KOV SBT 315 User manual

蓝牙耳机说明书
SBT 315
K V
Wireless Entertainment

1. 规格参数
*数据可能因用户的操作模式和设备设置而有所不同
感谢您选择KOV® 弹窗版TWS耳机AIR，在使用本设备
之前，请仔细参阅本操作指南，本指南将尽可能的
帮助您了解并正确使用AIR
蓝牙版本
支持协议
电池容量
耳机，免提，音乐，遥控
充电电压
充电时间*
播放时间*
产品重量
V5.0
50mAh(耳塞)
600 mAh(充电盒)
DC5V/1A（充电盒）
DC4.7-5.2V(耳塞)
小于2小时
约5 小时
约5小时
约100小时
23x18x14.8mm(耳塞)
72.8*42.6*31mm(充电盒)
5g（耳塞）, 51 g（充电盒）
待机时间*
产品尺寸
通话时间*

2.产品示意图
3.基本操作
开机/关机
把耳机从充电盒中取出，耳机会自动开机并进入配
对状态，也可长按MFB手动开机， 当您把耳机放回
充电盒时，耳机会自动关机并开始充电，也可长按
MFB手动关机
首次使用本产品之前，完全充电本产品以延长产品
内置电池的使用寿命
充电探针
电量显示灯
MFB 耳机指示灯 USB 显示电量按键

配对连接
接听/挂断电话
拒听来电
语音助手
1.从充电盒中取出耳机，耳机左右会自动配对连接成
TWS，然后主机（右耳）会红蓝灯 交替闪烁进入配
对等待状态
2.打开手机蓝牙功能，在可用蓝牙列表中发现并选择
SBT315，耳机将会和您的手机连接（请参考手机蓝
牙功能介绍）
3.如果连接成功，耳机将会进入待机状态，此时您可
以使用耳机享受音乐，拨打电话
4.如果连接不成功，5分钟后耳机会自动关机，请重
复以上步骤重新连接
5.本产品具有自动回连功能，如不能自动回连，您可
能需要手动连接或清除相关配对信息，重新配对连
接
双击MFB或者从手机拒听
短按MFB接听或挂断，或者从手机界面操作
在待机状态下，长按MFB约2秒激活语音助手（请参
阅手机的语音助手介绍）

尾号重拨
暂停/播放
上下曲切换
音量调节
断开连接
功能差异
在待机状态下，三击MFB或者通过手机操作
短按MFB暂停播放中的音乐，再次短按启动播放，
或者通过手机APP暂停或播放
请通过手机调节音量大小
关掉蓝牙耳机或者从手机蓝牙列表中断开连接
因为功耗差异，通常主耳会先于副耳电量耗尽。如
果主耳电量耗完，您可配对副耳进入单耳使用模式
单耳使用
您可选择任意一只耳机连接手机通话或者播放音
乐，在单耳模式下，本型号支持蓝牙双连功能
在音乐播放状态下，双击主耳MFB播放上一首或双
击副耳MFB播放下一首，也可通过 手机切换选曲

声明
SBT315是一款蓝牙5.0版本TWS，兼容性高，但不保
证兼容所有蓝牙功能设备 由于2.4G频段应用较多，
在某些环境下导致的蓝牙连接不稳定，属于正常现
象
制造商尽力保证规格参数和使用规范的准确，但不
保证符合所有蓝牙设备操作规范制造商保留产品说
明和更改的权利

Bluetooth headset User Guide
SBT 315
K V
Wireless Entertainment

1. Specifications
*May vary due to user’s operation mode and device settings.
Thank you for choosing KOV Bluetooth, it allows you the
freedom to make any calls and enjoy the music streaming.
Please read this user manual carefully before using the
headset, and read your device’s user manual regarding the
Bluetooth function, also pay attention to those important safety
and maintenance information.
Bluetooth Specification
Bluetooth Profiles
Supported
Battery Capacity
HSP , HFP ,2DP,
AVRCP
Charging Voltage
Charging Time*
Music Playing Time*
Weight
V5.0
50mAh(earpiece)
600 mAh(Power case)
DC5V/1A
DC4.7-5.2V(earpiece)
Less than 2 hours
Up to 5 hours
Up to 5 hours
Up to 100 hours
23x18x14.8mm(earpiece)
72.8*42.6*31mm(Power case)
5g/earpiece, 51g/whole unit
Standby Time*
Dimensions
Talking Time*

3 . Schematic Diagrams
2 . Charging Case LED status
Charge the case
Charge the earpiece
BLUE LED Capacity
25%
50%
70%
100%
FULL
100%
75%
50%
25%
EMPTY
1 flash
2 flashes
3 flashes
4 flashes
STEADY
4 flashes
3 flashes
2 flashes
1 flashes
OFF
Microphone/LED
MFB USB Power Display Key

4 . Basic Operations
Charging Your TWS
Turning on the TWS
Prior to using for the first time, the batteries needs to be fully
charged to prolong the battery life.
Put the earpieces into the charging case and plug the battery
case to a power source, the led will turn on and, if fully being
charged, the led will turn off.
Take off the earpiece from the charging case, it will power on
automatically and enter PAIRING MODE
Turning off the TWS
Put the TWS into charging case, it will power off automatically.
Note: you can long press the MFB about 3 seconds to power on
or power off the earpieces manually.
1.Take off the earpieces from charging case (or power on the
earpieces manually), the master and assistant earpiece will be
connected automatically as TWS, then its led flashes blue&red
alternatively with voice prompt “Pairing”, now the TWS readies
to connect with your cell phone
2.Activate the Bluetooth function on the phone; search
Pairing Your earpieces with a Bluetooth Mobile Phone
Charging probe
Power Display Light

Answering/Ending a Call
Press any MFB once or from your cell phone
Adjusting Volume
Please adjust volume from your cell phone
Rejecting a Call
Double press any MFB or from your cell phone
Voice assistant
In STANDBY MODE, long press any MFB about 2s to active
voice assistant function (please refer to your phone’s voice
function)
Last Number Redialing
Please triple press MFB to redial last number from your cell
phone
Bluetooth devices (See the user guide of your phone for
instructions).
3.Select “SBT315” from the found devices list of the phone.
4.If successfully paired, the TWS enters STANDBY MODE. (If
the pairing cannot be completed within 5 minutes after the
PAIRING MODE has been activated, the TWS will power off.
Repeat above steps to pair again).
5.Ensure the distance between your TWS and phone is within
10 meters, and without any obstacles. You can use the TWS
freely.
6.If the TWS had paired with your phone but disconnected, it will
be paired automatically again when turns on within operation
range.
Note: Not all cell phones support this function, some may
request reconnection manually.

Play/Pause
Press any MFB once for music playing or pause, or control from
your cell phone’s APP.
Disconnecting
To disconnect the TWS from your phone, please turn off the
TWS or disconnect the TWS from the Bluetooth menu of your
phone.
Note
Due to the power consumption difference, when master earbud
power drains, the assistant may remain power, it is normal. You
now can pair the assistant to your phone for music playing and
phone talk
Single use
Take any one of the TWS to pair with your phone for phone talk
and music playing, it supports multi-points connection if in
single use.
Additional Statements
SBT315 is compliant with the specified Bluetooth version. It
does not guarantee compatibility of all functions on every
Bluetooth enabled device. Please check your device’s user
manual for compatibility and functionality.
Manufacturer reserves the right to final explanation of all the
above statements
Next/Previous song
In PLAYING MODE, double press master MFB for previous
song, or assistant MFB for next song, or control from your cell
phone’s APP
