KODAK Pocket Pico Projector
User Manual
2.1"H | 2.1"W | 2.1"D (5.3 cm | 5.3 cm | 5.3 cm)
Please read all directions before using the product and retain this guide for reference.

3
Thank you for purchasing the KODAK Pocket Pico Projector. This User Guide is intended to provide you
with guidelines to ensure that operation of this product is safe and does not pose risk to the user. Any
use that does not conform to the guidelines described in this User Guide may void the limited warranty.
Please read all directions before using the product and retain this guide for reference. This product is
intended for household use only.
This product is covered by a limited one-year warranty. Coverage is subject to limits and exclusions.
See warranty for details.
1. INTRODUCTION
2. FEATURES
A. Focus Wheel
Turn the focus wheel to adjust the image focus of the projector.
B. Power/Exit Button
Press and hold this button for 5 seconds to turn the projector on or o. Press this button once to
return to the previous screen.
C. Volume – / Previous Button
Decreases the volume or moves to the previous option on the main menu.
D. Volume + / Next Button
Increases the volume or moves to the next option on the main menu.
E. Conirm Button
Selects the highlighted option on the menu.
F. Lens
Projects the video or image iles from your input device.
NOTE: Never touch the lens using your hands or any sharp object.

4
G. Air Vent
When the projector is in use, air will cycle through this vent.
NOTE: Always take care that the air vents are never blocked by paper, clothing, or any other
obstruction. Blocking the vents may result in overheating of the projector.
H. MicroSD™ Card Slot
This slot allows you to insert a microSD™ card (up to 64GB), allowing you to access your iles directly
from the projector.
I. DC Input
This port allows you to connect the DC power cord to the projector.
NOTE: the power adapter may become warm or hot while in use. Never cover or attempt to touch
the adapter while it is connected to a power source.
J. Mini HDMI® Input
This port is used to connect the HDMI® (High-Deinition Multimedia Interface) connector. It is
compatible with HD DVD, Blu-ray™, and other protected content playback.
K. Audio Output
This port allows you to connect an external speaker or headphones to the projector.
L. Power Indicator Light
Reference the chart below to understand your projector’s current status:
• Always take care that the replacement battery is the correct type. Risk of explosion.
• Only use the parts provided by the manufacturer.
NOTE: the battery capacity status will be displayed on the upper right corner of the projector’s main
screen.
The icon will appear on the upper right side of the screen when the power adapter is connected or
the battery is fully charged.
The will appear on the upper right side of the screen when the battery power is low. When this
happens, you should charge the projector.
LIGHT COLOR PRJECTOR IS ON PROJECTOR IS OFF
Red Charging Charging
Blue Working —

5
Controller
A. Volume – Button
B. Volume + Button
C. Up/Down/Left/Right Buttons
D. OK Button
E. Menu Button
F. Exit Button
G. Rewind Button
H. Fast Forward Button
I. Previous Button
J. Next Button
K. Play/Pause Button
L. Stop Button
M. Mute Button
Main Menu
Movie
Accesses the video iles on your microSD™ card.
Music
Accesses the music iles on your microSD™ card.
Accesses the image iles on your microSD™ card.
HDMI®
Connects the projector to an external device via the HDMI® cable.

6
Setup
Opens the settings menu, which includes the following options:
Language: the following languages are available
• English
• Spanish
• French
• Japanese
• Italian
• Dutch
• Portuguese
• Chinese
• German
Restore Default: restores the projector to factory settings
Power O
When this option is selected, you will be prompted “yes” or “no”. Select “yes” to power the projector o.
KODAK Pocket Pico Projector
HDMI® Cable
HDMI® Adapter
Power Cable
Power Adapter
Controller
Mini Tripod
Quick Start Guide
3. BOX CONTENTS

7
When Using the Projector
• Refer to this user guide and take note of all safety precautions before using your projector.
• Do not place the projector on uneven or unstable surfaces.
• Do not use the projector in any place where it may come into contact with smoke. The residue from
smoke may cause build-up on critical parts of the projector, resulting in damage or
decreased performance.
• Do not use damaged power cords, accessories, and other parts with your projector.
• Keep all parts out of the reach of children.
• Do not block or place anything near the projector’s ventilation holes. Doing so may cause internal
heat build-up that can result in degraded picture quality and damage to the projector.
• Always ensure that the operating voltage of your projector matches the voltage of your
power source.
• Do not store your projector in high temperatures, in direct sunlight, or any place where it may
become wet or damp.
• Do not handle this product with wet or damp hands.
• Do not reach for the unit if it has fallen into water. Always unplug it irst.
• Do not use this product in a place where it may fall.
• When using for the irst time, ensure that the projector is plugged into a grounded wall socket.
• Never attempt to short-circuit the battery.
• Discontinue use if leakage is found.
When Servicing or Replacing Parts
• Never attempt to disassemble this product. There are no user serviceable parts.
• Do not attempt to remove or disassemble the battery. This will increase the risk of ire or
chemical burns.
• Always take care that the replacement battery is the correct type. There is a risk of explosion.
• Only use the parts provided by the manufacturer.
4. SAFETY PRECAUTIONS

8
Before using your projector, check that all parts listed in the Box Contents section of this manual are
present. For best results, we recommend mounting the projector on the included tripod.
A. Connect the power cable to the power adapter.
B. Plug the power cord into an outlet or other
power source.
C. Plug the power adapter into the projector’s
DC input.
D. You may now use the projector.
E. While plugged in, the projector’s battery will
automatically charge. It is recommended that
you allow the projector to charge for at least 4
hours before using it in battery mode for the
irst time.
NOTE1: When the projector is charging, the power indicator light will glow red, regardless of whether it
is powered on or o. When the projector is on, but not charging, or is fully charged, the power indicator
light will glow blue.
NOTE2: You may charge the projector with any power adapter that uses a micro USB plug.
AC Power Cord Requirements
Ensure that the correct AC plug type is used, according to your location. If the power cord included
with your projector does not match your local power source, contact your sales dealer.
NOTE: It is recommended that your video source device uses a grounded plug. This will prevent signal
interference from voltage luctuations. When using the included power adapter, a two-pronged plug is
required.
5. SETUP
5A. CHARGE THE PROJECTOR
Australia and
Mainland China
USA, Canada,
and Taiwan
Continental
Europe UK Japan Sweden

9
A. Turn on the Projector
Press and hold the power button for 5
seconds to turn on the projector.
B. Adjust Screen Size
The screen size will increase or decrease as
the projector is brought closer or further from
the wall. The chart below details the
correlation between distance and screen size.
C. Adjust the Focus Wheel
Open a still image and carefully rotate the focus wheel until the image is clear.
D. Connect Speakers or Headphones
Connect your speakers or headphones to the projector’s audio output port using a 3.5mm cable.
Adjust the volume as needed.
E. Insert MicroSD™ Card
Position the microSD™ card with the chip facing up, and slide
it into the microSD™ card slot until it clicks into place.
NOTE: when the projector recognizes that a microSD™ card has
been inserted, the blue SD card icon will light up on the upper
right corner of the screen.
Your projector can be connected to a variety of external devices using the included HDMI® cable.
Compatible devices include laptops, smartphones, tablets, gaming devices, and more.
• Connect the mini HDMI® end of the cable to the projector.
• Connect the other end of the HDMI® cable to the external device.
5B. GENERAL SETUP
5C. CONNECT TO AN HDMI® DEVICE
SCREEN SIZE (INCHES) PROJECTED DISTANCE (FEET/METERS)
7 0.6 ft. / 0.18 m
38 3 ft. / 1 m
56 5 ft. / 1.5 m
100 8 ft. / 2.5 m

10
If your computer does not automatically recognize the projector, it means that you must irst enable
the use of external displays. Each computer is dierent and may require a dierent setup.
To set up Windows 7 for external displays, follow the instructions below.
a. Open the start menu and select the “Control Panel”.
b. Select “Appearance and Personalization”.
c. Under the “Display” section, select “Connect to an external display”.
d. Here you will be able to select your projector as an external display.
ab
5D. ENABLE YOUR COMPUTER FOR EXTERNAL DISPLAYS
1 Devices with HDMI port
2 Devices with mini HDMI port
3 Devices with micro HDMI port
4 iOS devices with lightning port
5Devices with USBC
(USB type C) port
6Devices with USBC
(USB type C) port
7Devices with Screen
Mirroring Function
HDMI to Mini HDMI cable
Mini HDMI adapter to HDMI cable HDMI to Mini HDMI cable
Micro HDMI adapter to HDMI cable HDMI to Mini HDMI cable
Lightning digital AV adapter HDMI to Mini HDMI cable
USBC to HDMI adapter HDMI to Mini HDMI cable
USB type C to Mini HDMI cable
Mini HDMI adapter to Wireless dongle

11
To set up a Mac® computer, follow the instructions below:
Note: in order to connect a Mac® computer to the projector via HDMI®, an adapter is needed.
a. Go to the “System Preferences” menu and select “Displays”.
b. Select the “Arrangements” tab. Make sure that “Mirror Displays” is checked.
c. After checking “Mirror Displays”, a new window will open. On this display screen, set the
resolution to 1024 x 768.
d
c
ab
c

12
Turn on the Projector
Press and hold the power button to turn on the projector.
A. From the main menu, use the and buttons on the projector, or the direction buttons on the
remote to highlight the Movies icon. Use the button on the projector or the OK button on the
controller to conirm.
B. Select the ile that you would like to play. You may select multiple iles. Note that after selecting a ile,
a red checkmark will appear on each selection.
C. Press the button on the projector or the button on the remote to play the iles.
Video Controls
Projector:
While playing a video, press the button on the projector to open the video controls
menu. Use the and buttons to cycle through menu options. Use the button to select.
Menu Options:
Pause: pauses or plays the video
Fast forward: each press will increase the speed by x2, x4, x8, x16, and x32
Rewind: each press will increase the speed by x2, x4, x8, x16, and x32
Previous: play the previous ile in the playlist
Next: play the next ile in the playlist
Stop: return to the video ile list
6. OPERATION
6A. PLAYING A MOVIE FILE

13
Repeat: each time this option is selected, a dierent repeat setting will be conirmed:
R_None: each selected ile will play in order. The projector will then return to the ile select screen
R_One: one ile will play on a loop
R_ALL: each selected ile will play in order, in a loop
Random: each selected ile will play in a random order
Playlist: view and select the iles in the current playlist
Controller:
While playing a video, press the OK button on the projector to open the video controls menu. Use
the directional buttons to cycle through menu options. Use the OK button to select.
: decreases the volume
: increases the volume
: use these buttons to cycle through menu options
: use this button to open the control menu and conirm menu choice
: press this button, then use the directional buttons to cycle through the following menu options:
picture mode, language, and restore settings
: press this button to return to the video ile list
: each press will increase the speed by x2, x4, x8, x16, and x32
: each press will increase the speed by x2, x4, x8, x16, and x32
: play the previous ile in the playlist
: play the next ile in the playlist
: pause or play the video
: return to the video ile list.
: mutes the sound
A. From the main menu, use the and buttons on the projector, or the direction buttons on
the remote to highlight the Music icon. Use the button on the projector or the OK button on the
controller to conirm.
B. Select the ile that you would like to play. You may select multiple iles. Note that after selecting a ile,
a red checkmark will appear on each selection.
6B. PLAYING A MUSIC FILE

14
C. Press the on the projector or the button on the remote to play the iles.
Music Controls
Projector:
While playing music, press the button on the projector to open the music controls menu. Use the
and buttons to cycle through menu options. Use the to select.
Menu Options:
Pause: pauses or plays the music
Fast forward: each press will increase the speed by x2, x4, x8, and x16
Rewind: each press will increase the speed by x2, x4, x8, and x16
Previous: play the previous ile in the playlist
Next: play the next ile in the playlist
Stop: return to the video ile list
Repeat: each time this option is selected, a dierent repeat setting will be conirmed:
R_None: each selected ile will play in order. The projector will then return to the ile select screen
R_One: one ile will play on a loop
R_ALL: each selected ile will play in order, in a loop
Random: each selected ile will play at random
Playlist: view and select the iles in the current playlist
Controller:
While playing music, press the OK button on the projector to open the music controls menu. Use the
directional buttons to cycle through menu options. Use the OK button to select.

15
: decreases the volume
: increases the volume
: use these buttons to cycle through menu options
: use this button to open the control menu and conirm menu choice
: not available in music mode
: press this button to return to the video ile list
: each press will increase the speed by x2, x4, x8, x16, and x32
: each press will increase the speed by x2, x4, x8, x16, and x32
: play the previous ile in the playlist
: play the next ile in the playlist
: pause or play the video
: return to the video ile list.
: mutes the sound
A. From the main menu, use the and buttons on the projector, or the direction buttons on
the remote to highlight the Picture icon. Use the button on the projector or the OK button on the
controller to conirm.
B. Select the ile that you would like to view. You may select multiple iles. Note that after selecting a
ile, a red checkmark will appear on each selection.
C. Press the on the projector or the button on the remote to view the iles.
6C. VIEWING A PICTURE FILE

16
Picture Controls
While viewing photos, press the OK button on the projector to open the photo controls menu. Use the
directional buttons to cycle through menu options. Use the OK button to select.
NOTE: When viewing photo iles, the projector will automatically enter slideshow mode. While in this
mode, each photo in the ile list will automatically play in order.
Menu Options:
Pause: pauses or plays the slideshow
Previous: play the previous ile in the playlist
Next: play the next ile in the playlist
Stop: return to the video ile list
Repeat: each time this option is selected, a dierent repeat setting will be conirmed:
R_None: each selected ile will play in order. The projector will then return to the ile select screen.
R_One: one ile will play on a loop
R_ALL: each selected ile will play in order, in a loop
Random: each selected ile will play at random
Playlist: view and select the iles in the current playlist
Rotate Right: turns the photo clockwise by 90°
Rotate Left: turns the photo counterclockwise by 90°
Controller:
While playing a slideshow, press the OK button on the projector to open the slideshow controls
menu. Use the directional buttons to cycle through menu options. Use the OK button to select.
: not available in picture mode
: not available in picture mode
: use these buttons to cycle through menu options
: use this button to open the control menu and conirm menu choice
: press this button, then use the directional buttons to cycle through the following
menu options: picture mode, language, and restore settings
: press this button to return to the picture ile list
: not available in picture mode
: not available in picture mode
: play the previous ile in the playlist
: play the next ile in the playlist
: pause or play the slideshow
: return to the picture ile list
: not available in picture mode

17
• Before cleaning your projector, make sure that it is switched o and unplugged.
• Wipe the projector’s housing using a clean dry cloth.
• Make sure that the lens is cool before cleaning it. Wipe it gently using a lens cleaning paper or cloth.
Never touch the lens with bare hands.
• Do not clean the projector with liquid or aerosol cleaners, or any harsh or abrasive chemicals
• Do not submerge this product in water or any other liquid.
• Never operate the projector immediately after moving it to a cold location. When exposed to a
drastic temperature change, moisture may condense on the lens and other internal parts, resulting
in damage to the projector. It is recommended to wait at least 2 hours after exposing the projector to
drastic temperature changes.
QWhy is the projector’s blue indicator on, but the projection screen has not yet turned on?
AMake sure not to press and hold the power key too long. Release the power key as soon as the blue
indicator is on. Please be patient and not push the power key repeatedly while the projector system
is booting. Otherwise this may cause the projector to become stuck.
QWhy can I not play the iles from my microSD™ card?
APlease check:
a. If the capacity of this microSD™ card is higher than 64GB. The capacity supported by the
projector is only up to 64GB.
b. If the microSD™ card is not standard compliant.
QWhy can some movies not be played?
AIn this case, there are several possibilities:
a. The ile size is too large.
b. The video resolution is higher than 1080p. The supported resolution is only up to 1080p.
c. The ile format is not supported. Please refer to the video format support list in the
speciications section.
QWhy is my movie not playing sound?
ADue to the copyright issue of Dolby®, this projector does not support Dolby® audio decoding. You
might not get sound from videos if they use Dolby® audio decoding.
7. CARE AND MAINTENANCE
8. TROUBLESHOOTING

18
QWhat should I do if the projector system has crashed or is stuck?
AIn this case, there are several possibilities that may cause the system to crash.
a. The computing power of the projector cannot catch up the one of the connected devices.
b. The display resolutions between the projector and the connected device do not match.
The possible solution is to restart the projector. Then the projector will work normally.
• Do not throw your projector into municipal waste. This product is designed to allow for proper reuse
of parts and recycling. The symbol of the crossed-out bin indicates that the product should not be
placed in municipal waste. Check local regulations for disposal of electronic products.
• Do not throw the battery into municipal waste. The symbol of the crossed-out bin indicates that the
battery should not be placed in municipal waste.
• Never attempt to dispose of this product in ire or water. Risk of explosion or injury.
• When disposing of this product, contact your local recycling center for proper and responsible
disposal instructions.
Native resolution 854*480 (FWVGA)
Compatible resolution 640*480~1920*1080
Display technology Ti DLP
Light source: RGB LED
Focus: manual adjust
Brightness (ANSI): 100 Lumens
Contrast ratio: 1000:1
Power supply: DC 5V/2A (Micro USB type)
Power consumption: 7W
Built-in Speaker: 8Ω1W(x1)
Input: mini HDMI®/MicroSD™ slot (up to 64GB)
Audio output: ( 3.5mm)
Battery: 3.7V 2500MAH
Dimensions: 2" x 2" x 2" (55 x 55 x 55mm)
Weight: 5.8 oz. (165g)
LED working life: above 30000 hrs.
Relative working humidity: 10%~90%
Supported photo ile formats: PNG/BMP/JPEG/JPG
Supported video ile formats: DAT/FLV/MKV/MOV/MP4/MPG/RM/TRP/TS/WMB/RMVB
Supported audio ile formats AAC/FLAC/M4A/OGG/MP3/WAV/WMA
9. DISPOSAL PRECAUTIONS
10. SPECIFICATIONS

19
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15
of the FCC Rules. Operation is subject to the following two conditions:
- This device may not cause harmful interference.
- This device must accept any interference received, including interference that may cause
undesired operation.
You are cautioned that any change or modiications to the equipment not expressly approved by the
party responsible for compliance could void your authority to operate such equipment.
If the time arises to throw away your product, please recycle all the components possible. Batteries
and rechargeable batteries are not to be disposed in your domestic waste! Please recycle them at your
local recycling point.
Should you experience any problems with your product, please contact us before returning the item to
the place of purchase. We’re here to help!
U.S. Support: [e-mail], 8445161539
International Support: [e-mail], 8445161540
11. FCC COMPLIANCE STATEMENT
12. CUSTOMER SERVICE CONTACT INFORMATION
