Koolatron LENTEK Sila IO-85 Manual

IONIC FRESH
HOME
instruction
guide
Creating Solutions for a Healthier Environment.
™
FRESH HOME
IONIC
onoff
_
_
+
+
PARTS & FUNCTIONS:
ON/Battery
LOW LED
power ON/OFF switch
battery
placement
diagram
FRESH HOME
IONIC
battery column
openings
boost mode ON LED
hook bracket
front back mounting bracket
front back
2 flat head
screws
boost mode
button
mounting
posts
double-stick
adhesive foam
© 2001 Lentek International. All rights reserved. INSTIO85-1200
All specifications are subject to change without notice.
Dimensions are approximate.
IO-85
THE TECHNOLOGY BEHIND SILA™
LENTEK INTERNATIONAL, INC.
PO Box 593812
Orlando, FL 32859-3812
Phone: 407•857•8786
Fax: 407•857•4045
Toll Free: 888•3LENTEK
E-Mail: [email protected]
™
This Limited Warranty is effective upon purchase.
Please complete the attached Registration and return to Lentek
International.
1. Lentek International warrants this product to be free of manufacturing
defects. Should any such defect develop or become evident within ONE
year from the date of purchase, Lentek International will replace the entire
product or, at its option, repair or replace the defective part(s) without
charge.
2. Securely pack the entire unit. Be sure carton clearly identifies sender by
name and address. Attach a letter or card describing the defect. Original
receipt of purchase must be included in returned package for warranty cov-
erage.
3. This warranty is void if damage or malfunction is due to abuse or failure to
operate product in accordance with instructions and on recommended
electrical current.
Mail prepaid via insured parcel post to:
LENTEK INTERNATIONAL • WARRANTY DEPARTMENT
1629 PRIME COURT • SUITE 800 • ORLANDO, FL 32809
LENTEK WARRANTY
Purchase Date ______________
Lentek has developed the “Zyonic Technology™”
to help breakdown the impurities in the air.
By introducing negative ions, using Lentek’s
“Zyonic™” Air Energizing Tech-nology, to pollutants,
the combined molecules drop to the
ground, significantly reducing the num-
ber of pollutants present.
The “Zyonic Technology™” Super
Oxidating Sanitizer (SOS) process will also
help rid the air of odors. The SOS process helps to permanently oxidize pollutants.
Leaves the air smelling as clean and fresh as a spring breeze after a thunderstorm.

batteries, following the diagram on the back of the device (see illustration C).
Replace the lid. Using a coin, lock into place. Repeat for other battery column.
The batteries will last up to four (4) months.
POWER ON:
To activate the cleansing power, turn the ON/OFF switch to the ON position.
LED INDICATORS:
GREEN LED - flashes during ‘ON’ duration.
RED LED - will flash when the batteries are low.
ORANGE LED - flashes during boost mode.
on
off
k
c
o
L
¥
k
c
o
l
n
U
_
_
+
+
A
on
off
k
c
o
L
¥
k
c
o
l
n
U
_
_
+
+
B
on
off
k
c
o
L
n
U
¥
k
c
o
l
_
_
+
+
C
k
c
o
L
n
U
¥
k
c
o
l
_
_
+
+
BOOST MODE & HOOK BRACKET:
Use the ‘boost’ mode to generate extra power to remove strong odors quickly.
ACTIVATING THE BOOST MODE:
The ‘boost’ mode button is located on the top of the device. Simply press
the blue ‘boost’ mode button to activate it (see illustration D). The ORANGE
LED will flash, indicating that the boost mode is functioning.
After eight (8) minutes in ‘boost’ mode, the device will return to normal operat-
ing mode automatically.
HOOK BRACKET:
There are two (2) different mounting brackets to choose from. The hook brack-
et attaches easily and can be moved easily. Line the holes in the hook bracket
up with the mounting posts and insert it. Then push the hook up to snap it into
place (see illustration E). The hook can be placed over the edge of a trash bin
Dear Customer,
Thank you and congratulations on your purchase of this
ingenious device. This product is the latest in new tech-
nology from Lentek
™
. We back our product with a one (1)
year limited warranty. Your satisfaction is very important
to us.
Visit our website at: www.lentek.com and view the rest
of our products, such as our Silã
™
line, Pet Appliance,
Biagianté and PestContro
®
pest control devices. While
you’re there, register your new purchase, sign up to
receive our newsletter, and learn more about our company.
Questions can also be asked on our website, or you can
call: 1-888-3LENTEK, or 407-857-8786 or contact your
local Lentek dealer.
We look forward to serving you, now and in the future.
Enjoy!
Joe Lou
Joe Durek Lou Lentine
CEO President
GETTING STARTED
LOADING THE BATTERIES:
First, locate the ON/OFF switch on the lower back of the device and make sure
it is set to OFF. This unit requires a total of four (4) ‘C’ batteries (not included) -
two (2) for each battery column. The battery columns openings are located on
the bottom of the device. Using a coin, turn the lid to the unlock position (see
illustration A). Remove the lid (see illustration B). Install two (2) of the ‘C’
(see illustration F), hamper or refrigerator lip.
DE
BOOST
F
MOUNTING BRACKET:
MOUNTING BRACKET:
The mounting bracket may be attached in two different ways. One way is with
the double stick foam adhesive supplied, the other is with the two screws, also
supplied. Determine which will work best for your application.
DOUBLE STICK FOAM ADHESIVE MOUNT:
Take the mounting bracket with its’ back facing you.
Place it over the mounting posts, as shown in illustra-
tion G, and push upward to lock into place. Peel off
one side of the protective covering on the foam
adhesive. Place it on the back side of the mounting
bracket, press firmly to assure adhesion. Peel the
other protective cover of the adhesive tape and
adhere the whole device to your chosen location.
SCREW MOUNT:
Attach the mounting bracket to your chosen
location using the supplied screws. Following
illustration H, line the mounting posts into the
grooves and snap it down to lock it into
place.
G
H
