Kramer TS-PEU User manual

Installation Instructions
MODEL:
TS-PEUUniversal Socket Power Extension
for Modular TBUS
SAFETY WARNING
Disconnect the unit from the power supply before opening and servicing
See www.KramerAV.com for updated safety information
For the latest information on our products and a list of Kramer distributors, visit our Web site where
updates to these installation instructions may befound.
We welcome your questions, comments, andfeedback.
www.KramerAV.com
[e-mail]
P/N:
2900- 300777QS
Rev:
2

Universal Socket Power Extension for Modular TBUS
Congratulations on purchasing your Kramer TS-PEU universal socket power extension for
modular TBUS (TBUS-1AXL, TBUS-1N and/or TBUS-1KWC).
The TS-PEU includes six universal power sockets: one on the surface of the unit and five hidden
neatly under the table. To use TS-PEU, simply pull it out of the TBUS surface using the handles and
lay it on the table. When not in use, carefully slide the TS-PEU into the TBUS.
The TS-PEU fits into TBUS inner frame modules that include dual power socket openings (for
example, P/N 80-000399 or P/N 80-000499).
Figure 1: TS-PEU
#
Feature
Function
1 Power Cable with Male C14 Connector
Connect to any universal C14 cable and to the mains.
2
Power Extension Unit Housing
Includes five built-in universal power sockets.
3
Bracket
Fit bracket over dual power socket opening on the TBUS frame.
4
Bracket Screw Openings (2)
Attach to frame surface using 2 M3x8 screws (supplied).
5
Bracket Handle Opening (4)
Used for resting the Power Extension Unit when hidden under
the table.
6
Power Extension Unit Opening
Pass-through for pulling and sliding the Power Extension Unit.
7
Pulling Handles (2)
Hold when pulling / hiding the Power Extension Unit.
8
Surface Power Socket
Power socket located on the unit surface.

Installing the TS-PEU
The Kramer TS-PEU fits into a dual power socket opening.
To install the TS-PEU:
1. Place the TS-PEU under the dual power
socket opening of a frame.
2. Tighten the bracket using the two M3x8
screws (supplied with the package).
Figure 2: TS-PEU installing in the TBUS
When needed, use the two side-handles to pull out the power socket extension.

Technical Specifications
Ports
6 power universal connectors
Power Source
(AC power limits):
Universal: 100-240V AC, 50/60Hz, 5A, maximum 5A per power outlet
Fully compatible with power plugs in the UK, India, Italy and Denmark, as well as
with the 2-prong Europlug.
Partially compatible (if the polarity is reversed) with plugs in China, Switzerland,
Israel and the USA. The universal socket does not supply grounding to plugs in
Central Europe and France.
Fuse Rating:
T 10A 250V
Operating Temperature:
0° to +40°C (32° to 104°F)
Storage Temperature:
-40° to +70°C (-40° to 158°F)
Humidity: 10% to 90%, RHL, non-condensing
Storage humidity range:
5% to 95%, RHL, non-condensing
Dimensions:
12.2cm x 36.4cm x 5.1cm (4.8" x 14.3" x 1") W, D, H.
Power cord length 170cm (67”)
Shipping Dimensions
13.2cm x 49cm x 6cm (5.2" x 19.3" x 2.4") W, D, H.
Weight:
1.18kg (2.6lbs) approx.
Shipping Weight
1.38kg (3.04lbs) approx.
Included Accessories:
2 M3x8 screws
Specifications are subject to change without notice at www.kramerav.com
