INSTALLATION INSTRUCTIONS
安装说明书
Pull-down Kitchen Faucet
**订购时请说明颜色编号
**Color code must be specified when ordering
SERVICE PARTS
零 件 图
Pull-down Kitchen Faucet
星珀丽
SIMPLICE
星珀丽
SIMPLICE
1434194-2-A 1
1434194-2-A 4
BEFORE YOU BEGIN
安装之前
安装尺寸 ROUGH-IN DIMENSIONS
所有的资料是按最新出版的产品资料编写而成。科勒
公司保留任何时候不经通知即可改变产品特性、包装
或产品可供类型的权利。
说明书包括重要的安装、保养及清洁方面的内容，请
把这些资料交给用户阅读。
注意事项：
1. 一定要先彻底冲洗供水管以清除管道中的杂质。
2. 如果是安装新的洗涤盆，可将龙头先装到洗涤盆上
3.花洒最高工作压力：0.5MPa(5bar)。水压超过
0.5MPa(5bar)时必须安装减压阀。花洒最高工作温
度及环境温度：60ºC。请特别注意花洒同花洒连接
的臂管须远离加热器，否则可能损坏花洒及其密封
件，甚至对使用者造成伤害。
596T-4 下抽拉厨房龙头596T-4 下抽拉厨房龙头
。
Ø34~Ø41
Ø51
64 Max.
81 234
745
All information is based on the latest product
information available at the time of publication.
Kohler Co. reserves the right to make changes in
product characteristics, packaging, or availability at
any time without notice.
Please leave these instructions for the consumer.
They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove
debris.
2. For new installations, install the faucet to sink before
installing.
3. The highest working pressure for sprayhead is
0.5MPa(5bar). If it exceeds 0.5MPa(5bar), a pressure
reducer is needed. The highest water and environment
temperature is 60ºC. Please keep sprayhead away
from heater, or it may become damaged and cause
injury to the user.
141
229682
406
14º
G1/2˝
1046153
1296289
1218824**
1447895
1307337
1288332
1446854
1267359
58946
1128531
1106466
1086396
1384194
1297533
1303572
1384195
1232505
1319955
1288038
1288208**
1243689**
1228706
56823

安装步骤 INSTALLATION
清洗说明 CLEANING INSTRUCTIONS
适用于所有加工处理过的表面：以中性肥皂水清洗镀
层表面，再以干净的软布彻底擦干整个表面，许多清
洁剂，比如氨水、去污粉及洁厕灵等，会对电镀表面
造成伤害，切忌使用。
有磨损性的清洁用具或清洁剂也不可使用于科勒牌的
水龙头及其配件上。
All Finishes: Clean the finish with mild soap and warm
water. Wipe entire surface completely dry with clean
soft cloth. Many cleaners may contain chemicals, such
as ammonia, chlorine, toilet cleaner etc. which could
adversely affect the finish and are not recommended
for cleaning.
Do not use abrasive cleaners or solvents on Kohler
faucets and fittings.
使用说明
轻轻打开把手，顺时针旋转为冷水，
逆时针旋转为热水。
手持使用花洒时，取下花洒，并拉出
软管。
如图所示，按下按钮(15)的不同位置A
或B，可分别获得两种不同水流。按住
按钮(16)，暂停出水。
注意：不要用力过猛或拉出过长，以
免造成软管及接头损坏。
OPERATION INSTRUCTION
Turn on the handle gently. Turn clockwise
for cold water, counter-clockwise for hot
water.
If you want to use the sprayhead by hand,
take the sprayhead and pull out the hose.
Press different position A or B of the
button(15), you will get different water flow
as shown. Press and hold the button(16),
it will stop water flow.
NOTE: Please pull it gently and do not
draw out the spray hose too long, or you
may damage the hose and connector.
INSTALLATION CHECKOUT
安装结果检查
检查并确保所有衔接处都已拧紧，确
保把手在关闭位置。打开主水源和排
水系统，检查并修理有漏水的接口。
将花洒(13)拆下，打开把手，让水流约
一分钟以清除杂质。关闭龙头，重新
装回花洒。
Ensure that all coupling nuts are tight.
Ensure that the handle is in the off
position. Turn on the main water supply
and drain, and check for leaks. Repair
as needed.
Remove the sprayhead(13). Run hot
and cold water about one minute to
remove any debris. Shut off the faucet.
Reinstall the sprayhead.
13
维护与保养 CARE AND MAINTENANCE
Turn on the faucet, rub the sprayhead
nozzles to dislodge debris.
To improve water flow, trun off the faucet.
Disconnect the sprayhead. Remove and
clean the screen(14) inside the sprayhead.
Reinsert the screen and reconnect the
sprayhead.
打开龙头，揉搓花洒喷嘴以清除杂质
当有杂质使水流变小时，关闭龙头，
取下花洒，取出里面的滤网垫片(14)
并清洗。
清洗后重新装回即可。
。
如何安装水龙头
将装饰罩(1)穿过软管、牙管(2)置于水
龙头(3)底部。从厨盆上方将水龙头组
件插入台面安装孔中，使装饰罩底部
接触台面，且把手置于右边。
确保螺钉(4)部分旋入安装环(5)。从厨
盆下方依次把垫片(6)及装有两个螺钉
的安装环装到牙管(2)上。调整水龙头
位置，使得花洒软管(7)在左边，与两
进水软管(8)左右对称。旋紧安装环直
至垫片紧贴厨盆底部，拧紧螺钉(4)以
固定水龙头。
将进水软管(8)接到水源上，贴有蓝点
标识的软管连接冷水，贴有红点标识
的软管连接热水。
将重锤(9)装到花洒软管(7)上。将快接
(10)有螺纹一端旋紧到花洒软管上，另
一端连接到出水软管(11)上。调整重锤
的位置使其距龙头底面距离合适，确
保抽拉顺畅，用扎带(12)固定重锤的位
置。
How to Install the Faucet
Slide the escutcheon(1) over the hoses
and shank(2) until it contacts the faucet
(3) bottom. From upside of the sink,
insert the faucet assembly into the
mounting hole until the escutcheon
bottom is against the deck. Ensure the
handle is on the right.
Partially thread two screws(4) into the
threaded ring(5). From underside of the
sink, place the washer(6) and threaded
ring with two screws over the shank(2).
Position the faucet so that the spray
hose(7) is on the left, the spray hose and
two supply hoses(8) are symmetrical.
Thread the threaded ring onto the shank
until the washer contacts the underside
of the sink. Tighten two screws(4) to
secure the faucet to sink.
Attach the hoses(8) to water supplies.
The hose with blue dot should be
connected to cold water. The hose with
red dot should be connected to hot
water.
Slide the weight(9) over the spray hose
(7). Tighten the connector(10) onto the
spray hose, and then install it to the
outlet hose(11). Adjust the weight to the
appropriate position, check for smooth
operation, and secure it with a loose
cable tie(12).
1
4
7
9
12
12
9
8
3
5
2
6
11
10
7
A
B
16
15
1434194-2-A 3
1434194-2-A 2
14
