KohlerEngines.com24 690 07 Rev. B 1
CV17-CV25, CV620-CV730, CV740, CV750
Service Manual
2 Safety
3 Maintenance
5 Specifications
15 Tools and Aids
18 Troubleshooting
22 Air Cleaner/Intake
23 Fuel System
29 Governor System
30 Lubrication System
32 Electrical System
48 Starter System
57 Disassembly/Inspection and Service
72 Reassembly
IMPORTANT: Read all safety precautions and instructions carefully before operating equipment. Refer to operating
instruction of equipment that this engine powers.
Ensure engine is stopped and level before performing any maintenance or service.

SAFETY PRECAUTIONS
WARNING: A hazard that could result in death, serious injury, or substantial property damage.
CAUTION: A hazard that could result in minor personal injury or property damage.
NOTE: is used to notify people of important installation, operation, or maintenance information.
WARNING
Explosive Fuel can cause
fires and severe burns.
Do not fill fuel tank while
engine is hot or running.
Gasoline is extremely flammable
and its vapors can explode if
ignited. Store gasoline only in
approved containers, in well
ventilated, unoccupied buildings,
away from sparks or flames.
Spilled fuel could ignite if it comes
in contact with hot parts or sparks
from ignition. Never use gasoline
as a cleaning agent.
WARNING
Rotating Parts can cause
severe injury.
Stay away while engine is
in operation.
Keep hands, feet, hair, and
clothing away from all moving
parts to prevent injury. Never
operate engine with covers,
shrouds, or guards removed.
WARNING
Carbon Monoxide can
cause severe nausea,
fainting or death.
Avoid inhaling exhaust
fumes.
Engine exhaust gases contain
poisonous carbon monoxide.
Carbon monoxide is odorless,
colorless, and can cause death if
inhaled.
WARNING
Accidental Starts can
cause severe injury or
death.
Disconnect and ground
spark plug lead(s) before
servicing.
Before working on engine or
equipment, disable engine as
follows: 1) Disconnect spark plug
lead(s). 2) Disconnect negative (–)
battery cable from battery.
WARNING
Hot Parts can cause
severe burns.
Do not touch engine while
operating or just after
stopping.
Never operate engine with heat
shields or guards removed.
WARNING
Cleaning Solvents can
cause severe injury or
death.
Use only in well ventilated
areas away from ignition
sources.
Carburetor cleaners and solvents
are extremely flammable. Follow
cleaner manufacturer’s warnings
and instructions on its proper and
safe use. Never use gasoline as a
cleaning agent.
CAUTION
Electrical Shock can
cause injury.
Do not touch wires while
engine is running.
CAUTION
Damaging Crankshaft
and Flywheel can cause
personal injury.
Using improper procedures can
lead to broken fragments. Broken
fragments could be thrown from
engine. Always observe and use
precautions and procedures when
installing flywheel.
WARNING
Uncoiling Spring can
cause severe injury.
Wear safety goggles or
face protection when
servicing retractable
starter.
Retractable starters contain a
powerful, recoil spring that is
under tension. Always wear safety
goggles when servicing retractable
starters and carefully follow
instructions in Retractable Starter
for relieving spring tension.
Safety
2 24 690 07 Rev. BKohlerEngines.com

MAINTENANCE INSTRUCTIONS
WARNING
Before working on engine or equipment, disable engine as
follows: 1) Disconnect spark plug lead(s). 2) Disconnect
negative (–) battery cable from battery.
Accidental Starts can cause severe injury or
death.
Disconnect and ground spark plug lead(s)
before servicing.
Normal maintenance, replacement or repair of emission control devices and systems may be performed by any repair
establishment or individual; however, warranty repairs must be performed by a Kohler authorized dealer.
MAINTENANCE SCHEDULE
Weekly
●Check heavy-duty air cleaner element. Air Cleaner/Intake
Every 25 Hours or Annually¹
●Service/replace low-profile precleaner. Air Cleaner/Intake
Every 100 Hours or Annually¹
●Replace low-profile air cleaner element. Air Cleaner/Intake
●Change oil. Lubrication System
●Remove cooling shrouds and clean cooling areas. Air Cleaner/Intake
●Check oil cooler fins, clean as necessary (if equipped). Lubrication System
Every 200 Hours
●Change oil filter. Lubrication System
●Replace fuel filter.
Every 250 Hours¹
●Replace heavy-duty air cleaner element and check inner element. Air Cleaner/Intake
Every 500 Hours¹
●Replace heavy-duty inner air cleaner element. Air Cleaner/Intake
●Replace spark plugs and set gap. Electrical System
Every 500 Hours2
●Have crankshaft spline lubricated.
1Perform these procedures more frequently under severe, dusty, dirty conditions.
2Have a Kohler authorized dealer perform this service.
REPAIRS/SERVICE PARTS
Kohler genuine service parts can be purchased from Kohler authorized dealers. To find a local Kohler authorized
dealer visit KohlerEngines.com or call 1-800-544-2444 (U.S. and Canada).
Maintenance
324 690 07 Rev. B KohlerEngines.com

OIL RECOMMENDATIONS
We recommend use of Kohler oils for best performance.
Other high-quality detergent oils (including synthetic)
of API (American Petroleum Institute) service class SJ
or higher are acceptable. Select viscosity based on
air temperature at time of operation as shown in table
below.
FUEL RECOMMENDATIONS
WARNING
Explosive Fuel can cause fires and severe
burns.
Do not fill fuel tank while engine is hot or
running.
Gasoline is extremely flammable and its vapors can
explode if ignited. Store gasoline only in approved
containers, in well ventilated, unoccupied buildings,
away from sparks or flames. Spilled fuel could ignite
if it comes in contact with hot parts or sparks from
ignition. Never use gasoline as a cleaning agent.
NOTE: E15, E20 and E85 are NOT approved and
should NOT be used; effects of old, stale or
contaminated fuel are not warrantable.
Fuel must meet these requirements:
●Clean, fresh, unleaded gasoline.
●Octane rating of 87 (R+M)/2 or higher.
●Research Octane Number (RON) 90 octane minimum.
●Gasoline up to 10% ethyl alcohol, 90% unleaded is
acceptable.
●Methyl Tertiary Butyl Ether (MTBE) and unleaded
gasoline blend (max 15% MTBE by volume) are
approved.
●Do not add oil to gasoline.
●Do not overfill fuel tank.
●Do not use gasoline older than 30 days.
STORAGE
If engine will be out of service for 2 months or more
follow procedure below.
1. Add Kohler PRO Series fuel treatment or equivalent
to fuel tank. Run engine 2-3 minutes to get stabilized
fuel into fuel system (failures due to untreated fuel
are not warrantable).
2. Change oil while engine is still warm from operation.
Remove spark plug(s) and pour about 1 oz. of
engine oil into cylinder(s). Replace spark plug(s) and
crank engine slowly to distribute oil.
3. Disconnect negative (-) battery cable.
4. Store engine in a clean, dry place.
Maintenance
4 24 690 07 Rev. BKohlerEngines.com

Dimensions in millimeters.
Inch equivalents shown in [ ].
Engine Dimensions with Low-Profile Air Cleaner
Specifications
524 690 07 Rev. B KohlerEngines.com

Dimensions in millimeters.
Inch equivalents shown in [ ].
Engine Dimensions with Commercial Mower Air Cleaner
Specifications
6 24 690 07 Rev. BKohlerEngines.com

Dimensions in millimeters.
Inch equivalents shown in [ ].
Engine Dimensions with Heavy-Duty Air Cleaner
93.30
[3.673]
EXHAUST
PORT #1
73.30
[2.886]
EXHAUST
PORT #2
OIL DRAIN PLUG
3/8 NPT (INCH)
40.80
[1.606]
ENGINE MOUNTING
SURFACE
14.20
[.559]
317.77
[12.511]
377.59
[14.866]
155.30
[6.114]
SPARK PLUG
424.75
[16.722]
89.94
[3.541]
134.97
[5.314]
15.76
[.621]
495.31
[19.501]
45.59
[1.795]
126.31
[4.973]
OIL FILL &
DIPSTICK
MOUNTING
HOLE “A”
15.75
[.620]
OIL FILTER
REMOVAL
301.77
[11.881] 130.03
[5.119]
AIR FILTER COVER
ASSEMBLY REMOVAL
SAFTY AIR FILTER
ELEMENT REMOVAL
PRIMARY AIR FILTER
ELEMENT REMOVAL
AIR FILTER RAIN
CAP REMOVAL
SPARK PLUG
FUEL
FILTER
275.56
[10.849]
15.80
[.622]
SPARK PLUG
417.59
[16.441]
529.91
[20.863]
CRANKSHAFT
89.41
[3.520]
241.66
[9.514]
77.68
[3.058]
334.19
[13.157]
50.00
[1.969]
EXHAUST
PORT #1
2X 89.41
[3.520]
2X 72.85
[2.868]
M8 X 1.25
4 STUDS
SOLENOID
SHIFT STARTER
MOUNTING HOLE “A”
4X Ø 9.20 [.362] THRU
Ø 254.00 [10.00] B.C.
104.02
[4.095]
50.00
[1.969]
EXHAUST
PORT #2
30˚
30˚
405.97
[15.983]
247.90
[9.760]
REGULATOR
RECTIFIER
135.30
[5.327]
SPARK
PLUG
52.76
[2.077]
OIL FILTER
14.44
[.569]
96.37
[3.794]
MOUNTING
HOLE “A”
26.41
[1.040]
405.97
[15.983]
OIL DRAIN PLUG
3/8 NPT (INCH)
85.50
[3.366]
KEYWAY
7/16-20 UNF 2B (INCH)
38.1 [1.500]
1/4 IN. SQ KEYWAY Ø 28.56
[1.125]
ENGINE MOUNTING
SURFACE
449.63
[17.702]
PULSE FUEL
PUMP
OIL COOLER
Specifications
724 690 07 Rev. B KohlerEngines.com

GENERAL SPECIFICATIONS3,6 CV17 CV18/CV20/
CV22/
CV620-CV640
CV22/CV23/
CV670-CV680 CV25/CV730/ CV740 CV750
Bore 73 mm
(2.87 in.)
77 mm
(3.03 in.)
80 mm
(3.15 in.)
83 mm (3.27 in.)
Stroke 67 mm (2.64 in.) 69 mm
(2.7 in.)
Displacement 561 cc
(34 cu. in.)
624 cc
(38 cu. in.)
674 cc
(41 cu. in.)
725 cc
(44 cu. in.)
747 cc
(46 cu. in.)
Oil Capacity (refill) 1.6-1.8 L (1.7-1.9 U.S. qt.)
ENGINE IDENTIFICATION NUMBERS
Kohler engine identification numbers (model, specification and serial) should be referenced for efficient repair,
ordering correct parts, and engine replacement.
Model. . . . . . . . . . . . . . . . . . . . . CV620
Command Engine
Vertical Shaft
Numerical Designation
Specification . . . . . . . . . . . . . . . CV620-0001
Serial . . . . . . . . . . . . . . . . . . . . . 3923500328
Year Manufactured Code Factory Code
Code Year
39 2009
40 2010
41 2011
Maximum Angle of Operation (@ full oil level)425°
TORQUE SPECIFICATIONS3,5 CV17 CV18/CV20/
CV22/
CV620-CV640
CV22/CV23/
CV670-CV680 CV25/CV730/ CV740 CV750
Blower Housing and Sheet Metal
M5 Fasteners 6.2 N·m (55 in. lb.) into new holes
4.0 N·m (35 in. lb.) into used holes
M6 Fasteners 10.7 N·m (95 in. lb.) into new holes
7.3 N·m (65 in. lb.) into used holes
Carburetor and Intake Manifold
Intake Manifold Mounting Fastener (torque in
2 increments)
first to 7.4 N·m (66 in. lb.)
finally to 9.9 N·m (88 in. lb.)
Carburetor Mounting Nut 6.2-7.3 N·m (55-65 in. lb.)
Connecting Rod
Cap Fastener (torque in increments)
8 mm straight shank
8 mm step-down
6 mm straight shank
22.7 N·m (200 in. lb.)
14.7 N·m (130 in. lb.)
11.3 N·m (100 in. lb.)
3 Values are in Metric units. Values in parentheses are English equivalents.
4Exceeding maximum angle of operation may cause engine damage from insufficient lubrication.
5Lubricate threads with engine oil prior to assembly.
6Any and all horsepower (hp) references by Kohler are Certified Power Ratings and per SAE J1940 & J1995 hp
standards. Details on Certified Power Ratings can be found at KohlerEngines.com.
Specifications
8 24 690 07 Rev. BKohlerEngines.com

TORQUE SPECIFICATIONS3,5 CV17 CV18/CV20/
CV22/
CV620-CV640
CV22/CV23/
CV670-CV680 CV25/CV730/ CV740 CV750
Crankcase
Breather Cover Fastener 7.3 N·m (65 in. lb.)
Oil Drain Plug 13.6 N·m (10 ft. lb.)
Cylinder Head
Head Fastener
Hex Flange Nut (torque in 2 increments) first to 16.9 N·m (150 in. lb.)
finally to 33.9 N·m (300 in. lb.)
Head Bolt (torque in 2 increments) first to 22.6 N·m (200 in. lb.)
finally to 41.8 N·m (370 in. lb.)
Rocker Arm Screw 11.3 N·m (100 in. lb.)
Flywheel
Fan Fastener 9.9 N·m (88 in. lb.)
Flywheel Retaining Screw 66.4 N·m (49 ft. lb.)
Fuel Pump
Fastener 2.3 N·m (20 in. lb.)
Governor
Lever Nut 6.8 N·m (60 in. lb.)
Ignition
Spark Plug 27 N·m (20 ft. lb.)
Module Fastener 4.0-6.2 N·m (35-55 in. lb.)
Rectifier-Regulator Fastener 1.4 N·m (12.6 in. lb.)
Muffler
Retaining Nuts 24.4 N·m (216 in. lb.)
Oil Cooler
Adapter Nipple 27 N·m (20 ft. lb.)
Oil Sentry™
Pressure Switch 4.5 N·m (40 in. lb.)
Oil Pan
Fastener 24.4 N·m (216 in. lb.)
Solenoid (Starter)
Mounting Hardware
Nippondenso Starter
Delco-Remy Starter
6.0-9.0 N·m (53-79 in. lb.)
4.0-6.0 N·m (35-53 in. lb.)
Nut, Positive (+) Brush Lead
Nippondenso Starter
Delco-Remy Starter
8.0-12.0 N·m (71-106 in. lb.)
8.0-11.0 N·m (71-97 in. lb.)
Speed Control Bracket
Fastener 10.7 N·m (95 in. lb.) into new holes
7.3 N·m (65 in. lb.) into used holes
3 Values are in Metric units. Values in parentheses are English equivalents.
5Lubricate threads with engine oil prior to assembly.
Specifications
924 690 07 Rev. B KohlerEngines.com

TORQUE SPECIFICATIONS3,5 CV17 CV18/CV20/
CV22/
CV620-CV640
CV22/CV23/
CV670-CV680 CV25/CV730/ CV740 CV750
Starter Assembly
Thru Bolt
Inertia Drive
Nippondenso Solenoid Shift
Delco-Remy Solenoid Shift
4.5-5.7 N·m (40-50 in. lb.)
4.5-7.5 N·m (40-84 in. lb.)
5.6-9.0 N·m (49-79 in. lb.)
Mounting Screw 15.3 N·m (135 in. lb.)
Brush Holder Mounting Screw Delco-Remy 2.5-3.3 N·m (22-29 in. lb.)
Stator
Mounting Screw 6.2 N·m (55 in. lb.)
Valve Cover
Gasket Style Cover Fastener 3.4 N·m (30 in. lb.)
Black O-ring Style Cover
With shoulder screws
With flange screws and spacers
5.6 N·m (50 in. lb.)
9.9 N·m (88 in. lb.)
Yellow or Brown O-ring Style Cover
With integral metal spacers 6.2 N·m (55 in. lb.)
CLEARANCE SPECIFICATIONS3CV17 CV18/CV20/
CV22/
CV620-CV640
CV22/CV23/
CV670-CV680 CV25/CV730/ CV740 CV750
Camshaft
End Play (with shim) 0.076/0.127 mm (0.0030/0.0050 in.)
Running Clearance 0.025/0.063 mm (0.0010/0.0025 in.)
Bore I.D.
New
Max. Wear Limit
20.000/20.025 mm (0.7874/0.7884 in.)
20.038 mm (0.7889 in.)
Bearing Surface O.D.
New
Max. Wear Limit
19.962/19.975 mm (0.7859/0.7864 in.)
19.959 mm (0.7858 in.)
Connecting Rod
Connecting Rod-to-Crankpin Running
Clearance
New
Max. Wear Limit
0.030/0.055 mm (0.0012/0.0022 in.)
0.070 mm (0.0028 in.)
Connecting Rod-to-Crankpin Side Clearance 0.26/0.63 mm (0.0102/0.0248 in.)
Connecting Rod-to-Piston Pin Running
Clearance
0.015/0.028 mm (0.0006/0.0011 in.)
Piston Pin End I.D.
New
Max. Wear Limit
17.015/17.023 mm (0.6699/0.6702 in.)
17.036 mm (0.6707 in.)
3 Values are in Metric units. Values in parentheses are English equivalents.
5Lubricate threads with engine oil prior to assembly.
Specifications
10 24 690 07 Rev. BKohlerEngines.com

CLEARANCE SPECIFICATIONS3CV17 CV18/CV20/
CV22/
CV620-CV640
CV22/CV23/
CV670-CV680 CV25/CV730/ CV740 CV750
Crankcase
Governor Cross Shaft Bore I.D.
6 mm Shaft
New
Max. Wear Limit
8 mm Shaft
New
Max. Wear Limit
6.025/6.050 mm (0.2372/0.2382 in.)
6.063 mm (0.2387 in.)
8.025/8.075 mm (0.3159/0.3179 in.)
8.088 mm (0.3184 in.)
Crankshaft
End Play (free) 0.070/0.590 mm (0.0028/0.0230 in.)
Bore (in crankcase)
New
Max. Wear Limit
40.965/41.003 mm (1.6128/1.6143 in.)
41.016 mm (1.6148 in.)
Crankshaft to Sleeve Bearing (crankcase)
Running Clearance - New
0.03/0.09 mm (0.0012/0.0035 in.)
Bore (in oil pan)
New 40.987/40.974 mm (1.6136/1.6131 in.)
Crankshaft Bore (in oil pan)-to-Crankshaft
Running Clearance - New 0.039/0.074 mm (0.0015/0.0029 in.)
Flywheel End Main Bearing Journal
O.D. - New
O.D. - Max. Wear Limit
Max. Taper
Max. Out-of-Round
40.913/40.935 mm (1.6107/1.6116 in.)
40.84 mm (1.608 in.)
0.022 mm (0.0009 in.)
0.025 mm (0.0010 in.)
Oil Pan End Main Bearing Journal
O.D. - New
O.D. - Max. Wear Limit
Max. Taper
Max. Out-of-Round
40.913/40.935 mm (1.6107/1.6116 in.)
40.84 mm (1.608 in.)
0.022 mm (0.0009 in.)
0.025 mm (0.0010 in.)
Connecting Rod Journal
O.D. - New
O.D. - Max. Wear Limit
Max. Taper
Max. Out-of-Round
35.955/35.973 mm (1.4156/1.4163 in.)
35.94 mm (1.415 in.)
0.018 mm (0.0007 in.)
0.025 mm (0.0010 in.)
T.I.R.
PTO End, Crank in Engine
Entire Crank, in V-Blocks
0.279 mm (0.0110 in.)
0.10 mm (0.0039 in.)
Cylinder Bore
Cylinder Bore I.D.
New 73.006/
73.031 mm
(2.8742/
2.8752 in.)
77.000/
77.025 mm
(3.0315/
3.0325 in.)
80.000/
80.025 mm
(3.1496/
3.1506 in.)
82.988/83.013 mm
(3.2672/3.2682 in.)
Max. Wear Limit 73.070 mm
(2.8757 in.)
77.063 mm
(3.0340 in.)
80.065 mm
(3.1522 in.)
83.051 mm (3.2697 in.)
Max. Out-of-Round 0.13 mm
(0.0051 in.)
0.12 mm (0.0047 in.)
Max. Taper 0.05 mm (0.0020 in.)
Cylinder Head
Max. Out-of-Flatness 0.076 mm (0.003 in.)
3 Values are in Metric units. Values in parentheses are English equivalents.
Specifications
1124 690 07 Rev. B KohlerEngines.com

CLEARANCE SPECIFICATIONS3CV17 CV18/CV20/
CV22/
CV620-CV640
CV22/CV23/
CV670-CV680 CV25/CV730/ CV740 CV750
Governor
Governor Cross Shaft-to-Crankcase Running
Clearance
6 mm Shaft
8 mm Shaft
0.013/0.075 mm (0.0005/0.0030 in.)
0.025/0.126 mm (0.0009/0.0049 in.)
Cross Shaft O.D.
6 mm Shaft
New
Max. Wear Limit
8 mm Shaft
New
Max. Wear Limit
5.975/6.012 mm (0.2352/0.2367 in.)
5.962 mm (0.2347 in.)
7.949/8.000 mm (0.3129/0.3149 in.)
7.936 mm (0.3124 in.)
Governor Gear Shaft-to-Governor Gear
Running Clearance
0.015/0.140 mm (0.0006/0.0055 in.)
Gear Shaft O.D.
New
Max. Wear Limit
5.990/6.000 mm (0.2358/0.2362 in.)
5.977 mm (0.2353 in.)
Ignition
Spark Plug Gap 0.76 mm (0.030 in.)
Module Air Gap 0.28/0.33 mm (0.011/0.013 in.)
Piston, Piston Rings, and Piston Pin
Piston-to-Piston Pin Running Clearance 0.006/0.017 mm (0.0002/0.0007 in.)
Pin Bore I.D.
New
Max. Wear Limit
17.006/17.012 mm (0.6695/0.6698 in.)
17.025 mm (0.6703 in.)
Pin O.D.
New
Max. Wear Limit
16.995/17.000 mm (0.6691/0.6693 in.)
16.994 mm (0.6691 in.)
Top Compression Ring-to-Groove Side
Clearance
0.040/
0.085 mm
(0.0016/
0.0033 in.)
0.040/
0.080 mm
(0.0016/
0.0031 in.)
0.030/
0.076 mm
(0.0012/
0.0030 in.)
0.025/0.048 mm
(0.0010/0.0019 in.)
Middle Compression Ring-to-Groove Side
Clearance
0.030/
0.080 mm
(0.0012/
0.0031 in.)
0.040/
0.080 mm
(0.0016/
0.0031 in.)
0.030/
0.076 mm
(0.0012/
0.0030 in.)
0.015/0.037 mm\
(0.0006/0.0015 in.)
Oil Control Ring-to-Groove Side Clearance 0.046/
0.201 mm
(0.0018/
0.0079 in.)
0.060/
0.202 mm
(0.0024/
0.0080 in.)
0.046/
0.196 mm
(0.0018/
0.0077 in.)
0.026/0.176 mm
(0.0010/0.0070 in.)
Top and Middle Compression Ring End Gap
New Bore
Top Ring
Middle Ring
0.180/
0.380 mm
(0.0071/
0.0150 in.)
0.180/
0.440 mm
(0.0071/
0.0173 in.)
0.25/
0.45 mm
(0.0098/
0.0177 in.)
---
---
0.18/
0.46 mm
(0.0071/
0.0181 in.)
---
---
0.25/0.56 mm
(0.0100/0.0224 in.)
---
---
3 Values are in Metric units. Values in parentheses are English equivalents.
Specifications
12 24 690 07 Rev. BKohlerEngines.com

CLEARANCE SPECIFICATIONS3CV17 CV18/CV20/
CV22/
CV620-CV640
CV22/CV23/
CV670-CV680 CV25/CV730/ CV740 CV750
Piston, Piston Rings, and Piston Pin (continued)
Used Bore (Max.)
Top Ring
Middle Ring
0.70 mm
(0.028 in.)
0.90 mm
(0.035 in.)
0.77 mm
(0.030 in.)
---
---
0.80 mm
(0.0315 in.)
---
---
0.94 mm (0.037 in.)
---
---
Thrust Face O.D.7
New 72.966/
72.984 mm
(2.8727/
2.8734 in.)
76.967/
76.985 mm
(3.0302/
3.0309 in.)
79.963/
79.979 mm
(3.1481/
3.1488 in.)
82.986 mm (3.2671 in.)
Max. Wear Limit 72.839 mm
(2.8677 in.)
76.840 mm
(3.0252 in.)
79.831 mm
(3.1430 in.)
82.841 mm (3.2614 in.)
Piston Thrust Face-to-Cylinder Bore7Running
Clearance
New 0.022/
0.065 mm
(0.0009/
0.0026 in.)
0.014/
0.057 mm
(0.0005/
0.0022 in.)
0.021/
0.062 mm
(0.0008/
0.0024 in.)
0.001/0.045 mm
(0.039/0.0018 in.)
Valves and Valve Lifters
Hydraulic Valve Lifter to Crankcase Running
Clearance
0.0241/0.0501 mm (0.0009/0.0020 in.)
Intake Valve Stem-to-Valve Guide Running
Clearance
0.038/0.076 mm (0.0015/0.0030 in.)
Exhaust Valve Stem-to-Valve Guide Running
Clearance
0.050/0.088 mm (0.0020/0.0035 in.)
Intake Valve Guide I.D.
New
Max. Wear Limit
7.038/7.058 mm (0.2771/0.2779 in.)
7.134 mm (0.2809 in.)
Exhaust Valve Guide I.D.
New
Max. Wear Limit
7.038/7.058 mm (0.2771/0.2779 in.)
7.159 mm (0.2819 in.)
Valve Guide Reamer Size
Standard
0.25 mm O.S.
7.048 mm (0.2775 in.)
7.298 mm (0.2873 in.)
Intake Valve Minimum Lift 8.07 mm (0.3177 in.)
Exhaust Valve Minimum Lift 8.07 mm (0.3177 in.)
Nominal Valve Seat Angle 45°
3 Values are in Metric units. Values in parentheses are English equivalents
7Measure 6 mm (0.24 in.) above bottom of piston skirt at right angles to piston pin.
Specifications
1324 690 07 Rev. B KohlerEngines.com

GENERAL TORQUE VALUES
Metric Fastener Torque Recommendations for Standard Applications
Property Class Noncritical
Fasteners
Into Aluminum
Size 4.8 5.8 8.8 10.9 12.9
Tightening Torque: N·m (in. lb.) ± 10%
M4 1.2 (11) 1.7 (15) 2.9 (26) 4.1 (36) 5.0 (44) 2.0 (18)
M5 2.5 (22) 3.2 (28) 5.8 (51) 8.1 (72) 9.7 (86) 4.0 (35)
M6 4.3 (38) 5.7 (50) 9.9 (88) 14.0 (124) 16.5 (146) 6.8 (60)
M8 10.5 (93) 13.6 (120) 24.4 (216) 33.9 (300) 40.7 (360) 17.0 (150)
Tightening Torque: N·m (ft. lb.) ± 10%
M10 21.7 (16) 27.1 (20) 47.5 (35) 66.4 (49) 81.4 (60) 33.9 (25)
M12 36.6 (27) 47.5 (35) 82.7 (61) 116.6 (86) 139.7 (103) 61.0 (45)
M14 58.3 (43) 76.4 (56) 131.5 (97) 184.4 (136) 219.7 (162) 94.9 (70)
Torque Conversions
N·m = in. lb. x 0.113 in. lb. = N·m x 8.85
N·m = ft. lb. x 1.356 ft. lb. = N·m x 0.737
English Fastener Torque Recommendations for Standard Applications
Bolts, Screws, Nuts and Fasteners Assembled Into Cast Iron or Steel Grade 2 or 5 Fasteners
Into Aluminum
Size Grade 2 Grade 5 Grade 8
Tightening Torque: N·m (in. lb.) ± 20%
8-32 2.3 (20) 2.8 (25) — 2.3 (20)
10-24 3.6 (32) 4.5 (40) — 3.6 (32)
10-32 3.6 (32) 4.5 (40) — —
1/4-20 7.9 (70) 13.0 (115) 18.7 (165) 7.9 (70)
1/4-28 9.6 (85) 15.8 (140) 22.6 (200) —
5/16-18 17.0 (150) 28.3 (250) 39.6 (350) 17.0 (150)
5/16-24 18.7 (165) 30.5 (270) — —
3/8-16 29.4 (260) — — —
3/8-24 33.9 (300) — — —
Tightening Torque: N·m (ft. lb.) ± 20%
5/16-24 — — 40.7 (30) —
3/8-16 — 47.5 (35) 67.8 (50) —
3/8-24 — 54.2 (40) 81.4 (60) —
7/16-14 47.5 (35) 74.6 (55) 108.5 (80) —
7/16-20 61.0 (45) 101.7 (75) 142.5 (105) —
1/2-13 67.8 (50) 108.5 (80) 155.9 (115) —
1/2-20 94.9 (70) 142.4 (105) 223.7 (165) —
9/16-12 101.7 (75) 169.5 (125) 237.3 (175) —
9/16-18 135.6 (100) 223.7 (165) 311.9 (230) —
5/8-11 149.5 (110) 244.1 (180) 352.6 (260) —
5/8-18 189.8 (140) 311.9 (230) 447.5 (330) —
3/4-10 199.3 (147) 332.2 (245) 474.6 (350) —
3/4-16 271.2 (200) 440.7 (325) 637.3 (470) —
Specifications
14 24 690 07 Rev. BKohlerEngines.com

Tools and Aids
1524 690 07 Rev. B KohlerEngines.com
Certain quality tools are designed to help you perform specific disassembly, repair, and reassembly procedures. By
using these tools, you can properly service engines easier, faster, and safer! In addition, you’ll increase your service
capabilities and customer satisfaction by decreasing engine downtime.
Here is a list of tools and their source.
SEPARATE TOOL SUPPLIERS
Kohler Tools
Contact your local Kohler source of
supply.
SE Tools
415 Howard St.
Lapeer, MI 48446
Phone [phone]
Toll Free 800-664-2981
Fax [phone]
Design Technology Inc.
768 Burr Oak Drive
Westmont, IL 60559
Phone [phone]
Fax [phone]
TOOLS
Description Source/Part No.
Alcohol Content Tester
For testing alcohol content (%) in reformulated/oxygenated fuels.
Kohler 25 455 11-S
Camshaft Endplay Plate
For checking camshaft endplay.
SE Tools KLR-82405
Camshaft Seal Protector (Aegis)
For protecting seal during camshaft installation.
SE Tools KLR-82417
Cylinder Leakdown Tester
For checking combustion retention and if cylinder, piston, rings, or valves are worn.
Individual component available:
Adapter 12 mm x 14 mm (Required for leakdown test on XT-6 engines)
Kohler 25 761 05-S
Design Technology Inc.
DTI-731-03
Dealer Tool Kit (Domestic)
Complete kit of Kohler required tools.
Components of 25 761 39-S
Ignition System Tester
Cylinder Leakdown Tester
Oil Pressure Test Kit
Rectifier-Regulator Tester (120 V AC/60Hz)
Kohler 25 761 39-S
Kohler 25 455 01-S
Kohler 25 761 05-S
Kohler 25 761 06-S
Kohler 25 761 20-S
Dealer Tool Kit (International)
Complete kit of Kohler required tools.
Components of 25 761 42-S
Ignition System Tester
Cylinder Leakdown Tester
Oil Pressure Test Kit
Rectifier-Regulator Tester (240 V AC/50Hz)
Kohler 25 761 42-S
Kohler 25 455 01-S
Kohler 25 761 05-S
Kohler 25 761 06-S
Kohler 25 761 41-S
Digital Vacuum/Pressure Tester
For checking crankcase vacuum.
Individual component available:
Rubber Adapter Plug
Design Technology Inc.
DTI-721-01
Design Technology Inc.
DTI-721-10
Electronic Fuel Injection (EFI) Diagnostic Software
For Laptop or Desktop PC.
Kohler 25 761 23-S
EFI Service Kit
For troubleshooting and setting up an EFI engine.
Components of 24 761 01-S
Fuel Pressure Tester
Noid Light
90° Adapter
In-line "T" Fitting
Code Plug, Red Wire
Code Plug, Blue Wire
Shrader Valve Adapter Hose
Kohler 24 761 01-S
Design Technology Inc.
DTI-019
DTI-021
DTI-023
DTI-035
DTI-027
DTI-029
DTI-037
Flywheel Holding Tool (CS)
For holding flywheel of CS series engines.
SE Tools KLR-82407
Flywheel Puller
For properly removing flywheel from engine.
SE Tools KLR-82408
Flywheel Strap Wrench
For holding flywheel during removal.
SE Tools KLR-82409

Tools and Aids
16 24 690 07 Rev. BKohlerEngines.com
TOOLS
Description Source/Part No.
Hydraulic Valve Lifter Tool
For removing and installing hydraulic lifters.
Kohler 25 761 38-S
Ignition System Tester
For testing output on all systems, including CD.
Kohler 25 455 01-S
Inductive Tachometer (Digital)
For checking operating speed (RPM) of an engine.
Design Technology Inc.
DTI-110
Offset Wrench (K and M Series)
For removing and reinstalling cylinder barrel retaining nuts.
Kohler 52 455 04-S
Oil Pressure Test Kit
For testing/verifying oil pressure on pressure lubricated engines.
Kohler 25 761 06-S
Radiator Tester
For pressure testing radiator and cap on Aegis liquid-cooled engines.
Kohler 25 455 10-S
Rectifier-Regulator Tester (120 volt current)
Rectifier-Regulator Tester (240 volt current)
For testing rectifier-regulators.
Components of 25 761 20-S and 25 761 41-S
CS-PRO Regulator Test Harness
Special Regulator Test Harness with Diode
Kohler 25 761 20-S
Kohler 25 761 41-S
Design Technology Inc.
DTI-031
DTI-033
Spark Advance Module (SAM) Tester
For testing SAM (ASAM and DSAM) on engines with SMART-SPARK™.
Kohler 25 761 40-S
Starter Servicing Kit (All Starters)
For removing and reinstalling drive retaining rings and brushes.
Individual component available:
Starter Brush Holding Tool (Solenoid Shift)
SE Tools KLR-82411
SE Tools KLR-82416
Triad/OHC Timing Tool Set
For holding cam gears and crankshaft in timed position while installing timing belt.
Kohler 28 761 01-S
Valve Guide Reamer (K and M Series)
For properly sizing valve guides after installation.
Design Technology Inc.
DTI-K828
Valve Guide Reamer O.S. (Command Series)
For reaming worn valve guides to accept replacement oversize valves. Can be used
in low-speed drill press or with handle below for hand reaming.
Kohler 25 455 12-S
Reamer Handle
For hand reaming using Kohler 25 455 12-S reamer.
Design Technology Inc.
DTI-K830
Valve Guide Service Kit (Courage, Aegis, Command, OHC)
For servicing worn valve guides.
SE Tools KLR-82415
AIDS
Description Source/Part No.
Camshaft Lubricant (Valspar ZZ613) Kohler 25 357 14-S
Dielectric Grease (GE/Novaguard G661) Kohler 25 357 11-S
Dielectric Grease Loctite®51360
Kohler Electric Starter Drive Lubricant (Inertia Drive) Kohler 52 357 01-S
Kohler Electric Starter Drive Lubricant (Solenoid Shift) Kohler 52 357 02-S
RTV Silicone Sealant
Loctite®5900®Heavy Body in 4 oz. aerosol dispenser.
Only oxime-based, oil resistant RTV sealants, such as those listed, are approved
for use. Loctite®Nos. 5900®or 5910®are recommended for best sealing
characteristics.
Kohler 25 597 07-S
Loctite®5910®
Loctite®Ultra Black 598™
Loctite®Ultra Blue 587™
Loctite®Ultra Copper 5920™
Spline Drive Lubricant Kohler 25 357 12-S

Tools and Aids
1724 690 07 Rev. B KohlerEngines.com
FLYWHEEL HOLDING TOOL ROCKER ARM/CRANKSHAFT TOOL
A flywheel holding tool can be made out of an old junk
flywheel ring gear and used in place of a strap wrench.
1. Using an abrasive cut-off wheel, cut out a six tooth
segment of ring gear as shown.
2. Grind off any burrs or sharp edges.
3. Invert segment and place it between ignition bosses
on crankcase so tool teeth engage flywheel ring
gear teeth. Bosses will lock tool and flywheel in
position for loosening, tightening, or removing with a
puller.
A spanner wrench to lift rocker arms or turn crankshaft
may be made out of an old junk connecting rod.
1. Find a used connecting rod from a 10 HP or larger
engine. Remove and discard rod cap.
2. Remove studs of a Posi-Lock rod or grind off
aligning steps of a Command rod, so joint surface is
flat.
3. Find a 1 in. long capscrew with correct thread size to
match threads in connecting rod.
4. Use a flat washer with correct I.D. to slip on
capscrew and approximately 1 in. O.D. Assemble
capscrew and washer to joint surface of rod.

Troubleshooting
18 24 690 07 Rev. BKohlerEngines.com
Engine Cranks But Will Not Start
●Battery connected backwards.
●Blown fuse.
●Carburetor solenoid malfunction.
●Choke not closing.
●Clogged fuel line or fuel filter.
●Diode in wiring harness failed in open circuit mode.
●DSAI or DSAM malfunction.
●Empty fuel tank.
●Faulty electronic control unit.
●Faulty ignition coil(s).
●Faulty spark plug(s).
●Fuel pump malfunction-vacuum hose clogged or
leaking.
●Fuel shut-off valve closed.
●Ignition module(s) faulty or improperly gapped.
●Insufficient voltage to electronic control unit.
●Interlock switch is engaged or faulty.
●Key switch or kill switch in OFF position.
●Low oil level.
●Quality of fuel (dirt, water, stale, mixture).
●SMART-SPARKTM malfunction.
●Spark plug lead(s) disconnected.
Engine Starts But Does Not Keep Running
●Faulty carburetor.
●Faulty cylinder head gasket.
●Faulty or misadjusted choke or throttle controls.
●Fuel pump malfunction-vacuum hose clogged or
leaking.
●Intake system leak.
●Loose wires or connections that intermittently ground
ignition kill circuit.
●Quality of fuel (dirt, water, stale, mixture).
●Restricted fuel tank cap vent.
Engine Starts Hard
●Clogged fuel line or fuel filter.
●Engine overheated.
●Faulty ACR mechanism.
●Faulty or misadjusted choke or throttle controls.
●Faulty spark plug(s).
●Flywheel key sheared.
●Fuel pump malfunction-vacuum hose clogged or
leaking.
●Interlock switch is engaged or faulty.
●Loose wires or connections that intermittently ground
ignition kill circuit.
●Low compression.
●Quality of fuel (dirt, water, stale, mixture).
●Weak spark.
TROUBLESHOOTING GUIDE
When troubles occur, be sure to check simple causes which, at first, may seem too obvious to be considered. For
example, a starting problem could be caused by an empty fuel tank.
Some general common causes of engine troubles are listed below and vary by engine specification. Use these to
locate causing factors.
Engine Will Not Crank
●Battery is discharged.
●Faulty electric starter or solenoid.
●Faulty key switch or ignition switch.
●Interlock switch is engaged or faulty.
●Loose wires or connections that intermittently ground
ignition kill circuit.
●Pawls not engaging in drive cup.
●Seized internal engine components.
Engine Runs But Misses
●Carburetor adjusted incorrectly.
●Engine overheated.
●Faulty spark plug(s).
●Ignition module(s) faulty or improperly gapped.
●Incorrect crankshaft position sensor air gap.
●Interlock switch is engaged or faulty.
●Loose wires or connections that intermittently ground
ignition kill circuit.
●Quality of fuel (dirt, water, stale, mixture).
●Spark plug lead(s) disconnected.
●Spark plug lead boot loose on plug.
●Spark plug lead loose.
Engine Will Not Idle
●Engine overheated.
●Faulty spark plug(s).
●Idle fuel adjusting needle(s) improperly set.
●Idle speed adjusting screw improperly set.
●Inadequate fuel supply.
●Low compression.
●Quality of fuel (dirt, water, stale, mixture).
●Restricted fuel tank cap vent.
Engine Overheats
●Cooling fan broken.
●Excessive engine load.
●Fan belt failed/off.
●Faulty carburetor.
●High crankcase oil level.
●Lean fuel mixture.
●Low cooling system fluid level.
●Low crankcase oil level.
●Radiator, and/or cooling system components clogged,
restricted, or leaking.
●Water pump belt failed/broken.
●Water pump malfunction.
Engine Knocks
●Excessive engine load.
●Hydraulic lifter malfunction.
●Incorrect oil viscosity/type.
●Internal wear or damage.
●Low crankcase oil level.
●Quality of fuel (dirt, water, stale, mixture).

1924 690 07 Rev. B KohlerEngines.com
Troubleshooting
Engine Loses Power
●Dirty air cleaner element.
●Engine overheated.
●Excessive engine load.
●Restricted exhaust.
●Faulty spark plug(s).
●High crankcase oil level.
●Incorrect governor setting.
●Low battery.
●Low compression.
●Low crankcase oil level.
●Quality of fuel (dirt, water, stale, mixture).
Engine Uses Excessive Amount of Oil
●Loose or improperly torqued fasteners.
●Blown head gasket/overheated.
●Breather reed broken.
●Clogged, broken, or inoperative crankcase breather.
●Crankcase overfilled.
●Incorrect oil viscosity/type.
●Worn cylinder bore.
●Worn or broken piston rings.
●Worn valve stems/valve guides.
Oil Leaks from Oil Seals, Gaskets
●Breather reed broken.
●Clogged, broken, or inoperative crankcase breather.
●Loose or improperly torqued fasteners.
●Piston blow by, or leaky valves.
●Restricted exhaust.
EXTERNAL ENGINE INSPECTION
NOTE: It is good practice to drain oil at a location away
from workbench. Be sure to allow ample time for
complete drainage.
Before cleaning or disassembling engine, make a
thorough inspection of its external appearance and
condition. This inspection can give clues to what might
be found inside engines (and cause) when it is
disassembled.
●Check for buildup of dirt and debris on crankcase,
cooling fins, grass screen, and other external surfaces.
Dirt or debris on these areas can cause overheating.
●Check for obvious fuel and oil leaks, and damaged
components. Excessive oil leakage can indicate a
clogged or inoperative breather, worn or damaged
seals or gaskets, or loose fasteners.
●Check air cleaner cover and base for damage or
indications of improper fit and seal.
●Check air cleaner element. Look for holes, tears,
cracked or damaged sealing surfaces, or other
damage that could allow unfiltered air into engine. A
dirty or clogged element could indicate insufficient or
improper maintenance.
●Check carburetor throat for dirt. Dirt in throat is further
indication that air cleaner was not functioning properly.
●Check if oil level is within operating range on dipstick.
If it is above, sniff for gasoline odor.
●Check condition of oil. Drain oil into a container; it
should flow freely. Check for metal chips and other
foreign particles.
Sludge is a natural by-product of combustion; a small
accumulation is normal. Excessive sludge formation
could indicate over rich fuel settings, weak ignition,
overextended oil change interval or wrong weight or
type of oil was used.
CLEANING ENGINE
WARNING
Cleaning Solvents can cause severe injury or
death.
Use only in well ventilated areas away from
ignition sources.
Carburetor cleaners and solvents are extremely
flammable. Follow cleaner manufacturer’s warnings
and instructions on its proper and safe use. Never use
gasoline as a cleaning agent.
After inspecting external condition of engine, clean
engine thoroughly before disassembly. Clean individual
components as engine is disassembled. Only clean
parts can be accurately inspected and gauged for wear
or damage. There are many commercially available
cleaners that will quickly remove grease, oil, and grime
from engine parts. When such a cleaner is used, follow
manufacturer’s instructions and safety precautions
carefully.
Make sure all traces of cleaner are removed before
engine is reassembled and placed into operation. Even
small amounts of these cleaners can quickly break down
lubricating properties of engine oil.

Troubleshooting
20 24 690 07 Rev. BKohlerEngines.com
Condition Conclusion
Crankcase breather clogged or inoperative. NOTE: If breather is integral part of valve cover and
cannot be serviced separately, replace valve
cover and recheck pressure.
Disassemble breather, clean parts thoroughly, check
sealing surfaces for flatness, reassemble, and recheck
pressure.
Seals and/or gaskets leaking. Loose or improperly torque
fasteners.
Replace all worn or damaged seals and gaskets. Make
sure all fasteners are tightened securely. Use appropriate
torque valves and sequences when necessary.
Piston blow by or leaky valves (confirm by inspecting
components).
Recondition piston, rings, cylinder bore, valves and
valves guides.
Restricted exhaust. Check exhaust screen/spark arrestor (if equipped). Clean
or replace as needed. Repair or replace any other
damaged/restricted muffler or exhaust system parts.
CRANKCASE VACUUM TEST
WARNING
Carbon Monoxide can cause severe nausea,
fainting or death.
Avoid inhaling exhaust fumes.
Engine exhaust gases contain poisonous carbon
monoxide. Carbon monoxide is odorless, colorless,
and can cause death if inhaled.
To test crankcase vacuum with manometer:
1. Insert rubber stopper into oil fill hole. Be sure pinch
clamp is installed on hose and use tapered adapters
to connect hose between stopper and one
manometer tube. Leave other tube open to
atmosphere. Check that water level in manometer is
at 0 line. Make sure pinch clamp is closed.
2. Start engine and run no-load high speed.
3. Open clamp and note water level in tube.
Level in engine side should be a minimum of 10.2
cm (4 in.) above level in open side.
If level in engine side is less than specified (low/no
vacuum), or level in engine side is lower than level in
open side (pressure), check for conditions in table
below.
4. Close pinch clamp before stopping engine.
To test crankcase vacuum with vacuum/pressure gauge:
1. Remove dipstick or oil fill plug/cap.
2. Install adapter into oil fill//dipstick tube opening,
upside down over end of a small diameter dipstick
tube, or directly into engine if a tube is not used.
Insert barbed gauge fitting into hole in stopper.
3. Run engine and observe gauge reading.
Analog tester–needle movement to left of 0 is a
vacuum, and movement to right indicates a pressure.
Digital tester–depress test button on top of tester.
Crankcase vacuum should be a minimum of 10.2 cm
(4 in.) of water. If reading is below specification, or if
pressure is present, check table below for possible
causes and conclusions.
WARNING
Rotating Parts can cause severe injury.
Stay away while engine is in operation.
Keep hands, feet, hair, and clothing away from all
moving parts to prevent injury. Never operate engine
with covers, shrouds, or guards removed.
A partial vacuum should be present in crankcase when engine is operating. Pressure in crankcase (normally caused
by a clogged or improperly assembled breather) can cause oil to be forced out at oil seals, gaskets, or other available
spots.
Crankcase vacuum is best measured with either a water manometer or a vacuum gauge. Complete instructions are
provided in kits.
