komoder MONACO User manual

Operation Instructions
MONACO MASSAGE CHAIR
SAVE THESE INSTRUCTIONS

01
02
04
06
07
08
20
Thanks for purchasing this product. Please read this manual instruction carefully in
order to know how to use this product correctly before operation. Please pay more
attention to some important safety warning and keep this manual book properly for
future use.
Note: Our Company reserves the right to revise the design and description of this
product without any further notice. Please refer to the actual color of this product.
CONTENTS
Safety and maintenance
Safety warning
Name and function of components
Function
Method of usage
Product specification

0302
Safety and maintenance Safety and maintenance
1.Important Safety Warning.
·Please do not allow children to touch moveable part of this product.
·Please use well-grounding power supply suited to this product.
·Please pull out the plug after use or before cleaning to avoid injury or damage to the
product.
·Please operate this product according to this manual instruction.
·Please do not use accessories which are not recommended.
·Please do not use this product outdoors.
·Please read this manual instruction carefully before operation.
·Any other usage that is not listed in this manual instruction is forbidden.
·20 minutes of usage each time is recommended.
·Please do not use it if the leather is broken or damaged.
·Please do not use it if the cover or leather is damaged.
·Please do not use it if the radiator hole is covered or blocked.
·Please do not drop anything into this product.
·Please do not fall asleep while using this product.
·Please do not use it if drunk or feel unwell.
·Please do not use it within one hour after having meal.
·Please do not make the massage function too strong for avoiding Injury.
·Please do not carry fragile, explosive and combustible materials in your pocket such as
mobile phones, lighters and so on, when using massage chair.
2. Environment for usage.
·Please do not use it under high temperature and moist environment such as bathroom.
·Please do not use it immediately while the environmental temperature changes sharply.
·Please do not use it under heavy-dusty or caustic environment.
·Please do not use it where there is not enough space or not good ventilation.
·Normal room temperature 0 °C to 35 °C.
·Please do not use this product in an excessively humid room (such as a bathroom) at a
relative humidity of 20% to 80%).
·Please do not use this product outdoors.
·Avoid direct sunlight.
·Keep this product away from heat source (such as the fireside, the air outlet of the air
conditioner).
·Please do not use this product in lightning weather.
·Please do not use this product in dusty places.
3. People who are not suitable to use this product.
·People who are suffering from osteoporosis are not suitable to use this product.
·People who are suffering from heart disease or carrying electronic medical equipment
such as heart pacemaker are not suitable to use this product.
·People who are suffering from fever are not suitable to use this product.
·Pregnant women or women that are in menses period are not suitable to use this
product.
·People who got injured or skin disease are not suitable to use this product.
·Children under 14-year old or people mentally unbalanced without being Supervised
are not allowed to use this machine.
·People who are told by doctor to have rest or people who feel unwell are not suitable to
use this product.
·People whose bodies are wet are forbidden to use this product.
·The appliance has a heated surface. persons insensitive to Heat must be careful when
using the appliance.
4. Safety.
·Check the voltage if it is suitable to the specification of this product.
·Please do not use wet hand to pull the plug.
·Please do not make water go inside this product to avoid electric shock or cause
damage to this product.
·Please do not damage the wires or change the circuit of this product.
·Please do not use wet cloth to clean the electric parts such as switch and plug.
·Be away from this product under power cut state to avoid injury if the power comeback
suddenly.
·Stop using this product while it works abnormal, and please consult local agent
immediately.
·Stop using this product if you feel unwell, and please consult health care doctor.
·This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
·Children should be supervised to ensure that they do not play with the appliance.
·If the supply cord is damaged, it must be replaced by the manufacturer, its Service
agent or similarly qualified persons in order to avoid a hazard.
5. Maintenance.
·This product should be maintained by certain appointed agents, users are prohibited to
disassemble or maintain by themselves.
·Please do not forget to cut the power after usage.
·Please do not use this product if the socket looses.
·If this product will be left unused for long, please curl up the wires and reserve this
product in dry and dustless environment.
·Please do not reserve this product under high temperature or near fire and avoid
longtime direct sunshine.
·If the detachable cord / supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to avoid a Hazard.
·Please clean this product by dry cloth. do not use thinner, benzene or alcohol.
·The mechanical components of this product are specially designed and made, it is not
necessary to be specially maintained.
·Please do not use edged res to thrust this product.
·Please do not roll or pull this product above uneven ground, it should be lifted before
moving.
·Please use it intermittently; please do not make this product work continuously for long.
6. Solution of ordinary malfunctions.
·It is nature movement voice if the motor sounds while in usage.
·If the controller can’t work normally, please check the plug and socket if they are
connected strongly and make sure the switch is turned on.
·If the rated working time is over, the product will automatically activate the power-off
button; If this product works continuously for long, the temperature protector will make
the product automatically power-off, it should be used again after half an hour's rest.
7. Storing conditions
·Storage room temperature -5 °C ~ 35 °C.
·Relative humidity 20% to 80%, no corrosive gas and well ventilated room.

0504
Safety warning Safety warning
Warning
Warning
Warning
Warning
When the footrest lifting, people should not apply pressure on the footrest to avoid
the massage chair falling forward to damage the product or cause personal injuries.
Prohibit pressing
Before sitting on the massage chair, make sure that the massage hand stays in the
seat cushion position to avoid discomfort to the buttocks during the body pressing
down and damage to the massage hand.
Do not strive to pull out the control cable or power cord during standby or power-on
state to avoid product damaged or electrocution accidents. Advise you unplug the
controller cable and power cord and put away after you use the chair.
When start the zero gravity lying function, be sure to check whether there are
children and pets under the bottom of the footrest and backrest, may cause the
product damaged or personal injuries.

06 07
Name and function of components Function
1.Head cushion
2.3D digital audio
3.Upper arm air
pressure component
4.Arm air pressure
component
5.Salient massage with
magnetic therapy
6.Manual controller
or mobile phone
placement slot
7.USB charging port
8.Seat cushion
9.Leg rest
10.Foot rest
11.Backrest
12.Armrest
13.Handrail shortcut key
14.LED light
15.side cover
16.Back cover
17.Manual controller
18.Drive box cover
19.Caster
20.Power cord and plug
21.Safety box
22.Power switch
23.Power line socket
16
18
20
17
19
21 22 23
FUSE:
T5AL 250V POWER INPUT
ON /OF F
·This product has designed a set of massage hand that can walk up and down,
four-wheel drive and mute design.
·There are five simulative massage techniques: Shiatsu, kneading, tapping,
kneading & tapping, knocking.
·Equipped with shoulder position detection automaticaly.
·Automatic massage functions: automatic massage includes 12 kinds of automatic
massage functions, including comfortable massage, relaxing massage, traction
massage, shoulder and neck massage, back and waist massage, whole body
massage, Protection of vertebral massage, fatigue recovery, stretching muscles
and activating collaterals, beautiful buttock shaping, soothing sleep and full air
pressure.
·Equipped with upper body manual massage function (the whole body, fixed point
and local three massage parts are selected, and the speed of each massage
manipulation can be adjusted with five speed. In fixed point and local state, the
massage hand can adjust the position up and down; When in tapping,shiatsu and
knocking massage program, the width of the massage ball can be adjusted in 3
levels
·It has air pressure massage function: upper arm air pressure massage function
(built-in 4 airbags), arm air pressure massage function (built-in 8 airbags), calf air
pressure massage function (built-in 16 airbags), and 3adjustable air pressure
intensity adjustment.
·Footrest extendable, push your feet forward to get your wanted length, and spring
back as your feet retract.
·Footrest lifting independently, backrest and footrest lifting together function, zero
gravity function.
·With back heat treatment function: carbon fiber as far infrared heat source.
·The backrest adopts slide rail technology to keep the zero space against the
deviation wall all the time, save space.
·Backrest frame guide adopts curve guide technology, which completely conforms
to the curve of human back, and can enjoy massage from head to thigh.
·Music playback system, 3D digital audio built into left and right upper arms. Use
the Bluetooth function of the smart device to play music wirelessly.
·With foot roller massage function, and a set of rollers scraping massage on foot.
·The front end of the right armrest is provided with a manual control slot or a mobile
phone slot, and has a USB charging function.
·In the left and right palm air bags, there is a salient massage with a magnetic
massage function.
·There are five kinds of handrail shortcut keys on the left handrail, such as the
opening key, the calf frame lifting button, the linkage adjustment button, the
automatic mode button, and the voice wake button.
·The left and right handrails are equipped with LED mood lights.
·LCD Color screen controller.
·Turn off the chair, it return to siting position automatically, and the massage hand
return to default position too.
1
2
3
4
9
11
12
813
15
7
6
10
14
5

0908
Method of usageMethod of usage
LCD: display all massage functions.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1.LCD:
·Display all massage functions.
2.Power switch:
·Turn on or off all massage functions.
3.Pause \ run button:
·Pause or run all massage functions.
4.Timer button:
·Sets the amount of time you want your chair to massage
5.Automatic reclining button:
·There are three automatic reclining modes, which can automatically switch
according to your own needs.
6.Footrest up button:
·Adjust footrest up.
7.Automatic massage button:
·Please refer to page 10 of this manual for details.
8.Air pressure mode button:
·Turn on/off air pressure massage function (please refer to page 11 of this manual
for details).
9.Manual massage button:
·Please refer to page 11 of this manual for details.
10.Foot roller button:
·Please refer to page 11 of this manual for details.
11.Shoulder adjustment button:
·Manual adjustment of human shoulder position massage finger pressure point.
12.Sitting:
·Adjust backrest frame rise and calf frame drop.
13.Calf frame down button:
·Adjust calf frame down.
14.Reclining:
·Adjust backrest frame to drop and footrest frame to rise.
15.Air pressure intensity button:
·Adjust air pressure intensity.
16.Heating button:
·On/off heating massage function.
zero

11
Method of usageMethod of usage
10
1.Switch power supply on
Diagram of plug in Diagram of the switch position of power supply
2.Start to massage
Button Description Display
Move the massage balls upward to a suitable position
Move the massage balls downward to a suitable position
Shoulder
adjust
High shoulder position
suitable shoulder position
Low shoulder position
F1 Auto
F2 Auto
F3 Auto
F4 Auto
F5 Auto
A1 Auto
A2 Auto
A3 Auto
A4 Auto
A5 Auto
A6 Auto
A7 Auto
·Automatic massage
Function Button Description Display
Comfort
Relax
Stretch
Shoulder&neck
Back&waist
More
Automatic
massage
Comfort: The most comfortable massage experience.
Easy: the depth of the soft and comfortable massage,
relieve body fatigue
Shoulder & neck: focus on shoulder and neck massage.
Back & waist: massage focus on back waist
Full body massage: Deep tisue massage rejuvenate
the body.
chiropractic massage: focus on chiropractic massage,
relax body and mind.
Fatigue recovery: improve the whole body fatigue pain,
for the back, limbs to achieve relaxation and improve
microcirculation, quickly relieve fatigue.
Meridians massage: dredge meridians, quickly improve
the body's microcirculation, enhance immunity.
Sleep peacefully massage: through the twelve major
health acupoints massage to help the body recuperate
balance, quickly improve sleep, improve sleep quality.
FUSE:
T5AL 250V POWER INPUT
ON/OF F
①.Press power button to start massage, start comfort auto massage by default.
②.The massage chair recline automatically.
③.Automatic shoulder position detection, make sure sit on massage chair closely.
④.If you feel the chair didn't recognize your actual shoulder position, press the
Shoulder Position Up or Down button to manually adjust the shoulder position.
You can select from 10 levels. You have 10 seconds to make an adjustment. After
10 seconds, the massage starts automatically.
Note: In the progress of start massage function, you can select the auto massage
function. Repeat select the same auto massage function, can skin the detection
process and start to massage directly
Beautiful buttock massage: be aimed at buttock and
thigh effective massage, beautify body shape, reduce
the accumulation of redundant adipose body.
Full air pressure: focus on the whole body pressure
massage to fully relax the body, to the depth of the
body massage, fully relieve fatigue and pain of the body.
During the detetion of shoulder massage and acupressure point process, (the hand
controller screen has the shoulder position adjustment icon and the sound "Di,Di" can
be heard from the hand controller, then press the shoulder position up and down
button to adjust the shoulder position.) You can also choose any 12 kinds of automatic
massage to enter the massage function (Comfort, Relax, Stretch, Shoulder & Neck,
Back & Waist, Full body massage, Chiropractic massage, Fatigue recovery, Meridians
massage, Beautiful buttock massage, Sleep peacefully massage and Full air pressure).
(Can skip 4th step directly).
With the footrest and backrest up and down,plus air
presure massage function, stretch on your legs,Relieve
fatigue,refresh yourself.

12 13
Method of usageMethod of usage
Function Button Display
·Upper body manual massage
Massage ball adjustment
Technique
Speed
Width
Back
stretch
Shiatsu: speed, width.
Kneading: speed.
Tapping: speed, width.
Kneading & tapping: speed.
Knocking: speed, width.
5 speed adjustable.
3 levels optional
Fixed position and spot massage.
Small area local round trip massage.
A round trip massage.
Massage position adjustment
(in fixed point and local mode,
massage position can
be adjusted).
Massage roller up
Massage roller down
·Pneumatic massage
Function Button Description Display
Air
pressure
Mode
intensity
Full pressure: air pressure massage on arms,
legs and feet.
Arm: air pressure massage focus on arms
Leg: air pressure massage on footrest
3 levels adjustable
·Foot roller massage
Function Button Description Display
Foot
roller
Press on the button repeatedly to choose the
intensity level of your choice (low, medium and
fast) or off this function. min
·Heated massage
Function Button Description Display
Heat
Press this button to turn on or off the back far
infrared hyperthermia. Turn on 3 minutes later
you will feel warm.
·Pause/start massage button
Function Button Description Display
Pause/start
Press this button in the process of massage, and
all massage movements will be suspended
urgently when time continues to countdown), and
then press this button resume all before suspended
massage modes
·Adjust lying Angle
Function Button Description
Lie down
automatically
Press and hold this button to slowly raise the back rest and
lower the footrest at the same time. Release the button to
stop at the desired massage angle.
Press and hold this button to slowly raise the calf rest and
lower the back rest at the same time. Release the button to
stop at the desired height
Press and hold this button to slowly lift the footrest.
Release the button to stop at the desired height
Press and hold this button to slowly lower the footrest.
Release the button to stop at the desired height.
Press the button every time to switch one automatic lying
mode. There are three modes in total.
·Other manual functions
Function Button Description Display
Timer
Press on this button to add 5 minutes to
the massage. Press repeatedly for up to
30 minutes
Backrest up
and footrest
down at the
same time
Footrest up
and backrest
down at the
same time
Footrest
down
Footrest
up
Timer

14 15
Method of usageMethod of usage
3.Introduction of handrail shortcut keys
The left arm
Function
Description
Right arm
USB
AUTO
1
2
3
4
5
6
7
Left armrest shortcut:
1.Power button: Turn the massage chair on or off.
2.linkage adjustment button: linkage adjustment of the backrest lifting adjustment.
3.calf frame lifting button: adjust the calf frame to rise or fall.
4.automatic button: turn on the automatic massage function.
5.voice control wake-up button: wake up voice control function.
Right armrest shortcut:
6.Place the slot: the hand controller and the mobile phone can placed in the slot.
7.USB charging port: smart device charging.
Power button: Press this button to turn the massage function on or off.
The calf riser button: pushes the button up and raises the calf frame
slowly, and releases it to stop the calf frame from rising.
Lower leg lowering button: Press the button down slowly to lower the
calf frame, and release to stop the lower leg frame.
Link up button: push the button up the back frame slowly, while the calf
frame slowly descends, release the backrest frame and the calf frame
are stopped.
Linking lying button: Press the button down slowly to lower the backrest
frame, while the calf frame rises slowly, releasing then the backrest
frame and the calf frame are stopped.
Auto mode button: Each time you press it, the auto massage function
switches.
USB jack: USB charging port, you can charge smart devices (such as
mobile phones).
Voice control wake-up button: press this button to wake up the voice
control function.

16 17
·When the massage chair is open or in standby mode, say "hi, Alice" or press the
voice control wake-up button on the right armrest to wake up the voice control
function.
·After the successful wake-up, the massage chair will reply “I am here”. At this time,
the voice control entry corresponding to the function is realized within 6 seconds.
After the massage chair is respond, the corresponding voice control function can be
realized; if did not correctly say any voice entry for more than 6 seconds, the voice
control function automatically turns off and needs to be reawakened.
·Note: When waking up the voice control function, please use Mandarin, the speech
rate is moderate, Voice commands should be follow up the Voice entry.
4.Voice control operation
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Voice control enter
Awakening words: “hi Alice”. Answer: I am here.
Serial No Voice control entry
Massage on
Massage close
Comfort Massage.
Relax massage.
Full body massage.
Neck and shoulder massage.
Back and waist massage.
Stretch massage.
Fixed massage.
Change the other mode.
Go little down.
Go little up.
Open the air pressure.
Close the air pressure.
Up the seat position.
Down the seat position.
Stop adjustment.
Answer entry
Answer: Ok, massage on.
Answer: Ok, massage close
Answer: ok, comfort massage
Answer: ok, relax massage
Answer: ok,full body massage
Answer: ok,Neck and shoulder massage
Answer: Ok,back and waist massage
Answer: ok,stretch massage
Answer: ok,fixed massage
Answer: Ok, change the other mode
Answer: Ok, go little down
Answer: Ok, go little up
Answer: OK, Open the air pressure
Answer: OK , Close the air pressure
Answer: Ok, Up the seat position
Answer: Ok, Down the seat position
Answer: Ok, stop adjustment
Method of usageMethod of usage
1.Enter the smart device manual and open the Bluetooth function to search the new
Bluetooth devices .
2.Will find the bluetooth named like (IMCM-XXXX),choose it to pair with the chair .
3.Turn on the Music Player in the smart device .
5.Bluetooth Player Operation
6.Turn off the power and stop massage.
·When pressing the power button during the massage, it will stop all the massage
functions immediately, the backrest and footrest will go back to the default posit
on.And when the massage time up, the massage hand will go back to the default
position, all the massage function will stop, the backrest and footrest will not go
back to the default position.
·Cut off the power of the whole machine. Figure (switch power off)
Diagram of the power switch position Unplug the power cord
1. After connecting the air hose and the wire harness on the calf and the massage
chair, untie the fixed line belt and insert the connecting part into the frame. (Figure 1).
2. Place the calf fixing block on the two sides of the round tubes of the calf (Figure 2).
7.The calf installation.
FUSE:
T5AL 250V POWER INPUT
ON/OF F
1 2

12
18 19
3. Hang the calf of the fixed block on the massage chair frame hook (Figure 3).
4.Then use 4 (each side two pcs) M4 screws to fasten the calf to the massage chair,
check whether there is any abnormality, whether the pipeline is folded or not, and
finish the installation (Figure 4).
8.Head cushions and backrest pad's dismounting and use manual
·The head cushion allows you to contr ol the intensity of the neck and shoulder
massage, You can decide whether to use the head cushion (Recommend to use).
The backrest cushion and the backrest is connected by zipper (1), head cushion
and the backrest cushion connected by the Velcro as show in the illustration (2).
Zipper Thread gluing
Method of usageMethod of usage
·Put the heavy massage chairs on the wood floor for a may damage the floor,
so please place a carpet or other object to avoid this damage.
Caution: Do not move the chairs with its wheels on wood floor, rough ground or in
a narrow space. Two people are required to lift the chair. During the lifting period,
take the calf rest end sealing plate and backrest cover grooves as the force-bearing
point(Please do not lift armrest directly.)
9.Floor Protection
10.Method of movement
3 4
Warning : Massage chair rear wheels are only suitable for short distance movement
for long distances, pls use other assistive tools to move the massage chair.
·Make sure that all wires are far above the ground, tilt the backrest backward to a
certain degree (with the gravity center resting on the wheels), push the chair
forward or backward with your hands and finally resume the chair to the normal
position in a slow and gentle manner.(Note: During movement you must turn off
the power first and then unplug the power cord and the controller cord.)

20
Product specification
Model: Monaco
Name: Massage Chair
Rated voltage: 110-120V~ 60Hz
220-240V~ 50Hz/60Hz
Rated power input:120W
Rated time: 20Min
Safety structure: Class I
Material introduction: PVC, PA, steel parts and electric & electron parts
MATERIAL PU LEATHER CLOTH WOOD
