Kogan KA71GAMEHPA User manual

7.1 GAMING HEADPHONES
KA71GAMEHPA

•Headphones
•Detachable Microphone
•3.5mm Audio Cable
•PC Splitter Cable
•USB to USB Type-C Cable
•User Guide
•Carry Pouch
1 Leatherette Headband
2 Adjustable Steel Arm
3 Protein Memory Foam Earmuffs
4 Detachable Microphone
5 Microphone Port
6 USB Type-C Port
7 3.5mm Audio Cable Port
8 Microphone Mute Switch
9 Volume Control
COMPONENTS
OVERVIEW

10
USB to USB Type-C Cable
11
3.5mm Audio Cable
12
PC Splitter Cable

1. Ensure the 3.5mm audio cable is clean and plug it into the 3.5mm audio cable
port.
2. Plug the detachable microphone into the microphone port.
ASSEMBLY
1
2
Note:
If you do not plug the microphone into the correct port, it will not work.

3. Ensure the microphone is not muted before using the headphones.
The microphone mute switch is available on the body of the headphones.
4. Ensure all the wires are in the correct position when using the headphones.
•Ensure to use 3.5mm audio cable for Mobile Devices and Gaming
Controllers.
Microphone
Mute Switch
3.5mm Audio Cable

•Ensure to use PC Splitter Cable for Personal Computers.
•Ensure to use USB to USB Type-C Cable for Laptops.
•Ensure the detachable microphone is plugged into the microphone port.
PC Splitter Cable
USB to USB Type-C Cable

Sound Settings
To set the headphones as your default audio device, perform the following:
•For Windows
•For IOS
OPERATION
[Control Panel]
[Hardware and Sound]
[Sound]
[USB PNP Audio Device]
[Set as Default Device]
[Green Check Mark]
[System Preferences] [Sound]
[Input] [Output]
[USB PNP Audio Device] [USB PNP Audio Device]

7.1 Virtual Surround Sound
To hear the 7.1 virtual surround sounds, perform the following:
1. Connect the headphones to the Type-C audio output of your device.
2. Go to the Kogan.com to download the 7.1 Surround Drivers.
Headphones Compatibility with PlayStation and Xbox
•Headphones are not compatible with Xbox®360 and PS3®.
•Headphones can only be used with Xbox®One S/X and PS4®.
Note: The 7.1 Surround Driver supports only the Windows operating system.
Xbox One S/X / PS4
Xbox 360/PS3
USB to USB Type-C Cable
Microsoft Adapter
(not supplied)

Using the Headphones with Xbox®One S/X
Earlier versions of the Xbox®One S/X controller require an adapter supplied by Microsoft.
This is not included.
To use the headphones with earlier version of the Xbox®One S/X, perform the following:
1. Plug the 3.5mm audio cable into the Microsoft headphone adapter (not supplied).
2. Connect the adapter to the Xbox®One S/X controller.
Information for Xbox®One S/X User
Current version of Xbox®One S/X
Earlier versions of Xbox®One S/X
Headphone Adapter not required
Microsoft Headphone Adapter required
Note: These headphones are not compatible with Xbox®360.
