BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co.
reserves the right to make changes in product characteristics, packaging, or availability at any time without
notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes throughly to remove debris.
2. An in line water filter must be used with this product.
3. Inspect the supply pipes for damage and leakage. Replace and maintain as necessary
4. Observe local plumbing codes.
5. If possible, install this faucet before installing the sink.
6. Recommended working pressure: 1 to 5 bar. If it exceeds 5 bar, a pressure reducer is needed. The highest
water and environment temperature is 60ºC.
7. All installations should comply with the relevant requirements of AS/NZS 3500 and AS/NZS 6400.
6332A-4 KITCHEN MIXER WITH PULLOUT SPRAY
INSTALLATION INSTRUCTIONS
Kitchen Mixer With Pullout Spray
ROUGH-IN DIMENSIONS
1117849-AN2-A 1
VOKE
ROUGH-IN DIMENSIONS
Lift the handle gently. Turn backwards for hot water, turn frontwards for cold water.
KOHLER
Min Ø35
203
214
249
265
157.7Max 63.5
82
G1/2˝

1117849-AN2-A 2
How To Install The Faucet
Remove the parts from the faucet body(2) and retain them according
to the following order: the threaded ring(5) with two screws(4), the
metal washer(7) and the washer(6).
Retain and slide the o-ring(1) into the groove of the body. Insert the
body kit with the hoses into the mounting hole of sink untill they
contact the deck.
Screw two screws into the threaded ring. From underside of the sink,
install the washer, the metal washer and threaded ring with two
screws onto the shank(3). Adjust the position of the faucet so that the
hose(8) is toward the front and two hoses(9) are symmetrical. Tighten
two screws to secure faucet to sink.
Attach the hoses to water supplies. The hose with blue round is for
cold water, the hose with red round is for hot water.
Slide the weight(10) onto the hose assembly(11). Adjust weight so
that the distance is right from the bottom of the faucet to the weight.
Insert the hose assembly into the hose.
INSTALLATION
INSTALLATION CHECKOUT
**Color code must be specified when ordering
SERVICE PARTS
1117849-AN2-A 3
CLEANING INSTRUCTIONS
All Finishes: Clean the finish with mild soap and warm water. Wipe entire surface completely dry with clean
soft cloth. Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc, which could
adversely affect the finish and are not recommended for cleaning.
Do not use abrasive cleaners or solvents on Kohler faucets and fittings.
How To Use Spray
Open the handle, if you want to use the spray by hand, take the spray
and pull out the hose.
Press the button (A) as shown for the water close. Press the button
(B), (C) as shown for two different forms of water flow, as figure (a),
(b) shown.
NOTE: Please pull it gently and do not draw out the spray hose too
long, or you may damage the hose and connector.
Ensure that all coupling nuts are tight. Ensure that the lever handle is
in the off position. Turn on the main water supply and drain, and
check for leaks. Repair as needed.
Remove the aerator(13) and the spray (12). Run hot and cold water
for about a minute to remove any debris. Remove any debris from the
aerator and the filter washer of the spray. Shut off the faucet.
Reinstall the aerator and the spray.
6332A-4 KITCHEN MIXER WITH PULLOUT SPRAY
Kitchen Mixer With Pullout Spray
VOKE
A
C
B
b
a
12
13
1066015
Bearing
1066106
Shank
84100
O-Ring
1128531
Washer
1069533
Threaded Ring
58946
Screw
1117847**
Handle
76713
Screw
1068078
Valve
1063135**
Bonnet
1019863**
Nut
1101631
Sleeve
1046153
Weight
1130408**
Hose Assembly
1066327
Hose
1069534
Hose Guide
1054593
Hose
1074398**
Spary
22352
Washer
1092184
Threaded Ring
1048084
Seal
1054973
Spacer 55925
O-ring
1032012**
Plug Button
Assembly
1071377
Insert
2
3
1
4
11
10
9
6
7
5
8
835696
Washer
1152594
Check Valve
865257
Nut
