KOIOS VS2233 User manual

FRESH
KEEP
INSTRUCTION
MANUAL

1-855-558-8777
[email protected]
www.mykoios.com
1 CONTACT US
Please send ‘VS2233’ to us by scanning the below QR-code.
(Instant reply):
SCAN ME
or visit: m.me/MyKoios

INTRODUCTION 2
INTRODUCTION
Package Contents
Warranty Customer Support
Thank you for purchasing our KOIOS VS2233 vacuum
sealer. This appliance is designed to meet ETL standard
for 120v. 60 Hz 110w appliances. Please read the user
manual carefully and keep it in a safe place for future
reference. Please contact us by email at
[email protected] if you need any assistance.
1. Vacuum sealer
2. Warranty Card
3. User Manual
4. Tube
5. Vacuum sealer bags
6. CReva
For questions, assistance, support. or warranty claims,
please contact us at the address below that corresponds
with your region. Please include your Amazon order
number and product model number.
Amazon orders: [email protected]
Please note: mykoios.com can only provide aπer-sales
service for products purchased directly from mykoios.com.
If you have purchased from a different seller. please
contact them directly for service or warranty issues.

3 PRODUCT SPECIFICATIONS
1. cover Lock: On the left and right side of the one-key
press cover.
2. Indicator Lamp: Indicates the status of vacuum or
sealing process.
3. Sealing Strip: Contains a heating wire covered with
Teflon which allows the bag to seal but not stick to the
strip.
4. Sealing Gasket: Press the bag onto the sealing gasket.
5. Vacuum Surface: Draws air out of bag and stops liquid
overflowing.
6. Airtight Seal: Prevents leakage during the vacuum
process.
PRODUCT SPECIFICATIONS
PRODUCT SPECIFICATIONS

FUNCTION BUTTONS INTRODUCTION 4
1. Vacuum/Seal (on/off)
Draws air out of the bag and automatically seals the
bag after vacuuming is complete.
2.Seal only （on/off)
Seals bags without vacuuming or halts the sealing
action whenever you want to stop the operation.
3. Food
Dry button: For dry bags and items without moisture;
has a shorter heat-sealing time.
Moist button: For wet bags or foods with a little
moisture; has a longer heat-sealing time.
Note: The default setting is set for dry bags and shorter
heat-sealing time.
FUNCTION BUTTONS INTRODUCTION

PRODUCT DIAGRAM
5 PRODUCT DIAGRAM
Vacuum
Surface
Sealing gasket
Airtight seal
Airtight seal
Sealing strip
Seal Only (on/off)
Indicator Lamp (for seal)
lndicatpr Lamp (for dry and moist)
lndicator Lamp (for vacuum)
Vacuum sealing (on/off)
Food

HOW TO CUT ASUITABLE BAG 6
1. Take out the cutter
from the sealer.
2. With one hand, hold
onto the bag.With your
otherhand, slide the
cutting knife to cut the
bag.Folding the bag
and cutting it along the
crease makes it easier
to cut.
3. Use the sealer to seal
one end of the bag.
HOW TO CUT ASUITABLE BAG

1. After putting the food
that you want to
preserve into the bag,
put the opening end of
the bag on the top of
the black rubber strip,
and then close the
cover
2. Press the cover down
heavily on both sides
by the lined area using
two hands - until two
click sounds are
heard.
3. Press the vacuum/seal
button and the bag will
automatically vacuum
and seal. The sealer
will automatically turn
off when sealing is
complete.
4. Press the two cover
lock buttons to retrieve
the vacuum-sealed
bag.
7 HOW VACUUM-SEAL FOODSTUFF
HOW VACUUM-SEAL FOODSTUFF
Silver / Black / Universal

HOW TO USE PUMPING HOSE 8
Step 1: Wipe the vacuum sealed storage container, making
sure it is clean and dry. Ensure that once the items are
placed in the container, it is not too full and that there is
a certain space within the vacuum cover. Connect the
two ends of the suction hose to the top center hole of
the vacuum cover and the machine suction hole.
Step 2: Make sure the lid is tightly closed and turn the lid's
pointer knob to the "seal" direction before vacuuming.
Step 3: Press the "Vacuum" button to start pumping. When the
machine sound stops and the "seal" indicator goes out,
the vacuum is complete.
Step 4: Remove the suction hose after the vacuum is completed
and store it for next use.
NOTE: Before using the hose, please ensure that the container
used is suitable for vacuum sealing.
HOW TO USE PUMPING HOSE

1. Prepare the moist items to be vacuum
sealed.
2. Select 'Moist' mode, then press the
vacuum and seal button.
3. Wait for about 10 seconds to allow the
heating wire to cool down.
4. Press the "Seal Only" button to
complete the sealing.
NOTE
A small amount of gas may remain in the bag because of water
vaporization when sealing moist items.
9 PROCEDURE FOR SEALING MOIST ITEMS
PROCEDURE FOR SEALING MOIST ITEMS

1. Do not put too much food inside the bag: leave enough empty
space so that the bag can be placed on the vacuuming plate
more effectively.
2. Do not wet the opening end of the bag. A wet bag may be
difficult to heat and seal tightly.
3. Do not vacuum-seal objects with sharP points like fish bones
and hard shells! Sharp points may penetrate and tear the
bag!
ADVICE FOR BEST VACUUM-SEALING RESULTS 10
ADVICE FOR BEST VACUUM-SEALING RESULTS
1. This appliance is not intended for persons (including
children)with reduced physical, sensory or mental
capabilities，or lack of experience and knowledge, unless
they have been given supervision or inst ruction concerning
use of the appliance by a person responsible for their safety
2. After a sealing procedure. do not immediately touch the
sealing bar in case you get burned by the remaining heat.
3. Keep away from hot gas. heated oven, electric burner and
any other hot surfaces.
4. Make sure your hands are dry and safe to do the actions
before operating.
5. Don’t immerse the sealer in water or any other liquid when
cleaning.
6. Do not use this appliance outdoor. it’s designed for indoor use
only.
CAUTIONS

Check if the edge of the bag has any
liquid，oii or any particles that are
preventing it sealing.
If yes, clean the edge of the bag and try
again.
Check if the heating element is damaged.
If damaged, please replace the heating
element and make sure it is installed
properly.
Check if the sealing strip is damageor not
installed correctly. If damaged, please
replace the sealing strip and make sure it
is installed properly.
Check if the edge of the bag has wrinkled?
If yes, please take out some foods so that
the bags have enough space for sealing
and smooth the bag mouth and try again.
Check if the bag is placed in the vacuum
chamber.
If not. please put the edge of bag correctly
into the vacuum chamber.
Check if the food has any sharp angles.
If yes, please remove or adjust the angle
of the sharp part of the food.
Check if the edge of bag is covering the
suction hole.
If yes, please put the bag into the correct
position.
Check if the gasket is deformed?
If deformed, replace it and try again.
11 FREQUENTLY ASKED QUESTIONS
FREQUENTLY ASKED QUESTIONS
Problem
Vacuums well
but seal function
is not good.
Sealing function
is good but it
does not vacuum.
solution

1. Always unplug the unit before cleaning.
2. Do not immerse in water or any other liquid.
3. Do not use abrasive cleaners to clean the unit. for they will
scratch the surface.
4. Wipe the outside of the unit with a damp cloth or sponge.
5. To clean the inside of the unit, wipe away any food or liquid
with a paper towel.
6. Dry thoroughly before using again.
CLEANING AND MAINTENANCE 12
CLEANING AND MAINTENANCE

13 ETLWARNING
1. Before plugging cord into wall outlet or disconnecting it, make
sure the appliance is turned OFF, and unplug from the wall
outlet when not in use or before cleaning.
2. This appliance is not a toy, when used by or near children,
close attention is necessary and store this appliance to a safe
place, out of the reach of children.
3. Do not use any attachments not recommended or supplied,
and do not use this appliance or other purposes, except its
intended use.
4. Stop using the machine immediately if the cord is damaged
and have it replaced by a professional.
5. Keep away from moving parts
6. Do not try to repair this appliance by yourself.
7. Do not use the appliance if it has fallen or if it appears to be
damaged.
8. Do not pull or carry the appliance by its cord, use the cord as
a handle, or pull the cord around sharp edges or corners. Do
not operate appliancee if the plug is wet.
9. Keep away from hot gasses. heated ovens. electric burner or
any other hot surfaces.
10. It's better not to use an extension cord with this unit. Howeve,
if one is used, it must have a rating equal to or exceeding the
rating of this appliance.
11. When disconnecting. to avoid any injury. please unplug by
grasping the plug. not the cord.
12. Before plugging the appliance in or operating it, make sure
your hands are drY.
13. Always place on a stable sur face. such as table or
countertop.
14. There is no need to use any lubricant. such as lubricating oils
or water with this appliance.
15. Close supervision is required when this appliance is used
near children.
16. If the supply cord is damaged, it must be replaced by the
manufacturer its service agent or similarly qualified persons in
order to avoid a hazard.
17. Cleaning and user maintenance shall not be carried out by
children without adult supervision.
18. To reduce the risk of electric shock. this product has a
polarized plug(one blade is wider than the other ). This plug is
intended to fit in to a polarized outlet only one way. When the
plug does not fit fully into the outIet，reverse the plug. When
it still does not fit, contact a qualified electrician to install a
correct outlet for this plug type. Do not change or modify the
plug in any way.
ETLWARNING

WARRANTY 14
Your product is guaranteed by us for 12 months from
your original date of purchase. If you want to extend your
warranty for one more year, please do not hesitate to
contact us.
Become a KOIOS member and get access to exclusive
benefits, such as updates about the latest KOIOS
products.
or
http://www.mykoios.com/warranty
SCAN ME
or visit: m.me/MyKoios
Please scan the QR-code to start chatting (Live chat).
1. Share your experience by leaving an honest review.
2. CONTACT US
Please leave a review with accompanying photos or a video would be greatly appreciated!
Submit
Add photos/video
WARRANTY

mykoios.com
