common way to position the projector for quick setup and portability.
• Front ceiling: The projector is suspended upside-down in front of the screen. A
ceiling/wall mount kit is required (not included).
• Rear: The projector is placed on a table behind the screen. A special rear projector
screen is required (not included).
• Rear ceiling: The projector is suspended upside-down from behind the screen. A
special rear projector screen and ceiling/wall mount kit are required (not included).
NOTES:
For more control over projector height, you can place it on a tripod (sold separately).

16 | EN
The distance between the projector lens and the screen determines the projector
screen size.
Zoom In/Out
Use the remote control to resize the picture size from 50% to 100% without moving the
projector.
Keystone Correction
To correct the keystone eect, go to “Keystone Correction” to select “Manual” or
“Vertical Auto.”
Keystone Benchmark Correction
Keystone Benchmark Correction can be selected once Keystone correction is set to
“Vertical Auto.”

EN | 17
Vertical Correction
Adjust the vertical orientation of the screen manually.
Horizontal Correction
Adjust the horizontal orientation of the screen manually.

18 | EN
Four Point Correction
If the projected image is stretched or distorted along both axes due to the angle of the
projection, go to “Four Point Correction”. Choose the corner you want to adjust and
follow the on-screen instructions to correct the image.
Keystone Correction Reset
To restore the default settings, select “Keystone Correction Reset” and then press “OK”.

EN | 19
OTHER SETTINGS
Press the Projector Settings button on the remote control and select “Other
Settings”.
Screen Saver
Change the default time that the screen saver will automatically activate.
Screen Saver Video
Change the screen saver video that you want to appear when the projector is idle.

20 | EN
Screensaver Timeout Shutdown
Set the shutdown timer for how long the screen saver will play before the projector shuts o.
Language Settings
Select an on-screen display language.
Restore Factory Settings
Reset the projector back to the default factory settings.
About
Press the Projector Settings button on the remote control and select “About” for
more information about the projector.
