INSTALLATION MANUAL
A083-9560-02
JS-505 Job Separator
I. Accessory parts
Note:
This manual provides the illustrations of the acces-
sory parts and machine that may be slightly differ-
ent in shape from yours. In that case, instead of
the illustrations, use the appearance of your
machine to follow the installation procedure. This
does not cause any significant change or problem
with the procedure.
II. Installation procedures
1. Turn off the machine and unplug the power cord
from the power outlet.
2. Remove protective tape and shipping materials
and take out accessory parts.
3. Remove the protective vinyl bag from the hookup
cord.
No. Name Shape Q’ty
1. Job separator
1
2. Mounting cover
1
3. Spacer A
1
4. Spacer B
1
5. Shoulder screw
1
6. Screw A
(3 × 8 mm) 4
7. Screw B
(3 × 16 mm)
2
8. Installation
manual
1 set
A083IXC001DA
A083IXC027DA
A083IXC028DA
A083IXC029DA
A083IXC030DA
9738
4551IXC028DA
4980IXC019DA
After unpacking, be sure to get rid of the
packaging materials and keep them out of
the reach of children.
Putting the head in the plastic bag
involves danger of suffocation.
A083IXC013DB
4. Attach the supplied spacer A and spacer B to the
locations of the job separator as shown in the
illustration. (Each two supplied screw A’s)
Note:
To attach the spacers, put the job separator upside
down on a flat surface.
5. Remove the output tray if it is mounted on the
machine.
* Remove it while pushing the claws of the output
tray in the direction of the allow ➀shown on the
illustration and unhook.
6. Peel seal off the machine.
7. Peel seals off the machine. (Two seals)
Note:
Perform this step only when the machine has the
seals on the places shown in the illustration.
8. Remove the cover from the main body as shown
in the illustration. (One screw)
A083IXC031DA
Spacer B
Spacer A
A083IXC006DB
➀
➀
A083IXC045DA
A083IXC032DB
83IXC033DA
< C360/C280/C220 >
A0HRIXC054DA
< 423/363/283/223 >
Applied Machines: C360/C280/C220/423/363/283/223
COLOR MFP: 36 ppm/28 ppm/22 ppm
MFP: 42 ppm/36 ppm/28 ppm/22 ppm
Product Code: A0ED/A1UD/A1UE/A1UF/A1UG
