Kolpa Kolpa-san ARIA SIMPLE User manual

ARIA SIMPLE (+radio)
ARIA QUAT A0 (+radio)
ARIA QUAT A3 (+radio)
MELBA SIMPLE (+radio)
MELBA M1 (+radio)
MELBA M3+radio

1
www.kolpasan.eu
PICTURE 1a

2
www.kolpasan.eu
PICTURE 1b

3
www.kolpasan.eu
PICTURE 2

4
www.kolpasan.eu
PICTURE 3

5
www.kolpasan.eu
PICTURE 4

6
www.kolpasan.eu
PICTURE 5

7
www.kolpasan.eu
PICTURE 6

8
www.kolpasan.eu
PRECAUTIONS FOR USE
oThe device may be used by children above 8 years of age and persons with
lesser psychological and mental capabilities or lack of knowledge and
experience in the event that they are supervised or adequately informed about
the safe use of the device and understand the dangers.
oChildren should not play with the device.
oChildren may not carry out cleaning or maintenance of the device unattended.
oUse the device only in accordance with the intended use as described in this
manual. Do not use extra plug-ins if not recommended by the manufacturer.
oNever place or insert objects in the openings.
oSpace (bathroom) in which your massage cabin is located, must be designed
according to the regulations in force in each state. In zones 0, 1, 2 there
should be no switches, sockets or connections placed at your fingertips. They
should be located at least 0.6 m from the massage cabin and of a height of
2.25 m, as shown in Figure 2 - space.
oExcessive retention in hot water or steam can cause hyperthermia. This
occurs when the internal body temperature significantly exceeds the normal
body temperature of 37°C. Signs of hyperthermia are increased internal body
temperature, dizziness, lethargy, drowsiness and fainting. The effects of
hyperthermia are inability for heat-detecting, absence of feeling the need to
leave the hot room, unawareness of the impending danger. It can cause
damage to the foetus in pregnant women, physical exhaustion loss of
consciousness, and general danger.
oAlcohol, drugs or medication before or during the use of massage cabins can
significantly increase the risk of fatal hyperthermia or slipping.
oDo not perform unauthorised interventions that affect the safe and smooth
operation of this product.
oBe careful when entering or leaving the hot tub / cabin.
oAvoid massage or steam bath immediately after hard day's work or after
strenuous exercise. Risk of hyperthermia.
oNo electrical installations, including those which produce steam or moisture
are allowed to be used inside the cab.
oTo remove particles from the pipes, the water supply needs to be drained by at
least 25-50 litres of water before connecting the massage cabin.
oUse of instantaneous water heater may reduce the flow of hot water. Due to
the difference in pressure of the hot and cold water the proper functioning of
the mixing water valve is hampered. In this case claims for improper operation
of the valve are not accepted.
oLow water flow or the use of multiple massage functions at the same time
reduces the effect (power) of jets.
oThe effect of the jet is directly dependent on the flow rate (pressure) of water.
oThe massage cabin is allowed to be connected to the water supply with
minimum pressure of 0.2 MPa (2 bar) but not more than 0,4 MPa (4 bar).
Connection to a higher water pressure is not allowed without the installation of
additional limiters set at 0.4 MPa (4 bar). Kolpa d. d. does not recognise any
claims which might arise from a higher water pressure than allowed for this
product.
oParts containing electrical components (except for remote control), must be
placed or fastened so that they cannot fall into the massage cabin. A person in

9
www.kolpasan.eu
massage cab is not allowed to have access to any parts containing live parts,
except those supplied with safety extra-low voltage (SELV) not exceeding 12 V.
oChildren are allowed to use the appliance without supervision only if
instructed on the safe use massage showers, and if they understand the
potential dangers in the event of improper use.
oThe device may only be connected to the mains electricity which is protected
by means of a fault current protection switch FID IΔN 30 mA. The FID switch
is designed to interrupt the phase conductor and the zero conductor in cases
when the current flowing into the switch along the phase conductor is not the
same as the one flowing out along the zero conductor.
oThe massage shower enclosure must be permanently connected to the power
supply network, i.e. plugging it into a socket is PROHIBITED. In addition, it
must be possible to switch off this circuit with a multipole switch. The device
enabling the separation of all poles from the power supply network must be
integrated within the electrical wiring in line with the national wiring-related
regulations.
oThe cable entry must be protected with a 16A safety fuse (3.5kW). Conductor
cross-section = 2.5 mm2.
oThe device may only be plugged into the mains electricity if furnished with a
ballast that disconnects the phase conductor and the zero conductor from the
device.
oThe manufacturer or repairer of this device (i.e. the massage shower
enclosure) is not responsible for the installation and proper functioning of both
switches, i.e. FID and ballast.
oThe additional earth conductor (cross-section = 6 mm2) must be
connected to the connection point for equipotential bonding, which is
marked with the symbol shown on the right:
oWhile the steam bath is on, all parts of the person’s body must be at least 15
cm away from the outgoing steam nozzle in order to avoid the risk of getting
burned.
oThe continuous-flow water heater decreases the flow of hot water. Due to the
different pressure of hot and cold water, the proper functioning of the water
mixer is impeded. In such cases, no complaints on the grounds of improper
mixer functioning shall be acknowledged.
oThe low flow of water or the simultaneous use of several massage functions
will decrease the effect (i.e. the intensity) of the massage jet nozzles.
oThe massage shower enclosure may be connected to the water supply with a
minimum pressure of 0.2 MPa (2 bar) or a maximum pressure of 0.4 MPa (4
bar). Connecting it to higher water pressure is prohibited without installing an
additional device intended to limit the water pressure and set at 0.4 MPa (4
bar). Kolpa d.d. shall not acknowledge complaints arising from the use of
water pressure that is higher than allowed for this product.
oThe parts which contain electrical components (with the exception of remote
controls) must be set or affixed in a way that prevents them from falling into
the bathtub. The parts that contain components under voltage, with the
exception of parts under safety extra low voltage (SELV) that does not exceed
12 V, may not be accessible to the person in the massage shower enclosure.
oCertain parts of the massage shower enclosure feature surfaces
that heat up to such an extent that they can cause burns in the
event of direct contact or lengthy exposure at a distance of 10 to
15 cm. Such surfaces feature a symbol shown on the right.

10
www.kolpasan.eu
CLEANING and MAINTENANCE OF A MASSAGE BATH
CABIN
oChildren may not carry out cleaning or maintenance of the device if
unattended.
oAfter completing the massage cycle, massage cabin shall be rinsed with
a jet of clean water and particles which might clog the openings in the
massage nozzle removed. Use a clean cloth to wipe the chrome parts.
oUse only liquid cleansers and a soft cloth to clean.
oTo clean the acrylic and other kerrock or metal surfaces as well as to
remove lime scale KOLPA SAN SPECIAL CLEANER is recommended.
Spray the special cleaner on the surface or apply it with a sponge and
allow a few minutes to operate. Rinse with clean water. For valves with
a distinct sheen wiping the surface is recommended.
oATTENTION: The use of detergents in concentrations higher than
indicated in the appropriate instructions is not allowed.
oATTENTION: Cleaner operating for longer than 60 minutes may HARM
THE SURFACES of coloured elements and high-gloss elements
(chrome).
oDescaling can also be done by using household vinegar which is more
effective when it warms up.
oIt is forbidden to use abrasive cleaning agents containing coarse fillers.
MAINTENANCE AND CLEANING INSTRUCTIONS
FOR SHOWER ENCLOSURE BALL BEARINGS
When cleaning the Kolpa San shower enclosures using the KOLPA SAN
SPECIAL CLEANING AGENT, which is very effective when it comes to
removing limescale and thorough cleaning of other components, make sure to
carefully adhere to the following instructions (the same applies to the
CLEANING LIQUID prior to the application of the protective coating):
- The cleaning agent should be left on to take effect for a maximum of 5
minutes.
- Afterwards, rinse off thoroughly with water for at least a minute, across the
entire surface of the casing of the ball bearing.
- Periodically check the movability of the turning part and the revolvable wheel.
Lubrication:
Wipe the bottoms of the lower and upper bearings with a cloth. When dried,
lubricate the balls, the revolvable cap on both bearings and the groove of the
profile with the KOLPA SAN lubricant for ball bearings.
For easier access to the ball bearings, we recommend taking the glass door
off the aluminium frame of the shower enclosure. This can be done in the
following manner:

11
www.kolpasan.eu
1. Press the spring on the bottom ball bearing.
2. Tilt the bottom part of the door towards the enclosure’s interior, enabling
the ball bearing to slip out of the aluminium groove. The door should
hang by the upper ball bearings only.
3. Slightly lift the entire glass door so that it slips from the aluminium
groove.
4. Lubricate the ball bearings.
5. Reattach the glass door to the massage shower enclosure.
We recommend lubricating the ball bearings once or twice per year, or more,
depending on the frequency of opening/closing of the massage shower
enclosure door.
GENERAL WARNINGS ON CONNECTION AND
INSTALLATION
oThe massage cabin is allowed to be connected to the water supply with
minimum pressure of 0.2 MPa (2 bar) but not more than 0,4 MPa (4 bar).
Connection to a higher water pressure is not allowed without the installation of
additional limiters set at 0.4 MPa (4 bar). Kolpa d. d. does not recognise any
claims which might arise from a higher water pressure than allowed for this
product.
oConnecting the water inlet hose to the massage cabin or pillar shall be
performed in a way avoiding that a pillar or wall would PRESS directly to the
connecting pipe or any other pipe of the massage system. To install the main
water inlet on the wall connector we recommend using of an ANGLED
connector or a 90° ELBOW for an easier connection and relieved joints.
oKolpa d. d. does not recognise any claims which might arise from an
inappropriate installation.
oPositions of electrical outlets, hot and cold water drains and inlets, as shown in
the attached drawings and installation instructions, are showing only one of
the possible layouts of these connections. Their position is allowed to change
to any other location within the dimensions of the item, as long as this position
does not interfere with the function / operation of the elements mounted on the
pillar or a massage cabin. Hot and cold water supply pipes can, if necessary,
be extended or replaced with pipes of suitable length. Kolpa d. d. does not
recognise any claims which might arise from damage made by replacing or the
quality of the replacing pipes.
oTo remove particles from the pipes, the water supply needs to be drained by at
least 25-50 litres of water before connecting the pillar or massage cabin.
oInlet of each product connected to a water source is recommended to feature
a stop valve. If this valve is already installed in the existing water installation
scheme and is able to stop water just for your apartment or bathroom, then the
installation of an additional valve is not required. CAUTION! Pay attention to
the dimensions of the valve, as the massage pillars leave very little space for
connection to the water network. Angled or straight ball valves of smaller
dimensions are recommended.

12
www.kolpasan.eu
oWe recommend the installation of one-way water flow valves on both the hot
and cold water where water pressure between the hot and cold water might
vary occasionally. Most often this happens in the following cases:
oWhen using flow water heater (without the hot water tank).
oIn buildings where hot water is supplied separately from the objects /
devices intended for heating water for a large number of residential
buildings at the same time. Examples: plants in major cities, thermal
springs and the like.
oIn multi-dwelling buildings with a large number of consumers of water.
The purpose of the one-way valves is to prevent return of hot water through
the cold water pipes and vice versa.
For small housing where the water is heated with electric heaters, the one-way
valves are not required.
Where the water is heated through central heating, one-way valves are only
required if property has a very large number of water customers (multi-
apartment block or tower).
oIn areas where the water contains a large quantity of particles (impurities) and
scaling, we recommend to install a device to remove or neutralize
contaminants. This increases the lifetime of massage pillars and greatly
facilitates the cleaning of surfaces and components. To the extent feasible, we
recommend such devices to be installed on the building's main water supply,
as this is the most economical and comprehensive solutions for the entire
facility.
Kolpa d. d. does not recognise any claims arising from limescale or dirt in the
pipes, if not a filter for impurities and device for reducing the amount of
limescale installed.
oKolpa d. d. recognises the complaint only for the defect in the product, rather
than from improper installation.
oAttention: Kolpa is not liable for injuries caused by excessive water
temperatures.

13
www.kolpasan.eu
oSpace in which your massage cabin is located (bathroom), must be designed
according to the national regulations in force. In zones 0, 1, 2 there should be
no switches, sockets or connections placed at your fingertips. They should be
located at least 0.6 m from the massage cabin and of a height of 2.25 m, as
shown in figure below: Picture 2:
ASSEMBLY INSTRUCTIONS
All massage shower enclosures manufactured by Kolpa d.d. should be assembled by
a person authorized by the seller, from whom the enclosure in question was
purchased. In Slovenia, the task is carried out by the official repair service of Kolpa
d.d., while other countries are covered by the official Kolpa d.d. product distributor for
that particular country. Before the arrival of the assembly crew tasked with
assembling and connecting the massage shower enclosure, the space where the
enclosure is to be installed must be properly prepared. The water, electricity and
outflow connection points must be correctly located in line with the enclosed plans for
each massage shower enclosure. While minor deviations in connection point
locations are allowed, major deviations should be discussed with the seller or with the
Kolpa d.d. repair service. If the space is not prepared in a suitable manner, the
person in charge of the assembly shall have the right to refuse carrying out the
assembly until the space is appropriately prepared. In addition, the person in charge
of the assembly has the right to refuse completing the assembly it the required
assembly height is not enabled at the spot where the massage shower
enclosure/massage column is to be installed.
ELECTRICAL WIRING AND FITTINGS
To ensure electrical safety, please adhere to the instructions in this section and
warnings in the PRECAUTIONS FOR USE section.
The massage shower enclosure may only be connected by a suitably qualified
company with official authorization to perform this task (i.e. concession).
All Kolpa san massage shower enclosures are compliant with the EN 15200
standard. All electrical wiring within the building where the massage shower
enclosure is to be assembled must comply with the IEC 60364-7-701 standard and
local regulations in effect in individual countries regarding electrical wiring safety.
The massage shower enclosure must be permanently connected to the power supply
network, i.e. plugging it into a socket is PROHIBITED. The connection must be made
via a fault current protection switch (I∆n30mA) and protected with a 16A safety fuse
(3500 W max.). In addition, it must be possible to break this circuit with a multipole
switch, i.e. a BALLAST. The device enabling the separation of all poles from the
power supply network must be integrated within the electrical wiring in line with the
national wiring-related regulations. For connection, use a conductor with dimensions
3x2.5 mm2and double insulation.
The additional earth conductor (cross-section = 6 mm2) must be
connected to the connection point for equipotential bonding, which is
marked with the symbol shown on the right:

14
www.kolpasan.eu
ASSEMBLY AREA
The area in which the massage shower enclosure is to be located (i.e. bathroom)
must be prepared in line with the regulations in effect in your particular country. In
zones 0, 1, 2, there may be no switch or socket, nor any connections within reach or
at least 0.6 m from the massage shower enclosure and 2.5 m high, as shown in
Figure 2.
The parts which contain electrical components (with the exception of remote controls)
must be set or affixed in a way that prevents them from falling into the bathtub. The
parts that contain components under voltage, with the exception of parts under safety
extra low voltage (SELV) that does not exceed 12 V, may not be accessible to the
person in the massage shower enclosure.
Figure 2 , page 3–assembly area
SETTING UP CONNECTIONS AND PREPARING THE SPACE FOR THE ARIA
MASSAGE SHOWER ENCLOSURE
EXTRACT FROM THE KOLPA-SAN TECHNICAL CATALOGUE
Picture 1 , page 1,2.
Warnings:
The massage shower enclosure may not be CONSTANTLY connected to the mains
electricity –it has to include a BALLAST to shut down the enclosure after use.
The hot and cold water connection in the wall must have a water shut off valve built-
in.
CAUTION: When assembling the massage shower enclosure, the walls must be
straight as any jutting edges might hinder the assembly process. We recommend
lining the walls, including the space behind the massage shower enclosure, with
(ceramic) tiles. For the purposes of the massage shower enclosure, the minimum
recommended height of the space is 235 cm.

15
www.kolpasan.eu
USER MANUAL
Picture 4 page 5. Picture 5 page 6. Picture 6 page 7.
The ARIA SIMPLE, MELBA SIMPLE, MELBA
M1 and ARIA QUAT A0 massage shower
enclosure models have a 2-function mixer built in.
Alternating between the functions is enabled by raising
the upper part of the mixer.
F1. Hand shower
F2. Head shower
F2. Aria (QUAT A0) Massage nozzles
The intensity of the water jet can be regulated by
raising the lower handle.
The water temperature can be regulated by turning the lower handle towards the left
or the right.
The ARIA QUAT A3 and MELBA M3+radio massage shower enclosure
models have a 5-function mixer built in.
Alternating between the functions is enabled by raising the upper part of the mixer
towards the left or the right.
The intensity of the water jet can be regulated by
raising the lower handle.
The water temperature can be regulated by turning
the lower handle towards the left or the right.
F1. Head shower
F2. Hand shower
F3. Back massage function
F4. Lower body massage
F3. Upper body massage
CAUTION: The intensity, i.e. the effect of the massage jet nozzles depends solely on
the water pressure.
NO ELECTRICAL DEVICES, INCLUDING THOSE PRODUCING STEAM OR
MOISTURE, MAY BE USED WITHIN THE SHOWER ENCLOSURE.
Warnings:
Kolpa is not liable for injuries caused by excessive water temperatures.
Variations and fluctuations of pressure in the pipes between the hot and
cold water interferes with the normal operation of the mixer. In this case,
Kolpa d. d. does not recognise the claims of improper operation of the
mixer.

16
www.kolpasan.eu
Additional RADIO option –applicable for all massage shower
enclosure models
To lower/increase the volume, press the UPPER RIGHT key.
The display will read “u XX”, whereby XX is the currently set volume. The volume can
be set within a range of 0 to 20. After 5 seconds, the volume display shuts down
automatically and the frequency is shown once again.
Turkish bath –STEAM
–applicable only for ARIA QUAT A3, MELBA M1, MELBA
M3+radio
Pressing the key on the keypad turns on/off the Turkish steam bath
function. The LED indicator on the key will be alight while this
function is running.
After app. 50 minutes of running, the system shuts down
automatically. If you would like to continue using this function, turn
it on by once again pressing the on key for the Turkish steam bath.
Right after the function is shut down (either manually or automatically), the process of
rinsing off the steam generator is activated and lasts for app. 5 minutes. During this
time, the steam generator fills up with water several times and is emptied right away.
During the rinsing process, IT IS PROHIBITED TO DISCONNECT the massage
shower enclosure FROM THE MAINS ELECTRICITY.
Radio on/off
Current
frequency/volume
display
- Manual frequency search
- Volume setting
Each pressing of the key
changes the
frequency/lowers the
volume
Volume setting/FM
frequency search
- Manual frequency search
- Volume setting
Each pressing of the key
changes the
frequency/increases the
volume

www.kolpasan.eu

www.kolpasan.eu

01/2019
SEDEŽ / SEAT
Kolpa, d.d. Metlika
Rosalnice 5
SI-8330 Metlika
SLOVENIJA
tel.: [phone]
fax.: + 386 07/36-92-166
PRODAJA / SALE
Kolpa, d.d. Metlika
Pod Barončevim hribom 4
SI-8000 Novo mesto
SLOVENIJA
tel.: [phone]
fax.: + 386 07/39-33-350
e-mail: [e-mail]
www.kolpa.si
