Kogan KAHCWATPURE User manual

Water Purifier and Dispenser System
KAHCWATPURE
Quick Start Guide
Product eatures
•Energy-saving, low noise and damage resistant structure. Suitable for use in homes,
hotels, schools etc.
•Double security system. Hot water temperature is always between 80 C and 95 C, hot
enough to make tea, coffee or other instant foods.
•Water dispenser cooling system is durable, suitable for use during summer.
Parts List
NO. NAME NO. NAME
1 Water Guard 6 Hot Water Faucet
2 Power Switch 7 Drip Tray
3 Indicator Lamp 8 Drain Plug
4 Data Plate 9 Electric Power Cord
5 Cold Water Faucet
Note: Image is for reference only. Actual unit may differ slightly.
Technical Infomation
Model KAHCWATPURE
Voltage – Frequency 240V / 60Hz
Heating Power 500W
Cooling Power 85W
Water Heating Capacity 5.0L/h
Water Cooling Capacity 1.0L/h
Electric Shock Prevention Type I

Operation
1. Insert the bottle vertically on the seat, then press the water faucets until water flows out
of the red hot water faucet.
2. Insert the power plug to the wall socket, then turn the electric switches to the ON
position to start the appliance. DO NOT MOVE BOTH SWITCHES AT THE SAME TIME.
The cooling and heating indicator lights should light up. This device is designed to
provide hot or cold water whenever you require it. It will automatically turn off when the
water reaches the desired temperature, then it will turn on again when the water falls
outside this temperature.
Attention
•Make sure you have checked that water will pour from the hot water faucet before
plugging the unit in and turning it ON. If the dispenser is turned on with an empty water
tank, it may damage the unit.
•When moving the water cooler, do not tilt the unit more than 45 to avoid damaging the
compressor.
•Always install the dispenser indoors on a flat surface, at a distance of no less than 15cm
from the wall behind it.
•Keep appliance away from high temperatures, in a dry, well ventilated place. Never
install unit in the open air, where it may be rained on or in direct sunlight.
•Children should NEVER use the hot water faucet.
•If the appliance is not going to be used for a long period of time, unplug the unit and
drain all water from the interior.
•Before first use and after a long period of non-use, the water tank and water pipes
should be cleaned. The first tank of heated water must be discarded (switch the heating
system to OFF while draining the tank).
•Wash the system once every 3-6 months.
•Do not just pull the plug to cut the power from unit. The unit must not be turned OFF or
ON by simply connecting or disconnecting the power source.
•Do not clean the outside of the unit with water to avoid electric shock. Clean it with a
soft cloth.
•If you are not using the unit for a long period of time, or even during the night, you can
turn it OFF to save energy.
•Do not attempt to change the power cord yourself in the event of damage. Contact the
Kogan.com customer support team.
•The equipment must be installed in a location where you have easy access to the
electrical plug.
•Keep the ventilation openings at the back of the unit uncovered and unobstructed.
•Do not damage the refrigerant circuit.
•The environmental temperature for this appliance should be between 18 C and 38 C.
•This appliance can be used by children aged from 8 years and above, or persons with
reduced physical, sensory or mental capabilities or lack of expereince and knowledge if
they have been given supervision or instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Do not store explosive substances such as aerosol cans with a flammable propellant
near this appliance.
•This appliance is designed to be used in household and similar applications such as:
✔Staff kitchen areas in shops, offices and other work environments
✔Farm houses and by clients in hotels, motels and other residential environments
✔Bed and breakfast type environments
✔Catering and other similar non-retail applications

Water Purifier
The service life of the water purifier element is 3000 litres of tap water.
Installation
Wash your hands thoroughly before handling the various elements.
1. Take the ceramic filter and multi-layer cartridge and place them in a clean bucket of
water and allow to soak for at least 30 minutes, then rinse them both thoroughly.
2. Wash the lower tank thoroughly.
3. Place the joining ring onto the top of the lower tank.
4. Take the multi-layer cartridge and screw it into the seating/holder, taking care not to
overtighten it.
5. Place the assembled cartridge onto the joining right properly.
6. Take the upper tank and insert the plastic filter. The washer must be on the inside. Once
again, do not overtighten.
7. Place the top tank on to the joining ring.
8. Place the floating valve onto the bottom of the lower tank.
9. Remove the smart seat of the dispenser and place the unit onto the dispenser.
10. Check all parts for secure fitness and alignment.
11. Fill tank with water, then place the top cover in place.
ilter Maintenance
1. Remove the top lid.
2. Remove the top filter cover, wash or replace the filter
cloth (as shown to right)
3. The filter element itself can be unscrewed
counterclockwise.
Notes
•Black activated carbon powder will float in the water when the filter is first used. Clean
the water filter and let this black water flow out before putting the filter onto the
dispenser.
•The water purifier must be located out of direct sunlight.
•Water being fed through the filter should be clean tapwater. Do not put grey water or
other dirty water through the filter as this will greatly reduce the lifespan of the filter.
•If you find that the speed of filtration after 200-300 litres is still slow, please take out
the top layer of the filter element and wash it under a fast flowing tap.
•Please change the filter after one year's use or after 3000 litres of water filtration.

Troubleshooting
In the event of a malfunction, turn off the water dispenser and disconnect it from the electrical
power source.
Problem Possible Cause Possible Resolution
Lights do not light up
1. Appliance is not
connected to the
electrical system.
2. Switch is not ON.
1. Make sure unit is plugged in
and the switch is ON.
2. Turn the power switch to ON.
Leaking
1. Water container is
broken.
2. Water pipe is broken.
3. Faucet is damaged.
Contact the Kogan.com customer
support team.
Not heating
1. Heating switch is
damaged or does not
make contact.
2. Heating tank is burnt.
3. Electrical connection is
loose.
Contact the Kogan.com customer
support team.
Not cooling
1. Cooling switch is
damaged or does not
make contact.
2. Electrical connection is
loose.
Contact the Kogan.com customer
support team.
ilter Troubleshooting
Problem Possible Cause Possible Resolution
Water leaks Ball has floated off
Impurity on head valve of ball
float
Valve core seal is misplaced
Screw on ball float
Clean the head valve of the ball float
Check that seal is in position
No water filtering Top filter layer is jammed due
to not being cleaned
Filter is old/failed
Remove the filter and wash it under
a fast flowing tap
Replace the filter
If you have any questions or concerns regarding the use of this product, please contact the
Kogan.com customer support team for advice.
