Kontron 786LCD/mITX User manual

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 1 of 77
User Manual
for
786LCD/mITX family
786LCD/mITX LV
(733/133MHz)
786LCD/mITX ULV
(400/100MHz)

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 2 of 77
Document revision history.
Revision Date By Comment
K Oct. 13th 2009 MLA Added info that CF support up to UDM2. Battery alternative
added. Added “mounting the board to chassis”.
J May 30th 2008 MLA PME/WOL option added to BIOS. Battery type updated.
I April 22nd 2008 MLA Battery load information added.
H Oct. 18th, 2007 MLA Note on CDROM audio connector and on ETHER2/3 connector.
Included warning in Installation procedure.
G May 25th, 2007 MLA USB0/3 pull-up resistor removed from description. USB
description modified. Suspend LED /HDD LED info added.
F Dec. 27th, 2006 MLA
USB port locations corrected. SATA and RAID installation guide
added. Riser card PCI IRQ and INT info added. “Onboard
connectors” updated. BIOS part updated. Other minor details
corrected.
E July 5th, 2006 MLA BKLTCTL and FAN3OUT signal description corrected.
D July 3rd, 2006 MLA
Pictures modified/added.
Chapter 3.3 corrected, chapter Power Concumption included.
Info on Boot Logo added.
RTC Resume function Watchdog Support added.
Added info to Fan Cruise Control.
C April. 26th, 2006 MLA Picture in Chapt. 4.1.1 changed. Feature Connector
specifications corrected.
B Mar. 17th, 2006 MLA
Page 12, 400MHz version has no onboard RAM. Sys Fan &
CPU Fan location exchanged. USB4/5 has no Shroud. Audio
connector pin 11/12 corrected to NC. Frontpanel connector pin 9
removed. Onboard Connector table updated. Chapter System
Resources added. BIOS description added.
A Feb 8th, 2006 MLA COMA-D corrected and changed to Port1 -4. LVDS Display res.
0 Sept 6th, 2005 PJA First preliminary manual version.
Copyright Notice:
Copyright ©2006, KONTRON Technology A/S, ALL RIGHTS RESERVED.
No part of this document may be reproduced or transmitted in any form or by any means, electronically or
mechanically, for any purpose, without the express written permission of KONTRON Technology A/S.
Trademark Acknowledgement:
Brand and product names are trademarks or registered trademarks of their respective owners.
Disclaimer:
KONTRON Technology A/S reserves the right to make changes, without notice, to any product, including
circuits and/or software described or contained in this manual in order to improve design and/or
performance.
Specifications listed in this manual are subject to change without notice. KONTRON Technology assumes
no responsibility or liability for the use of the described product(s), conveys no license or title under any
patent, copyright, or mask work rights to these products, and makes no representations or warranties that
these products are free from patent, copyright, or mask work right infringement, unless otherwise specified.
Applications that are described in this manual are for illustration purposes only. KONTRON Technology A/S
makes no representation or warranty that such application will be suitable for the specified use without
further testing or modification.

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 3 of 77
Life Support Policy
KONTRON Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN LIFE
SUPPORT DEVICES OR SYSTEMS WITHOUT EXPRESS WRITTEN APPROVAL OF THE GENERAL
MANAGER OF KONTRON Technology A/S.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for surgical implant into
body, or (b) support or sustain life and whose failure to perform, when properly used in accordance with
instructions for use provided in the labeling, can be reasonably expected to result in significant injury to
the user.
2. A critical component is any component of a life support device or system whose failure to perform can be
reasonably expected to cause the failure of the life support device or system, or to affect its safety or
effectiveness.
KONTRON Technology Technical Support and Services
If you have questions about installing or using your KONTRON Technology Product, check this User’s
Manual first – you will find answers to most questions here. To obtain support, please contact your local
Distributor or Field Application Engineer (FAE).
Before Contacting Support: Please be prepared to provide as much information as possible:
CPU Board
1. Type.
2. Part-number (Number starting with “535”).
3. Serial Number.
Configuration
1. CPU Type, Clock speed.
2. DRAM Type and Size.
3. BIOS Revision (Find the Version Info in the BIOS Setup in the Kontron Section).
4. BIOS Settings different than Default Settings (Refer to the Software Manual).
System
1. O/S Make and Version.
2. Driver Version numbers (Graphics, Network, and Audio).
3. Attached Hardware: Harddisks, CD-rom, LCD Panels etc.

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 4 of 77
Table of contents:
1. INTRODUCTION.....................................................................................................................................7
2. INSTALLATION PROCEDURE..............................................................................................................8
2.1 Installing the board............................................................................................................................8
2.2 Requirement according to EN60950................................................................................................9
3. SYSTEM SPECIFICATION...................................................................................................................10
3.1 Component main data .....................................................................................................................10
3.2 Configuration overview...................................................................................................................13
3.3 System Memory support.................................................................................................................14
3.4 Power consumption.........................................................................................................................14
3.5 System overview..............................................................................................................................15
3.6 786LCD Clock Distribution..............................................................................................................16
4. CONNECTOR DEFINITIONS................................................................................................................17
4.1 Connector layout..............................................................................................................................18
4.1.1 786LCD/mITX LV Plus................................................................................................................18
4.1.2 786LCD/mITX ULV Standard .....................................................................................................19
4.2 Power Connector (ATXPWR)..........................................................................................................20
4.3 Keyboard and PS/2 mouse connectors.........................................................................................21
4.3.1 Stacked MINI-DIN keyboard and mouse Connector (MSE & KBD) ...........................................21
4.3.2 keyboard and mouse pin-row Connector (KBDMSE).................................................................21
4.4 Display Connectors .........................................................................................................................22
4.4.1 CRT Connector (CRT)................................................................................................................22
4.4.2 LVDS Flat Panel Connector (LVDS)...........................................................................................23
4.4.3 DVI Interface Connector (DVI IFC).............................................................................................24
4.4.4 AGP connector - TBD .................................................................................................................25
4.5 Parallel ATA harddisk interface......................................................................................................29
4.5.1 IDE Hard Disk Connector (IDE_P) .............................................................................................30
4.5.2 IDE Hard Disk Connector (IDE_S2) ...........................................................................................30
4.5.3 CF Connector (CF) .....................................................................................................................31
4.6 Serial ATA harddisk interface.........................................................................................................32
4.6.1 SATA Hard Disk Connector (SATA0, SATA1) ...........................................................................32
4.7 Firewire / IEEE1394 connector .......................................................................................................33
4.7.1 IEEE1394 Connector (IEEE1394_0 and IEEE1394_1)..............................................................33
4.8 Printer Port Connector (PRINTER).................................................................................................34
4.9 Serial Ports.......................................................................................................................................35
4.9.1 Serial Port1 DB9 Connector. ......................................................................................................35
4.9.2 Serial Port2, Port3 & Port4 Pin Header Connectors...................................................................35
4.10 Ethernet connectors. ...................................................................................................................36

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 5 of 77
4.10.1 Ethernet connector 1 (ETHER1).................................................................................................36
4.10.2 Ethernet connector 2/3 (ETHER2/3)...........................................................................................37
4.11 USB Connector (USB)..................................................................................................................38
4.11.1 USB Connector 0/3 (USB0/3).....................................................................................................38
4.11.2 USB Connector 2/5 (USB25)......................................................................................................38
4.12 Audio Connector ..........................................................................................................................39
4.12.1 Audio Line-in, Line-out and Microphone.....................................................................................39
4.12.2 CD-ROM Audio input (CDROM).................................................................................................39
4.12.3 AUDIO Header (AUDIO HEADER).............................................................................................40
4.13 Fan connectors , SYSTEM FAN and CPU FAN..........................................................................41
4.14 The Clear CMOS Jumper, Clr-CMOS..........................................................................................41
4.15 LPC IFC connector (unsupported). ............................................................................................41
4.16 Front Panel connector (FRONTPNL)..........................................................................................42
4.17 Feature Connector (FEATURE)...................................................................................................43
4.17.1 PCI Slot Connector .....................................................................................................................44
4.17.2 Signal Description –PCI Slot Connector.....................................................................................45
4.17.3 786LCD PCI IRQ & INT routing..................................................................................................46
5. ONBOARD CONNECTORS .................................................................................................................47
6. SYSTEM RESSOURCES......................................................................................................................48
6.1 Memory map.....................................................................................................................................48
6.2 PCI devices.......................................................................................................................................48
6.3 Interrupt Usage ................................................................................................................................49
6.4 I/O Map ..............................................................................................................................................50
6.5 DMA Channel Usage........................................................................................................................50
7. OVERVIEW OF BIOS FEATURES.......................................................................................................51
7.1.1 System Management BIOS (SMBIOS / DMI) .............................................................................51
7.1.2 Legacy USB Support ..................................................................................................................51
8. BIOS CONFIGURATION / SETUP .......................................................................................................52
8.1 Introduction......................................................................................................................................52
8.2 Main Menu.........................................................................................................................................52
8.3 Advanced Menu................................................................................................................................53
8.3.1 Advanced settings – CPU Configuration ....................................................................................53
8.3.2 Advanced settings – IDE Configuration......................................................................................54
8.3.3 Advanced settings – LAN Configuration.....................................................................................56
8.3.4 Advanced settings – SATA/RAID Configuration.........................................................................57
8.3.5 Advanced settings – FW/IEEE 1394 Configuration....................................................................57
8.3.6 Advanced settings – SuperIO Configuration ..............................................................................58
8.3.7 Advanced settings – Voltage Monitor .........................................................................................59
8.3.8 Advanced settings – Hardware Health Configuration ................................................................60
8.3.9 Advanced settings – Remote Access Configuration ..................................................................61
8.3.10 Advanced settings – USB Configuration ....................................................................................62

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 6 of 77
8.3.11 Advanced settings – USB Mass Storage Device Configuration.................................................63
8.3.12 Advanced settings – ACPI Settings............................................................................................64
8.3.13 Advanced settings – General ACPI Configuration .....................................................................65
8.3.14 Advanced settings – Advanced ACPI Configuration ..................................................................65
8.4 PCIPnP Menu....................................................................................................................................66
8.5 Boot Menu.........................................................................................................................................67
8.5.1 Boot – Boot Settings Configuration ............................................................................................68
8.5.2 Boot – Boot Device Priority.........................................................................................................69
8.6 Security Menu...................................................................................................................................70
8.7 Chipset Menu....................................................................................................................................71
8.7.1 Advanced Chipset Settings – Configure advanced settings for SouthBridge ............................71
8.8 Power Menu......................................................................................................................................73
8.9 Exit Menu..........................................................................................................................................74
8.10 AMI BIOS Beep Codes.................................................................................................................75
9. OS SETUP.............................................................................................................................................76
9.1 How to install SATA and RAID while installing Windows XP .....................................................76
10. WARRANTY..........................................................................................................................................77

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 7 of 77
1. Introduction
This manual describes the 786LCD/mITX board made by KONTRON Technology A/S. The boards will also
be denoted 786LCD family if no differentiation is required.
All boards are to be used with the Intel® Celeron® LV and ULV Processors.
Use of this manual implies a basic knowledge of PC-AT hard- and software. This manual is focused on
describing the 786 Board’s special features and is not intended to be a standard PC-AT textbook.
New users are recommended to study the short installation procedure before switching-on the power.
All configuration and setup of the CPU board is either done automatically or by the user in the CMOS setup
menus. Except for the CMOS Clear jumper, no jumper configuration is required.

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 8 of 77
!
! Warning: When mounting the board to chassis etc. please notice that the board contains
components on both sides of the PCB which can easily be damaged if board is handled
without reasonable care. A dama
g
ed com
p
onent can result in malfunction or no function at all.
2. Installation procedure
2.1 Installing the board
To get the board running, follow these steps. In some cases the board shipped from KONTRON Technology
has SDRAM mounted. In this case Step 2 can be skipped.
1. Turn off the power supply.
2. Insert the SDRAM module (optional). Be careful to push it in the slot before locking the tabs. For a list of
approved SDRAM modules contact your Distributor or FAE.
PC133,168pin SDRAM modules are supported.
3. Insert all external cables for hard disk, keyboard etc. except for flat panel. A CRT monitor must be
connected in order to change CMOS settings to flat panel support. To achieve UDMA-66/100/133
performance on the IDE interface, 80poled UDMA cables must be used. If using the IDE_S2 connector
care should be taken in correct orientation when attaching the female cable. The cables that KONTRON
provide do not have a key. There is possibility of damage to the HDD or PCB if the cable is not orientated
correctly.
4. Connect power supply to the board by the ATXPWR connector.
5. Turn on the power on the ATX power supply.
6. The PWRBTN_IN must be toggled to start the Power supply; this is done by shorting pins 16
(PWRBTN_IN) and pin 18 (GND) on the FRONTPNL connector (see Connector description). A “normally
open” switch can be connected via the FRONTPNL connector.
7. Enter the BIOS setup by pressing the “F2” key during boot up. Refer to the Software Manual (under
preparation) for details on BIOS setup.
Enter Advanced Menu / CPU Configuration / Intel SpeedStep Tech. and set this option to “Maximum
Performance”.
Note: To clear all CMOS settings, including Password protection, move the CMOS_CLR jumper (with or without
power) for approximately 1 minute. Alternatively turn off power and remove the battery for 1 minute, but be
careful to orientate the battery corretly when reinserted.
8. Mounting the board to chassis
When fixing the Motherboard on a chassis it is recommended using screws with integrated washer and
having diameter of ~7mm.
Note: Do not use washers with teeth, as they can damage the PCB mounting hole and may cause short
circuits.
Note: If the Audio Amplifier shall be used to generate up to 3W on the Audio output channels,
then make sure that sufficent airflow is around the Audio Amplifier. The Amplifier has integrated
Thermal Protection and will not be damaged even though the airflow is insufficient for normal
o
p
eration.

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 9 of 77
2.2 Requirement according to EN60950
Users of 786LCD boards should take care when designing chassis interface connectors in order to fulfill the
EN60950 standard:
Lithium Battery precautions:
CAUTION!
Danger of explosion if battery is incorrectly
replaced.
Replace only with same or equivalent type
recommended by manufacturer.
Dispose of used batteries according
to the manufacturer’s instructions.
VORSICHT!
Explosionsgefahr bei unsachgemäßem Austausch
der Batterie.
Ersatz nur durch den selben oder einen vom
Hersteller empfohlenen gleichwertigen Typ.
Entsorgung gebrauchter Batterien nach
Angaben des Herstellers.
ADVARSEL!
Lithiumbatteri – Eksplosionsfare ved fejlagtig
håndtering.
Udskiftning må kun ske med batteri
af samme fabrikat og type.
Levér det brugte batteri tilbage til leverandøren.
ADVARSEL
Eksplosjonsfare ved feilaktig skifte av batteri.
Benytt samme batteritype eller en tilsvarende
type anbefalt av apparatfabrikanten.
Brukte batterier kasseres i henhold til fabrikantens
instruksjoner.
VARNING
Explosionsfara vid felaktigt batteribyte.
Använd samma batterityp eller en ekvivalent
typ som rekommenderas av apparattillverkaren.
Kassera använt batteri enligt fabrikantens
instruktion.
VAROITUS
Paristo voi räjähtää, jos se on virheellisesti
asennettu.
Vaihda paristo ainoastaan laltevalmistajan
suosittelemaan
tyyppiln. Hävitä käytetty paristo valmistajan
ohjeiden
mukaisesti.
When an interface/connector has a VCC (or other power) pin, which is directly connected to a power
plane like the VCC plane:
To protect the external power lines of peripheral devices the customer has to take care about:
•That the wires have the right diameter to withstand the maximum available power.
•That the enclosure of the peripheral device fulfils the fire protecting requirements of IEC/EN 60950.

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 10 of 77
3. System specification
3.1 Component main data
The table below summarises the features of the 786LCD/mITX embedded motherboard.
Form factor 786LCD/mITX: mini ITX (170.18millimeters by 170.18millimeters)
Processor •Support for Intel Celeron LV and Celeron ULV Processors in mPGA478 socket
with 400MHz system bus.
Memory •Onboard 128MB or 256MB PC133 SDRAM mounted depending on configuration.
•1x168pin DDR SDRAM Dual Inline Memory Module (DIMM) sockets. Support of
up to 256MB memory modules.
•Support for up to 512MB of system memory (onboard 256MB + 256MB in DIMM
socket)
•ECC support is not supported
Chipset Intel 815E Chipset consisting of:
•Intel 82815 Graphics and Memory Controller Hub(GMCH)
•I/O Controller Hub (ICH or ICH2)
Video •Intel Graphics controller
•Analog Display Support, 230-MHz integrated 24-bit RAMDAC with support for
analogue monitors up to 1600x1200x8bit at 85 Hz
•DVI interface support (depending on configuration)
•LVDS panel support, single or dual channel, 1280x1024 max. (1024x768 max.
using 786LCD/mITX ULV), DOS, WinXP/XPe/2000/CE.NET
•AGP 2.0, 1.5V connector (supporting 1x, 2x, and 4x AGP cards).
•DVO on AGP connector not supported
Audio Audio, AC97 version 2.3 subsystem using the Realtek ALC655 codec
•Audio Amplifier: 2x3W
•Line-out
•CDROM in
•SPDIF Interface
•Microphone
Onboard speaker
I/O Control Winbond W83627THF LPC Bus I/O Controller
Peripheral
interfaces •Six USB 2.0 ports
•Two IEEE Std 1394a-2000 fully compliant cable ports at 100M bits/s, 200M
bits/s, and 400M bits/s
•Four Serial ports (RS232).
•One Parallel port, SPP/EPP/ECP
•Two Serial ATA 150 IDE interfaces
•Two Parallel ATA IDE interfaces with UDMA 33, ATA-66/100 support
•PS/2 keyboard and mouse ports
•CF (Compact Flash) interface supporting CF type I and II. (UDMA2 max.). Note
that no PATA device is supported on the secondary IDE port when CF is used.
Optionally use SATA devices.
(continued)

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 11 of 77
LAN Support 3x 10/100Mbits/s LAN subsystem using the Realtek RTL8100C LAN controllers or
1x 10/100Mbits/s LAN subsystem using the Realtek RTL8100C LAN controllers
depending on board configuration.
PXE and RPL netboot supported. Wake On LAN (WOL) supported.
BIOS •Kontron Technology / AMI BIOS (core version)
•Support for Advanced Configuration and Power Interface (ACPI 1.0, 2.0), Plug
and Play
oSuspend To Ram
oSuspend To Disk
•SW Watchdog and RTC Resume supported by BIOS 0.7 an above
•Secure CMOS/ OEM Setup Defaults
•“Always On” BIOS power setting
•Boot Logo is optional (640x480, 24bit color) in customer specific BIOS
Instantly
Available PC
Technology
•Support for PCI Local Bus Specification Revision 2.2
•Suspend to RAM support
Expansion
Capabilities •SMBus routed to FEATURE connector
•LPC Bus routed to LPC connector
•DDC Bus routed to LVDS connector
•8 x GPIOs (General Purpose I/Os) routed to FEATURE connector
•PCI Bus routed to PCI slot (PCI Local Bus Specification Revision 2.2)
Hardware
Monitor
Subsystem
•Fan control system for three onboard Fan control connectors: CPU FAN,
SYSTEM FAN and FEATURE
•Three thermal inputs: CPU die temperature, System temperature and External
temperature input routed to FEATURE connector.
•Voltage monitoring
•Intrusion detect input
•SMI violations (BIOS) on HW monitor not supported. Supported by API
(Windows).
Operating
Systems
Support
•Win2000
•WinXP
•Win98 (LVDS Display not supported)
•Win2003(LVDS Display not supported)
•WinXP Embedded (limitations may apply)
•WinCE.net (limitations may apply)
•Linux: Feodora Core 3, Suse 9.2 (limitations may apply)
(continued)

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 12 of 77
Environmental
Conditions Operating:
0°C – 60°C operating temperature (forced cooling). It is the customer’s responsibility
to provide sufficient airflow around each of the components to keep them within
allowed temperature range.
10% - 90% relative humidity (non-condensing)
Storage:
-20°C – 70°C
5% - 95% relative humidity (non-condensing)
Electro Static Discharge (ESD) / Radiated Emissions (EMI):
All Peripheral interfaces intended for connection to external equipment are ESD/ EMI
protected.
EN 61000-4-2:2000 ESD Immunity
EN55022:1998 class B Generic Emission Standard.
Safety:
UL 60950-1:2003, First Edition
CSA C22.2 No. 60950-1-03 1st Ed. April 1, 2003
Product Category: Information Technology Equipment Including Electrical Business
Equipment
Product Category CCN: NWGQ2, NWGQ8
File number: E194252
Theoretical MTBF:
199,799hours (22,8years) , Calculation based on Telcordia SR-332 method.
Restriction of Hazardeous Substances (RoHS):
The 786LCD-M family is planned for RoHS compliance.
Capacitor utilization:
No Tantal capacitors on board
Only Japanese brand Aluminium capacitors rated for 100degrees Celsius used on
board
Battery Exchangeable 3.0V Lithium battery for onboard Real Time Clock and CMOS RAM.
Manufacturer Panasonic / PN CR2032NL/LE, CR-2032L/BE or CR-2032L/BN.
Approximately 5 years retention varies depending on temperature, actual application
on/off rate and variation within chipset and other components.
Approximately current draw is 6.2µA (no PSU connected).
CAUTION: Danger of explosion if the battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 13 of 77
3.2 Configuration overview
Feature 810045-4500, 786LCD/mITX LV Plus 810046-4500, 786LCD/mITX ULV Standard
CPU Intel Celeron LV 733MHz Intel Celeron ULV 400 MHz
Onboard Memory 256MB SDRAM, PC133 No
CRT Yes Yes
LVDS Yes (Max. 1280x1024) Yes (Max. 1024x768)
DVI No No
LAN 3x10/100MBit 1x10/100MBit
IEEE1394 2xIEEE1394 No
PATA Yes Yes
SATA Yes No
Compact Flash Yes Yes
Audio Yes Yes
USB Yes, 6xUSB2.0 Yes, 6xUSB2.0
Serial Ports Yes, 4xRS232 Yes, 4xRS232
Parallel Port Yes Yes
PS/2 / KBD Yes Yes
PCI Yes Yes
AGP Yes Yes
Table is preliminary and subject to change without notification

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 14 of 77
3.3 System Memory support
The 786LCD/mITX board has one onboard DIMM sockets and optionally on board memory.
•Maximum total 512MB
•64-bit data interface
•ECC not supported
The onboard memory is:
•0 MB (786LCD/mITX ULV Standard)
•256 MB/ PC133 (786LCD/mITX LV Plus)
The socket memory can be:
•168-pin PC100/PC133 SDRAM DIMMs from 32 MB to 256 MB
•Single - or double sided DIMMs with gold-plated contacts.
Note: 786LCD/mITX ULV Standard running PC100 even PC133 is installed.
3.4 Power consumption
The following power consumptions is based on measurements and are typical values.
The Power consumption of Keyboard and Mouse are included and CRT, HD and Floppy are not included.
786LCD/mITX LV Plus (733MHz/PC133)
In Windows XP and running 3DMARK2000:
Supply Current draw Power
consumption
+3V3 3.2A 10.5 W
+5V 1.5A 7.5 W
+12V 333mA 4.0 W
+5VSB 160mA 0.8 W
Total power
consumption 22.8 W
In Windows XP idle, total power consumption is 19 W.
In Standby (S3) power consumption (+5VSB) is 1.2 W.
786LCD/mITX ULV Standard (400MHz/PC100)
In Windows XP 3DMARK2000:
Supply Current draw Power
consumption
+3V3 2.4A 8.0 Watt
+5V 920mA 4.6 Watt
+12V 210mA 2.5 Watt
+5VSB 145mA 0.7 Watt
Total power
consumption 15.8 Watt
In Windows XP idle, total power consumption is 13 W.
In Standby (S3) power consumption (+5VSB) is 1.1 W.

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 15 of 77
3.5 System overview
The block diagram below shows the architecture and main components of the 786LCD boards. The two key
components on the board are the Intel®815E and Intel®ICH4 Embedded Chipsets.
Components shown shaded may differ depending on variants of the board.

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 16 of 77
3.6 786LCD Clock Distribution

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 17 of 77
4. Connector Definitions
The following sections provide pin definitions and detailed description of all on-board connectors.
.
The connector definitions follow the following notation:
Column
name Description
Pin Shows the pin-numbers in the connector. The graphical layout of the connector definition
tables is made similar to the physical connectors.
Signal The mnemonic name of the signal at the current pin. The notation “XX#” states that the signal
“XX” is active low.
Type AI : Analog Input.
AO : Analog Output.
I : Input, TTL compatible if nothing else stated.
IO : Input / Output. TTL compatible if nothing else stated.
IOT : Bi-directional tristate IO pin.
IS : Schmitt-trigger input, TTL compatible.
IOC : Input / open-collector Output, TTL compatible.
NC : Pin not connected.
O : Output, TTL compatible.
OC : Output, open-collector or open-drain, TTL compatible.
OT : Output with tri-state capability, TTL compatible.
LVDS: Low Voltage Differential Signal.
PWR : Power supply or ground reference pins.
Ioh: Typical current in mA flowing out of an output pin through a grounded load, while the
output voltage is > 2.4 V DC (if nothing else stated).
Iol: Typical current in mA flowing into an output pin from a VCC connected load, while the
output voltage is < 0.4 V DC (if nothing else stated).
Pull U/D On-board pull-up or pull-down resistors on input pins or open-collector output pins.
Note Special remarks concerning the signal.
The abbreviation TBD is used for specifications which are not available yet or which are not sufficiently
specified by the component vendors.

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 18 of 77
4.1 Connector layout
4.1.1 786LCD/mITX LV Plus
FEATURE IDE_P
A
GP
ATXPWR
AUDIO
SDRAM
IDE_S2
IEEE1394x2
SATA0
SATA1
FRONTPNL
LVDS
CDROM
Clr-CMOS
CPU FAN
CF (backside of 786LCD/mITX)
KBDMSE
COM1
CRT
ETHER1
USB3
USB0
MSE
KBD
PRINTER
PCI
LINE-IN
LINE-OUT
MIC
ETHER2
ETHER3
COM4
COM2
LPC IFC
USB25
COM3
SYSTEM
FAN

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 19 of 77
4.1.2 786LCD/mITX ULV Standard
FEATURE
IDE_P
A
GP
ATXPWR
AUDIO
SDRAM
IDE_S2
FRONTPNL
LVDS
CDROM
Clr-CMOS
CPU FAN
CF (backside of 786LCD/mITX)
KBDMSE
COM1 CRT
ETHER1
USB3
USB0
MSE
KBD
PRINTER
PCI
LINE-IN
LINE-OUT
MIC
COM4
COM2
LPC IFC
USB25
COM3
SYSTEM
FAN

786LCD/mITX Family
KTD-00629-K Public User Manual Date: 2009-10-13 Page 20 of 77
4.2 Power Connector (ATXPWR)
The 786LCD/mITX is designed to be supplied from a standard ATX power supply.
Power Connector 786LCD/mITX
Note
Pull
U/D Ioh/Iol Type Signal
PIN
Signal Type Ioh/Iol
Pull
U/D Note
- - PWR +12V 10 20 5V PWR - -
- - PWR SB5V 9 19 5V PWR - -
4K7 - I P_OK 8 18 -5V PWR - - 1
- - PWR GND 7 17 GND PWR - -
- - PWR 5V 6 16 GND PWR - -
- - PWR GND 5 15 GND PWR - -
- - PWR 5V 4 14 PSON# OC - -
- - PWR GND 3 13 GND PWR - -
- - PWR 3V3 2 12 -12V PWR - -
- - PWR 3V3 1 11 3V3 PWR - -
Note: -5V supply is not used onboard.
The requirements to the supply voltages are as follows (also refer to ATX specification):
Supply Min Max Tolerance
3V3 3.14V 3.46V +/-5%
5V 4.75V 5.25V +/-5%
SB5V 4.75V 5.25V +/-5%
+12V 11.4V 12.6V +/-5%
–12V –13.2V –10.8V +/-10%
Control signal description:
Signal Description
P_OK Active high signal from the power supply indicating that the 5V and 3V3 supplies are within
operating limits. It is strongly recommended to use an ATX supply with the 786LCD/mITX
boards, in order to implement the supervision of the 5V and 3V3 supplies. These supplies are
not supervised onboard the 786LCD/mITX boards.
PS_ON# Active low open drain signal from the board to the power supply to turn on the power supply
outputs. Signal must be pulled high by the power supply.
