Features
•66"L x 35-7/8"W x 20"H
•Removable apron for front pump access option
•Five adjustable ProFlex®whirlpool jets for maximum bather
comfort
•Drop-in or three-wall alcove installation
•Innovative technology enables this pump to provide a strong,
steady level of hydro-massage
•Constructed of acrylic
•Textured bottom surface
Hydrotherapy
•Whirlpool
Additional Hydrotherapy Options Codes/Standards
•Soaking Bath - 1229-0 ASME A112.19.7/CSA B45.10
CSA B45.5/IAPMO Z124
•Soaking Bath + Bask heated surface - 1229-W1
ASTM E162
•BubbleMassage air bath - 1224-G
ASTM E662
•VibrAcoustic - 1224-VB UL 1795
•VibrAcoustic + Bask heated surface - 1224-VBW
•Whirlpool - 1224-0 KOHLER®Plastic Baths and Receptors
Lifetime Limited Warranty
•Whirlpool + heater - 1224-H
•Whirlpool + Bask heated surface - 1224-W1
KOHLER®Hydrotherapy Components
Five-Year Limited Warranty
Recommended Products/Accessories
K-1234 Removable Apron See website for detailed warranty information.
K-7161-AF Bath Drain
K-24916 Wireless Music Kit
Available Colors/Finishes
K-1601 Bath/Whirlpool Footstop
K-7213 27" Cable Bath Drain
Color tiles intended for reference only.
K-7214 27" Cable Bath Drain
K-37380 30" Rough-in Cable Bath Drain DescriptionCodeColor
K-37383 30" Rough-in Cable Bath Drain White0
Biscuit96
Almond47
DuneNY
SandbarG9
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
10-31-2019 06:06 - US
Mariposa®
66" drop-in whirlpool
K-1224

Recommended Faucet Location
1-1/2"
Bath Drain
66" (1676 mm)
18"
(457 mm)
3-1/2"
(89 mm)
35-7/8" (911 mm)
1"
(25 mm)
2-7/8"
(73 mm)
3"
(76 mm)
1-11/16"
(43 mm)
8-11/16"
(221 mm)
20"
(508 mm) 18-1/2"
(470 mm)
Pump/Control Access
20" (508 mm) W x 15" (381 mm) H
No change in measurements if connected
with drain illustrated. (K-7161-AF)
1-1/2"
(38 mm)
Lumbar
Angle 38°
1-1/2"
(38 mm)
Drop-in Rim
Detail
Notes
Required Electrical Service Measure your actual product for rough-in details.
One dedicated circuit required, protected with Class A
Ground-Fault Circuit-Interrupter (GFCI). Outside North America,
this device may be known as a Residual Current Device (RCD).
Install this product according to the installation
instructions.
The hot water supply should be 70% of the
capacity of the bath or greater. Installations will
vary.
120 V, 15 A, 60 HzPump:
Technical Information
All product dimensions are nominal. Provide one grounded electrical outlet within 24"
(610 mm) of each component.
Drop-inInstallation:
EndDrain location: If installing a rim-mount faucet, make sure there
is no interference above or below the deck before
drilling any holes.
48" x 24" (1219 mm x 610 mm)Basin area, bottom:
59" x 30" (1499 mm x 762 mm)Basin area, top:
110 lbs (49.9 kg)Weight:
48 lbs/ft²(234.4 kg/m²)Minimum floor load:
14" (356 mm)Water depth:
67 gal (253.6 L)Water capacity:
Drop-in, 64" x 34" (1626 mm x 864 mm)Cutout:
Pump: 120 V, 7.5 A, 60 HzElectrical component
rating:
SinglePump speed:
1-15/16" (49 mm)Minimum flat for door:
