Kohler K-1753T User manual

-1-
·
·
·
·
Please read these instructions carefully to
familiarize yourself with the required tools, materials,
and installation sequences. Follow the sections that
pertain to your particular installation. This will help
you avoid costly mistakes. In addition to proper
installation, read all operating and safety instructions.
All information is based on the latest product
information available at the time of publication.
Kohler China Ltd. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning,
and warranty information-
Please provide adequate available space for the
bath unit in accordance with rough-in. Arrange the
location of drain in advance.
All installations must comply with council and local
authority by-laws. It is the responsibility of the installer
to ensure that the waste is made watertight by means
of silicone sealant or caulking compound.
Bath drain supplies and electric wiring should be
arranged preliminarily according to the selected bath.
please leave these
instructions for the consumer.
IMPORTANT:
NOTE: Bath can be installed after the wall is completed.
·
·
·
·
BEFORE YOU BEGIN
368 201419
32" HOURGLASS 32"
SYMBIO
INSTALLATION INSTRUCTIONS
INTEGRATED WHIRLPOOL
K-1753T/K-1754T K-1773T/K-1774T
, 2007
Copyright Kohler China Ltd., 2007
PRODUCT NOTICES
A.
(GFCI)
(ELCB)
A. Installation Hazard Notification
DANGER: Risk of fire, electric shock, or injury to
persons.
WARNING: Risk of electrical shock.
WARNING: Risk of electrical shock.
WARNING: Risk of electrical shock.
WARNING: Risk of injury or property damage.
NOTICE:
Read important safety instructions on inside
front cover of these instructions.
A licensed
electrician should make all electrical connections.
Connect only to
a circuit protected by a Ground-Fault Circuit-Interrupter
(GFCI) or Earth-Leakage Circuit-Breaker (ELCB).
Disconnect
power before servicing.
Please read all instructions thoroughly before beginning
installation, including the following Product
Requirements.
Follow all local plumbing and electrical codes.
1073414-T01-B

A.
·
·
A. Summary Of Key Requirements
Observe all local plumbing codes.
Install the unit to a level subfloor.
·
·
B. Product Inspection
Uncrate and inspect bath for damage. All Kohler s
baths have been manufactured with sophisticated
craftsmanship. However, please inspect for any
possible damage that may have occurred in transit.
Leave all materials in the crate during construction to
prevent damage.
Damage occurred during transit shall not be
covered by warranty.
’
NOTE:
B.
PRODUCT REQUIREMENTS
B. Factory-Assembled Features
Factory installed components include pump and air
switch transmitter. No installation is needed.
The whirlpool pump and piping are factory assembled.
Do not relocate the whirlpool pump, or make
other modifications to the whirlpool system, as this
could adversely affect the performance and safe
operation of the whirlpool. Kohler . shall not be liable
under its warranty or otherwise for personal injury or
damage caused by any such unauthorized modification.
WARNING: Unauthorized modification may cause
unsafe operation and poor performance of the
whirlpool.
Co
B.
-2-
C. Electrical Connection
1. Pump
The installation must have a 30mA Earth Leakage
Circuit Breaker. The GFCI protects against Line-to-
Ground shock hazard. Use a 220-240V, 10A
(minimum), 50Hz dedicated service for the whirlpool.
C.
1.
30mA
GFCI
220-240 /50
10
1073414-T01-B

SITE REQUIREMENTS
A.A. Preparation
Check the flooring under the bath, and make repairs as
needed. Make sure the is level.
Subfloor
subfloor
C.
C. Clearance Requirements
Check the rough-in and room dimensions to provide
adequate available space for the bath unit.
·
·
·
·
·
·
·
·
·
Adjustable pipe
wrench
Rule
Level
Safety shoes
Safety glasses
Square
Screwdriver
Pliers
Utility knife
·Adjustable wrench
·
·
·
·
·
·
·
Plumbers putty
Wall coverings(as necessary)
Silicone sealant
Gypsum cement(optional)
Construction adhesive
(optional)
Protective covering for
bathtub
Nails
B. Materials RequiredA. Tools Required
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
()
()
()
B.
A.
INSTALLATION REQUIREMENTS
-3-
BEFORE INSTALLING UNIT
A.
B.
A. The protective film must be removed from around
the waste and along the tiling bead prior to installation
in order to make a watertight seal at these points
possible.
B. Protect the Bath Unit
Position a protective covering or similar material in the
bottom of the unit. Be careful not to scratch the bath
surface.
NOTES:
1. Flush the water supply pipes thoroughly to remove
debris.
2. Inspect the supply tubing for damage. Replace as
necessary.
3. Observe local plumbing codes.
4. The minimum inlet water pressure for the faucet
diverter is 0.05Mpa(0.5bar).
1.
2.
3.
4. :0.05Mpa(0.5bar)
1073414-T01-B

-4-
INSTALL THE BATH
A. Locate the bath in the proposed position
Adjust the feet under the bath to make it level. Tighten
the nut to fix the height of the bath.
The bath must be installed level on all top edges.
Floor should be flat, level and free of any bumps or
protrusions.
Keep the clearance of minimum 10mm (for
HOURGLASS)/15mm (for SYMBIO) from floor to the
apron for installing the apron. Be careful with the
drain hose to prevent it to be squeezed.
10
15
IMPORTANT:
!
!
!
!
A.
Adjustable Feet
HOURGLASS>10mm
SYMBIO>15mm
Gasket, Overflow
Handle
Cover, Overflow
Fix Clip Assy
Flexible Pipe,
Overflow
Control Cable
O-ring for Overflow outlet
O
Screw
Bath Wall
Seal Plug
Adjustable Nut
Adjustable Screw
Fix screw, Strainer
Gasket, Thin, Drain
Gasket, Thick, Drain
Joint Nut
Joint Gasket
PVC Gasket
Fix Clip Assy
B. Plumbing Installation and Electric
Wiring
CAUTION: Risk of damage to bath bottom and
subfloor.
1 . When the bath is securely positioned, connect the
drain to the trap and apply silicone sealant.
2.
Open the hot and cold
water valves, and check the supply connections for
leaks.
The installation of the faucet and drain has been
completed before the bath leaves factory. Connect
cold and hot water supplies.
3). Connect power supply (220V/50Hz, 10A) to motor.
This should be a separato line, direct from the
switchboard.
The electrical connections must comply with
local authority regulations and must be done by an
authorized electriclan.
4).
Note:
Fill bathtub with water to the height of the
overflow and trial run pump for 10-15 minutes.
Check all the fittings for leaks and test the
control functions. Check the pump and pipes
union connections for leaks. Hand tighten union
connections if required. Check bath drains and
overflow for leaks.
)
)Plug Body
Strainer
Fix Clip Assy
PVC Pipe
PVC
Flexible Pipe
1073414-T01-B

-5-
Union Connections
B.
1).
2).
3). 220V/50Hz
10A
4). 10-15
C. Install and Remove the Apron
If the apron needs removing, please follow the steps
below:
1) Remove the screw cap and loosen the screw.
2) Push the upper part of the apron inwards, pull down
the apron and it can be removed easily.
3) When installing the apron, insert the top of the apron
into the enclosement, then fix and cap the screws.
IMPORTANT: Your spa has been factory tested and
approved. It is the responsability of the installer to test
run the spa check all the fittings for leaks and test the
control functions.
NON OBSERVANCE WILL INVALIDATE FACTORY
WARRANTY.
C.
1).
2).
3).
D. Apply Sealant
1. After the bath is fixed, apply sealant around the bath.
D.
1. Apply Silicone
Sealant
Apply Silicone Sealant
Apply Silicone Sealant
Apply Silicone Sealant
SPA PUMP OWNER S INSTRUCTIONS’
MOTOR/PUMP RECOMMENDED METHOD OF INSTALLATION
/
// ( )
/
Factory attached Motor/Pump /Heater. (Full
Warranty)
IMPORTANT: Do not remove factory attached
motor/pump and heater.
1073414-T01-B

-6-
ON/OFF AIR SWITCH CONNECTION
Ensure pump is connected to On/Off Air switch Control.
Bath Flange
Air Switch
To the Pump
To the Air Switch
Pump
Air Massage Control
Rotate clockwise and anticlockwise to adjust the air
massage.
On/Off Spa Control (Air Switch)
Push once to start the motor. Push again to stop the
motor.
/( )
IMPORTANT: Do not operate spa bath without water.
/
On/Off
Decrease Air
Massage
Increase Air
Massage
AIR SWITCH FUNCTION & OPERATION
A. Spa Bath will not operate
IMPORTANT:
Fill bath above jets.
2"
A.
2"
50mm
TROUBLE SHOOTING GUIDE
1073414-T01-B

1) Check that the adjustable jets are open.
1)
2) Adjust the air turbulence by turning the venturi
controls as shown.
2) Increase
Air Masage
Decrease
Air Masage
OPEN
CLOSED
-7-
Check:
·
·
·
·
·
Fuse at switchboard has not blown.
RCD (ELCB) has not tripped out.
Pump is plugged in.
On/Off air switch control is connected to the pump.
Check power is available to wall socket by running
an electrical appliance.
·
·
·
·/
·
B. Spa still not operates B.
SERVICE
/
A. B.
C. D.
The installer can check the "trouble shooting guide"
before a service agent needs to be called. If the unit is
still not operating properly advise your local
merchant/distributor from whom you purchased your
spa bath. It is important to give the following
information:
A. Warranty Number B. Bath type
C. Date of purchase D. Details of complaint
A. To Disassemble
1) Push the eyeball in using the thumb.
1)
A.
Facia
Eyeball
JET MAINTENANCE INSTRUCTIONS
2) While holding the eyeball in, gently lever the facia off,
either by hand or using an instrument that will not
damage the bath or the facia. The eyeball and washer
should come off with the facia.
2)
Facia
1073414-T01-B

-8-
3) Pull the sleeve and spring out of the jet body. Note
the sleeve may be jammed in place by debris and long
nosed pliers may be needed to remove it.
3)
4) Slide the spring off the sleeve.
4)
Jet Body Sleeve
5) Clean out any hair or grime from inside the jet body.
5)
6) Clean off any hair or grime from the sleeve, spring,
eyeball, washer and facia with a clean cloth.
6)
B. TO RE-ASSEMBLE
1) Exploded diagram of components.
1)
B.
Jet Body
Spring
Sleeve
Eyeball
Washer
Facia
2) Check the spring length is 22mm, gently stretch the
spring if necessary. Re-assemble the spring over the
sleeve.
2) 22mm
22mm
1073414-T01-B

-9-
3) Replace the spring and sleeve into the jet body.
3)
4) Re-assemble the two halves of the eyeball and fit
into the sleeve. Note that the 6 legs on the eyeball fit
between the castleations on the sleeve. Fit the washer
over the stalk on the front of the eyeball.
4)
5) Holding the eyeball in place, gently push the facia
back into the jet body until it clicks into place.
5)
6) To open or close the jet control, rotate the central
stalk. There is no solid stop on the control and it can
therefore be rotated clockwise or anticlockwise from the
ON position through OFF and back to ON.
6)
Both handles open with turning counter-clockwise and
close with turning clockwise. Turn on the faucet, water
flows from the bath spout. Pull diverter, water flows
form the handspray. When turn off the faucet, the
diverter returns to the bath postion.
OWNER S INSTRUCTIONS: FAUCET SECTION’
1073414-T01-B

-10-
Bath:
Pillow:
Faucet:
Your new vinyl pillow can be routinely cleaned
with mild soap and water. Remove stubborn stains with
cleaning products recommended for vinyl.
Periodically use a vinyl treatment product to
rejuvenate the appearance of the vinyl skin.
All Finishes: Clean the finish with a mild soap
and warm water. Wipe entire surface completely dry
with a clean soft cloth. Many cleaners may contain
chemicals, such as ammonia or chlorine, which could
adversely affect the finish and are not recommended
for cleaning.
Do not use abrasive cleaners or solvents on Kohler
faucets and fittings.
CARE AND CLEANING OF YOUR PILLOW
CLEAN-UP AFTER INSTALLATION
When cleaning up after installation, do not use abrasive
cleansers as they may scratch and dull the surface.
Use warm water and liquid, non-abrasive detergent to
clean the surface.
Stubborn stains, paint, or tar can be removed with
mineral spirits. Do not use cleaners containing solvent.
Plaster can be removed by scraping with wood edge.
Do not use metal scrapers, wire brushes, or other metal
tools. One of the powder type detergents may be used
on a damp cloth to provide mild abrasive action to the
residual plaster.
DIRLLING AND CUTTING ACRYLIC
DRILLING:
NOTE:
CUTTING:
Small holes can be drilled with a twist drill,
but the cutting edge MUST be backed off with an oil
stone (the sharp edge dulled). Large holes must be
drilled with a hole saw. Maximum drill size-12mm. Drill
speeds-6mm x 1800 RPM-12 mm x 900 RPM.
Always drill from acrylic surface.
If for any reason the acrylic requires cutting,
use a fine tooth hacksaw and proceed with caution.
Edges can be smoothed with a second-cut file and
medium-fine sandpaper. If the surface of the acrylic
should happen to be damaged, it can be restored by
polishing with an abrasive cleaner . Deep scratches
can be removed by rubbing with 600 grade wet & dry
sandpaper then polishing.
12mm 6mmx / 12mmx900
600
1800 /
1073414-T01-B

-11-
2
Mequiars 28 ( )
()
Consumer Responsibilities
Cleaning Acrylic Surfaces: Do not use abrasive
cleansers on any acrylic surfaces, as they will scratch
and dull the surface. Wipe out the bath after each use
to prevent a build-up of soap and scum.
If the acrylic surface becomes dull, an automotive type
rubbing compound may be used on the unit, followed
by an application of paste wax.
We recommended:
Rubbing compound mequiars mirror glaze 28 metal
polish (import product) or "green oil".
IMPORTANT CONSUMER INFORMATION
1073414-T01-B
