Konig CMP-WNROUT50 User manual

2013-01-29
CMP-WNROUT50
CMP-WNROUT55
CMP-WNROUT60
MANUAL (p. 2)
Wireless router
ANLEITUNG (S. 48)
WLAN-Router
MODE D’EMPLOI (p. 96)
Routeur sans fil
GEBRUIKSAANWIJZING (p. 145)
Draadloze router
MANUALE (p. 193)
Router Wireless
MANUAL DE USO (p. 241)
Router inalámbrico
HASZNÁLATI ÚTMUTATÓ (o. 289.)
Vezeték nélküli útválasztó
KÄYTTÖOHJE (s. 336)
Langaton reititin
BRUKSANVISNING (s. 383)
Trådlös router
NÁVOD K POUŽITÍ (s. 431)
Bezdrátový router
MANUAL DE UTILIZARE (p. 479)
Ruter wireless
ΕΓΧΕΙΡΙΔΙΟ XPHΣHΣ(σελ. 526)
Ασύρματο ρούτερ
BRUGERVEJLEDNING (s. 576)
Trådløs router
VEILEDNING (s. 624)
Trådløs ruter
ИНСТРУКЦИЯ (стр. 671)
Беспроводной маршрутизатор

2
ENGLISH
Wireless router
1) HARDWARE CONFIGURATION
CMP-WNROUT50
Auto MDI/MDIX RJ-45 Ports
Automatically senses the types of WAN and
LAN when connecting to the Ethernet
Reset Button
Power Jack
Antenna
LAN1~LAN4 LEDs
Status LED WAN LED Wi-Fi LED
2 in 1 Button
1. WPS
2. Wireless On

3
LED INDICATORS
LED status Description
Status Green flash Device status is working
Green RJ45 cable is plugged in
WAN LED
Green flash Data access
Green RJ45 cable is plugged in
LAN LED
Green flash Data access
Green Wi-Fi is on
Green flash Data access
Green fast flash Device is in WPS PBC mode
Wi-Fi LED
Dark green Wi-Fi is disabled
BUTTON DEFINITION
Description
WPS
1. When wireless is switched off, press and hold this button for about 1 second to
enable “wireless radio”.
2. When wireless is switched on, press and hold this button for about 1 second to
execute WPS function.
Reset Press and hold for 6 seconds to reset to default settings

4
CMP-WNROUT55 and CMP-WNROUT60
Power Jack
Antenna
Auto MDI/MDIX RJ-45 Ports
Automatically senses the types of WAN and
LAN when connecting to the Ethernet
LAN1~LAN4 LEDs
Status LED WAN LED Wi-Fi LED
CMP-WNROUT60
2 in1 Button
1. WPS
2. Wireless On
CMP-WNROUT55
3 in 1 Button
1. WPS
2. Wireless ON
3. Reset

5
LED INDICATORS
LED status Description
Status Green flash Device status is working
Green RJ45 cable is plugged in
WAN LED
Green flash Data access
Green RJ45 cable is plugged in
LAN LED
Green flash Data access
Green Wi-Fi is on
Green flash Data access
Green fast flash Device is in WPS PBC mode
Wi-Fi LED
Dark green Wi-Fi is disabled
BUTTON DEFINITION
Description
CMP-WNROUT55
When wireless is switched on, press and hold this button (about 1 sec) to execute
WPS function
WPS CMP-WNROUT60
1. When wireless is switched off, press and hold this button (about 1 sec) to
enable “Wireless Radio”
2. When wireless is switched on, press and hold this button (about 1 sec) to
execute WPS function
Wireless On
(CMP-WNROUT55
only)
When wireless is switched off, press and hold this button (about 1 sec) to enable
“Wireless Radio”
CMP-WNROUT55
1. Press this button and switch on the device
2. Press and hold for about 3 – 4 seconds. The device will reset to the default
settings. Then the Status LED flashes every second in Normal status
Notice: If the Status LED flashes very fast, it means this button was pressed too
long. Please try again
Reset
CMP-WNROUT60
Press and hold this button for 6 seconds to reset to default settings. Release the
button when the device works simultaneously.

6
2) HOW TO OPERATE
Step 1. Insert the Ethernet cable into the LAN
Port:
Insert one end of the Ethernet patch cable into
the LAN port on the back panel of the router, and
the other end into an available Ethernet port on
the network adapter of the computer you will use
to configure the unit.
Step 2. Insert the Ethernet patch cable into
the wired WAN port:
Insert the Ethernet patch cable from the DSL
modem into the wired WAN port on the back
panel of the router.
Step 3. Power on the router:
Connect the power adapter to the receptor on the
back panel of your router.
Step 4. Complete the setup.

7
Insert the CD into the CD-ROM reader of your PC. The program, AutoRun, will be executed
automatically. Click the Easy Setup icon for this utility.
Configure the settings by following the steps below:
2.1
Select the correct language and click “Next” to
continue.
2.2 Setup Mode
You can select Wizard mode to run the setup
step by step or run Advanced mode to
diagnose the network settings of the router.

8
2.3 Advanced Mode Setup.
Check the PC, router or Internet icons for the
status of your PC, router or Internet.
2.4 Quick Wizard Install Mode Setup
1. Check if the router is powered on.
2. Check if your network adapter is connected
to the LAN port of the router.
3. Check if your network adapter has an IP
address.
Click “Next” to continue.
2.5 Wireless Setting
Key in the SSID, Channel and Security
options, and click “Next” to continue.

9
2.6 Auto Detect WAN Service.
Click “Next” to continue.
Disable this function by selecting “Let me
select WAN service by myself”.
Note: This function only supports the
detection of the Dynamic and PPPoE WAN
Services.
For example: the Dynamic WAN type is
detected.
When the detection process is finished, the
router is ready for use.
2.7 Select WAN Service manually.
In manual mode, select an icon and click
“Next” to continue.

10
2.8 Apply Settings or Modify.
Click “Next” to apply the settings and continue.
Click “Modify Settings” to change the settings.
2.9 Test the Internet Connection.
Test WAN networking service. Click “Next” to
continue.
You can ignore this step by selecting
“Ignore Test”.
2.10 Setup Completed.
The EzSetup is complete. You can now open
the default web browser to configure the
advanced settings of the router.
Click “Finish” to complete the installation.
