MiniZ400
Operation manual

CONTENT
1. Introduction to safety materials. ..................................................................................................................................................5
2. Overview of safety labels.......................................................................................................................................................................................6
3. Summary safety rules...............................................................................................................................................................................................8
4. Mandatory actions before launching the loader operation......................................................................................................................9
5. Safety equipment.....................................................................................................................................................................................................9

5
WARNING: SECURING
ADDITIONAL DEVICE
PLACEMENT: HYDRAULIC
ARMS
Ensure the proper connection
of additional device.
Improper connection can lead
to injury or death.
WARNING: MOVEMENT
NEAR THE LIFTER
PLACEMENT: LOWER PART
OF HYDRAULIC ARM
The movement near the turned on
lifter can lead to injury or death.
Do not move near the turned-on
machine. Do not move below
the lifted arms, nor on the lifted
equipment.
WARNING: OF UPSETTING,
OVERTURNING OR LOSS
OF VIEW
PLACEMENT: BACK SIDE
OF HYDRAULIC ARMS
TOWARDS THE DRIVER
Upsetting, overturning or loss
of view from the machine can lead
to injury or death.
At first always familiarize yourself
with the environment in which you
will work.
!
!
!
1. INTRODUCTION TO SAFETY MATERIALS
The user using the machine is responsible for a safe operation of the machine during its use. MiniZ 400 is a high-performance
loader suitable to a variety of terrain conditions so it is necessary to abide all safety rules to prevent the possibility of injury or
death. Machine provider is responsible for a proper training of all users. A duty of the provider is to explain all risks connected to
machine use and to ensure a proper use. The provider is responsible for demonstration of proper machine control with regard
to the training materials (Manual for Machine Maintenance and Operation, Manual for Machine Operation), providing these to all
users for study:
Manual for Machine Maintenance and Operation includes all operating information and common maintenance and
service procedures.
Manual for Machine Operation includes all safety rules and elements necessary to be known and observed to
avoid injury or death.
The user is obliged to familiarize themselves with these documents before using the machine and have them
available at any time.
The warnings in the Manuals, on the machine or inside the machine (safety labels) are necessary to maintain
the safety of the driver. Failure to observe or familiarize with these warnings can lead to injury or death.
The user is obliged to familiarize themselves with safe loader operation.
The user must always wear a protective equipment (protective clothes, protective shoes, protective helmet,
protective glasses and protective gloves) according to the conditions, surrounding and load.
The user must be physically and mentally fit to drive the loader safely.
2. OVERVIEW OF SAFETY LABELS
In case the safety labels are damaged, contact the manufacturer immediately with a request to supply new labels and then
replace the labels immediately.

76
WARNING: FALL IN A SLOPE
PLACEMENT: IN FRONT SIDE
OF THE LOADER
Do not stand under the loader
scoop or arm.
The moving loader can cause
a fall or possibility of getting stuck
under the lifting equipment of the
loader which can result in serious
injury or death.
WARNING: OVERTURNING
THE MACHINE IN THE SLOPE
PLACEMENT: ON THE LOADER
In the slopes, drive the heavy side
of the loader towards the hill.
Driving with the arms lifted can
cause the loss of stability and
overturning of the loader resulting
in injury or death.
WARNING: OVERTURNING
THE MACHINE AS A RESULT
OF IMPROPER OPERATION
PLACEMENT: ON THE LOADER
Do not drive nor turn with the arms
lifted.
Load, unload and turn the machine
on the straight surface.
Do not exceed the permitted
operating capacity.
WARNING: DANGER
OF CRUSHING A BODY PART
PLACEMENT: ON THE LOADER
When working on an unstable
surface or in a hazardous
environment, use the stand
to secure the machine.
An unsecured machine can cause
injury or death.
WARNING: DANGER
OF PARTS EJECTED
INTO THE FACE
PLACEMENT: ON THE LOADER
When working with the machine,
the object may be thrown into
the face of the machine operator.
Always check the work environment
and wear protective clothing
(protective shield).
Not using protective equipment can
result in injury or death.
!
!
!
!
!
WARNING: ACCIDENTAL
LOADER MOVEMENT
PLACEMENT: ON THE LOADER
Accidental machine movement
can lead to death.
Familiarize yourself with loader
control - travel and hydraulics
before you start working.
WARNING: RISK OF PRESS
PLACEMENT: ON LIFTING
ARMS
Do not get close to a loader while
in operation.
Movement near the started loader
can lead to injury or death.
WARNING: DANGER
OF FALLING
PLACEMENT: IN FRONT SIDE
OF THE LOADER
Do not transport other persons.
Do not use the loader for lifting
persons or as a work platform.
WARNING: FLUID UNDER
HIGH PRESSURE
PLACEMENT: ON THE LOADER
Read the User Manual for
Operation and Maintenance to
prevent fluid leakage from the
machine.
Leaking fluid that is under high can
cause injury or death.
WARNING: POSSIBLE
BATTERY EXPLOSION
PLACEMENT: ON THE
BATTERY COVER
When the battery is being
charged, it may explode. Read the
User Manual for Operation and
Maintenance before handling the
battery.
An explosion of the battery can
cause injury or death.
WARNING: READ ALL
THE SUPPLIED MANUALS FOR
THE MACHINE OPERATION
PLACEMENT: ON THE LOADER
Do not use the loader without
reading Manual for Maintenance
and Operation and Manual for
Operation.
Ignorance of maintenance
procedures and work with the
loader can result in injury or death.
WARNING: GETTING
TRAPPED IN PARTS
OF THE LOADER
PLACEMENT: IN FRONT
SIDE OF THE LOADER
Do not touch the places where
any part of the loader is moving.
When the loader is moving the
limbs may get trapped in the
loader which can lead to injury
or death.
!
!
!
!
!
!
!

98
Do not use the loader in the environment with
air containing explosive dust or explosive gases
or where the loader may come into contact with
flammable material.
Do not use the loader without completed training.
Read the labels (stickers) on the machine, Manual
for Maintenance and Operation and Manual
for Operation.
Do not leave the motor turned on and arms lifted
without any supervision.
While parking lower the devices straight to the ground.
3. SUMMARY SAFETY RULES
Before the start of operation the operator must have all the necessary instructions for the machine operation. The untrained operators can cause injury or death.
4. MANDATORY ACTIONS BEFORE LAUNCHING THE LOADER
1. Before putting the loader into operation, make sure that its safe operation is guaranteed (see chapter 9.2. Operation and maintenance manuals).
2. Do not remove or turn o safety devices or switches.
3. Make sure there is no other person or living creature in the driving area.
4. Open the upper hydraulic cover.
5. Turn the connector to the correct position and push it in as far as it will go.
5. SAFETY EQUIPMENT
The loader Elise900 must be always equipped with safety components during every use. Information about the safe use of equipment and devices will be
provided by your dealer.
SAFETY EQUIPMENT:
1. MANUAL FOR OPERATION: Must be placed in the cab.
2. SAFETY LABELS (STICKERS): Replace them in case of damage.
Do not use the loader as a platform for lifting
the person.
Before the use, check the technical condition
of the loader.
Damaged components need to be replaced
immediately. Check the tire pressure regularly.
For loading the material and travel with the material
do not exceed the speed of 6 hm/h.
Keep the operated device in the lowest possible
position while driving.
Do not exceed the rated operating capacity
of the loader and individual additional devices.
Keep a safe distance from power lines while working
near them.
Do not operate the loader while or after ingestion
of drugs, alcohol or medication aecting the reactions
of a person.
Do not adjust the work equipment. Use only
the equipment approved by the company Kovaco
Electric for the given loader model.
Keep the scoop and other devices as low as possible.
Do not drive nor turn the machine with the arms lifted.
Load, unload and turn the machine on the straight
surface.
Never transport other persons.
Make sure no authorized persons are in the work
area.
Do not lift the load to extreme heights during
the travel in the slope.
Pay attention to the condition of the terrain
(evenness, strength).
The braking distance is extended during the travel
of loaded loader. Therefore, take extra care while
working on a sloping, muddy, icy or uneven surfaces.
