Kogan 8 Series UN8910 User manual

QUICK START GUIDE
70” 4K UHD HDR LED
SMART TV
SERIES 8 UN8910
(KALED70UN8910SGA)

3
COMPONENTS
A Kogan 70” 4K UHD HDR
LED Smart TV
B Magic remote control
C Standard remote control
D Stand (x2)
E M4 x 23mm screw (x6)
F AAA battery (x2)
G AA battery (x2)
H Quick start guide
I Warranty card
B C D E
A
NOT INCLUDED
Phillips head screwdriver, antenna cable, broadband internet connection.
F G H I

4
1
5
11
9
8
4
3
6
7
12
13
10
2
MAGIC REMOTE CONTROL
This TV comes with two remote controls:
• Magic remote control with additional features such as Bluetooth
connectivity, voice recognition, motion sensing cursor and scroll wheel
• Standard remote control for the classic, no-frills experience
1 Power: Press to enter or exit
standby mode
2 Voice Command microphone
3 Set-Top Box Power: Press to turn
connected Set-Top Box on or o
4 Number buttons: Press to select
channels or input passwords
5 List: Check saved programs
6 • • •: Displays additional functions, for
example Sports mode
AD/SAP: Press and hold to turn audio
description on or o
7 quick access:Long-press 0 to add
Quick Access
8 Mute: Toggle sound on/o
9 + –: Adjust the volume up
or down
10 to scroll channels
11 Home: Jump to the home page
12 Voice command button: Hold
and speak into microphone for voice
recognition. Short press to open
recommended content.
13 Settings: Open Quick Settings
menu

5
14
16
18
20
22
15
17
19
23
21
14 / / / Direction buttons for
navigating menus and settings
15 Wheel (OK): Scroll to navigate
menus. Press to select the current
item or confirm selection.
16 Back to the previous menu
17 guide:Opens the Electronic Program
Guide in DTV mode
18 : Open app homepage
19 : Open app homepage
20 Colour buttons for navigational
use within apps
21 Source:Displays the list of input
source channels.
22 movies:Search movies
23 Media playback controls: Play and
pause media, Live Playback function,
and recorded content.

6
STANDARD REMOTE CONTROL
1
9
8
13
11
7
3
4
2
10
14
15
5
12
6
1 Power: Press to enter or exit
standby mode
2 tv/rad: Press to switch between TV
and Radio
3 Search: Open recommended
content or search
4 subtitle: Turn on/o subtitles
5 Source:Displays the list of input
source channels
6 Settings: Open Quick Settings
menu
7 Number buttons: Press to select
channels or input passwords
8 List: Check saved programs
9 quick access:Long-press 0 to add
Quick Access
10 • • •: Displays additional functions, for
example Sports mode
11 ad: Press to turn audio description on
or o
12 guide:Opens the Electronic Program
Guide in DTV mode
13 + –: Adjust the volume up
or down
14 to scroll channels
15 Mute: Toggle sound on/o

7
16
19
23
25
28
21
17
24
26
27
29
18
22
20
30
16 Play: Play media and recorded
content, resume Live Playback
17 Pause: Pause media and recorded
content, pause Live Playback
18 Home: Jump to the home page
19 back to the previous menu
20 exit out of the current program
21 / / / Direction buttons for
navigating menus and settings
22 OK button: Press to select the
current item or confirm selection
23 text:Teletext on/o*
24 t.opt: Teletext options*
25 movies:Search movies
26 Stop:Press to stop recording,
stop media playback, and start Live
Playback function
27 rec: Initiate recording
28 : Open app homepage
29 : Open app homepage
30 Colour buttons for navigational
use within apps
*Note: Teletext is no longer available in Australia. Depending
on your region, this function may or may not be applicable.

8
BEFORE YOU GET STARTED
Spread cushioning flat to lay the TV on. This will help to prevent damage.
1. Stand assembly
a. Attach stands to base of TV, ensuring ‘L’ and ‘R’ markings on the TV
and stand match.
b. Insert three M4 x 23mm screws and use Phillips head screwdriver
(not supplied) to tighten.
1a
2. Remote control assembly
a. Open the battery compartment cover on the back side.
b. Insert batteries (x2 1.5V AAA size for the standard remote, x2 1.5V AA
size for the magic remote) making sure to match the polarity markings
(+ / -) of the batteries with the diagram inside the compartment.
c. Replace battery compartment cover.
2a 2b 2c
ASSEMBLY AND INSTALLATION
1b
• Standard = AAA
• Magic = AA

9
4. Turning TV on
Plug the power cord into a suitable power outlet, then press the
POWER ( ) button on the remote control, making sure to aim it at the
sensor at the front of the TV. Alternatively, you can press the power
button on the lower side of the back panel on the TV.
3. Connect to antenna
a. Connect an antenna cable (not supplied) via the ‘ANT’ input port at
the back of the TV.
b. Ensure the antenna cable is also connected to a working antenna,
either via an antenna wall socket in your home, or directly.
TURNING TV OFF
Press the POWER ( ) button on the remote control to enter standby mode.
To power down the TV completely, unplug the power cord from the power
outlet.
Do not leave your set in standby mode for long periods of time. If you will
not use the TV for a long time, it is recommended to unplug the set from
both the power outlet and aerial.
Antenna
wall socket
3a
3b
Antenna cable
(not supplied)
HDMI 4 HDMI 3 HDMI 2 HDMI 1
(ARC) ANT USB 2.0 (5V / 500mA)
AUDIO OUT
DIGITAL
AUDIO OUT
R -AUDIO- L VIDEO
AV
LAN

10
1 USB 2.0 (x2; 5v 500mA)
2 Ethernet port (LAN)
3 Composite video (RCA)
4 Composite audio (RCA, le and right)
5 Headphone jack (3.5mm line out)
6 HDMI (x3; ARC support on HDMI 2)
7 Antenna
8 Digital audio (Optical out)
PAIRING THE MAGIC REMOTE
After the TV has been on for at least 20 seconds,
point the remote toward the TV and then long-press
the wheel. The remote control will automatically be
registered. A notification will confirm, and the pointer
will appear on screen.
If the Magic Remote’s pointer does not appear on the
screen, you must re-register it. Point the remote control
towards the TV and long-press the guide button until
the notification appears.
guide
button
wheel
INPUTS AND PORTS
