Kogan KAWLMSTNDXA User manual

Height Adjustable Wall Bracket
KAWLMSTNDXA
Quick Start Guide
Cauti n
This product contains small items that could be a choking hazard if swallowed.
Keep these items away from young children.
•Make sure these instructions are read and completely understood before
attempting installation. If you are unsure of any part of the installation,
please contact a professional installer for assistance.
•The wall or mounting surface must be capable of supporting the
combined weight of the mount and the display, otherwise the structure
must be reinforced.
•Safety gear and proper tools must be used. A minimum of two people are
re uired for this installation. Failure to use safety gear may result in
property damage, injury or death.
•Please ensure children do not play with the mount or the mounted
television at any time.
•Please check the mount every two months to ensure that bolts and screws
are tight, and that the wall behind the mount appears to be in good
condition.
This product was designed to be installed on solid concrete walls.
Before installing, make sure the wall will support the combined load of the
e uipment and hardware.
Never exceed the maximum load capacity of 5kg, or it may result in product
failure or personal injury.
N te: this product is intended for indoor use only. Use of this product outdoors
could lead to product failure or personal injury.

Item Checklist
What's in the b x
1 – Wall bracket x 1
2 – Locking sheet x 1
3 – Shelf bracket x 1
4 – Plastic cover x 2
5 – Rubber washer x 2
6 – Plate cover x 1
7 – Plastic pad x 4
8 – Cable buckle x 1
9 – Washer x 4
10 – Shelf glass x 1
11 – Cross head bolt x 2
12 – M5 x 10mm bolt x 2
13 – M5 x 6mm bolt x 4
T ls required
M unting
Step 1 Step 2
14 – 2 pcs 15 – 2 pcs
16 – 2 pcs

Step 3-A (S lid c ncrete m unting)
Step 3-B (W d stud m unting)

Step 4 Step 5
Step 6

Pr duct Dimensi ns
If y u require any additi nal inf rmati n regarding the m unt r require
assistance in regards t a warranty claim, please c ntact the K gan cust mer
supp rt team.
