Kogan KAPDCHGN65A User manual

65W USB-A AND USB-C
WALL CHARGER
GaN, 3 PORTS
KAPDCHGN65A

Ensure to read all instructions in this user guide prior to first use. Retain this user guide for
future reference.
• Do not use this charger in a room warmer than 40°C or colder than 0°C.
• Before turning on the power supply, ensure all cables are plugged in properly. If
cables are not plugged in properly, this may lead to damage to the charger and/or
connected devices.
• The charging load must be compatible with the rated power (100–240V, 50/60Hz).
• Do not use damaged or peeling power cords.
• This charger cannot be disassembled or modified.
• Do not use or store this charger is dusty, damp, or humid areas.
• Do not use excessive force on the wall charger.
• Do not place charger under the sun or near any heat sources as this may cause the
charger to deform or fail.
• Do not disassemble the charger as it contains dangerously high voltage and may
damage internal parts.
• Do not apply strong vibrations to the charger.
• Do not use the charger in environments where there are large temperature
differences, or near strong magnetic fields.
• Do not allow any liquids to enter the charger.
Ports
OVERVIEW
SAFETY & WARNINGS
USB–C port 1
USB–C port 2
USB–A port

1. Plug the charger into a wall socket.
2. Plug your USB–C and/or USB–A cables into the charger and devices. The charger
can support up to three devices being charged/powered.
3. Turn on the socket.
Compatible devices
The following list of compatible devices is not comprehensive and intended only as a
guide. Always refer to the device’s user manual to ensure your device supports power
delivery (PD) charging.
Brand
Model
Apple
iPhone 8, 8 Plus, 11, 11 Pro, 11 Pro Max, XR, XS, XS Max, 13” MacBook Air,
13” MacBook Pro
Xiaomi
Mi CC9, CC9 Pro, 9, 9 SE, 10, 10 Pro, Mix 2S, Mix 3
Huawei
Mate 30, 30 Pro, 40, 40 Pro, 40 Pro+, MateBook X, X Pro 2020, 13 2020
Samsung
S10e, Note 10, S20, S20+, S20 Ultra, Galaxy Book S, Galaxy Book Flex
Nintendo
Switch, Switch Dock
Lenovo
Thinkpad E580, E4580, T470, X270
Input
AC 100–240V, 50/60Hz, 1.5A
Size
97.5 x 40 x 41mm
Weight
138g
USB–C1/C2 output
5V⎓3A, 9V⎓3A, 12V⎓3A, 15V⎓3A, 20V⎓3.25A
USB–A output
3.4-5.5V⎓5A, 5V⎓3A, 9V⎓3A, 12V⎓3A, 20V⎓3A
USB–C1 + USB–C2 output
45W (5V⎓3A, 9V⎓3A, 12V⎓3A, 15V⎓3A,
20V⎓2.25A) + 18W (5V⎓3A, 9V⎓2A, 12V⎓1.5A)
63W Max
USB–C1 + USB–A output
45W (5V⎓3A, 9V⎓3A, 12V⎓3A, 15V⎓3A,
20V⎓2.25A) + 18W (5V⎓3A, 9V⎓2A, 12V⎓1.5A)
63W Max
USB–C2 + USB–A output
(5V⎓4.8A) 24W Max
USB–C1 + (USB–C2 + USB–A) output
45W (5V⎓3A, 9V⎓3A, 12V⎓3A, 15V⎓3A,
20V⎓2.25A) 60W Max
SPECIFICATIONS
OPERATION

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
