Kohler ENGLEFIELD T1180-CP Installation guide

1
• Regular cleaning of spa jet fittings is recommended
to avoid the build up of soap scum, grime
and debri.
• These instructions contain important care, cleaning,
and warranty information-

GENERAL
STANDARD JET OPERATION AND MAINTENANCE
PN: V066570 - A04 Date: 7/9/10
TO DISASSEMBLE AND CLEAN JETS
• The use of abrassive cleaning products and tools
should be avoided as this can damage the jets.
JET OPERATION
Water flow from back jets and side jets can be individually
adjusted to suite your individual bathing requirements.
Simply rotate the inner ring of the jet to increase or decrease
the water flow.
Side jets also incorporate an adjustable eyeball to allow
the direction of water flow to be optimised. Simply use your
finger to adjust the eyeball direction.
Rotate to adjust flow rate
Angle eyelball to direct



Push the eyeball in using the thumb. While holding the eyeball in, gently lever the facia off,
either by hand or using an instrument that will not
damage the bath or the facia. The eyeball and washer
come off with the facia.
Pull the sleeve and spring out of the jet body.
Note the sleeve may be jammed in place by debris
and long nose pliers may be needed to remove it.
Clean out any hair or grime from inside the jet body. Clean off any hair or grime from the sleeve, spring,
eyeball , washer and facia with a clean cloth.
Slide the spring off the sleeve.

CONTACT AND WARRANTY INFORMATION
For warranty information, please visit our website.
Australia
www.englefield.com
New Zealand
www.englefield.co.nz
CALL US FOR HELP










2PN: V066570 -A04 Date: 7/9/10
SERVICABLE PARTS
TO REASSEMBLE JETS
Re-assemble the spring over the sleeve. Replace the spring and sleeve into the jet body.
Re-assemble the two halves of the eyeball and fit
into the sleeve. Ensure the front half is to the outside.  Holding the eyeball in place, gently push the fascia back into the jet body until it clicks into place.
Exploded assembly view of jet.
Jet cartridge - Wonder jet chrome - T1180-CP
Back jet cartridge - Non scalloped chrome - 1054010-CP
Back jet cartridge - Non scalloped chrome (restricted) - 1054227-CP
