Kramer VS-44DT User manual

VS-44DT
4x4 4K60 4:2:0 HDMI/HDBaseT
Extended−Reach PoE Matrix Switcher
|HDMI |Ethernet-RJ-45 |HDBaseT
VS−44DT is a 4x4 4K@60Hz (4:2:0) HDMI/HDBaseT
matrix switcher that transmits video, audio, Ethernet,
RS−232 and IR signals over extended distances. The
unit accepts up to four HDMI and four IR inputs as
well as Ethernet and RS−232 network and control. The
inputs can be routed to any or all of the four HDBaseT
outputs, the first two of which also have simultaneous
HDMI outputs. VS−44DT connects to compatible
HDBaseT receivers such as, TP−780RXR,
TP−580RXR and TP−588D. It supports resolutions of
up to 4K@60Hz (4:2:0) and WUXGA. The matrix is a
PoE provider that provides power over Ethernet to
compatible PoE receivers
FEATURES
Max. Data Rate-10.2Gbps (3.4Gbps per graphic channel)
Max. Resolution-4K@60Hz (4:2:0) and WUXGA
HDBaseT Range-Up to 130m (430ft) at normal mode (2K), up to 100m at normal mode (4K); up to
180m (590ft) ultra mode (1080p @60Hz @24bpp) when using BC−UNIKAT cables
Cables-For optimum range and performance, use the recommended Kramer cables available at
www.kramerav.com/product/VS−44DT
HDBaseT Extension-Includes Video, Audio, Ethernet, RS−232 and IR signals
Outputs-4 HDBaseT with outputs 1 and 2 having simultaneous HDMI outputs
PoE Support-PoE provider to HDBaseT receivers such as the TP−588D and TP−780RXR
HDTV Compatible
HDCP Compliant
EDID Capture-Copies and stores the EDID from a display device
HDMI Support-3D, Deep Color, x.v.Color™, Lip Sync, Dolby® TrueHD, Dolby Digital Plus,
DTS−HD® and 7.1 PCM
Non-Volatile Memory-Stores and recalls preset matrix configurations
Automatic Output Shutdown-If no input signal is detected after a configurable idle period
Kramer Protocol 3000 Support
Lock Button-Prevents unwanted tampering with the settings
Flexible Control Options-Embedded Web server, RS−232, IR remote (included)
Worldwide Power Supply-100−240V AC


TECHNICAL SPECIFICATIONS
INPUTS: 4 HDMI on HDMI connectors, 5 IR on 3.5mm mini jack connectors
OUTPUTS: 2 HDMI connectors, 4 HDBaseT on RJ−45 connectors, 5 IR on 3.5mm mini jack
connectors, 1 unbalanced stereo audio on a 3.5mm mini jack connector
PORTS: 1 Ethernet on an RJ−45 connector, 1 program on a USB connector, 1 RS−232
control on a 3−pin terminal block, 1 RS−232 data on a 3−pin terminal block
MAX. DATA RATE: 10.2Gbps (3.4Gbps per graphic channel)
SUPPORTED
RESOLUTIONS:
VGA to WUXGA (reduced blanking), 4Kx2K @30Hz with Deep Color up to 36bpp
HDMI RANGE: 15m (49ft) @ 8bit resolution, 10m (33ft) @ 12 bit resolution
HDBaseT RANGE: 100m (328ft) 4K @30Hz 180m (590ft) 1080 @60Hz@24bpp
POWER
CONSUMPTION:
100−240V AC, 50/60Hz, 60VA
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE
TEMPERATURE:
–40° to +70°C (–40° to 158°F)
PRODUCT
DIMENSION:
19" x 13.90 x 1U (43.6cm x 35.30cm 4.36cm) W, D, H
PRODUCT WEIGHT: 3.3kg (7.3lbs) approx
SHIPPING
DIMENSION:
54.30cm x 44.20cm x 10.70cm (21.38" x 17.40" x 4.21" ) W, D, H
SHIPPING WEIGHT: 4.1kg (9.0lbs) approx
HUMIDITY: 10% to 90%, RHL non−condensing
COOLING: Fan
ENCLOSURE TYPE: Aluminum chassis
VIBRATION: ISTA 1A in carton (International Safe Transit Association)
SAFETY
REGULATORY
COMPLIANCE:
CE
ENVIRONMENTAL
REGULATORY
COMPLIANCE:
Complies with appropriate requirements of RoHs and WEEE
INCLUDED
ACCESSORIES:
Rack “ears”, IR blaster, IR receiver RC−IR3 remote control transmitter
