Thank You For Choosing Kohler Company
Thank you for choosing the Bold Look of Kohler. Kohler craftsmanship
offers you a rare combination of proven performance and graceful
sophistication that will satisfy you for years to come. The
dependability and beauty of your Kohler faucet will surpass your
highest expectations. We’re very proud of our products here at Kohler
and we know you will be too.
Please take a few minutes to study this Homeowners Guide. Pay
special attention to the Care and Cleaning instructions.
All information in this manual is based upon the latest product
information available at the time of publication. At Kohler, we
constantly strive to improve the quality of our products. We reserve
the right to make changes in product characteristics, packaging or
availability at any time without notice.
Your Kohler Lavatory Faucet
Your new lavatory faucet blends elegant styling and beauty with
exceptional performance and reliability. Each faucet is precision
engineered and constructed of premium quality materials to provide
trouble-free operation even under the hardest water conditions.
Care and Cleaning
Like anything of lasting quality, Kohler faucets and fittings require a
certain amount of periodic care to preserve their lustrous finish. Clean
your new Kohler faucet and fittings with a mild soap, rinse thoroughly
with warm water and dry with a clean, soft cloth. The ideal cleaning
technique is to always blot dry any water from metal surfaces.
Allowing water to evaporate on metal will form water deposits. It is
important to use a dabbing action to dry metal, not an abrasive or
rubbing action.
Never use cleaners containing abrasive cleansers, ammonia, bleach,
acids, or chemicals that can damage the finish. By taking the time to
dry your faucet often, soap and water deposits can be prevented.
If your chrome or Vibrant
®
color/finish faucet gets excessively dirty,
consider using the following cleaners: Windex
®
Original, Fantastik
®
All Purpose, Spic and Span Pine Liquid, or Mr. Clean
®
Springtime
Fresh Scent. For solid color faucets and fittings, consider using these
cleaners: Fantastik
®
All Purpose, Spic and Span Pine Liquid, or Mr.
Clean
®
Springtime Fresh Scent.
Failure to comply with these cleaning instructions may void Kohler’s
warranty obligations.
116440-5-A 2 Kohler Co.

Service Parts
1000438**
Handle
1000439**
Handle
1000441**
Handle
1000442**
Handle
52622**
Button Cap
52622**
Button Cap
52622**
Button Cap
52622**
Button Cap
52623-H
52623-C (Red) (Blue)
Button Cap
52623-H
52623-C (Red) (Blue)
Button Cap
52623-H
52623-C (Red) (Blue)
Button Cap
52623-H
52623-C (Red) (Blue)
Button Cap
75849
Screw
75849
Screw
75849
Screw
75849
Screw
58892**
Screw
58892**
Screw
58892**
Screw
58892**
Screw
78125
Spline Adapter
58586
Spline Adapter
58586
Spline Adapter
78125
Spline Adapter
**Finish/color code must be specified when ordering.
Kohler Co. 3 116440-5-A

**Finish/color code must be specified when ordering.
51196**
Lift Rod
Wrench (VR)
32060
Washer
50903
Nut
58076
Valve
35213
Ball Sleeve
35886
Nut
32751
Coupling Nut
1001356
Seals
73240
Nut
77953
O-Ring
21271
O-Ring
74719
Supply
73679
Washer
33505
Nut 33505
Nut
73677
Washer
1001355
Tee
VR=Vandal-Resistant
78511** (VR)
Spout
78510**
82913** (VR)
Aerator
59728**
58575**
Escutcheon
77005**(Clockwise Close)
77006**(Counterclockwise Close)
Valve
78868
116440-5-A 4 Kohler Co.

78172**
78084**
78176
78175
78177
78092**
78091**
78089
78086**
78058
78085**
78090**
78057
78087
78063
78072**
**Finish/color code must be specified when ordering.
Stopper
Flange
Screw
Link
Clip
Nut
Rod
Seal
Tailpiece
Washer
Body
Nut
Washer
Gasket
Seal
Drain
Kohler Co. 5 116440-5-A

**Finish/color code must be specified when ordering.
1037022**
1036932**
1037346
1035564
40228
1025645**
1037390
1025642
1036351**
1030925
1025639**
1035348**
1025678
1025650
1035350**
Stopper
Trim Ring
Screw
Link
Clip
Nut
Rod
Washer
Tailpiece
Washer
Body
Nut
Washer
Seal
Fin
(Metal stopper fins with overflow)
1037023** (Plastic stopper fins with overflow)
Drain
(Metal)
1037021** (Plastic)
1025656
O-Ring
116440-5-A 6 Kohler Co.
