Kogan KASMABIDETA User manual

KOGAN SMARTERHOME™
SMART ANTIBACTERIAL WASH &
DRY ELECTRIC BIDET TOILET SEAT
KASMABIDETA

Read all instructions before use, and retain this user guide for future reference.
Read all following safety precautions carefully before use.
All images within this user guide are for reference only, refer to the actual product.
Symbols on the product and in this user guide:
WARNING! Warning: Failure to follow instructions with this symbol may result
in serious injury or death.
Caution Caution: Failure to follow instructions with this symbol may result
in injury and property loss / damage.
Forbidden: Statements with this symbol are forbidding an action
as described.
Alert: Statements with this symbol are alerting the user to an
enforced, compulsory action.
WARNING:
•Do not touch the electrical outlet with wet hand, or it may cause electric shock.
•Do not pour water, hot water or detergent on the top of the toilet or electrical outlet, as it
may cause fire, electric shock, heat or short circuit. It may also cause injury and indoor
water seepage due to damage of product.
•Never attempt to disassemble, repair or alter the product yourself, as it may cause fire,
electric shock, heat or short circuit.
•Do not install the toilet in car, ship or any other moving object, as it may cause fire, electric
shock, short circuit or fault. The ceramic, seat and main part may be damaged from
falling down due to motion.
•If the product is not working, stop using immediately.
•Under the following conditions, immediately disconnect the power supply and turn
off the water angle valve:
-Water leakage from pipe or inside of the product
-Crack or damage on the product
-Unusual sound or smell
-Smoke
-Unusual heating
-Block
SAFETY & WARNINGS

-Fall out of the cushion
•The continued used of the product, by ignoring the above faults, may result in fire,
electric shock, heat, short circuit, injury and indoor water seepage.
•Do not use any type of water except tap water or drinkable well water (underground
water). Do not use seawater. Use of other waters may cause skin inflammation or fault.
•Do not touch the electrical plug during thunder, as it may cause electric shock.
•Do not let the water inlet soft pipe connect to the electrical plug and outlet, as it may
cause fire, electric shock, heat, short circuit because of moisture condensation.
•Do not destroy or damage the power cable or plug.
•Do not damage, strike, yank, twist, excessively bend, bind, pinch or in any way alter the
electrical cords. Do not place anything heavy on the cords. Failure to follow this instruction
may cause fire, electric shock, heat and short circuiting.
•Do not use a loose or faulty electrical outlet or it may cause fire or short circuit.
•Do not use any power supply other than AC 220V~ AC 240V, 50Hz.
•Do not place fingers or anything else into the warm air outlet, and do not place objects or
clothes on the air outlet or cover it. Failure to follow this may cause scalding, electric shock
or fire damage to accessories.
•Keep open flames (matches, cigarettes, etc) away from the product at all times, as it may
cause fire.
Caution:
•Pay attention to low temperature scalding.
•Improper use of the seat warmer may cause low temp scalding. If sitting for a long
time, turn the temp setting to “off”.
•Turn the seat temp setting to “off’, and warm air-dry temp to “low”, under following
conditions:
-Being used by children, older people, or people who cannot adjust the
temperature settings.
-People with disabilities who may be unable to adjust the temperature settings
-People who have taken medicine causing drowsiness (cold medication,
sleeping pills, etc), under the effects of alcohol, or are otherwise inebriated.
•As this an electrical product, do not install it in a location where it can easily get wet or a
location with high humidity. If installed in bathroom, please also install ventilator to
maintain the bathroom ventilation. Failure to do so may cause fire or electric shock.
•Do not install close to a bathtub.
•Ensure the product is connected to cold water supply, or it may cause body burn or
machine fault.
•The product must be connected to the ground correctly. If not connected to the ground, it
may cause electric shock. Only use with supplied 3-prong (grounded) electrical plug.
•Use only an electrical outlet with leakage switch (rated induced currents below 15mA) or
insulating transformer (1.5kVA~3kVA) to protect outlet loop. Failure to do so may cause fire
or electric shock.
•Ensure the plug is firmly inserted into the wall outlet at all times, or it may cause fire, heat
or short circuit.

•When removing the plug from wall outlet, remove by holding the plug. Do not pull on the
cord.
•If the power soft wire is broken, cease use immediately and contact Kogan.com for
replacement or repair.
•Turn off the power before doing any general maintenance or spot checks. Nozzle clean will
require power to check.
•People in need of supervision or a guardian (people with disability, children, older people)
must not be left unattended with the device.
•Do not let children play this product.
•Do not throw lit cigarettes, matches, or any other flaming material into the toilet.
General safety notices:
•Do not use the product when it is loosely fitted. The toilet and seat may separate and fall
off, causing body injury.
•If damaged, do not touch broken area. Cease use and contact kogan.com for assistance.
•Do not impact forcefully, put heavy weight upon, crouch on, or stand on the product. This
may cause product damage, personal injury, or indoor water seepage.
•Do not use the seat for anything other than what it was designed for. Do not pull the
product by holding the seat or cover, and do not attempt to sit on it while it is not in
position. Failure to do so result in product damage or injury.
•Use kitchen detergent (neutral) to clean the plastic parts (seat cover, etc) and water inlet
soft hose. Do not use the following materials: bathroom detergent, house detergent,
petrol, banana oil, cleaning powder, nylon brushes, etc. These products may damage the
plastic parts, cause cracks, or may cause water leakage because of damaged soft hose.
•To avoid sudden water leakage, do not remove the water inlet filter when angle valve is
open. Refer to Cleaning and Care section of this user guide.
•Do not crush or bend water inlet hose, as it may cause water leakage.
•If replacing another bidet, use the new hose supplied with this product. Do not reuse the
previous hose, as it may cause water leakage.
•Do not pour hot water into toilet, as it may cause body injury or indoor water seepage due
to toilet damage.
•Do not flush with large amount of toilet paper or other subjects except sewage and small
amount toilet paper, as it may cause toilet damage. Do not flush tampons, condoms, or
sanitary products.
•Do not lean on the toilet cover while using, it may damage the seat cover.
•Close the angle valve when water leaking
•When room temperature is below 0°C, to avoid piping or soft hose damage, anti-freezing
measures should be adopted. If water Inlet soft hose is frozen it may destroy main body or
piping, leading to water leakage. To avoid damage, please pay attention to room
temperature adjustment.
•When not use for a long time, drain the inlet soft hose and disconnect from power. When
next using, open the angle valve and let water connect first, or it may cause skin
inflammation due to poor water quality. It may cause fire or overheating if the power
supply is always connected.

•Confirm that the filter is screwed to correct position installed, prior to using. It may cause
water leakage if not screwed tight.
•When the toilet drain outlet is blocked, cut off the power then clean the obstruction.
Otherwise sewage may overflow, causing indoor water seepage because of auto flush
function.
•Flush the toilet after each use. Failure to do so may result in difficulty cleaning the toilet,
blocked drain outlet or sewage overflow, resulting in indoor water seepage.
•After each use, if there is any mess on floor, always clean immediately to prevent corrosion
or unhygienic build-up.

Ensure you have all of the components listed in this user guide before disposing of any
packaging.
•x1 Toilet Seat
•x1 User Guide
•x1 Spanner
•x2 Rubber Gaskets
•x1 T Valve with Filter
•x1 PE Inlet Pipe
•x1 Fix Bracket
•x1 Filter (Back up)
•x1 Front Wash Nozzle (Back up)
•x1 Rear Wash Nozzle (Back up)
•x2 Metal Gaskets
•x2 Mounting Bolts
•x2 Rubbers
COMPONENTS

1
Toilet lid
6
Damper
2
Water inlet
7
Dryer outlet
3
Control panel
8
Nozzle for rear wash
4
Heated seat
9
Nozzle for front wash
5
Cushion pad
OVERVIEW

Components for installation:
PE Intel Pipe Gasket (x2) Spanner T Valve
with Filter
Mounting bolts
(x2)
Rubber sleeves
(x2)
Metal gasket
(x2)
Fix bracket

Functions overview:
Function
Description
Rear wash
Provide rear cleansing
Rear oscillating
wash Move the nozzle back and forth for rear cleansing
Front wash
Provide cleansing by front cleansing nozzle with a gentle
spray
Front oscillating
wash Move the nozzle back and forth with a gentle spray
One solution
Auto rear clean and dry
Strong wash
Large amount of water to clean the buttocks to promote
laxative
“Child Wash” Warm water gentle cleaning, suitable for children.
“Lady Care”
Cleansing suitable for menstruation
Nozzle position
adjustment Adjust the suitable washing positions
Temperature
adjustment Set the temperature of seat and water
Water pressure
adjustment Change cleaning water pressure
Seat sensor
Functions activated by sitting on the seat
Drying
Dry the users after cleansing
Changing drying
intensity Control the temperature of warm air from the dryer
Nozzle self-clean
Provide nozzle self-cleaning before washing
Deodorizer
Removing odours
Saving energy
Saves electricity
Night light
Preparations for insufficient light
Soft close
Damper in the seat and cover, to make it close softly
Power switch
Turn power on and off

Precautions before Installation
•Before installation, ensure toilet wall, floor tile, ceramic toilet has been completed,
bathroom should supply water and power socket nearby toilet.
•Water pressure should be between 0.06Mpa (flow) - 0.75MPa (Static), water
temperature 5°C - 35°C.
•In case of transportation in subzero (freezing) condition, please put the product in a
warm place and wait for any residual water to thaw before installing.
•Connect daily-use water pipe only. Use tap water or drinkable well water only. Do
not connect to recycled water or industrial water supplies, due to possible
contamination as this would cause jamming or internal damage.
•Be sure to use T valve with filter.
•Do not connect to electricity and turn on before finishing installation.
1. Install T valve with filter
•Lock inlet valve to remove water pipe (picture 1).
•Connect T valve and inlet valve (picture 2).
•Install flush tank and inlet pipe (picture 3).
INSTALLATION
Valve
T Valve with filter
Gasket
Water pipes
Flush tank
Valve
Valve
OFF

2. Toilet Seat Installation
Remove original toilet seat
•Loosen bolts with wrench
•Remove the nut and gasket,
remove the toilet seat
Install fix bracket
•Before the installation, please put the product on the toilet bowl to check for
correct fitting.
•Embed and install the rubber sleeve, fix bracket, metal bracket as shown below.
•Insert the mounting bolt and tighten it so that the fix bracket cannot move.
•If the product does not match the toilet bowl ideally, please loosen the mounting
bolts, take the metal gasket out, readjust the position of the fix bracket, then insert
the metal gasket and tighten the bolt.
Bolt
Gasket
Nut
Release
To i l e t
Seat
Rubber Sleeves
Fix Bracket
Metal Bracket
Mounting bolts
Screw
The fix bracket
can adjust the
range within
130-170mm

3. Install bidet
Aim the bottom card slot of the seat to the
edge of fixed bracket, slide in gently. You will
hear a “click” sound when it is correctly
placed.
Ensure the bidet fits into the area before
placing, then lift bidet to fit it on correct
position.
4. Connect inlet pipe
•Connect T valve:
Hold on PE inlet to push it towards connector of T valve.
•Connect bidet:
Hold on PE inlet to push it towards connector of bidet.
•It is recommended to replace the PE pipe every year
•Turn on inlet valve after connecting to check the connectors for signs of leakage.
Fix bracket
Bidet
PE inlet
Quick
Connecter
T valve with filter
Valve
Note:
Do not forget to allow space for the
power cable between the toilet and bidet.

Preparation
1. Open the water-inlet valve.
2. Ensure the plug is inserted into socket
and the indicator light is on.
3. Confirm the power icon in LED display is on.
Power
4. If the power light on the product indicator panel is not
lit, all functions will be unavailable. Press the power
button on the operation button panel to activate.
Sit on the seat
1. Seating sensor responds to work
2. Nozzle cleaning indicator lights
3. If the automatic deodorisation function is turned
on, the deodorisation starts to work.
Clean
OPERATION

Control panel
1. Stop
Stop the current cleaning operation. If do not press stop button, rear washing/
front washing will stop automatically after 2 minutes
2. Front
Press Front, nozzle reaches out to work; Press again change to front oscillating
cleansing, nozzle repeatedly swings back or front. Press again to stop oscillating
cleansing, Switch back to front wash.
3. Rear
Press Rear, nozzle reaches out to work; Press again change to rear oscillating
cleansing, nozzle repeatedly swings back or front. Press again, stop oscillating
cleansing. Switch back to rear wash.
4. Dry
Press this button to start warm air drying. Press Stop to turn off the drying
function. or the warm air will stop automatically after running for 4 minutes.
5. Seat temp
The seat temperature can be adjusted in 4 levels:
Room temperature
(No light)
33°C
(Blue)
36°C
(Green)
39°C
(Red)
Press the seat temp button to cycle through the settings.
Note: To prevent the low temp burn, the machine automatically reduces the
seat temp below 35°C after sit on the seat for 10 minutes.
6. Clean
Press Clean to enter nozzle cleaning, then water flows out to clean nozzle.
Repeatedly press this button, the nozzles switch between rear and front
cleansing, then you can clean and replace the nozzles.
Nozzle clean is effective when people are not seated.
Nozzle will automatically clean the peripheral part of the nozzle before rear wash
and front wash.
7. Light
Press this button, the indicator lights up and the night light turns on. Press this
button again, the indicator is off, the night light is also off, it could be switched
repeatedly.
8. Pressure
Select from four levels, adjust comfortable water pressure by pressing +or –
buttons.

9. “Lady care”
Cleansing suitable for menstruation. In Idle mode, press this button to begin
function. The nozzle reaches out to work and water temp is set to the highest
level (39°C), water pressure is set to 2-level, cleaning position set as default.
Water temp/water pressure not adjustable, cleaning position is adjustable in
this mode, automatic ends after cleaning for 2 mins. Press Stop to end.
10. “Child”
Warm water gentle cleaning, suitable for children. In Idle mode, press this
button to enter function. The nozzle reaches out to work and nozzle position is
at the front (5 level), mini water pressured level) and the water temp is mid-
grade (36°C) After washing 30s to end or press Stop to end. Under this mode,
cleaning position/ water pressure /water temp are not adjustable.
11. Position
Select from five levels, adjusting the satisfied position to clean by pressing +or
–buttons.
Note: Under oscillating cleaning, the nozzle position adjustment is unavailable
12. “Super”
Strong wash mode. In Idle mode, press this button to enter the powerful
washing mode, nozzle reaches out to work and the hole starts to effluent.
Water pressure is highest level, after washing 2mins to end. Press Stop to end.
13. “Auto”
“One solution”, an automatic sequence performing Rear Wash (40 seconds),
Oscillate Wash (20 seconds), Warm Air Dryer (2 minutes), then stop. Press this
button to start in Idle mode, and press Stop to end.
14. Water Temp
The water temperature can be adjusted in 4 levels:
Room temperature
(No light)
33°C
(Blue)
36°C
(Green)
39°C
(Red)
Press the water temp button to cycle through the settings.
15. ECO
Low power mode. Press this button, the corresponding indicator blink on
control panel in standby, after leaving the seat for 1.5 minutes then enter
power saving mode. Under this mode, seat temp is kept at 25°C and the
settings before power saving are automatically restored the next time.
16. Deodoriser
Press this button to start deodorising, indicator on the control panel lights up.
Press again to close.
Note: During drying, the deodorising function is temporarily stopped and it will
automatically start again after the drying is completed. When a person leaves
the seat, the deodorising function will continue to work automatically after 90
seconds.
17. Power Press this button to enter standby mode. All lights will be off. When pressed
again, the device will power on and the Power indicator light will be on.
Note:
Idle mode means rear wash, front wash, dryer, flush, etc. are not enabled. Child wash,
one solution, strong wash, lady care must be enabled in idle mode.

Install App
Download the “Kogan SmarterHome” app from the Play Store (Android) or App Store (iOS).
Register
If you do not have a Kogan SmarterHome™ account, register or sign in with a verification
code sent by SMS.
To register:
1. Ta p to enter registration page.
2. The system automatically recognises your country/area. You can also select your
country code manually. Enter your email address and tap ‘Next.’
3. Alternatively, you can select ‘Register by mobile number’ and enter the verification
code sent to you by SMS.
4. Create a profile on the next page to define your location and room.
CONNECT TO SMARTERHOME™ APP

Set device in pairing mode
When the device is first turned on, it may automatically enter pairing mode (making a
“beep” sound).
If not automatically in pairing mode when powered on, you can manually set the device in
pairing mode by long-pressing the Drying and Rear Wash buttons simultaneously until you
hear a prompt tone (beep).
Add device through network
5. Once registered, tap “+” in the upper right corner of the app’s home page to add a
new device through the network.
6. Select the product type from the list of options in the app (Other > Smart Bidet
Seat).
7. Ensure that the device is in pairing mode, with the prompt tone heard, and tap
“Next step”.

8. Upon successfully confirming pairing mode, enter your Wi-Fi details. It is important
that your SmarterHome™ device and the app are connected to the same Wi-Fi
network during setup.
9. The device will commence the pairing process and connect to the app. Ensure your
Wi-Fi router, mobile phone, and the SmarterHome™ device are kept close until
connection is complete.
10. After successfully being added, you will have the option to rename the device and
assign it to a location. It will now be listed on the app’s home page. Tap the device
listing to enter its control page.
Notes:
•The device and the app have to use the same Wi-Fi network.
•The device is only compatible with 2.4Ghz networks.

App functions
Adjust water
temperature
Adjust seat
temperature
Warm air to make the
cleaned part dry
“Lady care”
Rear clean wash
Indicates the position of
the toilet when the light
is insufficient
Nozzle clean
Remove odour
when using
Energy Saving
(ECO mode)
•
Stop hip wash
•Stop front wash
•Stop dry
•Stop automatic wash
One Solution mode
Note:
App design, functions and firmware are subject to change without notice. The functions
and designs shown in this guide may be updated at a later date. The information shown
here is for reference only.
