Kohler K-1913 Assembly instructions

Homeowners Guide
Rising Wall Bath
Mproduct numbers are for Mexico (i.e. K-12345M)
Los números de productos seguidos de Mcorresponden a México
(Ej. K-12345M)
Français, page “Français-1”
Español, página “Español-1”
K-1913
1128532-5-G

Important Information
INSTRUCTIONS PERTAINING TO A RISK OF FIRE,
ELECTRICAL SHOCK, OR INJURY TO PERSONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS
WARNING: When using electrical products, basic precautions should always be followed,
including the following:
DANGER: Risk of accidental injury or drowning. To reduce the risk of injury, do not permit
children to use this unit unless they are closely supervised at all times.
WARNING: Risk of personal injury. To avoid injury, exercise care when entering or exiting the
bath.
WARNING: Risk of electric shock. Do not permit electric appliances (such as a hair dryer, lamp,
telephone, radio, or television) within 5’ (1.5 m) of this bath.
WARNING: The use of alcohol, drugs, or medication can greatly increase the risk of fatal
hyperthermia. Prolonged immersion in hot water may induce hyperthermia. Hyperthermia occurs
when the internal temperature of the body reaches a level several degrees above the normal body
temperature of 98.6°F (37°C). The symptoms of hyperthermia include an increase in the internal
temperature of the body, dizziness, lethargy, drowsiness, and fainting. The effects of hyperthermia
include: (a) failure to perceive heat, (b) failure to recognize the need to exit the bath, (c)
unawareness of impending hazard, (d) fetal damage in pregnant women, (e) physical inability to
exit the bath, and (f) unconsciousness resulting in the danger of drowning.
WARNING: Risk of fetal injury. Pregnant or possibly pregnant women should consult a physician
before using the bath.
WARNING: Risk of hyperthermia or drowning. Do not use the bath immediately following
strenuous exercise.
WARNING: Risk of hyperthermia or drowning. Water temperature in excess of 100°F (38°C) may
cause injury. Test and adjust the water temperature before use.
WARNING: Risk of personal injury. Never drop or insert any object into any opening.
Use this bath only for its intended purpose as described in this manual. Do not use attachments not
recommended by the manufacturer.
The bath must be connected only to a supply circuit that is protected by a Ground-Fault Circuit-Interrupter
(GFCI)*. Such a GFCI should be provided by the installer and should be tested on a routine basis. To test the
GFCI, press the test button. The GFCI should interrupt power. Press the reset button. Power should be
restored. If the GFCI fails to operate in this manner, the GFCI is defective. If the GFCI interrupts power to
the bath without the test button being pressed, a ground current is flowing, indicating the possibility of an
electric shock. Do not use this bath. Disconnect the bath and have the problem corrected by a qualified
service representative before using.
Your new Kohler bath has been listed by Underwriter’s Laboratories, thus ensuring safety for you and your
family. Your new bath also conforms to rigid ANSI and IAPMO standards set within the plumbing industry.
* Outside North America, this device may be known as a Residual Current Device (RCD).
1128532-5-G 2 Kohler Co.

Bath Features
Door Switch - Used to open the side wall drain. Push the door switch once and the water will
automatically begin to drain after bathing. For faster water removal the toe tap must also be
manually opened. Pushing the switch a second time closes the drain.
Controller - Provides power to the door assembly, switches, level sensors and drain valve.
Handle - Squeeze the handle to lower the door after the seal has fully deflated.
Door - Raise and lower to permit easy movement in and out of the bath. The door also contains an
inflatable seal and electronics to make the bath watertight when the door is raised.
Access Panel - Removable panel that allows access to serviceable components from the front of the
bath.
Receptor Tray - The drip tray collects water from the accumulator drain line and excess water that
escapes over the top of the seal in the door, removing the water through a dedicated drain.
Drain Valve - The drain valve is connected to the side wall drain and is designed to quickly empty
the water from the bath. The bath can be emptied in approximately 2 minutes or less when used
along with the toe tap drain.
Grab Bar - The grab bar is a handhold to assist the bather when entering and exiting the bath.
Toe Tap Drain - Secondary drain that is manually controlled. When used at the same time as the
drain valve, the bath can be emptied in approximately 2 minutes or less.
Overflow - Helps prevent bath from overfilling.
Footwell - Used to temper the water before entering the bath or washing feet with the door
lowered.
Overflow
Grab Bar
Door Switch
Drain Valve
Access Panel
Footwell
Toe Tap Drain
Level Sensors
Controller
Side Wall Drain
Handle
Limit Switch (2)
Accumulator Door (with Seal)
Model and Serial Number Label
Receptor Tray and Drain
Heated Surface (If Equipped)
Kohler Co. 3 1128532-5-G

Bath Features (cont.)
Accumulator - A small tank located on the back of the bath that produces the sheet flow action
observed while the bath is filling. A small drain line empties the tank to the receptor after every use.
Level Sensors - The sensors monitor the water level in the bath. When the water level is above the
sensors, the door seal will not deflate and the door will not lower.
Heated Surface (if equipped) - Warms your back and neck with adjustable heat.
1128532-5-G 4 Kohler Co.

Operating Your Bath
Using the Bath
NOTE: A removable label is included with the literature packet. It should be applied over the door switch
as a reminder on how to operate the bath.
With the door lowered, turn on the water and adjust it to the desired temperature. The water will
run into the footwell and exit through the sidewall drain and toe tap drain (if open) until the door
is closed.
Enter the bath and close the toe tap drain located in the footwell.
Lightly grasp the handle recess and raise it until the latches on each side of the door engage. The
drain valve will close and the seal will begin inflating.
IMPORTANT! If water does not cover the level sensors within 2 minutes, the drain valve will open
automatically.
Immediately add water to the bath until it is above the level sensors.
Fill the bath until the water is just below the overflow drain.
Exiting the Bath
Push the door switch and open the toe tap drain. The water will drain from the bath in
approximately 2 minutes.
When the water level is below the level sensors, the door seals will automatically deflate. Periodic
cleaning of the sensors will improve response time.
To lower the door, grasp the handle and squeeze while lightly pushing down.
If the bath does not function properly, please refer to the ″Troubleshooting″section.
Toe Tap Drain
Door Switch
Handle Footwell
Sidewall Drain
Level Sensors
Label 1 - To Drain
Press button once
and
press floor drain
2 - To Exit
When drained,
lift latch on outside
of rising wall
Kohler Co. 5 1128532-5-G

Operating Your Bath (cont.)
NOTE: In the event of a power outage, your bath will not function. The door will not lower until power
is restored. Assistance may be required to exit the bath. To avoid this possibility, consider installing an
Uninterruptible Power Supply (UPS) as described in the installation guide.
1128532-5-G 6 Kohler Co.

Operating the Heated Surface (if equipped)
Keypad Operation
Power Icon - Turns the heater ON and OFF.
Heat/Temperature Indicator - The [Flame] icon illuminates yellow, orange, or red depending on the
heat level. Yellow indicates low heat, orange indicates medium heat, and red indicates high heat.
Up Arrow - Increases the temperature.
Down Arrow - Decreases the temperature.
NOTICE: The heater will remain on until it is manually turned OFF by pressing the [Power] icon.
NOTE: After 60 minutes of inactivity, the heater will automatically reset to low heat if the temperature
was set to medium or high.
NOTE: The heater will turn on at the last selected temperature setting.
Error Codes
Heat indicator blinking red - The heater is not functioning.
Heat indicator blinking yellow - The temperature sensor is not functioning or is loose.
Refer to the ″Troubleshooting″section to troubleshoot any problems.
Confirm Heating System Operation
Press the [Power] icon on the user keypad.
Observe that the heat indicator turns yellow and the heater produces low heat.
Press the [Up] arrow. Verify that the heat indicator turns orange and the temperature increases.
Press the [Up] arrow a second time. Verify that the heat indicator turns red and the temperature
increases.
Press the [Down] arrow. Verify that the heat indicator turns orange and the temperature decreases.
Press the [Down] arrow a second time. Verify that the heat indicator turns yellow and the
temperature decreases.
Press the [Power] icon to turn the heater OFF.
Increase Temperature
Decrease TemperaturePower On/Off
Heat/Temperature Indicator
Kohler Co. 7 1128532-5-G

Maintenance
For best results, perform the following maintenance steps periodically.
•Use a can of compressed air to clean off the seal surface.
•Apply a drop or two of oil to the lower face of the striker plate mounted on either side of the bath.
This is the surface that the latch pins strike when the door is raised. Light oiling will help improve
performance.
•Occasionally wipe off the level probes to keep them clean. This will help improve the system
response time as the water drains from the bath.
•For commercial applications, Kohler Co. recommends periodic maintenance of the door seal by a
Kohler Co. Authorized Service Representative (ASR) or a qualified installer every 3 to 4 years or if
any of the symptoms in the ″Troubleshooting″section occur.
Care and Cleaning
For best results, keep the following in mind when caring for your KOHLER product:
•Always test your cleaning solution on an inconspicuous area before applying to the entire surface.
•Wipe surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and
dry any overspray that lands on nearby surfaces.
•Do not allow cleaners to soak on surfaces.
•Use a soft, dampened sponge or cloth. Never use an abrasive material such as a brush or scouring
pad to clean surfaces.
For detailed cleaning information and products to consider, visit www.kohler.com/clean. To order Care &
Cleaning information, call 1-800-456-4537.
Warranty
Ten Year Limited Warranty for the Bath Component
Lifetime Limited Warranty for the Inflatable Door Seal Component
One-Year Limited Warranty on all other components
Kohler Co. warrants the bath component of the Elevance Wall Bath manufactured after September 1, 2010, to
be free of defects in material and workmanship during normal residential use for ten years from the date of
installation. Kohler Co. warrants the inflatable door seal component to be free from defects in material and
workmanship during normal residential use for as long as the original consumer owns his or her home,
provided the Elevance Wall Bath is installed by a qualified installer. Kohler Co. warrants all other
components to be free from defects in material and workmanship for one-year from the date of installation.
These warranties only apply to Elevance Wall Baths installed in the United States of America, Canada and
Mexico (North America).
If the Elevance Wall Bath is used commercially or is installed outside of North America, Kohler Co. warrants
that for one (1) year from the date the Elevance Wall Bath is installed the bath and inflatable door seal
components and all other components to be free from defects in material and workmanship. All other terms
of this warranty apply except for duration.
If a defect is found in normal residential use, Kohler Co. will, at its election, repair, replace or make
appropriate adjustment where Kohler Co. inspection discloses any such defects. Damage caused by accident,
improper installation, misuse or abuse is not covered by this warranty. This warranty expressly excludes
labor charges, removal charges, installation, or other incidental or consequential costs. Improper care and
cleaning will void the warranty. In no event shall the liability of Kohler Co. exceed the purchase price of the
product. If the warranty claim is for the inflatable door seal component, proof of purchase by the original
consumer purchaser is required.
If you believe that you have a warranty claim, contact your Dealer, Plumbing Contractor, Home Center or
E-tailer, or by writing Kohler Co., Attn: Customer Care Center, 444 Highland Drive, Kohler, WI 53044, USA.
Please be sure to provide all pertinent information regarding your claim, including a complete description of
the problem, the product, model number, color, the date the product was purchased, from whom the product
was purchased and the name and address of the qualified installer. Also include your original receipt. For
1128532-5-G 8 Kohler Co.

Warranty (cont.)
other information or to obtain the name and address of the service and repair facility nearest you or to
contact a qualified installer, call 1-800-4KOHLER (1-800-456-4537) from within the USA and Canada and
001-800-456-4537 from within Mexico.
KOHLER CO. AND/OR SELLER ARE PROVIDING THESE WARRANTIES IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. KOHLER CO.
AND/OR SELLER DISCLAIM ANY LIABILITY FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES. Some states/provinces do not allow limitations on how long an implied warranty lasts, or the
exclusion or limitation of special, incidental or consequential damages, so these limitations and exclusions
may not apply to you. This warranty gives you specific legal rights. You may also have other rights which
vary from state/province to state/province.
This is Kohler Co.’s exclusive written warranty.
Troubleshooting
NOTICE: This section is for general aid only. A Kohler Co. Authorized Service Representative or qualified
electrician should correct any electrical problems. For warranty service, call 1-800-4KOHLER from within
the USA and Canada, or 001-800-456-4537 from within Mexico.
NOTE: For service parts information, visit your product page at www.kohler.com/serviceparts.
Normal Operation Includes:
While filling the bath with water, some water is routed to the drip tray and drain through
the accumulator drain hose. It is normal to see or hear a trickle of water either during or
immediately after filling. The accumulator is draining into the drip tray.
It is normal to hear the compressor run for up to 90 seconds after the door is raised. The
compressor is located inside the door and is inflating the door seal.
If the door is fully raised for more than 20 minutes when there is no water in the bath,
the seals will automatically deflate.
It is normal to hear the solenoid valve, located inside the door, open and expel air when
the water level falls below the sensors. The valve is deflating the door seal.
Water coming from the bottom of the door and entering the drip tray is normal when it is
caused by the bather moving about in the bath when it is completely full. Excessive
splashing will cause water to run over the top of the inflated seals into the drip tray.
Water dripping into the drip tray as the seals deflate is normal. Water collects on the seal
during use and runs into the drip tray when the seals deflate.
Troubleshooting the Bath System
Symptoms Probable Causes Recommended Action
1. Door is difficult to raise or
lower. A. One or both counterweights are not attached. A. Reattach the counterweight(s).
B. One or both of the
counterweight cables are not fed
through the pulleys.
B. Use the provided tool to run the
counterweight cable onto the
pulleys.
Kohler Co. 9 1128532-5-G

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
C. The bath was not leveled
properly, causing
counterweights to rub or
generate a noise.
C1. Level the bath.
C2. Confirm the counterweights do not
contact the receptor when the door
is up. If there is contact the
receptor drain is not low enough in
the subfloor. Enlarge the drain
cutout and lower the receptor or
raise the bath using the adjustable
feet.
D. Mounting bracket is not
adjusted properly. D. Reduce the pressure on the door by adjusting the mounting brackets
outward using the slots.
E. Door is rubbing against the bath
or access panel. E1. Adjust the door outward using the slots in the pulley assembly.
E2. Adjust the lower access panel
bracket rearward using the slots.
E3. Adjust the brush seal under the
door forward using the slots.
F. A roller is damaged or has
fallen off. F. Replace the roller.
G. There is excessive wear on the
latch pin and/or strike plate. G1. Apply a drop or two of oil to the face of the strike plate.
G2. Adjust the rubber bumper to center
the latch pin in the strike plate
opening when the door is raised.
2. Door shimmies or shakes. A. Mounting bracket needs
adjustment. A. Adjust one or both of the mounting brackets inward using the slots,
until it is snug against the rollers.
3. Water is leaking/running
from accumulator. A. Normal operation. The accumulator is draining into the
receptor.
A. See the ″Normal Operation
Includes″portion of the
″Troubleshooting.″
B. Water supply connection is
loose or damaged. B. Reseal the water inlet connections and/or reconnect them.
C. Accumulator fitting(s) are loose
or disconnected. C. Replace the accumulator connection fitting(s).
D. Accumulator drain hose is
disconnected or leaks. D. Reconnect or tighten the accumulator drain line connection
and route it to the receptor drain.
4. Bath will not fill all the
way to overflow. A. The water supply connection is loose or damaged. A. Reseal the water inlet connections and reconnect them.
B. Toe tap drain does not close or
is leaking. B. Clean the toe tap assembly. Reseal and reattach the drain. Replace if
needed.
C. No power to the bath controller. C. Plug in both ends of the controller
power cord or reset the breaker.
1128532-5-G 10 Kohler Co.

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
D. Error code in controller has
been activated (beeping sound
heard).
D1. Reset the controller. To do this;
lower the door
quickly tap the door switch 5
times
wait 3 seconds, then tap the
switch 11 times within a 5
second span
the controller should beep 3 to
5 times to indicate the issue
has been resolved, then go
quiet.
D2. If the error code is still activated or
reoccurs, unplug the power and
call the Customer Care Center
using the information provided on
the back page of this manual.
E. Drain valve is not plugged into
the controller (no power). E. Plug the drain valve directly into the controller located under the
bath.
F. One or both of the limit
switches are not making contact
or are damaged.
NOTE: Never force the door
downward with the seal
inflated.
F1. Adjust the limit switch/switches
until contact is made.
F2. The limit switch/switches need to
be replaced. Call the Customer
Care Center using the information
provided on the back page of this
manual.
F3. Ensure the counterweights do not
contact the receptor when the door
is up. If there is contact the
receptor drain is too high. Enlarge
the receptor drain relief or raise the
bath using the adjustable feet to
eliminate the contact..
G. Bath fill is too slow, or the drain
valve and/or level probe
circuit(s) are not working.
G1. Make sure the water level reaches
the sensor probe within 2 minutes
after closing the door. Increase the
supply valve size and water flow.
G2. Check or replace the level probes
and wiring to the controller.
G3. Replace the drain valve.
H. There is a loose wire connection
to the bath controller outside
the door.
H. Check all wire connections to the
controller.
I. The internal wire connections in
the door are loose. I. Call the Customer Care Center using the information on the back
page of this manual.
J. The primary or secondary seal
is leaking air. J. Check the inflated seal for air leaks using soapy water. Replace if
needed.
K. There is an air leak inside the
door. K. Call the Customer Care Center using the information provided on
the back page of this manual.
Kohler Co. 11 1128532-5-G

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
L. The compressor is not working. L. Replace the compressor. Call the
Customer Care Center using the
information provided on the back
page of this manual.
M. The air pressure switch is not
working. M. The air pressure switch needs to be replaced. Call Customer Care
Center using the information
provided on the back page of this
manual.
N. One or more of the solenoid
valves are not working or is
venting (open).
N. The solenoid valve needs to be
replaced. Call Customer Care
Center using the information
provided on the back page of this
manual.
O. The controller is not working. O. Replace the controller or call the
Customer Care Center using the
information provided on the back
page of this manual.
5. Water is leaking into
receptor tray. A. It is normal for water to leak into the receptor tray from the
accumulator drain hose, when
water splashes over the top of
the door seals, or from the
bottom of the door when the
seal deflates. This water is
captured by the receptor tray.
A. No action needed if water enters
receptor tray through normal
operation. Ensure the drain line
from the accumulator routes to the
receptor drain.
B. Water is splashing over the top
of the seal. B. Do not fill the bath as high or reduce any sudden movements
while bathing.
C. There is debris between the
door and the seal. C. Clean all debris off the seal using a can of compressed air.
D. The door gap is too large
because the pulley assembly is
not properly adjusted.
D. Adjust the pulley assembly inward
using the slots.
6. Controller is making a
high pitched squeal or
beeping sound.
A. Error code in controller has
been activated (beeping sound
heard).
A1. Reset the controller. To do this;
lower the door
quickly tap the door switch 5
times
wait 3 seconds, then tap the
switch 11 times within a 5
second span
the controller should beep 3 to
5 times to indicate the issue
has been resolved, then go
quiet.
A2. If the error code is still activated or
reoccurs another problem exists.
Unplug the power and call the
Customer Care Center using the
information provided on the back
page of this manual.
7. The door will not lower
and the latch pins will not
retract.
A. The mounting bracket is not
adjusted properly. A. Adjust the mounting brackets inward using the slots until the
latch pins reliably contact both the
limit switches.
1128532-5-G 12 Kohler Co.

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
B. Bumpers in strike plate need
adjustment. B. Adjust the bumpers as needed.
C. The handle latch mechanism in
the door is not working. C. Call the Customer Care Center using the information provided on
the back page of this manual.
D. There is excessive wear on the
latch pin and/or strike plate. D. Apply a small amount of oil to the face of the strike plate, replace the
strike plate, or call the Customer
Care Center using the information
provided on the back page of this
manual.
E. A roller has been damaged or
has fallen off. E. Replace the roller(s).
8. The seal will not deflate
when the water level is
below the sensor probes
(door cannot be lowered).
A. Level probes are dirty. A. Clean off both level probes.
B. The door switch has not been
pressed. B. Press the door switch to initiate deflation.
C. One or both limit switches are
not making contact or are
damaged.
C. Confirm the counterweights do not
contact the receptor when the door
is up. If there is contact the
receptor drain is not low enough in
the subfloor. Enlarge the drain
cutout and lower the receptor or
raise the bath using the adjustable
feet.
D. The internal wire connections in
the door are loose. D. Call the Customer Care Center using the information provided on
the back page of this manual.
E. The controller is not working. E. Replace the controllers or call the
Customer Care Center using the
information provided on the back
page of this manual.
F. The pressure switch or solenoid
vent valves inside the door are
not working.
F. Call the Customer Care Center
using the information provided on
the back page of this manual.
G. Error code in the controller has
been activated (beeping sound
is heard).
G1. Reset the controller. To do this;
lower the door
quickly tap the door switch 5
times
wait 3 seconds, then tap the
switch 11 times within a 5
second span
the controller should beep 3 to
5 times to indicate the issue
has been resolved, then go
quiet.
G2. If the error code is still activated or
reoccurs, unplug the power and
call the Customer Care Center
using the information provided on
the back page of this manual.
Kohler Co. 13 1128532-5-G

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
9. The bath will not drain or
drains slowly after
pressing the switch.
A. Tap toe drain will not open. A. Close and/or clean the toe tap
assembly. Reseal and reattach the
drain. Replace if needed.
B. The door switch is not being
pressed correctly. B. Press the center of the door switch button once lightly.
C. One or both drains are blocked. C. Remove the blockage.
D. The drain valve is connected to
another 120 V outlet and/or is
not plugged into the controller.
D. Plug the drain valve directly into J2
in the controller.
E. The drain valve is not working. E. Replace the drain valve or call the
Customer Care Center using the
information provided on the back
page of this manual.
F. Error code in controller has
been activated (beeping sound
heard).
F1. Reset the controller. To do this;
lower the door
quickly tap the door switch 5
times
wait 3 seconds, then tap the
switch 11 times within a 5
second span
the controller should beep 3 to
5 times to indicate the issue
has been resolved, then go
quiet.
F2. If the error code is still activated or
reoccurs, unplug the power and
call the Customer Care Center
using the information provided on
the back page of this manual.
G. There is a loose wire connection
in the door. G. Call the Customer Care Center using the information provided on
the back page of this manual.
H. Door switch is not working. H. The door switch needs to be
replaced. Call the Customer Care
Center using the information
provided on the back page of this
manual.
I. The controller is not working. I. Replace the controller or call the
Customer Care Center using the
information provided on the back
page of this manual.
10. Bath water empties
prematurely. A. Toe tap drain is open and does not close or is leaking. A. Close and/or clean the toe tap assembly. Reseal and reattach the
drain. Replace if needed.
B. Level sensor wires are too close
together, resulting in
interference.
B. Separate the level probe wires at
both ends.
C. One or both of the level sensors
are not properly connected. C. Firmly connect the level sensor wires to the controller.
1128532-5-G 14 Kohler Co.

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
D. One or both of the limit
switches are not making contact
or are damaged.
D1. Adjust the limit switch/switches
until contact is made.
D2. The limit switch/switches need to
be replaced. Call the Customer
Care Center using the information
provided on the back page of this
manual.
E. The drain valve is connected to
another 120 V outlet and/or is
not plugged into the controller.
E. Plug the drain valve directly into J2
in the controller.
F. Error code in controller has
been activated (beeping sound
heard).
F1. Reset the controller. To do this;
lower the door
quickly tap the door switch 5
times
wait 3 seconds, then tap the
switch 11 times within a 5
second span
the controller should beep 3 to
5 times to indicate the issue
has been resolved, then go
quiet.
F2. If the error code is still activated or
reoccurs, unplug the power and
call the Customer Care Center
using the information provided on
the back page of this manual.
G. The drain valve is not working. G. Replace the drain valve or call the
Customer Care Center using the
information provided on the back
page of this manual.
H. The controller is not working. H. Replace the controller or call
Customer Care Center using the
information provided on the back
page of this manual.
11. The seal will not fully
inflate or the compressor
keeps turning on after
inflation.
A. One or both limit switches are
not making contact or are
damaged.
A1. Adjust the limit switch or switches
until contact is made.
A2. The limit switch needs to be
replaced. Call the Customer Care
Center using the information
provided on the back page of this
manual.
B. The primary seal system is not
operating properly or the air
line might be pinched.
B. Call the Customer Care Center
using the information provided on
the back page of this manual.
C. There is air leaking inside the
door. C. Call the Customer Care Center using the information provided on
the back page of this manual.
D. The air pressure switch is not
working or is leaking air. D. The air pressure switch needs to be replaced. Call the Customer Care
Center using the information
provided on the back page of this
manual.
Kohler Co. 15 1128532-5-G

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
E. One or more of the solenoid
valves is leaking air. E. The solenoid valve needs to be replaced. Call the Customer Care
Center using the information
provided on the back page of this
manual.
12. Noisy operation. A. After filling the bath, water
drains from the accumulator
into the drip tray drain. This
will create noise.
A. See the ″Normal Operation
Includes″portion of
″Troubleshooting.″
B. The bath is not leveled properly
and counterweights are making
contact.
B. Check the back ledge and the sides
of the bath for level. Adjust the feet
until the bath is level if needed.
Check counterweight clearance.
C. The counterweight
guide/guides are not in place. C. Reinstall the counterweight guides in the correct position.
D. The compressor is making
excessive noise. D. Call the Customer Care Center using the information provided on
the back page of this manual.
13. Discoloration is observed
on the front of the bath. A. Water is splashing over the top of the seal. A. Lower the water level when filling the bath. Periodic cleaning of the
bath face is normal where the seal
makes contact.
B. Door panel is rubbing against
the bath or access panel. B1. Adjust the lower slotted mounting bracket (for the access panel
mount) back and, if needed, adjust
the brush seal under the door until
it barely makes contact with the
access panel.
B2. Adjust the door outward using the
slots in the pulley assembly.
14. Water is seen or heard
during or after filling the
bath.
A. During normal operation, it is
normal for water to discharge
from the accumulator drain hose
or for small amounts of water to
spill over the seals and run
down to the drip tray.
A. See the ″Normal Operation
Includes″portion of
″Troubleshooting.″
B. Accumulator attachment is
damaged or leaks. B. Reconnect or tighten the accumulator drain line connection.
C. Water is splashing over the top
of the seal. C. Lower the water level when filling the bath. Reduce sudden
movements while bathing.
D. The door gap is too big because
the pulley assembly is not
properly adjusted.
D. Adjust the pulley assembly inward.
15. The bath will fill to the
overflow, but fails to
maintain its water level.
A. Toe tap drain is open, does not
close, or is leaking. A. Close and/or clean the toe tap assembly. Reseal and reattach the
drain. Replace if needed.
B. There is no power to the
controller. B. Plug in both ends of the controller power cord or reset the breaker.
C. One or both of the limit
switches are not making contact
or are damaged.
C1. Adjust the limit switch/switches
until contact is made.
C2. The limit switch/switches need to
be replaced. Call the Customer
Care Center using the information
provided on the back page of this
manual.
1128532-5-G 16 Kohler Co.

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
D. Water is splashing over the top
of the seal. D. Lower the water level when filling the bath. Reduce sudden
movements when bathing.
E. There is debris between the
door and seal. E. Clean all debris off the seal using a can of compressed air.
F. The drain valve is not working. F. The drain valve needs to be
replaced. Replace the drain valve or
call the Customer Care Center
using the information provided on
the back page of this manual.
G. The controller is not working. G. Replace the controller or call the
Customer Care Center using the
information provided on the back
page of this manual.
16. The seal will not inflate. A. There is no power to the
controller or bath. A1. Connect the controller to the power supply.
A2. Reset the circuit breaker.
A3. Connect the bath power cord to the
J1 port on the controller.
B. Error code in controller has
been activated (beeping sound
heard).
B1. Reset the controller. To do this;
lower the door
quickly tap the door switch 5
times
wait 3 seconds, then tap the
switch 11 times within a 5
second span
the controller should beep 3 to
5 times to indicate the issue
has been resolved, then go
quiet.
B2. If the error code is still activated or
reoccurs, unplug the power and
call the Customer Care Center
using the information provided on
the back page of this manual.
C. The door power wiring
connection to the controller is
loose.
C. Connect the door power wire to the
J6 port in the controller.
D. The drain valve is connected to
another 120 V outlet or is not
plugged into the controller.
D. Plug the drain valve directly into J2
in the controller.
E. One or both of the limit
switches are not making contact
or are damaged.
E1. Adjust the limit switch/switches
until contact is made.
E2. The limit switch/switches need to
be replaced. Call the Customer
Care Center using the information
provided on the back page of this
manual.
F. The level sensor circuit is not
detecting water within 2
minutes of raising the door.
F. Check the level probes and wires
for proper connection to the
controller.
G. The drain valve is not working. G. Replace the drain valve or call the
Customer Care Center using the
information provided on the back
page of this manual.
Kohler Co. 17 1128532-5-G

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
H. The wire connections are loose. H1. Check the power cord from the
outlet to the controller.
H2. Check the drain valve power cord
to the controller.
H3. Check the level probe wiring to the
controller.
H4. Check the limit switch wiring to
the controller.
H5. Check the door power cord to the
controller.
I. The internal wire connections
inside the door are loose. I. Call the Customer Care Center using the information provided on
the back page of this manual.
J. The primary seal system is not
operating properly or the air
line may be pinched.
J. Call the Customer Care Center
using the information provided on
the back page of this manual.
K. The secondary seal systems are
not operating properly or the air
line may be pinched.
K. Call the Customer Care Center
using the information provided on
the back page of this manual.
L. There is an air leak inside the
door. L. Call the Customer Care Center using the information provided on
the back page of this manual.
M. The compressor is not working. M. The compressor needs to be
replaced. Call the Customer Care
Center using the information
provided on the back page of this
manual.
N. The pressure switch inside the
door is not working or is
leaking air.
N. Call the Customer Care Center
using the information provided on
the back page of this manual.
O. The controller is not working. O. The controller needs to be replaced.
Call the Customer Care Center
using the information provided on
the back page of this manual.
17. Water splashes off the
drip tray onto the floor. A. The brush seal is not installed or is not adjusted correctly. A. Install or adjust the brush seal.
B. The bath is not leveled properly. B. Check the back ledge and the sides
of the bath for level. Adjust the feet
until the bath is level if needed.
C. The door gap is too big because
the pulley assembly is not
properly adjusted.
C. Adjust the pulley assembly inward.
D. Water is splashing over the top
of the seal. D. Lower the water level when filling the bath. Reduce sudden
movements when bathing.
18. Door will not stay in the
raised position. A. One or both counterweights are not attached. A. Attach the counterweight(s).
B. Door bumper needs adjustment. B. Adjust the door bumper as needed.
C. The mounting bracket is not
adjusted properly. C. Adjust the mounting brackets inward using the slots.
1128532-5-G 18 Kohler Co.

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
D. There is excessive wear on latch
pin and/or strike plate. D. Apply a small amount of oil to the face of the strike plate, replace the
strike plate, or call the Customer
Care Center using the information
provided on the back page of this
manual.
E. The handle/latch mechanism
inside the door is not working. E. Call the Customer Care Center using the information provided on
the back page of this manual.
19. Seal will not remain
inflated. A. There is a loose wire connection under the door. A. Check the 10-pin wire connection located behind the plate on the
bottom of the door, opposite the
drain end.
B. Error code on the controller is
activated. B. Reset the controller.
lower the door
quickly tap the door switch 5
times
wait 3 seconds, then tap the
switch 11 times within a 5
second span
the controller should beep 3 to
5 times to indicate the issue
has been resolved, then go
quiet.
C. Primary seal may be leaking. C. Call the Customer Care Center
using the information provided on
the back page of this manual.
D. Air line inside the door may be
pinched. D. Call the Customer Care Center using the information provided on
the back page of this manual.
E. There is an air leak inside the
door. E. Call the Customer Care Center using the information provided on
the back page of this manual.
F. One or more of the solenoid
valves is leaking air. F. Call the Customer Care Center using the information provided on
the back page of this manual.
Troubleshooting the Heated Surface (if equipped)
Symptoms Probable Causes Recommended Action
1. Heated bath does not turn
on. A. No power to power supply. A. Set/reset GFCI or RCD breaker; check wiring.
B. User keypad cable loose or
damaged. B. Check wire connections. If necessary, replace user keypad
cable.
C. User keypad does not work. C. Check wire connections. Replace
user keypad.
D. Power supply does not work. D. Replace power supply.
2. Bath is turned on, but
there is little or no heat. A. Heater cable loose or damaged. A. Check wire connections. If necessary, replace heater cable.
B. Heater/insulation loose on the
bath. B. Secure the heater/insulation to the bath.
C. Heat indicator is yellow or
orange. C. Press the [Up] arrow to increase temperature.
Kohler Co. 19 1128532-5-G

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
D. Heater does not work. D. Replace the heater.
E. Temperature sensor does not
work. E. Replace the heater.
3. Temperature does not
automatically reset to low
after 1 hour.
A. Temperature sensor does not
work. A. Replace the heater and/or keypad.
4. Heat indicator is blinking
red. A. Heating system needs to be reset. A. Press the [Power] icon to turn the power OFF. Wait 10 seconds, then
turn the power ON.
B. Heater does not work. B. Replace the heater.
5. Heat indicator is blinking
yellow. A. Heating system needs to be reset. A. Press the [Power] icon to turn the power OFF. Wait 10 seconds, then
turn the power ON.
B. Temperature sensor does not
work. B. Replace the heater.
1128532-5-G 20 Kohler Co.
