bizhub 223/283/363/423
Product Guide
Status: 15.07. 2010 Version: 1.1

2
bizhub 223/283/363/423
P
Pr ro od du uc ct t B Ba as si ic c
MODEL DEVELOPMENT CODE Taiga 0 Taiga 1 Taiga 2 Taiga 3 Product
Basic
PROPOSED MODEL NAME bizhub 423 bizhub 363 bizhub 283 bizhub 223 Product
Configuration
SUCCESSOR MODEL FOR bizhub 421 bizhub 362 bizhub 282 bizhub 222 System
Specifications
ESTIMATED SALES START 06/10 06/10 06/10 06/10
Copier
Specifications
DATAQUEST SEGMENT III III II II
Printer
Specifications
ALSO AVAILABLE AS Develop ineo
423 Develop ineo 363 Develop ineo 283 Develop ineo 223 Scanner
Specifications
TYPE Console/Stationary Platen Fax
Specifications
MAX. MONTHLY COPY VOLUME 60 k 48 k 28 k 19 k Consumables
AVERAGE MONTHLY COPY VOLUME 10.7 k 7.9 k 4.8 k 2.9 k Article Numbers
MACHINE LIFE 1,200 k or 5 years* 800 k or 5
years* 500 k or 5 years* Recommended
Media
SCANNER LIFE 200 k Appendix
MCBF Body
(Mean Copies Between Failure) --- --- --- ---
MCBF System
(Mean Copies Between Failure) 72.4 k 62.2 k 48.5 k 33.6 k
MCBJ (Mean Copies Between Jam) 10 k
MCBV (Mean Copies between Visit) no data
MTTR (Mean Time To Repair) 30 min. or less
MACHINE SETUP TIME Main Body: within 30 min.
Full System: within 60 min.
SAFETY & ENVIRONMENT
English Data Sheets InfoHub / Business Solutions / Safety and Environment
German Data Sheets http://partner.konicaminolta.de
* whichever comes first

3
bizhub 223/283/363/423
P
Pr ro od du uc ct t C Co on nf fi ig gu ur ra at ti io on n
SYSTEM DIMENSIONS Product
Basic
Product
Configuration
System
Specifications
Copier
Specifications
Printer
Specifications
Scanner
Specifications
Fax
Specifications
Consumables
Article Numbers
Recommended
Media
Appendix

4
bizhub 223/283/363/423
SYSTEM CONFIGURATION Product
Basic
Product
Configuration
System
Specifications
Copier
Specifications
Printer
Specifications
Scanner
Specifications
Fax
Specifications
Consumables
Article Numbers
Recommended
Media
Appendix
bizhub 223/283
FK-508
Fax board
EK-605
I/F kit
1st
2nd
AU-102
Biometric
Authentication
AU-201 or other
IC-Card Authentication
EK-604
I/F kit
FS-527
50 sheet Staple finisher
KH-101
Keyboard Holder
WT-506
Working Table
LK-101v2
i-Option license
LK-102
i-Option license
UK-203
i-Option Memory
SD-509
Saddle Kit
PK-517
Punch Kit
JS-603
Job Separator
MK-726
Fax Mount Kit
LK-105
i-Option license
FS-529
Embedded
JS-505
Job Separator
PC-208
2x Universal Tray DK-508
Copier Desk
PC-109
1x Universal Tray
PC-409
Large Capacity Tray
OC-509
Original Cover DF-621
Document Feeder
HD-516
Hard disc
SC-507
Security Kit

5
bizhub 223/283/363/423
SYSTEM CONFIGURATION Product
Basic
Product
Configuration
System
Specifications
Copier
Specifications
Printer
Specifications
Scanner
Specifications
Fax
Specifications
Consumables
Article Numbers
Recommended
Media
Appendix
bizhub 363/423
FK-508
Fax board
EK-605
I/F kit
1st
2nd
AU-102
Biometric
Authentication
AU-201 or other
IC-Card Authentication
EK-604
I/F kit
FS-527
50 sheet Staple finisher
KH-101
Keyboard Holder
WT-506
Working Table
LK-101v2
i-Option license
LK-102
i-Option license
UK-203
i-Option Memory
SD-509
Saddle Kit
PK-517
Punch Kit
JS-603
Job Separator
MK-726
Fax Mount Kit
LK-105
i-Option license
FS-529
Embedded
JS-505
Job Separator
PC-208
2x Universal Tray DK-508
Copier Desk
PC-109
1x Universal Tray
PC-409
Large Capacity Tray
SC-507
Security Kit

6
bizhub 223/283/363/423
S
Sy ys st te em m S Sp pe ec ci if fi ic ca at ti io on ns s
DOCUMENT FEEDER (DF-621) Product
Basic
Availability Status Standard for bizhub 363/423
Option for bizhub 223/283 Product
Configuration
Original Size A6 – A3 System
Specifications
Original Weight Simplex: 35 ~ 128 g/m²
Duplex: 50 ~ 128g/m² Copier
Specifications
Tray Capacity 100 originals (80 g/m²) Printer
Specifications
Feeding Type Face up, upper sheet Scanner
Specifications
Dimensions (WxDxH) mm 596 x 542 x 116 Fax
Specifications
Weight (kg) Approx. 11.5 Consumables
ORIGINAL COVER (OC-509) Article Numbers
Availability Status Option for bizhub 223/283 Recommended
Media
Remark Required if no DF-621 is attached. Appendix
PAPER CASSETTES
Availability Status Standard
Capacity 2 x 500 sheets universal (80 g/m²)
Paper Format A5 – A3
Paper Weight 60 – 90 g/m²
Max. Paper Capacity 1150 sheets standard, max. 3650 sheets
PAPER FEED CABINET PC-109
Availability Status Option
Capacity 1 x 500 sheets universal (80 g/m²)
Paper Format A5 – A3

7
bizhub 223/283/363/423
PAPER FEED CABINET PC-109 cont.. Product
Basic
Paper Weight 60 – 90 g/m² Product
Configuration
Dimensions (WxDxH) (mm) 600 x 603 x 325 System
Specifications
Weight (kg) 30.0 Copier
Specifications
TWO WAY PAPER CABINET PC-208 Printer
Specifications
Availability Status Option Scanner
Specifications
Capacity 2 x 500 sheets universal (80 g/m²) Product
Basic
Paper Format A5 – A3 Fax
Specifications
Paper Weight 60 – 90 g/m² Consumables
Dimensions (WxDxH) (mm) 600 x 603 x 325 Article Numbers
Weight (kg) 33.0 Recommended
Media
LARGE CAPACITY CABINET PC-409 Appendix
Availability Status Option
Capacity 2,500 sheets (80 g/m²)
Paper Format A4 crosswise
Paper Weight 60 – 90 g/m²
Dimensions (WxDxH) (mm) 600 x 603 x 325
Weight (kg) 32.0
COPY DESK DK-508
Availability Status Option
Dimensions (WxDxH) (mm) 572 x 601 x 337
Weight (kg) 18.6

8
bizhub 223/283/363/423
DUPLEX UNIT Product
Basic
Availability Status Standard Product
Configuration
Capacity one sheet duplex System
Specifications
Paper Format A5 lengthwise – A3 Copier
Specifications
Paper Weight 60 – 90 g/m² Printer
Specifications
BYPASS Scanner
Specifications
Availability Status Standard Fax
Specifications
Capacity 150 sheets (80 g/m²) Consumables
Paper Format A6 – A3 (Width.: 90 to 297 mm, Length: 140 to 432 mm)
with automatic size detection Article Numbers
Paper Weight 60 to 210 g/m² Recommended
Media
Copy Media Envelopes (refer to recommended media), OHP, thick
paper Appendix
EMBEDDED FINISHER (FS-529)
Availability Status Option
Functionality Sorting, Grouping, Offset, Stapling
Paper Weight 60 – 271 g/m²
Paper Size A6 – A3
Stack Capacity 300 sheets A4, 250 sheets A3
Offset Shift 30 mm (Tray 1)
Staple Mode Corner front/back, 2-point
Stapling Capacity 50 sheets A4 (80 g/m²), 30 sheets B4 and bigger
Staples SK-602 (One cartridge is packed to the finisher)
Dimensions (WxDxH) (mm) 471 x 564 x 147
Weight (kg) 12

9
bizhub 223/283/363/423
50 SHEETS STAPLE FINISHER FS-527 Product
Basic
Availability Status Option Product
Configuration
Finishing Mode Non-sort, sort, group, staple, punch (option), fold (option) System
Specifications
Tray Capacity 200/3000 sheets A4, 200/1500 sheets A3,
20 sheets OHP/Labels Copier
Specifications
Paper Weight 60 – 300 g/m² Printer
Specifications
Paper Size A6 – A3 Scanner
Specifications
Offset Shift 30 mm (Tray 2) Fax
Specifications
Stapling Modes Corner (front/back), centre 2 points, saddle stitch (option) Consumables
Stapling Capacity Max. 50 sheets, depending on paper weight Article Numbers
Stapling Format A3 – A5 lengthwise Recommended
Media
Staples SK-602 (one staple cartridge is packed to the finisher) Appendix
Dimensions (WxDxH) (mm) 658 x 641 x 1,025
Weight (kg) 42
Remark Options for FS-527: PK-517 for Europe/Sweden, SD-509
and JS-603
SADDLE KIT SD-509
Availability Status Option for FS-527
Folding Crease fold
Paper Size A4 lengthwise / A3W (311 x 457 mm)
Paper Weight 60 – 209 g/m²
Tray Capacity 20 sets (1-3 pages), 5 sets (11-15 pages)
Stapling Modes Centre parallel 2 points (booklet staple)
Stapling Capacity 15 sheets (14 sheets 90 g/m² + 1 sheet 209 g/m²)
Staples SK-602 (one staple cartridge is packed to the Saddle Kit)

10
bizhub 223/283/363/423
SADDLE KIT SD-509 cont… Product
Basic
Dimensions (WxDxH) (mm) 239 x 579 x 534 Product
Configuration
Weight (kg) 24 System
Specifications
PUNCH KIT PK-517 for
Europe/Sweden Copier
Specifications
Availability Status Option for FS-527 Printer
Specifications
Punch Method On-line, page by page, 4 holes Scanner
Specifications
Hole Diameter 6.5 mm ± 0.5 mm Fax
Specifications
Paper Size A3, B4, A4 L, B5 L Consumables
Paper Weight 60 – 256 g/m² Article Numbers
Dimensions (WxDxH) (mm) 58 x 470 x 135 Recommended
Media
Weight (kg) 1.8 Appendix
Remark Punch mode can’t be used together with the folding mode,
stitch and fold mode or 3-folding mode
JOB SEPARATOR JS-603
Availability Status Option for FS-527
Paper Weight 60 – 90 g/m²
Paper Size A5 – A3W (311 x 457mm)
Stacking Capacity Max. 100 sheets (60 – 90 g/m²), 10 sheets (91 – 300 g/m²)
Dimensions (WxDxH) (mm) 165 x 389 x 63
Weight (kg) 1.0
JOB SEPARATOR JS-505
Availability Status Option
Number of Trays 2
Tray Capacity Tray 1: 150 sheets (60 – 90 g/m²),
Tray 2: 50 sheets (60 – 90 g/m²)
