komodo ATVSBCF User manual

ATV
Owner's ManualOwner's Manual
FLIP
ATV
FLIP
Congratulations on your purchase of Komodo ATV Flip Single Bucket Carrier. We build the
carrier to be durable for years of trouble free use. We provide you the innovative design which
allows the carrier to be used for standard 5 gallon buckets and folds up when not in use. With
proper installation and maintenance the carrier will be a reliable tool providing greater use and
will increase the value of your ATV.
#ATVSBCF
TM
SINGLEBUCKETCARRIER
SINGLEBUCKETCARRIER

Read, study, and follow all instructions before attempting to use these
devices. Failure to follow instruction or head warnings may result in
personaland/orpropertydamage.
Do not attach Single Bucket carrier where it will interfere with safe
operationofATV.
Caution: attaching Single Bucket carrier where it may extend out
beyond ATV may cause it to get caught on passing objects, care
should be taken when Bucket Carrier is in down position and ATV is
in motion.
Always secure the bucket in the carrier with straps and make sure items
inbucketscannotflyout.
Caution should be taken if bungee's or rubber straps are used to hold
itemincarrierasthesemayallowforitemtobounceandcancauseinjury
ifstrapdisengagesorsnaps.
Do not place items in carrier which exceed 50 lbs. or the limit of the
factoryATVrack.
Do not cantilever the mounting bracket more than 1” beyond the rack as
thiswilldramaticallyreducetheweightcapacityofthecarrier.
Specialcareshouldbetakenwhentransportingflammableliquidsasthe
mayspillasthevehicleisinmotion,causingpossibledamageorinjuryto
ATVorrider.
Make sure all bolts are tight before use and periodically check for
tightnessas vibrationmaycausenutstoloosen overtimeandcancause
damagetocarrierorpersonalinjury.
Donotforce screws as thismaycausethreadstostrip,whichmay cause
damagetocarrierorpersonalinjury.
DoNotoperateATVwithoutSnapPininplaceasthismaycausedamage
WARNINGSWARNINGS
1

PartsList/DiagramPartsList/Diagram
2
No. Qty. Description
1 1
Hinged Bucket Plate
2 1 Hinged Pin
3 1 Hinged Bucket Frame
4 1 Bucket Support Strap
5 2 6mmX38mm Hex Bolt
6 1 6mmX45mm Snap Pin
7 1 Chain Lanyard
8 8 6mm Lock Nut
9 2 6mmX20mm Clevis Pin & Clip
10 2 6mmX20mm Hex Bolt & Nut
11 2 Mounting Plate
12 4 6mmX80mm Hex Bolt
13 8 6mm Flat Washer
Insert Hinge Pin (2) through Hinged Bucket
Frame (3) and Hinged Bucket Plate (1), Using
2ea. Screw (5) and 2ea. Nylok Nut (8) line up
holes and fasten hinge pin to bucket frame.
Note:Pins(14) can be substituted for screws (5)
to allow for bucket carrier to be removed from
ATVeasily,leavingonlythemountingplate(1).
AssemblyInstructions(Carrier):AssemblyInstructions(Carrier):
Next using, 2ea. Screws (10) and 2ea. Clevis Pin & Clip (9),Attach Bucket Support Strap
(4)toBucketFrame(3)asshown.
Note: one screw and one pin per each side, hole farthest from mounting plate when in down
position should have pin.
14 2
6mmX40mm Pin (not included)
Suggestion: Using a 6mmx40mm Clevis Pin and Clip to replace
part number 5 will allow a faster flipping of your carrier.
6mmX40mm Clevis Pins and Clips should be available at most
local hardware stores.
(not included)

AttachmentInstructions:AttachmentInstructions:
Using two mounting plates (11), four bolts (12), four
nuts (8), and eight washers (13) secure the Bucket
plate(1)totheATVrack,asshown.
Note: do not cantilever the mounting plate more than 1”
beyond the rack. The brackets should be placed where
they straddle the factory rack tube. Do not fully tighten
fasteners at this time. Care should be taken to assure
that the bolt heads and brackets will not interfere with
ability to flip the Bucket carrier. Also that bolts do not
contact plastic or other parts of the ATV that may get
scratched or damaged. Bolts should be cut down to
prevent interference.
UseofCarrier:UseofCarrier:
Once Single Bucket Carrier is installed properly, insert bucket and properly secure using
tie-downsoradditionalfasteningmethod.
Note: make sure screws are tightened before using carrier.
3
KOMODOATVAccessories
1311 John Reed Ct.
City of Industry, CA 91745 USA
1(800)333-8889
For parts or warranty issues contact:
REV. UTVSBCF.082809
Verify that the Single Bucket Carrierfitsproperlyand does not interfere while operating the
ATV,tightenallboltsmakingsurethatmountingbracketiscorrectlyaligned.
Note: it is normal for the mounting brackets to deform as they are tightened. For composite
racks find the best mounting hole location and mount brackets, making sure to have access to
the mounting nuts from underneath.
IN USE POSITION - Using Snap Pin (6) insert into hinge hole
location to prevent Bucket Frame from bouncing up and causing
damage.
STORED POSITION – Remove Snap Pin (6) and rotate 180°,
reinsert Snap Pin. Remove Clevis Pin (9) from Bucket Support
Strap(4)androtate90°andreinsertClevisPinandClip.
In Use Position Stored Position
Patent Pending
