komoder NOVA II User manual

NOVA Ⅱ
Please read SAFETY INSTRUCTIONS carefully before using the chair.
User 's Manual
Massage Chair

NOVA Ⅱ
1. Back adopts the patented low noise ultra-thin 3D massage machine,which can
achieve kneading, rocking, knocking, tapping, shiatsu etc. massage methods,
create a composite kneading technique that is close to a professional massagist.
2. It has the function of automatic body detection and can be used for precise
massage for people of different height and size.
3. One-button press to perform zero gravity lie down function .It can effectively
alleviate the pressure on spine and joints, allowing you to experience the real
zero gravity.
4. Micro space from the wall (5cm) forward sliding function,the chair can be put
close the wall to save the home space, make you have a good massage
experience even in a limited home space.
5. With the roller and air bag massage in the footrest. By stimulating the foot
reflection zone, it can dredge the meridians, regulate the joints and restore the
functions of viscera.
6. With the mechanical roller in the calf, combined with the airbags, it can knead
the leg muscle, increase the blood circulation, relax your legs.
7. Air pressure squeezing massage on your arms,which can promote blood
circulation of blood capillary.
8. The Legrest can be extended and retracted within the range of 22cm,suitable for
different people to use.
9. With a shortcut control panel on the armrest, which can give you a much easier
operation for the massage; the remote control uses high resolution full color LCD
screen.
10. Wireless bluetooth music player can effectively adjusts the mood, ease
mental fatigue.
11. With Chinese medicine unique heating treatment on the waist, it can achieve
the promotion of human blood circulation to ease the back pain and take care of
the spleen and stomach.
12. With USB port hidden in the armrest, no worry for your phone’s charge
during massage.
Function Introduction
Massage Chair
17
27
28
1
5
6
15
23
25
26
7
8
9
The use method of convenient hand controller
21
Note:We reserve the right for design modification.It is subject to change
without notice.The pictures in this manual are only for reference.
Please refer to the actual product.
1.Thank you for choosing this Massage Chair NOVA Ⅱ.
2.Please read this manual carefully before using the massage chair.
3.Please keep this manual in a safe place for further reference.
4.Please pay attention to SAFETY INSTRUCTIONS.
Content
External structure parts
Internal structure parts
Preparation
Safety instructions
Mechanical components diagram
Mechanical components list
Installation
Installation
The adjustment before massage
Operation instruction &function illustration
Manual control
Massage Operation
After massage
Please keep this manual in a safe place for future reference.
Clean and maintenance
Malfunction guide
Maintenance
Others
Technical data

1 2
Please read this manual carefully to make sure the installation and operation of the
massage chair is correct.
“Safety Instructions” is provided in both Warning and Caution for important safety
information.
Both Warning and Caution are important safety caution, please pay more attention.
This sign indicates forbidden behavior.
This sign indicates must follow
instruction to operate.
This sign indicates self disassembly
is forbidden.
This sign indicates correct operation
of cable.
Warning This sign indicates warning of causing possible death or hurt to body.
Caution This sign indicates caution of causing possible hurt or damage to things.
▲
Symbol meaning
The following should be kept for any further references.
Safety instructions Safety instructions
Preparation
People with osteoporosis, vertebral fractures, and acute painful diseases such as
sprains or muscle strains.
Heart disease patients (including those who have pacemakers or are using other
medical electronics).
Cancer patients.
People with perceptual disorders due to high levels of peripheral circulatory
disturbances such as diabetes.
People with abnormal spine or crooked spine.
People with Protruded intervertebral Disc.
Pregnant women and those who have just completed childbirth, as well as people
with poor health.
People with trauma, such as thrombosis, acute varices, and various skin
inflammations.
People who have been identified as having lost their ability to discern temperature.
People with high fever (acute inflammation: such as burnout, chills, blood pressure
changes, physical weakness).
Elderly people over 80.
Persons with impaired consciousness, mentally handicapped persons, or those
who are incapable of operating the unit are prohibited from using this unit.
People who can not take care of themselves, infants, and drunkards.
Do not use this unit when it is wet or when you are wet.
It must be taken care of, or not used by people who are not sensitive to heat or
people who are allergic to heat.
Do not fall asleep in this unit.
Not suitable
users.
People with above symptoms should not use massage chair, or use it under doctor's advice.
User's discretion is advised if use the chair.
Risk of causing
accident or body
discomfort.
Warning
Before sitting, please confirm that there are no foreign matter inclusions
between the various parts of the machine.
When using the backrest ，calf up &down, or calf extend, be sure to
check that there are no people or objects in the area (behind, under, or
in front of the chair).
In the event of a physical abnormality or abnormality in use, stop using
it immediately and ask a doctor.
Massage around the head should pay attention to the movement of the
massage rollers, the head should not do too much or too strong
massage.
Pay special attention when you massage the area around your neck.
Avoid excessive neck massage.
Do not massage the abdomen or knees with this machine.
If you want to leave your seat during the massage, you must stop the
massage chair before you leave the seat.
Do not use it with other instruments.
Do not allow children or pets to play on or around the unit (especially in
use); nor can they sit or stand on backrests ,armrests or legrest.
When people are inconvenient for action or lack of communication skills,
they must have strict and continuous care.
Before moving the unit, the backrest and legrest must be angled back to
their original position.
If the chair works dysfunctional, or is broken, splashed with water or falls into
water, please have it repaired by professional repairman or send the chair to
assigned service agent.Self-modification, disassembly or maintenance is
forbidden.
If power cord or plug is damaged, please don't replace it yourself, please
contact us or appointed dealer for replacement.
To avoid electric shock or body hurt, please don't open or disassemble any part
of the chair, there is not any attached part of the chair for maintenance by
customers.
Check leather or cloth material on the back and other areas is broken or not. If
broken, even though it is small,please stop using the chair, unplug the power
and have it repaired
Disassembly
and
maintenance
Power cord, plug, socket can't be used in broken or loose contact
condition.
Don't use other electric power except rated voltage in case of fire,
electric shock or any breakdown.
Any broken, re-process, knotted, twisted power cord or pressed under
heavy cargo is not allowed to use.
Never operate this appliance if it has a damaged cord or plug, if it is not
working.
Keep the power line away from stove or other heating products.
Fire and electric
shock
Massage cushions of the chair are not allowed to fold for storage.
The machine is forbidden for no-load running for a long time.
An appliance should never be left unattended when plugged in.
Accident
Insert the plug of the chair into correct and suitable power socket.
Make sure the plug is completely inserted into the socket to
reduce short circuit or fire risk.
Unplug the power when not in use,stop all massage functions
and turn off on/off key before unplugging.
Fire and electric
shock
Accident/injury
Warning
When assembling, turn off the switch and unplug it after the chair returns.
Preparation

3 4
Hand control should be timely put into the hand control bag, do
not arbitrarily put away, to avoid squeezing or drop damage.
Keep Dry-Don't use or store the chair in the wet environment
like nearing the swimming pool, or bathroom.
Keep the chair and remote control dry all the time.
Do not use it when user's body is wet.
Unplug the power when any damage on the power.
Caution
Unplug the power before cleaning the chair.
Unplug the power after using the chair.
Please turn off the power switch and unplug the power after
massage.
Unplug the power immediately when electricity goes off.
Make sure to install the earth wire in correct way(Incorrect
install way may cause electric shock. If you don't know how
to install, please find a professional electrician)
Don't use plug adapter (If the enclosed plug doesn't match
with socket, please don't change the plug by yourself and
find a professional electrician to install a matched
socket. )
Hold the plug to unplug the power but not try to pull the wire
to unplug the power.
Safety instructions Safety instructions
Preparation Preparation
To avoid leakage or
electric shock.
To avoid electric shock.
To avoid electric shock
or fire harzard.
To avoid accidents
To avoid damage or accidents
when power on again.
▲Gas pipe: probably cause explosion or fire.
Phone wire and lightning rod: probably cause electric shock
and fire when thundering.
Water pipe: earth wire is useless where there are plastics
Earth wire is not allowed
to be in these places
Grounding instruction
※The chair is equipped with a cord having a grounding conductor.The plug must be
plugged into an appropriate socket that is properly installed
and matched with the plug.
※When the fuse is burned out, please turn off the switch
and unplug the power. Opening the lid covered the fuse
which is located in the switch box. Using a same size
fuse to replace the old one, then cover the lid. Or you
can find an electrician to replace the fuse.
Please operate the chair in a flat or level place.
Installing earth wire in correct way.
The plug must be inserted into socket
with earth connect ,the earth connect
couldn't be bend or cut off.
Don't press with hands or step on the massage heads with feet.
Don't put hands between the working massage heads.
Don't put hands or feet in the gap of mechanical parts.
Don't drop or embed anything into the slot of massage chair.
Don't stand or sit or put anything on the backrest, armrest or leg-rest.
Don't move the chair during operation.
Don't stand on the chair during operation.
Don't pull out the plug or turn off the power during operation.
Don't put your hands or head between leg-rest or beneath.
Don't use the massage chair while wearing hair ornaments.
Don't put hard things in pocket when take buttocks and huckle
massage.
Don't sit or press on the backrest when the chair is in reclining
position.
Don't use at bare skin or were thin clothes, thin clothes may can
achieve better massage effect, But it also may cause irritation to
the skin or cryogenic burns.
Do not use massager in close proximity to loose clothing or jewelry.
Keep long hair away from massager while in use.
Caution
Keep the chair away from stove or other heating products.
Don’t put the chair directly under the sun or other high
temperature places.
To use electric blanket or other heating products on the chair
is forbiden.
To avoid sudden falling.
The maximum suggested operating time is 20mins. 5mins
for each position beginning with the slight- step massage.
Along continuous massage in the same position may
cause uncomfortable feeling.
Before sitting on the chair to avoid injury please inspect
everything to confirm that the massage heads are in the
correct position.
Too long time massage is bad for
your body.
To avoid electric shock in any
leakage or breakdown.
To avoid fade, discolor on upholstery
or hardened, deteriorated on PU.
Don't use the chair outdoor.
Keep the chair away from heat, wet, sharp things and corrosive,
inflammable, explosive environment.
Make sure the plug completely insert into the socket.
To reduce short circuits and any
fire hazard.
To avoid the accident when turn on
the power.
Turn off all controls before removing plug from outlet.
Checking whether any damage on wire,make sure no
water or rubbish on wire.
Please make sure that the power switch is at the“OFF”
position before inserting the plug into the socket.
To avoid accidental injury.
To avoid accidents or injury
Don't put in the space of dust serious or corrosive gas
environment,
Don't put the chair in a small space places or use in the bad
air circulation places.
Replace fuse

5 6
OK
AUTO EMERGENCY
MENU
Heating
Method
Position
Simple remote
control
Mechanical Roller
for the Leg
Preparation
Internal structure parts
External structure parts
Preparation
External structure
Internal structure
Right shoulder massage device
Loud speaker
Back seat cushion
Right armrest
Seat
Legrest
Footrest
Head pad
Left armrest
Castor
Left shoulder
massage device
Remote control pocket
Back cover
Power switch
Power case
Power cord socket
Fuse holer
Remote control
Massage head
Shoulder airbag
Waist heating cloth
Air bags in the arm area
Side airbag of leg
Foot roller
Footrest airbag

8
1
1
1
1
1
1
1
11
12
13
14
15
16
17
18
1
2
3
4
7
6
1
1
1
1
1
Left Side fender Assembly
Shoulder Assembly
5
9
10
1
1
1
1
13 14
按摩操作
7 8
1
1
19
20
1
1
211
22 1
23 1
Mechanical components diagram
Mechanical components list
Explosion Diagram
Preparation
Mechanical components list
Preparation
NO.Q'ty Q'tyNameNO.Name
Power case assembly
Back cover assembly
Back cover
Massage mechanism
Right side fender
Front swing assembly
Back swing assembly
Footrest electric actuator
Front fender assembly
Power case assembly
Solenoid valve assembly
Leg support plate
Right armrest assembly
Remote control
Back electric actuator
Foot and leg assembly
Left amrest assembly
Back frame assembly
Back seat cushion
Pillow
Bottom frame assembly

9 10
决定设置场所
请确保可以倾斜的空间。
①②
Installation(1)
Installation
Installation
Installation
Installation(2)
Installation
①First take out the accessory box and the legrest.
②More than two people carry out the main body of the massage chair.
③Confirm all the accessories.
Taking out the legrest device from the legrest
carton box,catching the and two sides left right
of the legrest and take them out
Hold the lower part
of the armrest and
carry out the chair
slowly.
Step 1. Take out the main body and accessories from the carton box.
Massage chair main body
The accessories
Electric power cable Remote control
Legrest device
Check environment
Make sure the recline space.
At least 50cm
from wall
Cushions Grounding part
Because the chair is heavy, it may ruin your floor in long time setting.
Please put a blanket or other soft things to protect your floor.
Caution
Don’t use the chair in wet places liks near swimming pool , bath room to avoid
leakage or electric shock.
Don’t use under sunlight or near stove or other heating place to avoid upholstery
deteriorated.
Please use chair in flat place to avoid chair falling or noise or other unexpected
trouble.
At least 5cm
from wall
Step2. Place the hand controller bag and hand controller
Remove the hand controller bag from the inner arm airbag of the right armrest.
Put the hand controller into the hand controller bag.
Remote control
Remote control
pocket
OK
AUTO EMERGENCY
MENU
Heating
Method
Position
OK
AUTO EMERGENCY
MENU
Heating
Method
Position

11 12
①④
1
2
3
4
⑥
⑤
②
③
Installation
Installation(3)
Installation Installation
Installation(4)
Installation
Put the rear of leg-rest near the seat front part.
Pair the leg and foot harness plug with the socket on the main machine.
Insert one of the air pipes in the legrest firmly into the air nozzle on the main body.
Raise the legrest with both hands,push the shaft of legrest to the limit level pin of
hangers,put the shaft into hangers,the limit level pin reset.
Paste the Velcro of the legrest connection leather into the front of seat.
Paste the Velcro of the legrest connection leather with the Velcro of the front of seat cushion.
▲
Note: The shaft must be securely attached, otherwise it will fall off. When inserting the air
pipe and wiring harness, do not wrap the air pipe and wiring harness together.
The wiring
harness plug.
Limit level pin
The wiring
harness plug.
Insert the plug of cable line into the socket.
Turn on the switch behind the power box.
(Switch on/off "O/I", press I down to turn
it on.)
Use the hand controller to choose massage
functions, enjoy the relax and comfortable
massage by our products.
1
2
3
4
Spindle
Air tube
Air tube
Step 4. After assembling.
Plug the cable line in the hole a on the
power box as shown in the right picture.
Make sure the switch is off before you
insert the plug of cable line into the
socket.
Plug the power cord
into the power box
socket.
Hand controller
Power box
socket
Velcro of the front of seat.
Velcro within the legrest
connection leather.
Velcro outside the
legrest connection
leather.
Velcro of the front of
seat cushion.
Step 3. Fix the Leg-rest
OK
AUTO EMERGENCY
MENU
Heating
Method
Position

1
▲
13 14
Check
The adjustment before massage
Caution
Environment Check environment
Don’t use the chair in wet places like near
swimming pool, bath room to avoid lea-
kage or electric shock.
Don’t use under sunlight or near stove
or other heating place to avoid upho-
lstery deteriorated.
Please use chair in flat place to avoid
chair falling or noise or other unexpected
trouble.
Check places in front
Check the areas when back and leg extending,
make sure no people, pets or other things
around.
Check power cable, plug
Space size for using the chair
(1) Clean the dust on plug on time.
(using dry cloth).
(2) No damage, re-do, bend, stretch, tie or
press with heavy thing(especially can’t be
pressed by the chair) on power cable.
At least 50cm in front of the leg.
Check surroundings
When the backrest or legrest reclines or
extends, please pay attention to:
(1) Check any person or things in every
direction.
(2) Check the space size.
The adjustment before massage
Massage operation
At least 5cm for the back-rest from the wall.
Right position: Your back
cling to the chair back, the
head clings to the pillow.
The remote control gives
"beep" sound after acupuncture
point tracking detecting finished,when
micro-adjustment is needed,just press
up/down key on the remote control.
Press down the head part to make the gravity
fall on the back castors. Then push the chair
to desired destination steadily and set it
down slowly.
Make sure the massage
machine rollers stop in
the upper of backrest,
then sit on the chair slowly.
If you feel the
massage isn't
strong enough,
you can remove
the pillow .
During massage chair backrest lie down
process, can't move the armrest.
Rolling Wheel
No more than 40 degrees
Kind suggestion
How to move massage chair Adjustment before massage
Caution
Don’t move chair when it’s working in case
of accidents or damage
How to move
Bind the cables and put them in the seat to
avoid damage when moving.
If you plump the chair, it may damage the inner
parts of the chair.
Don’t use the castor if the floor is wooden or
other easy damaged material. It will need 2
or more persons to lift the chair.
Make sure the power is off and the plug
doesn't touch the floor(It’s better to
let the chair in standing
status to avoid the back
crashing the floor)
Normally
Please hold the footrest to move the
chair as shown in the picture in case
any scratches on the leatherette
Avoid a wrong detection of your shoulder
position which will influence the massage
comfort.
Because the chair is heavy, it may ruin
your floor in long time
setting. Please put a
blanket or other soft
things toprotect
your floor.
Before adjustment
To avoid injure caused by
wrong position of the
massage head.
When doing Acupunture Point Detecting, if
the massage head can not find the shoulder
position, highest position. it will default to the
Massage operation

OK
15 16
1、In standby mode, press this key, the massage chair enters the power-on state. At this
time, select any kind of automatic massage program through the menu or buttons, and
the massage machine will start to detect the shoulder height and start the massage. In
the power-on state, press the switch key, the massage chair enters the shutdown reset
process, the legrest goes to to the lowest, the back rise to the highest, and the remote
controller is turned off after 6-10 seconds.
5、In the main interface, press this key to switch to the menu interface, you can select all
massage functions of the massage chair. The menu key needs to be used in
conjunction with the navigation key, and then press this key to enter the massage
status interface.
15、Press and hold this button, the leg will rise, release this button, the leg will stop
running.
17、Press and hold this button, the backrest goes up and the legrest goes down.
Release this button and the backrest and legrest stop running.
18、Press and hold this button, the backrest goes down and the legrest goes up.
Release this button and the backrest and legrest stop running.
2、In the power-on state, press this key to enter the cycle switching of three automatic
massage programs: "“Recover”,“Relief”,“Stretch”. The default working time is 20
minutes.
16、Press and hold this button, the leg will descend, release this button, the leg will stop
running.
19、In the power-on state, press this button to adjust the chair posture to zero gravity,
then press this button again to reset the chair to the initial working state. The zero
gravity icon on the main interface will show the current zero gravity status after the
massage starts.
9、The navigation direction keys have four buttons: up, down, left, and right. They are used
as menu navigation keys in the menu mode. You can use the up and down direction keys
to quickly select the menu items, as well as the left and right direction keys to quickly
enter the previous and next menus. The up and down direction keys play the role of
manually adjusting the position of the massage machine during the shoulder height
detection and the fixed-point adjustment function in the manual massage mode.
10、In the menu mode in the power-on state, press this key to confirm the selection of menu
items and pop up the next menu.
3、In the power-on state, press this key to enter the full-body air pressure, upper body, and
lower body air pressure massage functions in sequence.
7、In the power-on state, press this key to turn on and off the waist heating function. When
turned on, the corresponding heating symbol turns red, and when turned off, the
corresponding heating symbol disappears.
4、In the power-on state, press this button to immediately stop all massage functions. At
this time, only the shutdown button can be selected.
13、Under the manual massage state, press this key to adjust the massage speed, 5 levels
can be adjusted.
12、Under the state of air pressure massage, press this key to adjust the air pressure
intensity, 5 levels can be adjusted.
11、During the operation of manual tapping, knocking and shiatsu, press this button on the
main interface to adjust the massage width. Narrow , Middle and Wide can be selected.
6、In the main interface, press this key to switch the massage method, followed by
kneading, tapping, knocking, kneading&tap , and shiatsu.
8、In the state of manual massage, you can press this button to select Whole, Partial and
Point.
14、Under the state of power on, press this key, the sole roller can select three speed of
Quick, Soft and Stop in sequence.
Manual control
Manual control Manual control
Massage operation
Massage operation
Auto Manual Airbag
Roller Heating Timing
Setting Stop
Menu
Select by the navigation keys
OK
AUTO EMERGENCY
MENU
Heating
Method
Position
Foot roller
Back up &Leg down
Back down & leg up
On/Off
Menu
Confirm button
Left
Up
Right
Down
Auto
Heating
Air pressure
Zero-Gravity
Legrest up
Legrest down
Speed
Width
Intensity
Emergency
Method
Position
AUTO
EMERGENCY
MENU
Method
Heating
Position

17 18
Menu Interface
After power on ,if you press the “on/off ”button,the buzzer will ring with a
short and crisp sound.The LCD displays the main menu interface and
enters the standby state.The Main screen displays information such as
auto,manual ,airbag,roller, heating, timing,setting ,stop current working
state,etc.Those information will be updated in real time after the operation.
Menu Main Interface
Manual Massage: On the main interface of
the menu, select manual massage through
the navigation key. After pressing the "OK"
key, there are four functional options: mode,
position, width and speed; After selecting the
corresponding function, press "OK" to enter
the next menu, and select the desired massage
mode: kneading, tapping, knocking, kneading
and tapping, shiatsu; Massage position include
whole, partial and point; Massage width
and speed.
Stop: In the main interface of the
menu, use the navigation keys to
select Stop. After pressing the
[OK] key, the massage chair stop
massaging, and heating turn off.
Press Menu key again, to go back
to main interface.
Heating: In the main interface of the menu,
use the navigation keys to select Heating.
After pressing the [OK] key, you can
choose to turn on or turn off waist heating.
Auto Massage: After pressing the “on/off”key, the cursor will stop in
the automatic massage program by default. After pressing the “OK”
key, you will enter the menu interface. There are the following
massage modes:“Recover ”,“Relief”,“Stretch”,“Music Sync”,“Renew”,
Calming”and “Special ”.Under Special , there are two automatic
massage modes to choose after pressing “OK”.
After pressing the “OK”Key in the main menu interface,it will
switch to the menu interface and all massage functions can be
set by pressing the button.Pressing the “Menu”key in the menu
interface will exit the menu and return to the main interface.
Airbag: In the main menu interface, use the navigation keys to
select "Airbag", after pressing the [OK] key, there are two air
pressure function options: position and intensity. After selecting
the corresponding function, press the [OK] key to enter the next
menu and select the desired massage parts: full body, upper
body, legs and feet; massage intensity: 5 levels of display.
Foot Roller: In the main interface of the
menu, use the navigation keys to select
Roller. After pressing the [OK] key, you
can choose quick, soft and stop.
When power on, the first time you use
the auto program, massage chair will
start the body scan and “body
scanning ...'' will be shown on screen.
After the body scan is finished, the
Timer: In the main interface of the
menu, use the navigation keys to
select Timer. After pressing the [OK]
key, you can choose massage time to
10 mins, 20mins or 30 mins. The
default time is 20 mins, the massage
chair will turn off automatically when
the time is up.
Settings:In the main interface of
the menu, use the navigation keys
to select Settings. After pressing
the [OK] key, you can choose the
desired language.
中文
English
한글
Massage State Interface
Under the main interface of the menu
displayed on the LCD screen,press the
“Menu”button to enter the massage state
interface,and then press the “Menu”button
to return to the main interface of the menu.
Auto Manual
Roller Heating Timing
Setting Stop
Menu
Select by the navigation keys
Airbag
Kneading
Tapping
Shiatsu
Knocking
Massage
time left
Zero gravity
09:35
Massage width(narrow, mid, wide)
Air Massage Strength( 5 levels)
Massage speed（5 levels）
Auto
Manual
Roller
Heating
Timer
Settings
Stop
Menu
Select by the navigation keys
Airbag
Recover
Relief
Stretch
Music Sync
Renew
Calming
Special Refresh
Energy
Auto
Manual
Roller
Heating
Timer
Settings
Stop
Airbag
Select by the navigation keys
Mode
Position
Width
Speed
Level 1
Level 2
Level 3
Level 4
Level 5
Kneading
Tapping
Knocking
Knead&Tap
Shiatsu
Narrow
Middle
Wide
Whole
Partial
Point
Menu
Select by the navigation keys
Menu
Position
Intensity
Full Body
Upper Body
Legs & Feet
Level 1
Level 2
Level 3
Level 4
Level 5
Auto
Manual
Roller
Heating
Timer
Settings
Stop
Airbag
Auto
Manual
Roller
Heating
Timer
Settings
Stop
Airbag
Auto
Manual
Roller
Heating
Timer
Settings
Stop
Airbag
Auto
Manual
Roller
Heating
Timer
Settings
Stop
Airbag
Select by the navigation keys
Menu
Quick
Soft
Stop
Select by the navigation keys
Menu
ON
OFF
Select by the navigation keys
Menu
10 min
20 min
30 min
Select by the navigation keys
Menu
Language
Auto
Manual
Roller
Heating
Timer
Settings
Stop
Airbag
Massage operation
Manual control
LCD display graphic description
Massage operation
Manual control
LCD display graphic description
Massage function
Massage position
Auto
Manual
Massage State
Airbag
Roller
Heating
Timer
Settings
Stop
buzzer will tick (once every second). At this point, the massage rollers
are in the shoulder position, you can press Up and Down to adjust.
When adjusting, “shoulder height adjusting...” will be displayed on the
screen. The default working time is 20 minutes. The massage chair will
turn off and reset to its upright position once the massage is over.
Body Scanning
Body Scanning
Body Scanning…
Set function by pressing Menu key

How to Use the Simple Control
How to Use the Simple Control How to Use the Simple Control
19 20
1. Press on/off key to turn on or turn off the chair.
5. Keep pressing this button for seconds , backrest goes down and legrest goes up.
Release this button, backrest and legrest stops moving, the angle is locked in this
position.
4. Keep pressing this button for seconds, backrest goes up and legrest goes down.
Release this button, backrest and legrest stops moving, the angle is locked in this
position.
2. In on status, press the Auto to enter three auto programs: Recover, Relief , Stretch .
3. In on status , press this button , massage chair will go to Zero-gravity position, press it
again to return to the original position.
AUTO
AUTO
Massage operation Massage operation
On/Off
Auto
Zero-Gravity
Back up &Leg down
Back down & leg up

21 22
Backrest Down/Legrest Up
2
32
1
1
Backrest up/Legrest down
a
3
4
Foot massage function :
The foot has an all-around
rolling and airbag massage
function. By stimulating the
foot reflection area, it can
dredge the meridians of
human body, regulate and
restore the body's viscera
function, effectively improve
human body resistance and immunity.
Press this button on controller,
backrest goes down and
legrest goes up. Release
this button, backrest and
legrest stops moving,the
angle is locked in this
position.
Press this button on controller,
backrest goes up and legrest
goes down. Release this
button, backrest and
legrest stops moving,
the angle is locked in
this position.
Operation instruction and function illustration
Massage operation
ON/OFF
Massage operation
Operation instruction and function illustration
Function Illustration
Remote control
① Operate according to controller operation
instructions. As for the massage method's
details, please refer to remote control's
Usage page.
② When the massage ends, massage machine
will return to the default position, meanwhile
"Shutting down" will be displayed on the
controller.
④ Press "ON/OFF" button on the remote which
will beep once. It will then enter the display
interface .
① Put one end plug of power line to “a” hole.
② Put power plug to socket.
③ Turn on the power switch on the power
box, massage chair powers on.
Step1. Power on
Power switch
Step2. Massage
Step3. Turn off the power
①When the chair is On, press On/Off button
to turn off the massage chair and it will
restore automatically.
Turn off the power switch on the bottom of ②
the back of chair after the rollers reach
storage position.
Unplug the power plug from the socket.③
1. Before using, pull up the pillow,
back cushion etc. to check if the
PU material is broken, if there is
damage, please stop using,
unplug the chair, and ask for
repairment.
2. Only plug to proper socket.
Warning
Attention
1.Before sitting down, make sure there is no
things pinched between armrest, legrest ,
backrest and seat of the chair.
the chair is in reset state before 2.Make sure
using.
3.Do not stand on it when using the massage
chair.
Legrest can extend or retract within a
range of 22 CM.
Legrest Up
Press this button on controller,
legrest goes up.Release the
button,legrest stops moving,
the angle is locked in this
position.
Legrest Down
Press this button on controller,
legrest goes down.Release
the button,legrest stops
moving, the angle is
locked in this position.
Zero gravity
Press the button "Zero” ,backrest
go down and legrest raise up,
the chair go into Zero gravity status
automatically.Press the Button again,
the backrest and legrest stop
moving, and it will lock at
this position.However to
change the angles,we
can keep comfortable
massage status all the time.
Legrest extend and retract
The armrest has built-in pulse
pressure massage function,
put your arm in the air bag
when it is not inflating.
After the airbag is inflated,
the arm and palm can be
massaged,no matter how
the seat changes, can
always maintain a
comfortable massage
state on the arm.
Arm massage
Multilayer extrusion airbags
is deployed on both sides
of the shoulder. Achieve
pressure shoulder
stretch massage,
relieve shoulder
fatigue.
Shoulder massage
Foot massage function
1. Please make sure there is no people, no pets or any stuff around the backrest to avoid unexpected hurt or
property loss.
2. When adjusting the backrest, be careful of the gap between the backrest and armrest.
3. When the legrest is moving, please do not stand on or leave from the seat, do not stop the legrest from moving
in case of causing damage to the chair.
4. Please refer to control instruction for more details.
OK
AUT O EMERGENCY
MENU
Heating
Method
Position

23 24
4
1
2
5
6
3
Massage operation
After massage
Restoration of massage chair
Clean and Maintenance
Maintenance
Put the controller back into the controller
bag of the right armrest after the chair
back to the initial position.
Make sure there is no people or pet or anything
within the range of backrest and legrest.
Make backrest and legrest restore to the
normal position by controller.(or press
ON/Off key to make backrest and legrest
restore to the normal position)
Switch off the power.
Unplug the electricity from the socket.
(Attention: hold the right plug position)
Clean the chair if necessary.
Attention!
After using, press ON/OFF to end all the
massage method and wait for restoration.
Make sure to cut the electricity to avoid any
unexpected hurt to children or pets.
After using, turn off the power, unplug the
electricity. Avoid moisture, dirt and aging
of insulation in case of causing damage.
Or
●
1
●
2
●
3
●
1
●
2
●
3
●
4
●
4
●
1
●
2
●
3
●
1
●
2
●
1
●
3
●
2
●
2
●
1
●
1
●
1
●●
3
2
Synthetic leather
Plastic parts
Do not use the thinner,
gasoline, alcohol or
other chemical
materials.
Clean with tidy, soft and dry cloth slightly.
Dip soft cloth into 3-5% neutral detergent
solution, squeeze it then clean the stain on
the surface gently.
Wash cloth, squeeze it and wipe with
detergent.
General cleaning
Clean it softly with dry cloth.
Allow to dry (air blower is prohibited)
If leather is dirty
Brush the dirty parts
with weak neutral detergent.
(avoid excessivebrushing)
Dip cloth into weak neutral
detergent, squeeze it and clean
the material surface.
Wipe with water-dipped but
squeezed cloth.
Excessive cleaning may cause
damage to cloth material.
Allow to dry.
Do not use the thinner, gasoline,
alcohol or other chemical
materials.
Cloth material
Dip cloth into neutral detergent,
squeeze it and clean.
Wipe with water-dipped but
squeezed cloth.
Allow to dry.
Clean the controller
Wipe with soft cloth after squeezing.
Allow to dry.
Do not use the thinner, gasoline, alcohol or
other chemical materials.
Remote control
About cleaning
Before cleaning, unplug the electricity,
don't touch plug with wet hands.
Make sure hands are dry when plugging
to the socket.
If failed to follow the mentioned instruction,
user may get electric shock or burned.
Water
Water
Neutral Detergent
Neutral Detergent
Water
Neutral Detergent
Water
OK
AUTO EMERGENCY
MENU
Heating
Method
Position
OK
AUTO EMERGENCY
MENU
Heating
Method
Position

25 26
NOVA Ⅱ
180W
1160×770×1265mm
（ )L×W×H
84/100.5kg
Malfunction guide
FAQ and Troubleshooting
Note: If the troubles are not caused by above reasons, please turn off the power switch and
cut off the power, then contact the manufacturer or service agent to repair your chair.
Trouble Possible reason Troubleshooting
The massage chair can't
work after power is on.
Massage function suddenly
stops while working.
Check if the control is on or not.
Setting time is up.
Open control switch
Not choose massage function Choose massage function
Normal sound, no need to pay
attention to it.
Normal, no need to pay attention to it.
Turn off the power to have the
massager rest for over half an
hour before next turn working.
Connect the electricity power again
Check whether the plug and socket
in poor contact.
It is sound of air pump, motor and
mechanical parts.
Inner parts fretted away due to long
time work. It’s normal
Sound suddenly becomes
much louder while working.
Remove the obstacles; turn off
the power to have the massager
rest for over half an hour before
next turn working.
Check if there are any obstacles; the
chair overloads; for the sake of safety,
sometimes the massage machine may
automatically stop working.
Neither the backrest nor the
legrest can be lay down.
Please ask manufacturer or appointed
or authorized maintenance man for
checking and replacement.
Excessive operation; setting time is up.
The chair can't return to its
original position.
Massage rollers work on shifts.
Different height of the left
roller and right roller.
Make sure plug and socket are connected.
There is beep sound inside
the massager while working.
Check if it is due to long time working.
Please ask appointed or authorized
maintenance man for checking and
repairing.
Electric wire or plug
give out heat
Turn off the power to have the
massager rest for over half an
hour before next round working.
Wire or plug has damaged.
Please ask manufacturer or appointed
or authorized maintenance man for
checking and replacement.
The fuse burned out.
Replace fuse of same specification.
Something wrong with inner circuit
Please ask appointed or authorized
maintenance man for checking and
repairing.
Suddenly power-down
Turn off the power to have the
massager rest for over half an
hour before next turn working.
Stop using，and ask appointed
maintenance man for help.
It may work overload
Other abnormal case
Others
Technical data
Technical data
Others
Name
Model
Input voltage
Safety design
NW/GW
Packing size
Power
Class
Massage Chair
Ⅰ
□120V~ 60Hz
□220V~ 50/60Hz
□240V~ 50Hz
