KRAFTWERK 38129 User manual
Instruction Manual
Engine leveler
Art. 38129
EN
www.KRAFTWERKtools.com
680
Max.
kg
2
Description
The Engine Leveler is a device to be used between an overhead lifting hoist and an unevenly weighted
load such as an auto engine with transmission intact. The device is designed to increase efficiency in a
variety of hoisting applications by allowing the operator to lift off-center loads and adjust the working
angle of the loads.
Owner/User Responibility
he owner and/or user must have an understanding of the manufacturer’s operating instructions and
warnings before using this engine leverer. Personnel involved in the use and operation of equipment shall
be careful, competent, trained, and qualified in the safe operation of the equipment and ist proper use
when servicing motor vehicles and their components. Warning information should be emphasized and
understood. If the operator is not fluent in English, the manufacturer’s instructions and warnings shall be
read to and discuesse with the operator in the operator’s native language by the purchaser/owner,
making sure that the operator comprehends ist contents.
Owner and/or user must study and maintain for future reference the manufacturer’s instructions. Owner
and/or user is responsible for keeping all warning labels and instruction manuals legible and intact.
Inspection
Visual inspection should be made before each use of the engine leverer, checking for damaged, losse or
missing parts. Each sling must be inspected by a manufacturer’s repair facility immediately, if
accidentally subjected to an abnormal load or shock. Any sling which appears to be damaged in any way,
is found to be badly worn, or operates abnormally MUST BE REMOVED FROM SERVICE until necessary
repairs are made by a manufacturer’s authorized repair facility. It is recommended that an annual
inspection of the sling be made by a manufacturer’s authorized repair facility and that any defective
parts, decals or warning labels be replaced manufacturer’s specified parts.
WARNING
Maximum rated load is 680 pounds.
Before lifting load, be sure all bolts on lifting beam and all fastenesers connected to load are engaged
and tightened.
Keep body and body parts from under lifted load at all times.
Failure to follow operating and safety instructions provided may result in personal injury or death.
Read instructions in operator’s manual.
3
Operating
To remove an auto or truck engine with transmission
intact, first uncouple the transmission and remove
motor mount bolts. With the Engine Leverer hooked
to an overhead hoist above the engine, attach the
L-shape connections at the end of the four (4)
chains (choose one of the two holes provided) to the
engine head bolts – two at front, both sides, and two
at rear, both sides. Using the engine hoist, take up
slack in chain carefully. Lift a few inches and check
load balance. To reach the desired angle for load
balance, adjust the position of the movable fulcrum
in the beam by turning the 1“ hex adjusting nut at
end of the worm shaft with a ratchet wrench. Then
carefully lift out the engine and transmission. By
turning the handle one direction or the other, the
suspended engine and transmission can the be
tipped only enough to remove. Reverse the above
steps to reinstall repaired engine transmission. For
this and other types of loads, make sure all
connections are tight and secure before operating the hoist.
The following operational instructions are recommended to prevent serious personal injury or
damage.
Never use this Engine Leverer with an engine host having a capacity of less than 1 ton!
Operating Instructions
1. Be familiar with sling operating controls, procedures and warnings.
2. Make sure all connections to load are tight and secure.
3. Maintain firm footing when operating sling.
4. Make sure that load is free to move and will clear all obstructions.
5. Take up slack carefully, check laod balance, lift a few inches and check load holding action before
continuing.
6. Avoid swinging of load.
7. Make sure that all persons stay clear of the suspended load.
8. Warn personnel of an approaching load.
9. Protect load chain from weld spatter or other damaging contaminats.
10. Promptly report to your supervisor unusual performance, or damage of the sling.
11. Inspect beam regularly, replace damaged or worn parts, and keep appropriate record of maintenance.
Warnings
1. Never lift more than rated load.
2. Never use damaged sling or sling that is not working correctly.
3. Never ise neam with twisted, kinked, damaged or worn chain.
4. Never lift a load if any binding prevents equal loading on all supporting chains.
5. Never allow attention to be diverted from operating the sling.
6. Never use beam to lifht, support or transport people.
7. NEVER LIFHT LOADS OVER PEOPLE !
8. Never leave a suspended load unattended.
9. Never allow sharp contact between sling and obstructions.
10. Never allow the chain or link to be used a as ground for welding.
11. Never allow the chain or ling to be touched by a live welding electrode.
12. Never attempt to lengthen the load chain or repair damaged chain.
www.KRAFTWERKtools.com
www.KRAFTWERKtools.com
KRAFTWERK Europe AG
Mettlenbachstrasse 23
CH-8617 Mönchaltorf
Tel. +41-44 949 40 50
KRAFTWERK Sàrl.
25, rue du Stade
F – 67870 Bischoffsheim
Tel. +33-388 48 64 50
Switzerland France
