Kogan KAOHSETBT4A User manual

BLUETOOTH HEADSET WITH
MICROPHONE AND CHARGING BASE
KAOHSETBT4A

A. Bluetooth
Headset
B. Charging Base
C. Micro USB
charging cable
D. User Guide
OVERVIEW
Volume -
LED Indicator
Micro USB Port
Volume +
Microphone
Multi-Function Button (MFB)
Charge Base Interface
COMPONENTS

Button
Function
Operation
Multi-
Function
Button
(MFB)
Power On
While off, long-press for 1-3 seconds to power on.
Power Off
While on, long-press for 5 seconds to power on.
Bluetooth
Pairing Mode
(from power off) Long-press for 5-8 seconds to enter
Bluetooth pairing mode.
(from power on)Double-press the MFB to enter
Bluetooth pairing mode.
Play / Pause
Press once while playing audio.
Redial a call
Double-press MFB to re-dial the last outgoing call.
Reconnect
When there is an existing Bluetooth connection,
powering on will automatically enter into reconnecting
state. Otherwise, press MFB to reconnect under pairing
mode.
Voice Dialling
Long-press MFB for 1 second, then release.
Audio Switch
(with audio playing) Long-press MFB for 1 second to
switch the audio between phone and Bluetooth
headset.
Answer a call
(with incoming call) Press once.
Hang up a call
(during a call) Press once.
Reject a call
(with incoming call) Long-press for 1 second.
Volume +
Volume Up
Press once.
Next Song
Press and hold for 1 second.
Volume -
Volume Down
Press once.
Previous Song
Press and hold for 1 second.
USING THE BUTTONS

Paring mode
•While the headset is off, long-press MFB for 5-8 seconds to enter Bluetooth pairing
mode.
•If the headset is already on, double-press the MFB to enter Bluetooth pairing
mode.
•The LED indicator will flash blue and red when searching for a connection.
Connection
•On your device (phone, computer, etc), ensure Bluetooth is turned on, and search
for nearby devices. Select the headset (“KAOHSETBT4A”) from the list to connect.
•Once successfully connected, the LED indicator will change to a solid blue light.
•You can now operate the headset using the MFB, Volume+ and Volume- buttons.
CONNECTING
1 metre
Search and connect

Connection with two devices:
•Follow the previous steps to connect with the first device (phone, computer, etc),
and then turn off that device’s Bluetooth function.
•Double press MFB to enter pairing mode again. The LED indicator will flash blue
and red when searching for a connection.
•On your second device, ensure Bluetooth is turned on, and search for nearby
devices. Select the headset (“KAOHSETBT4A”) from the list to connect.
•Once successfully connected, the LED indicator will change to a solid blue light.
•Turn on Bluetooth function of the first device, and from the Bluetooth list, click to
reconnect to the headset. The headset will be connected with both devices now.
Note: Music only can be played from one device under two connections. When you
want to play music from another device, you need to pause or close the music of the
first device.

LED Indicator
Mode
LED Indicator
Power on
Flashes blue for 1 second
Power off
Flashes red for 1 second
Pairing mode
Flashing red and blue, alternating
Unconnected standby mode
Flashes blue, once every 2 seconds
Connected standby mode
Flashes blue, once every 5 seconds
Playing Music
Ta l k i n g
Delete paired record
Flashes red and blue once, simultaneously
Charging
Solid red
Fully charged
Solid blue
Low battery
Flashes red
Three-way calling function
When receiving an incoming call while already on a call:
•Pressing the MFB once will answer the new call and hang up the current call
•Double pressing the MFB will answer the new call and keep the current call
•Long-press the MFB for 1 second will reject the new call and keep the current call
When you are on a three-way call, press the MFB once to drop the initial call and keep the
new caller. Double press the MFB to switch priority between the initial call and new caller to
control which call will be dropped.
OPERATING

Battery Low
When the LED is flashing red, the battery is low and requires charging. Charging time is
approximately 2 hours for full charge. When charging, the LED will display a solid red light.
This will change to solid blue light when fully charged and ready to remove from base.
Use of Charging Base
Place the headset on the charging base and then connect the charging base to USB
charger (adaptor, PC, etc) through the Micro USB port for charging.
This allows the headset to be easily recharged without having to plug/unplug the USB cable
between uses.
Charging directly via Micro USB cable
You can also charge the headset by directly connecting to any USB power supply via the
Micro USB cable. This allows you to connect directly to an in-car charger, travel charger,
computer USB port, etc.
Charging via PC
Charging via adaptor
Note: Remember to charge the headset at least once every 2 months when not in use.
Charging with PC
Charging with Charger
CHARGING

Attempt to reconnect failed
When the headset is connected with your mobile phone successfully for the first time, it will
search and reconnect the paired device automatically when power on. If failed, please pair
and connect again.
How to remove automatic connection to a device
When powered on, press and hold the volume+ and the volume- buttons simultaneously for
5 seconds to clear the pairing record. The LED indicator lights will flash blue and red at the
same time, meaning the pairing record has been cleared and the headset will not
automatically connect back to the previously device. When there are various connection
problems, try clearing the pairing records first.
Need password to pair
Some connection devices require a password for pairing. If not shown on the device’s screen,
we recommend trying any of the following basic codes: “0000”, “8888”, “1111” or “1234”.
Device not charging the headset
Any car charger, power bank, PC USB port, or any adaptor with DC 5V and at least 500mA
can provide charge for this item. Ensure your selected device has meets these requirements.
TROUBLESHOOTING

Bluetooth Version
Bluetooth 5.0
Bluetooth Chipset
CSR 8615
Operation Range
10 metres
Bluetooth Protocols
HSP HFP A2DP AVRCP
CODEC Code
SBC
Battery Capacity
180maH/3.7V
Charging Time
2 hours
Stand-by Time
200 hours
Working Time
approximately 17 hours
(at 50% volume)
Headset Net Weight
51g (approx.)
Charge Base Net Weight
242g (approx.)
Headset Dimension
163.21 x 142.2 x 48.5mm
Charging Base Dimension
79 x 73 x 31mm
SPECIFICATIONS

NOTES

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
