Koolatron Lentek Sila IO-70 Manual

AIR PURIFIER/
DEODORIZERS for
TRASH, FRIDGE
and HAMPER
instruction
guide
For Use With
Models:
IO-70Trash
IO-80Fridge
IO-90Hamper
Creating Solutions for a Healthier Environment.
™
Trash Purifier/Deoderizor
Refrigerator Purifier/Deoderizor
Hamper Purifier/Deoderizor
on off
_
_
+
+
PARTS & FUNCTIONS:
ON/Battery LOW
LED
power
ON/OFF
switch
battery
column
opening
battery
placement
diagram
Trash Purifier/Deoderizor
Refrigerator Purifier/Deoderizor
Hamper Purifier/Deoderizor
battery
column
opening
boost mode ON
LED
hook bracket
front back
mounting bracket
front back
2 flat head
screws
boost mode
button
mounting
posts
IO-70Trash IO-90Hamper
IO-80Fridge
double-stick
adhesive foam
Lentek has developed the “Zyonic Technology™” to help
breakdown the impurities in the air.
By introducing
negative ions, using
Lentek’s “Zyonic™”
Air Energizing Tech-
nology, to pollu-
tants, the com-
bined molecules
drop to the ground,
significantly reducing the number of pollutants present.
The “Zyonic Technology™” Super Oxidating Sanitizer (SOS)
process will also help
rid the air of odors.
The SOS process
helps to permanent-
ly oxidize:
© 2000 Lentek International. All rights reserved.
All specifications are subject to change without notice. IO-70/80/90 INST
THE TECHNOLOGY BEHIND SILA™
Y BEHIND SILA™

GETTING STARTED:
LOADING THE BATTERIES:
First, locate the ON/OFF switch
on the lower back of the
device and make sure it is set
to OFF. This unit requires a total
of four (4) ‘C’ batteries (not
included) - two (2) for each
battery column. The battery
columns openings are located
on the bottom of the device.
Using a coin, turn the lid to the
unlock position (see illustration
A). Remove the lid (see illustra-
tion B). Install two (2) of the ‘C’
batteries, following the dia-
gram on the back of the
device (see illustration C).
Replace the lid. Using a coin,
lock into place. Repeat for
other battery column. The
batteries will last up to four
(4) months.
POWER ON:
To activate the cleansing
power, turn the ON/OFF switch
to the ON position.
LED INDICATORS:
GREEN LED - flashes during
‘ON’ duration.
RED LED - will flash when the
batteries are low.
ORANGE LED - flashes during
boost mode.
on
off
k
c
o
L
¥
k
c
o
l
n
U
_
_
+
+
A
on
off
k
c
o
L
¥
k
c
o
l
n
U
_
_
+
+
B
on
off
k
c
o
L
n
U
¥
k
c
o
l
_
_
+
+
C
BOOST MODE & HOOK BRACKET:
Use the ‘boost’ mode to gener-
ate extra power to remove
strong odors quickly.
ACTIVATING THE BOOST MODE:
The ‘boost’ mode button is
located on the top of the
device. Simply press the blue
‘boost’ mode button to acti-
vate it (see illustration D). The
ORANGE LED will flash, indicat-
ing that the boost mode is func-
tioning. After eight (8) minutes in
‘boost’ mode, the device will
return to normal operating
mode automatically.
HOOK BRACKET:
There are two (2) different
mounting brackets to choose
from. The hook bracket attach-
es easily and can be moved
easily. Line the holes in the hook
bracket up with the mounting
posts and insert it. Then push the
hook up to snap it into place
(see illustration E). The hook can
be placed over the edge of
a trash bin (see illustration F),
hamper or refrigerator lip.
D
E
k
c
o
L
n
U
¥
k
c
o
l
_
_
+
+
BOOST
F
MOUNTING BRACKET:
MOUNTING BRACKET:
The mounting bracket may be attached in two different ways. One way
is with the double stick foam adhesive supplied, the other is with the two
screws, also supplied. Determine which will work best for your application.
DOUBLE STICK FOAM ADHESIVE MOUNT:
Take the mounting bracket with
its’ back facing you. Place it
over the mounting posts, as
shown in illustration G, and push
upward to lock into place. Peel
off one side of the protective
covering on the foam adhesive.
Place it on the back side of the
mounting bracket, press firmly
to assure adhesion. Peel the
other protective cover of the
adhesive tape and adhere the
whole device to your chosen
location.
SCREW MOUNT:
Attach the mounting bracket
to your chosen
location using the
supplied screws.
Following illustra-
tion H, line the
mounting posts into
the grooves and
snap it down to
lock it into place.
