Kohler Maestro K-842-H User manual


MaestroBath Whirlpools:
K-842-H K-845-H
113906-2-BA (A) 1999 Kohler Co.

Kohler Co., Kohler, WI
113906-2-BA (A) 2
IMPORTANT SAFETY INSTRUCTIONS
ATTENTION INSTALLER: INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC
SHOCK, OR INJURY TO PERSONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING: When using this unit, always follow basic precautions, including the following:
WARNING: RISK OF ELECTRICAL SHOCK.
The unit must be connected only to a circuit
that is protected by a Ground-Fault
Circuit-Interrupter (GFCI). Such a GFCI should
be provided by the installer and should be tested
on a routine basis. To test the GFCI, press the test
button. The GFCI should interrupt power. Press
the reset button. Power should be restored. If the
GFCI fails to operate in this manner, there is a
ground current flowing or the GFCI is defective.
The possibility of an electric shock may exist.
DO NOT use this unit. Disconnect the unit and
havetheproblemcorrectedby aqualifiedlicensed
electrician.
Grounding is required. The unit should be installed
and grounded by a qualified service representative.
A pressure wire connector is provided on the pump to
permit connection of a solid copper bonding conductor
between this unit and all other electrical equipment and
exposed metal in the vicinity, as needed to comply with
local requirements.
DANGER: RISK OF INJURY.
Hotwhirlpoolbathscanputcertainstressesonthebody,
as do any hot bath, shower, sauna, or steam bath.
Prolonged immersions in hot water may induce
hyperthermia. Hyperthermia occurs when the internal
temperatureofthebodyreachesalevelseveraldegrees
above the normal body temperature of 98.6°F. The
symptoms of hyperthermia include an increase in the
internal body temperature, dizziness, lethargy,
drowsiness, and fainting. The effects of hyperthermia
include: (1) failure to perceive heat, (2) failure to
recognize the need to exit the bath, (3) unawareness of
impendinghazard,(4)fetal damageinpregnantwomen,
(5) physical inability to exit the bath, and (6)
unconsciousness resulting in the danger of drowning.
Warning: Theuseofalcohol,drugs,orothermedication
can greatly increase the risk of fatal hyperthermia.
DO NOT operate this unit without the guard on the
suction fitting.
Never drop or insert any object into any opening.
Use this unit only for its intended use as denoted in this
manual. DO NOT use attachments not recommended
by the Kohler Co.
Install to permit access for servicing.
DANGER: RISK OF INJURY. To reduce the risk
of injury, do not permit children to use this unit
unless they are closely supervised at all times.

3113906-2-BA (A)
Kohler Co., Kohler, WI
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 2. . . . . . . .
INTRODUCTION 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ROUGHING-IN: K-842-H, K-845-H 4. . . . . . . . . . . . .
Ordering Information 4. . . . . . . . . . . . . . . . . . . . . . .
Required Electrical Service 4. . . . . . . . . . . . . . . . . .
Product Information 4. . . . . . . . . . . . . . . . . . . . . . . .
Installation Notes 4. . . . . . . . . . . . . . . . . . . . . . . . . .
PRODUCT NOTICES 5. . . . . . . . . . . . . . . . . . . . . . . . .
Installer Hazard Notification 5. . . . . . . . . . . . . . . . .
Factory-Assembled Features 5. . . . . . . . . . . . . . . .
PRODUCT REQUIREMENTS 5. . . . . . . . . . . . . . . . .
Summary of Key Requirements 5. . . . . . . . . . . . . .
Plumbing Specifications 5. . . . . . . . . . . . . . . . . . . . .
Product Inspection 5. . . . . . . . . . . . . . . . . . . . . . . . .
Connections and Service Access 5. . . . . . . . . . . . .
Electrical Requirements 5. . . . . . . . . . . . . . . . . . . . .
INSTALLATION REQUIREMENTS 6. . . . . . . . . . . . .
Tools Required 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Materials Required 6. . . . . . . . . . . . . . . . . . . . . . . . .
Clearance Requirements 6. . . . . . . . . . . . . . . . . . . .
New Or Replacement Installation Requirements 6
SITE REQUIREMENTS 6. . . . . . . . . . . . . . . . . . . . . . .
Old Bath Removal 6. . . . . . . . . . . . . . . . . . . . . . . . . .
Subfloor Preparation 6. . . . . . . . . . . . . . . . . . . . . . . .
Stud Pocket Preparation 7. . . . . . . . . . . . . . . . . . . .
Plumbing Preparation 8. . . . . . . . . . . . . . . . . . . . . . .
BEFORE INSTALLING UNIT 8. . . . . . . . . . . . . . . . . .
Tiling-In Bead Installation 8. . . . . . . . . . . . . . . . . . . .
Partially Install Bath Drain 8. . . . . . . . . . . . . . . . . . .
Protect Whirlpool Unit 8. . . . . . . . . . . . . . . . . . . . . .
INSTALL WHIRLPOOL 8. . . . . . . . . . . . . . . . . . . . . . .
Whirlpool Set-In 8. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pump Banding Strap Cut 9. . . . . . . . . . . . . . . . . . . .
Install Plumbing 10. . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTALL GRIP RAILS 10. . . . . . . . . . . . . . . . . . . . . . . .
ELECTRICAL CONNECTIONS 10. . . . . . . . . . . . . . . .
Identify Electrical Requirements 10. . . . . . . . . . . . . .
Wiring Information – 120 V, 60 Hz 10. . . . . . . . . . . .
WATER TEST WHIRLPOOL & ELECTRONICS 11. .
COMPLETE FINISH WALL 11. . . . . . . . . . . . . . . . . . . .
COMPLETE INSTALLATION 11. . . . . . . . . . . . . . . . . .
Install Handles and Spout 11. . . . . . . . . . . . . . . . . . .
Install Whirlpool Trim Kit 12. . . . . . . . . . . . . . . . . . . .
CLEAN-UP AFTER INSTALLATION 12. . . . . . . . . . . .
CONFIRM PROPER OPERATION 12. . . . . . . . . . . . .
Start-Up Whirlpool 12. . . . . . . . . . . . . . . . . . . . . . . . .
Operating Sequence 13. . . . . . . . . . . . . . . . . . . . . . . .
TROUBLESHOOTING PROCEDURES 13. . . . . . . . .
Flexjet Installation 13. . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshoot Whirlpool System 14. . . . . . . . . . . . . .
INTRODUCTION
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and
installation sequences. Follow the sections that pertain
to your particular installation. This will help you avoid
costlymistakes.Inadditiontoproperinstallation,readall
operating and safety instructions.
The variety of installations possible with this bath may
require framing procedures other than those described
in this manual.
All information in this manual is based upon the latest
product information available at the time of publication.
Kohler Co. reserves the right to make changes in
product characteristics, packaging, or availability at any
time without notice.
Identify and record the model and serial numbers below (found at the pump end of the bath):
Model No. Serial No. Date of Manufacture

1.25>132
1-1/2” I.P.S. THR’D
PUMP/CONTROL ACCESS
1-1/2” O.D.
3/4”
18-1/4”
1/4”
2-7/8”
3”
9-1/4”
16”
32”
2-1/4”
3-1/4”
66”
4
113906-2-BA (A) Kohler Co., Kohler, WI
1. ROUGHING-IN: K-842-H, K-845-H
A. ORDERING INFORMATION
Applicable product:
With grip rail drillings K-842-H shown
Without grip rails K-845-H not shown
Accessories/hardware:
Jet trim kit K-9695 required
Drain K-7161-AF recommended
Adjustable feet K-1172 optional
Grip rails (K-842 only) K-9621 required
Vinyl tiling-in bead* K-1179 optional
*Use K-1179 vinyl bead when wall material contacts any
top surface of bath.
B. REQUIRED ELECTRICAL SERVICE
Dedicated branch circuit required, protected with Class A
Ground-Fault Circuit-Interrupter (GFCI):
Pump/control 120 V, 20 A, 60 Hz
C. PRODUCT INFORMATION
Fixture*: basin area top area weight
Bathing well 47” x 21” 57” x 25” 410 lbs.
water depth capacity
To overflow 13” 55 gal.
* Approximate measurements for comparison only.
Pump HP V Hz A
2-speed 1 120 60 16.5
D. INSTALLATION NOTES
Pump is supplied with a grounding-type plug-in cord. Locate
the outlet behind the whirlpool, and within 24” of the pump.
Read the entire installation instruction before beginning the
installation.
ROUGHING-IN NOTES
Fixture dimensions are nominal and conform to
tolerances in ANSI/ASME Standard A112.19.1.
No change in measurements if connected with drain il-
lustrated.
Cut-out 64-1/2” x 30-1/2”
Minimum access panel:
Pump/control 20” W x 15” H required

5113906-2-BA (A)
Kohler Co., Kohler, WI
2. PRODUCT NOTICES
A. INSTALLER HAZARD NOTIFICATION
DANGER: Risk of fire, electric shock, or injury
to persons. Readimportantsafetyinstructionson
inside front cover of these instructions.
WARNING: Risk of electrical shock. A licensed
electrician should make all electrical connections.
WARNING: Risk of electrical shock. Connect
only to a circuit protected by a Ground-Fault
Circuit-Interrupter (GFCI).
WARNING: Risk of electrical shock.Disconnect
power before servicing.
WARNING: Risk of injury or property damage.
Please read all instructions thoroughly before
beginning installation, including the following
Product Requirements.
NOTICE: Follow all local plumbing and electrical
codes.
B.FACTORY-ASSEMBLED FEATURES
Factoryinstalledcomponentsincludepumpwithintegral
heater, control, and switch. No installation is needed.
The whirlpool pump and piping are factory-assembled.
WARNING: Unauthorized modification may
cause unsafe operation and poor performance
of the whirlpool. Do not relocate the whirlpool
pump,ormakeothermodificationstothewhirlpool
system, as this could adversely affect the
performance and safe operation of the whirlpool.
Kohler Co. shall not be liable under its warranty or
otherwiseforpersonalinjuryordamagecausedby
any such unauthorized modification.
3. PRODUCT REQUIREMENTS
A. SUMMARY OF KEY REQUIREMENTS
Install unit to a level subfloor.
Provide properly dimensioned framing.
The whirlpool can be installed in a corner. Recess
or sunken installation is also possible.
B. PLUMBING SPECIFICATIONS
If using a rim-mounted bath faucet, flexible connections
betweenthevalves and spoutmay berequired. Confirm
adequate mounting and connection space of specified
faucet for your installation.
Confirm adequate support for the faucet; large faucets
that may be inadvertently used as a means of support
are not appropriate or safe for this installation.
C. PRODUCT INSPECTION
Carefully unpack the whirlpool, remove the protective
tape, and inspect the unit for damage. Leave all
materials in the carton during construction to prevent
damage.
NOTICE: Make sure both union connections to the
pump are securely tightened.
D. CONNECTIONS AND SERVICE ACCESS
Before installation, ensure proper access to the final
connections.
NOTICE: Provideunrestrictedserviceaccesstothe
pump. Anaccesspanelmustbeconstructedtoallowfor
sufficient clearance for servicing the pump or controls.
Theaccesspanelmustbelocatedatthepumpendofthe
whirlpool.
E. ELECTRICAL REQUIREMENTS
The installation must have a Class A Ground-Fault
Circuit-Interrupter (GFCI). The GFCI protects against
line-to-ground shock hazard. Use a 120 V, 20 A, 60 Hz
dedicated service for the whirlpool.

6
113906-2-BA (A) Kohler Co., Kohler, WI
4. INSTALLATION REQUIREMENTS
A. TOOLS REQUIRED
Conventional woodworking tools
Arc pliers or 14” pipe wrench
Rule
Level
Safety shoes
Safety glasses
Square
Screwdriver
Pliers
Utility knife
Tin snips
B. MATERIALS REQUIRED
Plumbers putty
Wall coverings, as necessary
Silicone sealant
2x4’s
Drop cloth
Nails
C. CLEARANCE REQUIREMENTS
Check the roughing-in and room dimensions to provide
adequate available space for the bath unit.
D. NEW OR REPLACEMENT INSTALLATION
REQUIREMENTS
This unit can be installed in new or existing bathrooms.
For new installations:Positiontheplumbingaccording
to the roughing-in on Page 4. Cap the supplies, and
check for leaks.
For replacement installations: Remove the old bath.
Remove the old wall material, and remove any old floor
covering from the area. Remove any old plumbing that
does not conform to roughing-in requirements.
5. SITE REQUIREMENTS
A. OLD BATH REMOVAL
Disconnect the drain at the trap. Remove the old wall
material. Slip boards under the old bath feet to
protect the floor andslidetheoldbathoutoftherecess
as illustrated.
Floor
Protection
Boards
Old Bath
B. SUBFLOOR PREPARATION
Check the flooring under the bath, and make repairs as
needed. Make sure the subfloor is level.

7113906-2-BA (A)
Kohler Co., Kohler, WI
C. STUD POCKET PREPARATION
Construct a minimum 2x4 recess designed for your
particular installation. Make sure you allow for access to
the pump in the event the unit requires service. When
constructing the framing, allow for the thickness of sub
and finish wall materials.
If an apron wall without a ledge is desired, the finished
apron wall surface must be 1/16” under the bath rim.
The whirlpool can be installed in a corner. Recess or
sunken installations are also possible. Steps 1. through
3. below illustrate suggested stud construction.
Modifications may be needed for other types of
construction.
1. Corner Installation: The suggested stud
construction is illustrated.
2. Recess Installation: The suggested stud
construction is illustrated.
3. Sunken Installation: Refer to Roughing-In notes
on Page 4 for cut-out details. Make sure the
whirlpoolis supported by the supporting feet onthe
bottom of the whirlpool. Do not hang the
whirlpool by the rim.

8
113906-2-BA (A) Kohler Co., Kohler, WI
D. PLUMBING PREPARATION
Position the plumbing according to the roughing-in
dimensions. Cap the supplies, and check for leaks.
6. BEFORE INSTALLING UNIT
A. TILING-IN BEAD INSTALLATION
Anoptionaltiling-in beadisrecommendedforthesideof
the whirlpool that contacts the wall. This bead prevents
water from seeping between the whirlpool and the wall.
RefertoOrderingInformationlocatedintheRoughing-In
section on Page 4.
Installthisbeadnow.Refertotheinstallationinstructions
packed with the tiling-in bead.
B. PARTIALLY INSTALLBATHDRAIN
Install the whirlpool drain according to the drain
manufacturer’s instructions. Do not connect the trap at
this time.
C. PROTECT WHIRLPOOL UNIT
Position a drop cloth or similar material in the bottom of
the unit. Be careful not to scratch the surface of the
product.
7. INSTALL THE WHIRLPOOL
A. WHIRLPOOL SET-IN
CAUTION: Risk of product damage.Donotuse
the piping or pump for structural support or
positioning.
Option For Corner or Recessed Installation: Slide
the new whirlpool into position. Insert the drain tailpiece
into the trap. Level the whirlpool by placing metal shims
under the whirlpool feet, as needed. The whirlpool must
belevelandrestingonallfourfeet.Checkforlevelalong
thetopandtheendofthewhirlpool,andacrossthedrain
side. The whirlpool may need to be moved in and out of
the recess until it is shimmed properly if the feet are not
accessible from the back or side.
Metal Shims
Metal Shim

9113906-2-BA (A)
Kohler Co., Kohler, WI
Option For Sunken Installation: Set the bath into the
sunken installation. Make sure the unit is level and
resting on all support feet. Insert the drain tailpiece into
the trap. Apply a bead of silicone sealant under the rim
of the unit.
CAUTION: Risk of product damage. Do not
hang the unit by the rim. Whirlpool Rim
1/16” Gap Between
Whirlpool Rim and
Framing
B. PUMP BANDING STRAP CUT
NOTICE: This step is necessary to make your
Kohler whirlpool operate more quietly.
1. Use tin snips to cut the two banding straps. These
banding straps secure the pump to the
whirlpool-mounted shipping bracket. When the
banding straps are cut, the pump base and pump
will drop about 1/2” until they rest on the subfloor. If
the pump drops more than 1/2”, be sure the proper
pitch is maintained (with shims under the motor) to
allow the pump to drain through the suction line
when the whirlpool is drained.
Shipping Bracket
(leave attached
to bath)
Suction Line
Pump
Subfloor
Banding Straps
Pump Base
2. If the subfloor is level, no adjustments to the pump
are necessary. Proceed to Step 3. If the subfloor is
not level, slide plywood shims between the pump
baseandthesubfloor,butonlyhighenoughtoallow
water to drain out the suction line when the bath is
drained.
NOTE: Do not raise the pump higher than it was before
youcutthebandingstraps.Ifthepumpisraisedtoohigh,
it may not prime properly. Shim if necessary, using 5” x 7”
(minimum) plywood
Drainage
Suction Pipe
3. To minimize bath noise and vibration, be sure the
pump is not in direct contact with the shipping
bracket after the banding straps are cut. The pump
base contains rubber isolation feet to reduce pump
noise and vibration.
Pump
Rubber
Isolation
Feet

10
113906-2-BA (A) Kohler Co., Kohler, WI
C. INSTALL PLUMBING
CAUTION: Risk of damage to bath bottom and
subfloor. Ensure a watertight seal on the bath
drain connections.
1. When the bath is securely positioned, connect the
drain to the trap.
NOTE: An access panel will simplify future mainte-
nance. Connect Here
2. Install the faucet valving and spout tee. Open the
hot and cold water valves, and check the supply
connections for leaks.
3. Run water into the bath, and check the drain
connections for leaks.
8. INSTALL GRIP RAILS
Refer to the installation instructions packed with thegrip
rail kit when installing the grip rails.
9. ELECTRICAL CONNECTIONS
A. IDENTIFY ELECTRICAL REQUIREMENTS
The model number is printed on a label at the pump end
of the whirlpool.
The label identifies electrical rating.
B. WIRING INFORMATION – 120 V, 60 HZ –
2-SPEED PUMP (UL LISTED) MODELS
WARNING: Risk of electrical shock. To reduce
theriskofelectricshock,connectonlytoaproperly
grounded, grounding-type receptacle, protected
by a Ground-Fault Circuit-Interrupter (GFCI). Do
not remove the plug’s grounding pin. Do not usea
grounding adapter.
Your Kohler whirlpool bath is equipped with a cord and
plug. All wiring of the pump and control has been
completed at the factory. A licensed electrician must
install a GFCI-protected, 120 V, 20 A, grounded outlet.
Your whirlpool may then be plugged into this outlet. No
other load should be on this circuit. Locate the outlet
behind the whirlpool, and within 24” of the pump.
* For bonding in accordance with national and local
codes.
Switch
Wire Bonding
(Earthing) Lug*
Pump
Plug-in
Cord
20 A
Receptacle
Control Box

11 113906-2-BA (A)
Kohler Co., Kohler, WI
10. WATER TEST WHIRLPOOL AND ELECTRONICS
Check all electrical connections.
Makesureallpipeconnectionstothepumparesecurely
tightened.
Fillthe whirlpooltoalevelatleast2” abovethe topof the
highest jet.
Operate the whirlpool for 5 minutes, and check all
whirlpool harness (piping) connections for leaks.
For additional information on whirlpool operation, see
Start-Up Whirlpool instructions on Page 12.
11. COMPLETE FINISH WALL
CAUTION: Risk of product damage. Do not
support the weight of the bath by the rim.
Protect the whirlpool surface. Make sure the vinyl bead
is attached securely to the sides being built intothe wall.
Cover the framing and walls with water-resistant wall
material.
Tapeandmudthewater-resistantwallmaterial.Sealthe
wall material and joints under the whirlpool rim. Install
the finish wall material. Seal the joints between the
whirlpool rim and the finish wall using silicone sealant.
RTV (Room Temperature Vulcanizing) sealant is
recommended.
ÍÍ
ÍÍ
ÍÍ
É
É
É
É
É
ÇÇ
ÇÇ
ÇÇ
ÇÇ
ÇÇ
ÇÇ
ÇÇ
Ç
Finish Wall Covering
Water-Resistant
Wall Material
Silicone Sealant
Vinyl Bead
2x4 Studding
Framing or
Ledger Strip
Whirlpool
For installations that do not use a vinyl bead, cover the
framing with water-resistant wall material as shown.
Seal the joints between the whirlpool rim edge and the
wall material with silicone sealant.
Tape and mud the water-resistant wall material. Install
the finish wall to the water-resistant wall material as
shown.Sealthe jointsbetweenthewhirlpoolrimandthe
finish wall material with silicone sealant.
Silicone Sealant
Whirlpool
Finish Wall
Material
Water-Resistant
Wall Material
12. COMPLETE INSTALLATION
A. INSTALL HANDLES AND SPOUT
After the deck is finished, attach the handles and spout
to complete the faucet installation according to the
faucet manufacturer’s instructions.

12
113906-2-BA (A) Kohler Co., Kohler, WI
B. INSTALL WHIRLPOOL TRIM KIT
Refer to the installation instructions packed with thetrim
kit when installing the jet or suction trim.
13. CLEAN-UP AFTER INSTALLATION
When cleaning up after installation, do not use
abrasive cleansers as they may scratch and dull the
bath surface. Use warm water and a liquid detergent to
clean the surface.
Stubborn stains, paint, or tar can be removed with
turpentine or paint thinner. Do not allow cleaners
containing petroleum distillates to remain in
contact with whirlpool surfaces for long periods of
time. Plaster can be removed by scraping with a wood
edge. Do not use metal scrapers, wire brushes, or other
metal tools. A powder-type detergent may be used on a
dampclothtoprovidemildabrasiveactiontotheresidual
plaster.
14. CONFIRM PROPER OPERATION
A. START-UP WHIRLPOOL
Refer to Important Safety Instructions on Page 2.
Please perform the following so the owner can safely
receive the benefits of whirlpool bathing.
1. Rotate the jets so they are facing down toward the
basin.
2. Fill the whirlpool to a water level at least 2” above
the top of the highest jet.
Water temperature in the bath should not exceed
104F (40C).
Bath
Wall 2” Minimum
Water Line
Jet Trim

13 113906-2-BA (A)
Kohler Co., Kohler, WI
B. OPERATING SEQUENCE
Refer to the chart at right for the proper operating
sequence.
1. Turn on the whirlpool jets. Adjust each jet for
optimum air/water mixture.
2. A built-in timer automatically stops the motor after
approximately 20 minutes of operation.
3. A built-in heater automatically maintains the water
temperature while whirlpool bathing.
Reduce
Air and
Water Add Air
and
Water
TO METHOD OBSERVE
Turn on high
speed whirlpool
massage and
heater.
Turn on low
speed whirlpool
massage and
heater.
To add air and
water to the
whirlpool action,
rotate trim ring
counterclockwise.
To reduce air and
water, turn it
clockwise.
Shut off whirlpool.
Restart whirlpool
after 20 minute
cycle is
complete.
15. TROUBLESHOOTING PROCEDURES
A. FLEXJET INSTALLATION
NOTE: The Flexjet O-ring must be correctly positioned,
must be lubricated, and must be in good condition to
permit easy rotation and proper operation.
1. Install the O-ring onto the first shoulder of the
Flexjet. Lubricate the O-ring with silicone lubricant
to prevent noisy operation of the Flexjet.
2. Insert the Flexjet into the housing, and lightly push
androtatethe Flexjetuntil itsnapsintoposition.Do
not force the Flexjet.
NOTE: When installed correctly, the Flexjet should turn
smoothly both clockwise and counterclockwise.
Flexjet Housing
O-Ring (Must Be
Lubricated)
Flexjet
First
Shoulder

14
113906-2-BA (A) Kohler Co., Kohler, WI
B. TROUBLESHOOT WHIRLPOOL SYSTEM
Thistroubleshootingguideisforgeneralaidonly.AKohlerAuthorizedServiceRepresentativeoraqualifiedelectrician
should correct all electrical problems. For warranty service, contact your dealer or wholesale distributor.
SYMPTOMS PROBABLE CAUSES RECOMMENDED ACTION
1. Whirlpool does not
start/stop. A. No power to pump/control. A. Set/Reset GFCI; check wiring to pump/receptacle.
B. Jets are blocked. B. Remove blockage.
C. Switch disconnected from
pump/control box. C. Reconnect switch to pump/control box.
D. Switch faulty. D. Replace switch.
E. Faulty circuit board. E. Replace circuit board inside
pump/control box.
F. Faulty motor/pump assembly. F. Replace motor and pump.
2. Motor starts, all jets
t f ti i
A. Jet is closed. A. Rotate jets counterclockwise to open.
,j
are not functioning. B. Trim kit installed incorrectly. B. Reinstall trim kit, checking for damage
to O-ring.
3. Whirlpool stops
ttill
A. GFCI trips. A. Identify source of fault and correct.
automatically
before 18 minutes
B. Suction blocked. B. Remove obstruction.
before
18
min
u
tes
.C. Jets are blocked. C. Remove blockage.
D. Motor overheated and protection
device activated. D. Check for blockage at motor vents. Remove blockage and allow motor to
cool.
Check for suction blockage. Remove
blockage and allow motor to cool.
Check for jet blockage. Remove
blockage and allow motor to cool.
E. Faulty circuit board. E. Replace circuit board inside
pump/control box.
4. Whirlpool does not
automatically stop
after 22 minutes.
A. Faulty circuit board. A. Replace circuit board inside
pump/control box.
5. Pump does not
prime. A. Pump shimmed too high. A. Lower pump/control to subfloor level that bath is resting upon.
6. Noisy operation. A. Pump straps have not been cut. A. Cut straps with tin snips.
B. Jet squeals due to dislodged jet
O-ring. B. Remove jet, replace and lubricate O-ring on valve body, and reinstall jet.

15 113906-2-BA (A)
Kohler Co., Kohler, WI


113906-2-BA (A) Kohler Co., Kohler, WI
