Kodak Pocket Portable Projector User manual

KODAK Pocket Portable Projector
User Manual
3"H | 3"W | 0.8"D (8 cm | 8 cm | 2 cm)
Please read all directions before using the product and retain this guide for reference.

3
Thank you for purchasing the KODAK Pocket Portable Projector. This User Guide is intended to provide
you with guidelines to ensure that operation of this product is safe and does not pose risk to the user.
Any use that does not conform to the guidelines described in this User Guide may void the limited
warranty.
Please read all directions before using the product and retain this guide for reference. This product is
intended for household use only.
This product is covered by a limited one-year warranty. Coverage is subject to limits and exclusions.
See warranty for details.
1. INTRODUCTION
KODAK Pocket Portable Projector
HDMI® Cable
USB Cable
User Guide
2. BOX CONTENTS
When Using the Projector
• Refer to this user guide and take note of all safety precautions before using your projector.
• Do not place the projector on uneven or unstable surfaces.
• Do not use the projector in any place where it may come into contact with smoke. The residue
from smoke may cause build-up on critical parts of the projector, resulting in damage or
decreased performance.
• Do not use damaged power cords, accessories, and other parts with your projector.
• Keep all parts out of reach of children.
• Do not block or place anything near the projector’s ventilation holes. Doing so may cause internal
heat build-up that can result in degraded picture quality and damage to the projector.
• Always ensure that the operating voltage of your projector matches the voltage of your
power source.
• Do not store your projector in high temperatures, in direct sunlight, or any place where it may
become wet or damp.
• Do not handle this product with wet or damp hands.
• Do not reach for the unit if it has fallen into water. Always unplug it irst.
• Do not use this product in a place where it may fall.
• When using for the irst time, ensure that the projector is plugged into a grounded wall socket.
• Never attempt to short-circuit the battery.
• Discontinue use if leakage is found.
3. SAFETY PRECAUTIONS

4
When Servicing or Replacing Parts
• Never attempt to disassemble this product. There are no user serviceable parts.
• Do not attempt to remove or disassemble the battery. This will increase the risk of ire or
chemical burns.
• Always take care that the replacement battery is the correct type. Risk of explosion.
• Only use the parts provided by the manufacturer.
TOP VIEW
1. Control Panel Buttons
Use the control panel buttons to navigate the on screen menu.
These buttons are also used to control speciic projector
settings as shown below.
A. Back
B. Conirm / Play / Pause
C. Right / Fast-Forward / Volume+
D. Left / Rewind / Volume–
E. Volume
F. Power Indicator
2. Power Indicator
A. The projector’s current charge is shown by the 4 lights on the side of the control panel. When the
projector is powered on, the lights will lash.
B. Each light represents 25% charge, 1 light indicating low charge, and 4 lights indicating full charge.
C. When charging, the next power level will blink on and o.
D. To view the current charge, press the power button once.
FRONT VIEW
1. Lens
Projects the video or image iles from your input device.
NOTE: Never touch the lens using your hands or any sharp object.
2. Speaker
Plays back the audio from the currently playing video.
REAR VIEW
1. Audio Output
This port allows you to connect an external speaker
or headphones to the projector.
2. USB Input/Power Out
This port allows you to connect a USB lash drive or other external device to the projector.It also
provides up to 5V/2A of voltage and current, allowing you to use the projector to charge a
mobile device.
4. FEATURES
A
B
D C
E
F
12
1 2 3 4

5
3. HDMI® Input
This port is used to connect the HDMI® (High-Deinition Multimedia Interface) connector. It is
compatible with HD DVD, Blu-Ray, and other protected content playback.
NOTE: If the USB and/or microSD™ inputs are used at the same time as the HDMI®, the HDMI® will
take priority.
4. DC Input
This port is used to connect the power adapter (not included). It is used both to provide direct power to
the projector and to charge the internal battery.
NOTE: the power adapter may become warm or hot while in use. Never cover or attempt to touch the
adapter while it is connected to a power source.
RIGHT SIDE
1. Power Button
Press and hold this button for 5 seconds to turn the
projector on or o. Press this button once to view the current charge.
2. Focus Wheel
Turn the focus wheel to adjust the image focus of the projector.
LEFT SIDE
1. MicroSD™ Slot
This slot allows you to insert a microSD™ card, giving
you access to your iles directly from the projector.
2. Air Outlet Vent
When the projector is in use, warm air will exit from this vent.
NOTE: Always take care that the air vents are never blocked by paper, clothing, or any other
obstruction. Blocking the vents may result in overheating of the projector.
BOTTOM VIEW
1. Air Inlet Vent
When the projector is in use, cool air will enter this vent.
NOTE: Always take care that the air vents are never blocked
by paper, clothing, or any other obstruction. Blocking the
vents may result in overheating of the projector.
2. Tripod Dock
This dock allows the projector to be mounted onto a tripod.
3. Rating Label
The speciications of the projector can be found here.
4. Non-Slip Feet
These rubber feet provide additional traction to the projector,
allowing it to be more stable when on a surface.
12
1 2
1
2
4
3

6
1. Charge the Projector
A. Connect the adapter to the micro USB port of the projector, using the included power cord.
B. Plug the adapter into an outlet or other
power source.
C. You may now use the projector.
D. While plugged in, the projector’s battery will
automatically charge. It is recommended that
you allow the projector to charge for at
least 4 hours before using it in battery
mode for the irst time.
5. SETUP
2. Connect an External Device to the Projector
A. Turn on the Projector
Press and hold the power button for 5 seconds
to turn on the projector.
B. Adjust the Focus Wheel
Open a still image and carefully rotate the
focus wheel until the image is clear.
A
B
Australia and
Mainland China
USA, Canada,
and Taiwan
Continental
Europe
UK Japan Sweden
AC Power Cord Requirements
Ensure that the correct AC plug type is used, according to your location. If the power cord included
with your projector does not match your local power source, contact your sales dealer.
NOTE: It is recommended that your video source device uses a grounded plug. This will prevent signal
interference from voltage luctuations.

7
5.0inch
10 inch
20inch
40inch
60inch
80inch
0.25M 0.48M 0.97M 1.95M 2.90M 3.90MDistance
C. Adjust Screen Size
The screen size will increase or decrease as the projector
is brought closer or further from the wall. The chart below
details the correlation between distance and screen size.
After the screen is the desired size, use the
focus wheel to adjust the image clarity.
D. Connect to a an External Device
Your projector can be connected to a variety of external devices using the included HDMI® cable.
Compatible devices include laptops, smart phones, tablets, gaming devices, and more.
a. Connect one end of the HDMI® cable to
the projector.
b. Connect the other end of the HDMI® cable
to the external device.
NOTE: Some devices may require an adapter in
order to connect to the projector. Check the table
below if using a device that is not HDMI® compatible.
1 Devices with HDMI port
2 Devices with mini HDMI port
3 Devices with micro HDMI port
4 iOS devices with lightning port
5Devices with USBC
(USB type C) port
6Devices with USBC
(USB type C) port
6Devices with Screen
Mirroring Function
HDMI to HDMI cable
Mini HDMI to HDMI adapter HDMI to HDMI cable
Mini HDMI to HDMI adapter HDMI to HDMI cable
Lightning digital AV adapter HDMI to HDMI cable
USBC to HDMI adapter HDMI to HDMI cable
USB type C to HDMI cable
Wireless dongle

8
E. Enable your Computer for External Displays
If your computer does not automatically recognize the projector, it means that you must irst enable
the use of external displays. Each computer is dierent and may require a dierent setup.
To set up Windows 7 for external displays, follow the instructions below.
a. Open the start menu and select the “Control Panel”.
b. Select “Appearance and Personalization”.
c. Under the “Display” section, select “Connect to an external display”.
d. Here you will be able to select your projector as an external display.
ab
d
c

9
To set up a Mac® computer, follow the instructions below.
NOTE: In order to connect a Mac® computer to the projector via HDMI®, an adapter is needed
(not included).
a. Go to the “System Preferences” menu and select “Displays”
b. Select the “Arrangements” tab. Make sure that “Mirror Displays” is checked.
c. After checking “Mirror Displays”, a new window will open. On this display screen,
set the resolution to 1024 x 768.
ab
c

10
1. Turn on the Projector
Press and hold the power button to turn on the projector.
2. Playing a Video File
A. After turning on the projector, you will be prompted to select either Movies or Images.
B. Tap the Conirm button to gain access to the control panel, then use the conirm button to
select Movies.
C. You will then be prompted to select either USB or MicroSD™. Use the and buttons to
highlight the format you wish to access. Then tap the conirm button to select.
D. Use the and buttons to cycle through the list of iles. Select the ile you wish to play with the
conirm button.
3. Connect Speakers or Headphones
A. Connect your speakers or headphones
to the projector’s audio output port,
using a 3.5mm cable.
B. Adjust the volume as needed.
4. Insert MicroSD™ Card or USB Drive
Slide the microSD™ card into the microSD™ card
slot until it clicks into place. If using a USB drive,
insert it into the USB input.
6. OPERATION
B C D

11
3. Video Controls
Before you can use the control panel, you must always tap the conirm button to make it appear irst.
Pause: Tap the conirm button.
Fast Forward: Tap the button. Each tap will increase
the speed by x2, x4, x8, and x16.
Rewind: Tap the button. Each tap will increase the speed
by x2, x4, x8, and x16.
Back: tap the button to return to the video ile list. Tap this
button again to return to the main menu.
Volume Control: Tap the button. Then use the
and buttons to increase or decrease the volume.
4. Playing a Photo File
A. After turning on the projector, you will be prompted to select
either Movies or Images.
B. Tap the conirm button to gain access to the control panel.
C. Use the to highlight the Images option. Then use the conirm button to select Images.
D. You will then be prompted to select either USB or MicroSD™. Use the buttons to highlight
the format you wish to access. Then tap the conirm button to select.
E. Use the left and right buttons to cycle through the list of iles. Select the ile you wish to play with
the conirm button.
C D E
5. Photo Controls
When playing a photo ile, the projector will automatically enter slideshow mode. While in this mode,
each photo in the ile list will automatically play in order.
Pause Slideshow: Tap the conirm button.
Resume Slideshow: Tap the conirm button.
Play Next Image: Tap the button.
Play Previous Image: Tap the button.

12
7. CARE AND MAINTENANCE
8. DISPOSAL
• Before cleaning your projector, make sure that it is switched o and unplugged.
• Wipe the projector’s housing using a clean dry cloth.
• Make sure that the lens is cool before cleaning it. Wipe it gently using a lens cleaning paper or cloth.
Never touch the lens with bare hands.
• Do not clean the projector with liquid or aerosol cleaners, or any harsh or abrasive chemicals.
• Do not submerge this product in water or any other liquid.
• Never operate the projector immediately after moving it to a cold location. When exposed to a
drastic temperature change, moisture may condense on the lens and other internal parts, resulting
in damage to the projector. It is recommended to wait at least 2 hours after exposing the projector
to drastic temperature changes.
• Do not throw your projector into municipal waste. This product is designed to allow for proper reuse
of parts and recycling. The symbol of the crossed-out bin indicates that the product should not be
placed in municipal waste. Check local regulations for disposal of electronic products.
• Do not throw the battery into municipal waste. The symbol of the crossed-out bin indicates that the
battery should not be placed in municipal waste.
• Never attempt to dispose of this product in ire or water. Risk of explosion or injury.
• When disposing of this product, contact your local recycling center for proper and responsible
disposal instructions.
9. SPECIFICATIONS
Display Display Technology 0.2" DLP DMD
Light Source RGB LED
Light Source Life 30000 hours
Native Resolution 640x360
Brightness 75 lumens
Contrast Ratio(typical) 1300:1
Color Saturation(NTSC) 100%
Display Colors 16.7 million colors
Pixel Shape Square
Projection images Throw Ratio 2.2
Aspect Ratio 16:9
Projection Distance 0.65 ft. to 12.5 ft. (0.2m to 3.8m)
Projection Screen Size 580 inches (12.7cm to 203cm)
Projection Oset 100%
Input/Output Image Input Modes HDMI® input
Speakers 1w *1
Audio Out 3.5 mm Headphone jack

13
Signal Frequency Digital Signal Frequency 24.7 KHz(H) to 74.6 KHz(H)/50Hz(V) to 60Hz(V)
Power Power On Mode ≤ 4W
Power O Mode ≤ 0.003W
Battery Battery Capacity 2500 mAH
Battery Life up to 2 hours when Video Mode
Noise Acoustic Noise 30dB
Mechanical Design Panel Colors White
Frame Colors Gold
Chassis Colors White
Tripod Socket Copper M6 screw hole
Button Touch button
Dimension Physical Dimensions 3" x 3" x 0.8" (80mm x 80mm x 20mm)
Weight Net Weight 5 oz. (140g)
Gross Weight with Packing 10 oz. (280g)
Working
Environment
Operating Temperature 0°F to 40°F
Operating Humidity 20% to 90%
Regulation Approvals Certiicate FCC, IC, CP65, IEC60065
10. CUSTOMER SERVICE
[e-mail]
8445161539
11. WARRANTY
LIMITED WARRANTY TO ORIGINAL CONSUMER
This KODAK Pocket Portable Projector (“Product”), including any accessories included in the original
packaging, as supplied and distributed new by an authorized retailer is warranted by C&A Marketing,
Inc. (the “Company”) to the original consumer purchaser only, against certain defects in material and
workmanship (“Warranty”) as follows:
To receive Warranty service, the original consumer purchaser must contact the Company or its
authorized service provider for problem determination and service procedures. Proof of purchase
in the form of a bill of sale or receipted invoice, evidencing that the Product is within the applicable
Warranty period(s), MUST be presented to the Company or its authorized service provider in order to
obtain the requested service.
Service options, parts availability, and response times may vary and may change at any time. In
accordance with applicable law, the Company may require that you furnish additional documents
and/or comply with registration requirements before receiving warranty service. Please contact our
