Kohler ELLISTON 72782T-4 User manual

1250176-2A-A 1
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. Inspect the supply tubing for damage and leakage. Replace and maintain as necessary.
3. Observe local plumbing codes.
4. If possible, install this faucet before installing the lavatory.
5. Shut off the water supplies to the fitting.
HANDLE OPERATION
Lift handle gently. Turn clockwise for hot water, counter-clockwise for cold water.
INSTALLATION INSTRUCTIONS
72782T-4 Single Handle Lavatory Faucet72782T-4 Single Handle Lavatory Faucet
ELLISTONELLISTON
ROUGH-IN DIMENSIONS
65Min.
38Max.
The finished wall
1250176-2A-A 4
SERVICE PARTS
**Color code must be specified when ordering
105
446 191
G1/2˝
Ø58
123
68
18.5º
Ø32~Ø38
Ø36.5
Ø54
102 108
Ø31.75
1121328**
1080817
880406
880008**
880037
1260041**
1233282
1200253
77951
1205736
1212341
1258633
1198657
1271397
52202
78150
837111
1204791
1200754**
52149
1188984**
1214987
1092946
1212347**
77434
77949
1218487
1212351
1228834

1250176-2A-A 2 1250176-2A-A 3
INSTALLATION
How to Install the Spout
Install the stud(1) and washer(2) into the bottom of
faucet(3). Insert hoses(4) and stud into the hole of
lavatory. Insert the lift rod(5) into the hole at the rear
of the faucet.
From underside of the lavatory, fit the bracket(6) onto
the stud. Position the faucet. Install the washer(7) and
nut(8) onto the stud, tighten the nut by tool(9) to
secure the faucet.
Attach the hoses to water supplies, the hose with
“COLD” label connects to cold water.
Remove the retaining nut(18) and ‘V’-clip(17). Fit the
plastic washer(19) and retaining nut onto the ball
lever(20). Insert the ball lever assembly into the drain
lever hole and through the stopper hole. Tighten the
retaining nut.
Be sure that the ball lever(20) points to the back of the
lavatory, tighten the locknut(13) on the drain body by
wrench.
NOTE: Do not reposition the drain if plumbers putty
applied after the locknut is tightened, or you may
break the putty seal. Wipe away excess plumbers
putty.
How to Install the Drain
Remove stopper(15), flange(10) and washer(11) from
drain body(14). Insert drain body kit into the lavatory
from underside, and make sure the drain lever
hole(12) facing to the back of the lavatory. Screw the
flange with washer into the drain body. Tighten the
locknut(13) by hand from the underside of the fixture.
NOTE: If needed, apply a ring of plumbers putty
around the underside of the drain flange(10), instead
of using washer(11).
Place stopper(15) into drain body aligning the flat side
of stopper hole(16) with the drain lever hole.
Ensure that all coupling nuts are tight. Ensure that the
lever handle is in the off position.
Turn on the main water supply and drain, and check
for leaks. Repair as needed.
Remove the aerator(22) by key(23). Run hot and cold
water through faucet for about one minute to remove
any debris. Check for leaks. Repair as needed.
Remove any debris from the aerator. Shut off the
faucet. Reinstall the aerator.
Assemble thumb screw(21) to link(22), and link onto
ball lever(20) with ‘V’-clip(17).
Slide lift rod(5) through the hole of the link. Push the
ball lever down into the open position. Position the lift
rod. Tighten thumb screw(21).
INSTALLATION CHECKOUT
CLEANING INSTRUCTIONS
All Finishes: Clean the finish with mild soap and warm water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc, which could adversely
affect the finish and are not recommended for cleaning.
Do not use abrasive cleaners or solvents on Kohler faucets and fittings.
15
16
11
11
3
2
1
4
7
6
8
5
9
10 10
14
13
12
19
12
20
18
17
13
22
23
5
20
22
17
21
