USER MANUAL:
HOW TO CONNECT TO C5 CONTROLLER
USING KOMFOVENT APP

EN
UAB KOMFOVENT we reserve the right to make changes without prior notice
2
C5KH2-17-06
This symbol indicates that this product is not to be disposed of with your household waste, according to the
WEEE Directive (2002/96/EC) and your national law. This product should be handed over to a designated
collection point, or to an authorised collection site for recycling waste electrical and electronic equipment (EEE).
Improper handling of this type of waste could have a possible negative impact on the environment and human
health due to potentially hazardous substances that are generally associated with EEE. At the same time, your
cooperation in the correct disposal of this product will contribute to the effective usage of natural resources. For
more information about where you can drop off your waste equipment for recycling, please contact your local city
ofce, waste authority, approved WEEE scheme or your household waste disposal service.
Content
1. ACCESS TO THE AIR HANDLING UNIT PARAMETERS IN THE LOCAL AREA NETWORK
THROUGH THE PHONE, USING THE ROUTER......................................................................................... 3
2. ACCESS TO THE AIR HANDLING UNIT PARAMETERS ONLINE
(IN THE EXTERNAL NETWORK) THROUGH THE PHONE, USING THE ROUTER............................... 5

UAB KOMFOVENT we reserve the right to make changes without prior notice
3
C5KH2-17-06
All Komfovent air handling unit settings are available through the integrated web site, at the IP address
192.168.0.50, which is set by default at the factory. There are several methods for connection to the controller
scheme based on the way of connection.
Connection via browser:
1. Access to the air handling unit parameters directly through the computer, using the Internet browser.
2. Access to the air handling unit parameters in the local area network through the computer, using the Inter-
net browser.
3. Access to the air handling unit parameters on the internet (external network) through the computer, using
the Internet browser.
Connect via the Android app named Komfovent:
1. Access to the air handling unit parameters in the local area network through the phone, using the router.
2. Access to the air handling unit parameters online (in the external network) through the phone, using the
router.
This instruction contains a brief overview of the connection methods using the Android app.
1. ACCESS TO THE AIR HANDLING UNIT PARAMETERS IN THE LOCAL AREA
NETWORK THROUGH THE PHONE, USING THE ROUTER
It is the simplest way to control the unit from your phone, when you are in the vicinity of the unit. You can only
control it by connecting to a local area network router that is connected to the air handling unit.
You must have:
1. Air handling unit with controller (C5), controller version 1.140 and above.
2. Mobile phone with Android OS 4.0.0 (GingerBread) and higher, with Komfovent app.
3. Standard router.
Local area network is the network created by the router from the devices in the local area network for which
it has assigned the local area network address. The address is assigned as soon as the device is connected to
the router in any way: using a LAN cable or WiFi wireless connection. In this particular case, in the image the
mobile phone is connected to the local area network because it is connected to the router wirelessly through
WiFi. Therefore, the mobile phone and the air handling unit are in the common Local area network and can
interact with each other. It should be emphasized that the local area network has no connection to the nternet.
192.168.0.200
192.168.0.25
192.168.0.30 55.68.110.51
84.15.200.253
VIDINIS TINKLAS IŠORINIS TINKLAS
WIFI
192.168.0.50
INTERNET
WIFI
LOCAL AREA NETWORK EXTERNAL NETWORK
The scheme for controlling the air handling unit with the mobile phone
Connecting the router to the air handling unit:
1. Connect one end of the LAN cable to the connector of controller in the unit, marked with a special icon .
2. Connect the other end of the LAN cable to one of the several router connections marked with the text “LAN”.
Their number is usually 4 or more.

EN
UAB KOMFOVENT we reserve the right to make changes without prior notice
4
C5KH2-17-06
Connection to the air handling unit with Komfovent app:
COMPLEXITY
(Situation 1 – local area network address in the router’s default settings: 192.168.0.1)
1. Use your phone to connect to the router’s WiFi network to which you have connected the air handling unit.
2. Run the app, if the local area network is located in the xx0.x subnet, the app will immediately connect to the
air handling unit.
COMPLEXITY
(Situation 2 – the local area network address is not 192.168.0.x in the factory default settings of the router, but
the address is known – for example: 192.168.1.x)
1. Use your phone to connect to the router’s WiFi network to which you have connected the air handling unit.
2. Change the subnet number from the panel at the device. Settings are available by clicking Menu > Settings
> Air handling unit > Connectivity. Change the IP address from 192.168.0.50 to 192.168.1.50.
3. Run the app, because the local area network is located in the subnet xx1.x. The app will attempt to connect
to the default factory address, which is 192.168.0.50, but will fail. In such case, in the app, select Menu >
Settings > Connectivity > click and hold Add, until the message appears, then click . The app automatically
locates the device on the local area network and adds it to the list.
4. Select the air handling unit Komfovent from the list, click the Exit arrow, and conrm the changes.
COMPLEXITY
(Situation 3 – the local area network address in the router’s default settings is unknown: 192.168.x.x)
1. Use your phone to connect to the router’s WiFi network to which you have connected the air handling unit.
The router will automatically assign the IP address to the phone.
2. Run the app, because the local area network is located in the unknown subnet. The app will attempt to
connect to the default factory address, which is 192.168.0.50, but will fail. In such case, in the app, select
Menu > Settings > Connectivity > click and hold Add. In the pop up message, note the phone’s IP address.
It should be something like this: 192.168.?.x. Here – x-any number, ? – a subnet number. Take note or write
it down.
3. Cancel the automatic device search in the app.
4. Change the subnet in the control panel on the device. Menu > Settings > Air handling unit > Connectivity.
Change one number in the factory IP address from xx0.x (the subnet number you have written down instead
of the question mark) 192.168.?.50 and save the changes.
5. In the app, select Menu > Settings > Connectivity > click and hold Add, until the message appears, then
click . The app automatically locates the device on the local area network and adds it to the list.
6. Select the air handling unit Komfovent from the list, click the Exit arrow, and conrm the changes.
In this case, in the image the mobile phone is connected to the Internet, i.e. the external network, and the
router in the local area network has no Internet connection. Therefore, the mobile phone cannot access the air
handling unit which is in the router’s local area network.

UAB KOMFOVENT we reserve the right to make changes without prior notice
5
C5KH2-17-06
192.168.0.200
55.188.10.222
192.168.0.30
192.168.0.50
84.15.200.253
VIDINIS TINKLAS IŠORINIS TINKLAS
INTERNET
LOCAL AREA NETWORK EXTERNAL NETWORK
The scheme which cannot be used for controlling the air handling unit with the mobile phone
2. ACCESS TO THE AIR HANDLING UNIT PARAMETERS ONLINE
(IN THE EXTERNAL NETWORK) THROUGH THE PHONE, USING THE ROUTER
By connecting the router to the Internet, one can imagine that part of the router is connected to the external
network (internet), and the other part is the part that can create another own local area network with its external
devices. See Fig.
192.168.0.200
55.188.10.222
192.168.0.30
192.168.0.50
84.15.200.253
Modemas
VIDINIS TINKLAS IŠORINIS TINKLAS
INTERNET
LOCAL AREA NETWORK EXTERNAL NETWORK
Modem
To prevent the router being lost in the external network, and maintain communication with the router and
with other devices in the network, the router must have a uinique IP address assigned by your Internet provider.
Therefore, let’s assume that the Internet provider has assigned the address to the router – 84.15.200.253. Now,
all devices on the external network can access our router at this address, but the local area network created by
the router and the devices in it are still out of reach. Meanwhile, devices in the local area network can interact
with each other and access the devices on the external network (internet).
COMPLEXITY
(Situation 1 – the phone on the Internet wants to reach the Komfovent air handling unit)
First, create a route in the router (Port forwarding), and indicate in it: the way in which the device from the
external network will communicate with the device in the local area network.

EN
UAB KOMFOVENT we reserve the right to make changes without prior notice
6
C5KH2-17-06
This is very simple. Assign the unique port number to the specic address of the device in the local area
network, indicating the protocol type (TCP or UDP).
With this specied data, the router will know what the device from the external network is trying to access
and route its data to the device on the local area network.
The Komfovent device communicates with other devices using two ports: Port 80 with the browser and
Port 502 with Komfovent app, using the TCP protocol type. This is how it looks schematically:
Maršruzatorius
Telefonas1
Vėdinimo įrenginys
192.168.0.50
Kompiuteris
192.168.0.2
Telefonas 2
192.168.0.100
Televizorius
192.168.0.1
84.15.200.253
PORT: 4502
INTERNETAS
PORT: 502
PORT: 80
WIFI/GSM
PORT: 4080
Vinidis nklas
In the Komfovent app,
enter the router IP address:
84.15.200.253 and the Port
number created in the route:
4502
In the WEB browser enter the
router IP address and the Port
number created in the route in
the following format:
http://84.15.200.253:4080
ROUTE SETTING
(PORT FORWARD):
1. For addressing the router’s
4502 Port number, direct to the air
handling unit with the IP address in
the local area network 192.168.0.50,
PORT number 502,
for communication with the
Komfovent app.
2. For addressing the router’s
4080 Port number, direct to
the air handling unit with the IP
address in the local area network
192.168.0.50, PORT number 80, for
communication with the browser.
192.168.0.25 192.168.0.30 192.168.0.200192.168.0.50
Local area network
INTERNET
Telephone 1
Router
Telephone 2 Air handling unit TV set Computer
You can create external, i.e. (Start) Port numbers based on your preferences. It is important to remember
or write them down. You must specify them for connection to the external devices. Internal (End) Port numbers
of devices are usually indicated by the manufacturer, otherwise they should be determined by yourself.
Let’s have a look at what’s going on in the picture above. The phone 1, using the Komfovent app, wirelessly
(GSM/WiFi) connects to the Internet by specifying the router address 84.15.200.253 and the PORT number
4502. The router receives the request, and using its settings creates a tunnel for data transfer to the air han-
dling unit with an IP address on the local area network 192.168.0.50 and Port number 502. In this way, the
devices on the Internet can connect to, and control the air handling unit.
When connecting through the browser, on the device’s address bar, enter the router address and specify
the Port number in the following format: http:// 84.15.200.253:4080. We will access the air handling unit, which
is within the router’s local area network.

UAB KOMFOVENT we reserve the right to make changes without prior notice
7
C5KH2-17-06
Important – the type of network you are using – the local or external, depends
on the address you are using to connect to the ventilation unit.
1. If you are connecting to the unit via WiFi indicating an IP address such as
192.168.0.50 and the Port number 502 – you are on the local area network. (It
is not possible to login at this address when you are on the external network).
2. If you connected to the device over the Internet, i.e. by turning on the mobile
data or WiFi and have entered the IP address: 84.15.200.253, PORT number
4502 – you are on the external network.
In both cases, the result will be the same – you will connect to the ventilation
unit and can control it.
The essential differences between these connections are: In case 2, the data
travel path will be very long, although it may be that you are physically close to
the device and the router, which may cause connection interruptions and slow
down the performance of the app. Meanwhile, in case 1 there will be no commu-
nication failures, but you can control the ventilation unit only while being within
the router’s visibility zone. When you leave, the connection to the ventilation
unit will be terminated.

C5KH2-17-06
UAB KOMFOVENT
VILNIUS Ozo g. 10, LT-08200
Tel. [phone]
Mob. [phone]
el. p. [email protected]
KAUNAS Taikos pr. 149, LT-52119
Tel.: [phone]
Mob. [phone]
el. p. [email protected]
KLAIPĖDA Dubysos g. 25, LT-91181
Mob.: [phone]
el. p. [email protected]
ŠIAULIAI Metalistų g. 6H, LT-78107
Tel. [phone]
el. p. [email protected]
PANEVĖŽYS Beržų g. 44, LT-36144
Mob. [phone]
el. p. [email protected]
EXPORT & SALES DEPARTMENT
Tel.: [phone]
Fax [phone]
[email protected]
GARANTINIO APTARNAVIMO SK. /
SERVICE AND SUPPORT
Tel. [phone]
Mob. [phone]
[email protected]
www.komfovent.com
PARTNERS
AT J. PICHLER Gesellschaft m. b. H. www.pichlerluft.at
AU Pacic HVAC www.pacichvac.com
BE Ventilair group www.ventilairgroup.com
ACB Airconditioning www.acbairco.be
CZ REKUVENT s.r.o. www.rekuvent.cz
CH
WESCO AG www.wesco.ch
SUDCLIMATAIR SA www.sudclimatair.ch
CLIMAIR GmbH www.komfovent.com/en/business/
more/contact-us/
DK UNIQ COMFORT ApS www.uniqcomfort.dk
AIR2TRUST www.air2trust.com
EE BVT Partners www.bvtpartners.ee
FR AERIA www.aeria-france.fr
GB ELTA FANS www.eltafans.com
HR Microclima www.microclima.hr
HU
AIRVENT Légtechnikai Zrt. www.airvent.hu
Gevent Magyarország Kft. www.gevent.hu
Merkapt www.merkapt.hu
IR Fantech Ventilation Ltd www.fantech.ie
IS Blikk & Tækniþjónustan ehf www.bogt.is
Hitataekni ehf www.hitataekni.is
NL Ventilair group www.ventilairgroup.com
DECIPOL-Vortvent www.vortvent.nl
NO Ventistål AS www.ventistal.no
Thermo Control AS www.thermocontrol.no
PL Ventia Sp. z o.o. www.ventia.pl
SE Nordisk Ventilator AB www.nordiskventilator.se
SI Agregat d.o.o www.agregat.si
SK TZB produkt, s.r.o. www.tzbprodukt.sk
ООО «АМАЛВА-Р»
Россия, Москва
ул. Выборгская д. 16,
стр. 1, 2 этаж, 206 офис
Тел./факс [phone]
[email protected]
www.komfovent.ru
ООО «АМАЛВА-ОКА»
390017 г. Рязань
Ряжское шоссе, 20 литера Е, пом Н6
Тел.: [phone],
[phone]
[email protected]
www.komfovent.ru
ИООО «Комфовент»
Республика Беларусь, 220125 г. Минск,
ул. Уручская 21 – 423
Тел. [phone]
[email protected]
www.komfovent.by
Komfovent AB
Ögärdesvägen 12B
433 30 Partille, Sverige
Tel. [phone]
[email protected]
www.komfovent.se
Komfovent Oy
Muuntotie 1 C1
FI-01 510 VANTAA
Tel. [phone]
info_@komfovent.com
www.komfovent.com
Komfovent GmbH
Konrad-Zuse-Str. 2a, 42551 Velbert,
Deutschland
Tel. [phone]
[email protected]
www.komfovent.de
Komfovent SIA
Bukaišu iela 1,
LV-1004 Riga
Tel. [phone]
[email protected]
www.komfovent.lv
