Komo Flocino User manual

Operating instructions for
mills and akers

2 3
For more than 30 years
We would like to thank you and are glad that you have decided to purchase a product from our company. You will enjoy
your solid device for a long time, since it has been produced by hand with an impressive love for the detail from best
materials. Please thoroughly read these operating instructions before using the device for the rst time. There you will
nd all information for a safe operation.
We wish you to enjoy preparing your ne dishes
Marcel and Peter Koidl

4 5
1. Please thoroughly read the operating
instructions and follow the included notes.
2. Connect your electrical device only to a suitable
power socket. Check if the data which are indicated on
type plate comply with your power grid. Do not use any
multiple plugs or extension cables.
3. Only use the device if all associated parts are
in perfect condition.
4. Only use puried raw food. Non-puried raw food
often contains small stones and impurities, which might
damage the device.
5. Your KoMo device is mainly made of
wood. This material reacts on environmental
inuences. Climate and temperature
uctuations might result in small fractures. This does
not impair the function. Do not place the device in
proximity to radiators or the stove and avoid places with
direct solar radiation in order to protect the housing at
the best.
Safety instructions for KoMo
devices
6. Our devices are engineered for grinding of normal
household quantities of corn to our, akes and grist
and it is not intended for commercial use. The exception
are our professional devices.
7. They must only be operated by adults who
are physically and mentally able to operate the
devices and who have completely read these
instructions.
8. Switch your device o when it is no longer used.
9. Before opening the device the power line
must always be disconnected! Risk of injury by
mobile parts and risk of entrapment!
10. Place your device during use on a hard support (e.g.
a kitchen counter). It will guarantee that the slots at the
bottom of the device will be free to ventilate the motor.
11. Do not use the device outside, in humid
rooms or nearby open water containers. The
device must not get wet.
12. Make sure to collect the grist or akes with a
suciently large container, so that the grist or akes do
not get jammed in the outlet.
13. Before using the device, check with the overview of
grist in the attached brochure or under www.komo.bio,
if the device is suitable for the desired raw food.
14. Insofar as the device is screwed together
and can only be opened with tools, only our
customer service is allowed to open it. In case
of disregard, the warranty becomes null and void. No
tools are required for cleaning. This applies except for
the disassembly of the millstones for maintenance and
cleaning purposes. Observe the instructions in this
manual for the disassembly.
15. Do not use the cable to pull the plug out of the
socket, but directly pull on the plug and do not place
the cable on sharp edges.
16. If the power cable of the device would
get damaged, it needs to be replaced by
the manufacturer, his customer service or a
qualied person.
17. Keep the device away from liquids, heat, open
ames and humid rooms.
18. The manufacturer cannot be held liable for
damages, which are caused by improper use or wrong
operation.
19. Never leave the appliance unattended during
operation.

6 7
What materials can be crushed?
Oat, rye, wheat, buckwheat, millet, barley, spelt, unripe
spelt grain, rice, sesame, ax seeds, poppy seeds as well
as spices such as caraway seeds, pepper or fennel. This
is only a small choice, this list is continuously extended
and its latest version can always be found under www.
komo.bio.
Flakes
• The akes need to be well puried, otherwise
it might result in damages of the device by
impurities such as e.g. stones.
• Fresh oat akes should be immediately
consumed, since they rapidly
loose valuable nutrients when storing them and
might taste bitter.
• We recommend oat without spelt (non-hulled oat) for
aking.
• Briey moisten other grain varieties in a
strainer, let them dry for a few hours and then
ake them. Otherwise they would crumble
when aking them and they will be more digestible
after leaving them to soak.
General operation of the
aker
Assembly
1. Fix the aker to a table plate or similar means with the
help of the two screw clamps.
2. Then turn the hand crank clockwise.
3. Finally put on the hopper with the adapter piece and
the hopper lid.
Instructions
1. Place a container underneath the device.
2. Fill akes (e.g. non-hulled oat) into the hopper.
3. Turn the crank clockwise.
4. If required adjust the ake thickness with the
adjusting screw. To do so, the aker needs to be empty.
Disassembly
1. Disassemble the jacket below the aker, by shifting
them to the side and removing them.
2. Block the rollers from the bottom user the wedge
which is included in the delivery volume.
3. Disassemble the crank by turning it counter-
clockwise.
Care
The Flocino is made of solid beech and
plastic material free from BPA and nished
with vegetable oils The regular care can be
performed with a dry or humid cloth. If there are signs
of wear after some time, you can lightly sand the wood
and coat it with e.g. boiled linseed oil, which is available
in the specialist trade.
Cleaning
1. Optional - Disassemble the Flocino from the table
plate.
2. Disassemble the jacket below the aker, by shifting
them to the side and removing them.
Do not reach with the ngers into the rotating
rollers. Danger of getting jammed!
3. Clean the rollers with a brush or a cloth. At the same
time, move the rollers by turning the crank.
Operation
Flocino

8 9
Assembly
1. Fix the aker to a table plate or similar means with the
help of the two screw clamps.
2. Then turn the hand crank clockwise.
3. Insert a steel sheet into the gap with the FlicFloc label
showing upwards.
Instructions
1. Place the glass which is included in the delivery
volume underneath the device.
2. Fill akes (e.g. non-hulled oat) into the hopper.
3. Turn the crank.
The aker is set in a way that it can crush corn as well
as oilseeds. Thanks to the FlicFloc technique it is not
necessary to set the thickness of the akes .
Disassembly
1. Block the rollers from the bottom user the wedge
which is included in the delivery volume.
2. Disassemble the crank by turning it counter-
clockwise.
Care
The housing is made of beech Multiplex and
nished with vegetable oils. The regular care
can be performed with a dry or humid cloth.
If there are signs of wear after some time, you can coat
it with e.g. boiled linseed oil, which is available in the
specialist trade.
Cleaning
1. Pull the steel sheet with the logo upwards in order to
remove it.
Do not reach with the ngers into the rotating rollers.
Danger of getting jammed!
2. Clean the rollers with a brush or a cloth. At
the same time, move the rollers by turning the
crank.
Operation
FlicFloc
Instructions
1. Connect the device.
Never reach into the akes. Danger of getting
jammed.
2. Place a container underneath the device.
3. Fill akes (e.g. non-hulled oat) into the hopper.
4. Switch on the device,
TIP: If required, it is possible to adapt the ake
thickness by turning the adjusting knob. To
do so, remove the front plate and empty the
aker.
5. Switch o the device after the aking process.
Care
The housing is made of solid beech Multiplex and
nished with vegetable oils. The regular care
can be performed with a dry or humid cloth.
If there are signs of wear after some time, you
can coat it with e.g. boiled linseed oil, which is available
in the specialist trade.
Cleaning
1. Disconnect the device.
2. Remove the front plate.
3. Remove the aker to the front.
4. Clean the aker with a cloth or a brush with owing
water and dry it before reassembling the device.
5. When reassembling,
make sure that the coupling behind the aker
is neatly inserted.
Operation
Electric aker

10 11
General operation of the mills
What materials can be ground?
Wheat, oat, spelt, buckwheat, rice, barley, millet, unripe
spelt grain, corn, coee, lots of spices such as caraway
seeds, pepper, coriander, anise or fennel. This is only a
small choice, this list is continuously extended and its
latest version can always be found under www.komo.
bio.
Grist
• The grist needs to be well puried, otherwise
it might result in damages of the device by
impurities such as e.g. stones.
• Grind your our only once, it is not possible to increase
the neness by grinding it several times, but the
millstones would smear.
• Always keep your grist in a dry place. If the grist is too
humid, either place it in a linen bag beside the heater
for a longer time or put it on a baking tray in the oven at
50° C for half an hour.
TIP: Test the humidity by crushing one corn
with a spoon on a smooth surface. If the corn
cracks, it is dry enough. If it crushes like an oat
ake it is too humid.
• To avoid moths and insects when you do not use the
mill, you can put a tea bag with herbal tea or laurel leafs
into the outlet or into the milling chamber.
• In particular when grinding hard corn such as rice
or maize, put the grist into the funnel while the mill is
switched on and do not interrupt the grinding process.
• The drier the grist, the ner is the ground product and
the cooler is the our.
Assembly
1. Fix the mill to a table plate or similar means with the
help of the two screw clamps.
2. Then turn the hand crank clockwise.
3. Finally put on the hopper with the adapter piece and
the hopper lid.
Instructions
1. Place the tray, which is included in the delivery
volume, underneath the device.
2. Fill the grist into the hopper.
3. Turn the crank clockwise.
4. If required, adjust the neness of the our by setting
the adjusting screw. To do so, either simultaneously turn
the crank or empty the grinder.
Disassembly
Generally, it is not necessary to disassemble the mill.
However, if it should be necessary, please observe the
following instructions:
1. Have the device xed to the table.
2. Take o the hopper with the small connection pipe.
3. Set the ne adjustment to coarse.
4. Turn out the two screws counter-clockwise with an
Allen key.
5. Pull o the side part with the adjusting knob to the
rear.
6. Carefully remove the plexiglass tube.
7. You can clean the millstones with a hard brush, never
use a humid or wet brush.
8. Assemble the mill in reverse order.
9. Tighten the screws uniformly but not too rmly.
3. Set the adjustment
knob to coarse
4. Unscrew
the screws
5. Pull o the
side part
Care
The hand mill is made of solid maple and the
surface is lacquered. Therefore, it is sucient
to clean it with a dry or humid cloth.
Cleaning
It is not necessary to clean the mill separately, if it is
being used as intended. However, if the millstones
would smear due to e.g. wrong, humid or oily grist,
please proceed as follows:
1. Turn the ne adjustment to medium to coarse.
2. Turn the crank until the grinder is empty.
3. Fill in about 2 handful of long grain rice and grind it
with the adjustment medium to coarse.
Operation of the manual mill

12 13
Instructions
1. Connect the device.
2. Place a container underneath the device.
3. Switch on the device,
4. Adjust the desired neness by turning the hopper.
TIP: Set the nest adjustment by turning the
hopper without grist to the direction Fine while
the mill is running until you can hear how the
millstones are grinding on one another. Then, turn a little
bit to the direction Coarse, until the grinding noise stops
and you have found the nest setting!
5. Fill the grist into the hopper.
6. If required, readjust the neness by turning the hopper
either while the grinder is empty or while grinding.
7. Switch o the device after the grinding process.
Disassembly
Generally, it should not be necessary to open the
milling chamber, but when necessary, please observe
the following instructions:
1. Disconnect the device.
2. Turn the hopper as long to the direction
Coarse (counter-clockwise), until you can
remove the hopper.
3. Remove the upper millstone.
4. Clean the milling chamber with a cloth or brush and
dry the millstones with a hard brush as required, never
use a wet or humid brush.
Care
The housing is made of solid beech or of
Multiplex beech and nished with vegetable
oils. The regular care can be performed with a
dry or humid cloth. If there are signs of wear after some
time, you can coat it with e.g. boiled linseed oil, which is
available in the specialist trade.
Cleaning
It is not necessary to clean the mill separately, if it is
being used as intended. However, if the millstones
would smear due to e.g. wrong, humid or oily grist,
please proceed as follows:
1. Set the ne adjustment to Coarse by turning the
hopper.
2. Fill in about 2 handful of long grain rice and grind it.
3. Repeat this process, if the mill is heavily soiled.
4. Before a longer standstill, it is recommended to
proceed as described above while holding a vacuum
cleaner to the outlet and to the open lid, in order to
remove all our residues.
Operation of the
electrical mill

14 15
Our combined devices are a combination of our
mills and akers. Please nd the description for the
corresponding devices in the following chapters:
• FidiFloc: Electrical mill, FlicFloc, see notes below
• Duett: Electrical mill, electrical aker
FidiFloc:
Remover the aker
1. Disconnect the device.
2. Turn the hopper as long to the direction
Coarse (counter-clockwise), until you can
remove the hopper.
3. Pull the cover above the aker to the right and lift it
o.
4. Unscrew the crank from the aker. To do so, block the
rollers at the bottom with the wedge which is included
in the delivery.
5. Loosen the white screw counter-clockwise with the
ngers.
6. Remove the aker by pulling it upwards.
Operation
Combined devices
3. Take o the cover
white
screw
4., 5. Remove the crank,
loosen the screw
6. Lift out the aker.
Instructions
Flour of all grain varieties such as wheat, rice, maize, etc.
can be sifted.
However, it is not possible to sift e.g. oil seeds or nuts,
otherwise the sifters would smear.
Mounting the our sifter onto the mill:
1. Switch o the device.
2. Turn the hopper of the mill as long to the
direction Coarse (counter-clockwise), until you
can remove the hopper.
3. Remove the upper millstone.
4. Put the white plastic ring to the position of the upper
millstone, refer to the illustration.
5. Put the plexiglass cylinder on the bottom part of the
our sifter. At this, two balls will cam in the indentations
of the cylinder. To that, turn the cylinder a little bit, if
necessary.
Operation
Flour sifter
6. Screw the our sifter instead of the hopper on the
mill by turning it once.
7. Switch on the mill.
8. Turn the our sifter as long to the direction Fine until
the brushes start turning.
9. Turn another quarter of a turn to the direction Fine.
10. Switch o the mill.
11. Put the grist into the our sifter.
12. Put on the lid.
13. Place a blow underneath the outlet.
14. Switch on the mill.
15. Switch o the mill as soon as the our is sifted.
16. Remove the our sifter after use by turning it
counter-clockwise.
TIP: Always retain the our sifter on the wooden base
when turning it; never retain the plexiglass tube.

16 17
Replacing the sifter
1. Remove the our sifter after use by retaining the
wooden base and turning it counter-clockwise.
2. Remove the plexiglass cylinder from the our sifter
with a slight jerk upwards.
3. Unscrew the brush holder, to do so, turn the white
plastic disc clockwise (left-handed thread!) while
locking the bottom part.
4. Replace the sifter; make sure that the at side of the
plastic ring in the centre is positioned upwards (Illustr.
5).
5. Retighten the brush seat by hand.
6. Reposition the plastic glass cylinder; at this, the 2
balls will cam in the in the indentations of the cylinder
(Illustr. 6).
2. Remove
the cylinder
3. Remove
the retainer
3. Unscrew the
retainer
4. Replace
the sifter
5. Plastic
ring
6. Cam in
the ball
7.
6.
8.
Instructions
1. Disconnect the device.
2. Turn the hopper of the mill as long to the
direction Coarse (counter-clockwise), until
you can remove the hopper.
3. Remove the upper millstone.
4. Retain the bottom millstone and screw o the screw in
the centre clockwise with the Allen key which is included in
the delivery (left-handed thread!); in doing so, also remove
the disc and the block.
5. Uniformly drag the bottom millstone upwards with the
wire which is included in the delivery and remove it; in
doing so, the brush of the millstone should be positioned
in direction of the outlet.
6. Clean the milling chamber and the outlet with the brush.
7. Insert the milling chamber insert, starting from the
outlet.
8. Insert the bottom replacement millstone with the disc,
block and screw and tighten it counter-clockwise by hand.
9. Put on the upper replacement millstone.
10. Mount the hopper.
11. Perform the ne adjustment as described in the
operating instructions of the mill, in order to nd out the
nest adjustment (it might deviate from the original set
point).
12. Set the desired grinding degree.
13. For details regarding the commissioning or ne
adjustment, refer to the chapter“Operation of the
electrical mill”.
Operation
Interchangeable
milling system

18 19
The motor is humming, but the mill does not
start up.
Turn the setting to Coarse, until the mill starts up. Then
set the desired degree of neness.
The mill stops during operation.
Switching o due to overheating only takes place in
case of overload. In this case, disconnect the device and
let it cool down at least twice as long as the grinding
process before. In doing so, nd out the cause and then
subsequently avoid overload.
The grinder is clogged.
Turn the setting to Coarse, until the mill starts up.
Then set the desired degree of neness. If the problem
persists, refer to the chapter“Cleaning”in the operating
instructions of the corresponding mill.
The milling noise is no longer auditable –
the millstones are clogged.
This might happen, if you grind wrong, humid
or oily grist. For troubleshooting, please refer
to the chapter“Cleaning” in the operating
instructions of the corresponding mill.
Troubleshooting
The mill stops when running with very ne
adjustment. No our is output from the mill.
Set a coarser degree of neness and restart.
The millstones are soiled.
Observe the notes in the chapter “Cleaning” in the
operating instructions of the corresponding mill or have
a look at the video tutorials on our homepage.
Your question is not mentioned.
Do not hesitate to contact us; please nd the
phone number and e-mail addresses on the
last page of this manual.
Also refer to the section“FAQ” under
www.komo.bio .
Easy to prepare wholemeal bread
Preparation for a loaf of bread:
1 packet of dry yeast
1⁄2 teaspoon of honey
500 ml lukewarm water
350 g spelt
150 g rye
2 teaspoon of sea salt
2 tablespoon cider vinegar
75 g mixed seeds (sunower seeds, sesame, ax seeds,
poppy seeds, pumpkin seeds)
1⁄4 teaspoon each ground coriander, caraway seed and
fennel
Liquidate the dry yeast and honey in half of the
lukewarm water. Allow to swell for about 10 minutes.
Fine grind spelt and rye in the grain mill, mix with salt
cider vinegar, the seeds and spices in a bowl. Add the
yeast mixture as well as the remaining water and mix
the whole thing to a gooey dough. Do not leave the
dough to stand, but immediately ll it into a greased
loaf pen spread with sesame. Put the bread in the cold
oven and bake it at 200 °C (hot air 180 °C) for about 75
minutes. Remove the bread crust with a knife from the
mould and allow it to cool down on a cooling rack.
Try out the following recipes
Preparation time: about 20 minutes preparation and
about 75 minutes baking time.
Tip: Since the dough does not need to rise, the proper
preparation time is quite short. Therefore, the recipe is
also suitable for children and adults who do not have
much time.
The result is a fragrant seed bread which would taste
delicious when it is buttered.

20 21
KoMo breakfast cereals
Preparation per person:
1 ripe banana
3⁄4 cup of aked non-hulled oat
Milk or fruit juice
1 tablespoon sesame (unpeeled)
1 small apple (also fresh berries or any other
fresh fruits)
3-4 walnuts
Pulp the rape banana with a fork in a soup plate.
Crush the oat in the ake crusher at the desired
setting. Spread the sesame on it, add some milk
and mix it all. Cut the apple into small cubes
and add the coarsely chopped walnuts.
As you like, you can also add other fruits instead
of the apple.
Try out the following recipes

Please note the following:
You may only make use of the warranty if you
can present the original cash voucher. The
warranty service only applies for material or
manufacturing defects, but not for any damages e.g. on
the housing, which occurred after the commissioning of
the device. Small fractures in the wood are not deemed
as material damages. In case of misuse or improper
use, use of force and interventions, which have not
been performed by our service, any warranty claims are
excluded.
The warranty period will neither be extended nor
renewed by warranty services.
Please nd the warranty period for each individual
device in our current brochure or on our homepage:
www.komo.bio.
Of course, we can also repair your device after
the expiry of the warranty period; please do
not hesitate to contact us! Please nd our
contact details (phone numbers and e-mail addresses)
on the last page of this manual.
Dear Customers,
If we do not meet your expectations or if you have any
problems with one of our devices, please call us or write
us. Our technical sta will often be able to rapidly help
you by phone. Please contact us before returning the
device.
Warranty terms
23

24
WE’RE HERE FOR YOU
KoMo AUSTRIA
KoMo GmbH & Co. KG
Penningdörfl 6, 6361 Hopfgarten
T: [phone], F: [phone]
[e-mail]
KoMo GERMANY
KoMo GmbH
Rupert-Mayer-Straße 44, 81379 Munich
T: [phone], F: [phone]
[e-mail]
For more information on our products,
suppliers and recipes visit: www.komo.bio
All our videos, including instructions on how to
use our mills and flakers can be found at
YouTube komogmbh
You also find us on Instagram and
facebook – search for komo.bio
Supplier’s stamp
www.komo.bio
© KoMo GmbH & Co. KG, June 2018
