4
VP-441 - Overview
3 Overview
The Kramer VP-441 is a high quality presentation switcher and scaler. It accepts
one of seven inputs: a component video on RCA connectors, computer graphics on
a 15-pin HD connector, composite video on an RCA connector, s-Video on a
4-pin connector and two HDMI signals. It scales the video, embeds the audio, and
outputs the signal as follows: to the HDMI output, to the computer graphics output,
and to the RGBHV video output together with a digital audio output and an analog
stereo audio output.
Component video is also known as Y, Pb, Pr, or Y, Cb, Cr or YUV; compatible with both SD
and HD component
The VP-441 is HDTV compatible and the resolution can be up- or down-scaled as
follows: Native, VGA, SVGA, XGA, SXGA, UXGA, 480i, 480p, 576i, 576p,
720p (@50 and 60Hz), 1080i (@50 and 60Hz), 1080p (@50 and 60Hz), WXGA,
WSXGA, WUXGA, 1280x800, 1440x900, 1400x1050, 1600x900 and 2K resolutions
(2048x1080@50Hz and 2048x1080@60Hz).
The VP-441 Presentation Switcher / Scaler:
Features K-Storm™ Scaling Technology - Kramer’s extremely high
performance scaling technology. High-quality 3:2 and 2:2 pull down
de-interlacing and full up and down scaling of computer graphics video input
signals
Has analog audio inputs and digital (S/PDIF) and analog stereo audio
outputs as well as 5.1 analog audio bypass
The VP-441 converts digital audio information to Dolby 5.1 analog outputs, facilitating
the routing of up to six analog audio inputs (left, center, right, left surround, right
surround and subwoofer) directly to the output without being processed
Automatically detects and selects the audio source for the HDMI input.
Default selection is HDMI –if this is not present, the machine uses the audio
from the analog input
Comes with an On-Screen Display (OSD) for easy setup and adjustment,
accessible via the IR remote control and via the front-panel buttons
Has an HDTV compatible component input

VP-441 – Overview
5
Is HDCP Compliant - The HDCP (High Definition Content Protection) license
agreement allows copy-protected data on the HDMI input to pass only to the
HDMI output
Has a non-volatile memory that retains the last settings used
Supports firmware upgrade via RS-232
Control your VP-441:
Directly, via the front panel push buttons
By RS-232 serial commands transmitted by a touch screen system, PC, or
other serial controller
Remotely, from the infrared remote control transmitter
Via the Ethernet
The VP-441 is housed in a 19” 1U rack mountable enclosure, with rack “ears”
included, and is fed from a 100-240 VAC universal switching power supply.
3.1 Defining the VP-441 Presentation Switcher/Scaler
This section defines the VP-441.

Figure 1: VP-441 Presentation Switcher/Scaler Front Panel
#
Feature
Function
1
POWER Switch
Illuminated switch for turning the unit ON or OFF
2
IR Receiver
Receives signals from the remote control transmitter
3
INPUT
SELECTOR
Buttons
CV
Press to select the composite video input
4
YC
Press to select the s-Video input
5
COMPONENT
Press to select the component video input (from 1 to 2)
6
VGA
Press to select the computer video graphics input
7
HDMI
Press to select the HDMI input (from 1 to 2)
8
BLANK Button
Press to toggle between a blank screen (blue or black screen) and the display
9
MUTE Button
Press to toggle between muting (blocking out the sound) and enabling the audio output
The FREEZE button can be programmed to follow MUTE (see Section 6.2.3)
10
FREEZE Button
Press to freeze/unfreeze the output video image
This button can be programmed to follow MUTE (see Section 6.2.3)
11
MENU Button
Displays the OSD menu (see Section 6.2)
12
ENTER Button
Press to accept changes, change the SETUP parameters (see Section 6.2) and to auto adjust the image (when not within the OSD
menu), see Section 6.1.1
13
- Button
Press to decrease numerical values or select from several definitions
When not within the OSD menu mode, press to reduce volume (for embedded HDMI inputs, this does not affect the embedded output)
14
Button
Press to move up the menu list values (see Section 6.2)
15
+ Button
Press to increase numerical values or select from several definitions
When not within the OSD menu mode, press to increase volume (for embedded HDMI inputs, this does not affect the embedded output)
16
Button
Press to move down the menu list (see Section 6.2)
17
PANEL LOCK Button
Press and hold for about 2 seconds to lock/unlock the front panel buttons
18
RESET TO XGA/720p Button
Press to reset the video resolution to XGA or 720p
Press and hold for about 2 seconds to reset to XGA; or press and hold for about 5 seconds to reset to 720p
6
VP-441 –Overview

VP-441 –Overview
7
Figure 2: VP-441 Presentation Switcher/Scaler Rear Panel
#
Feature
Function
19
VIDEO INPUT
Connectors
HDMI
Connect to the HDMI source (from 1 to 2)
20
VGA 15-pin HD
Connect to the computer graphics source
21
CV RCA
Connect to the composite video source
22
YC 4-pin
Connect to the s-Video source
23
Pr/Cr RCA
Connect all three connectors to the component video source (from 1 to 2)
24
Pb/Cb RCA
25
Y RCA
26
VIDEO OUTPUT
Connectors
R BNC
27
G BNC
28
B BNC
Connect to the RGBHV video acceptor
29
H BNC
30
V BNC
31
HDMI
Connect to the HDMI acceptor
32
VGA 15-pin HD
Connect to a VGA acceptor
33
AUDIO IN Unbalanced
Stereo Terminal Block
Connectors
HDMI
Connect to the analog audio HDMI source (from 1 to 2)
VGA
Connect to the analog audio computer graphics source
COMP
Connect to the analog audio component video source (from 1 to 2)
CV
Connect to the analog audio composite video source
YC
Connect to the analog audio s-Video source
34
RS-232 9-pin D-sub Port
Connect to the PC or the remote controller
35
OUT RCA Connectors
LEFT
Connect to the left stereo analog audio acceptor
36
RIGHT
Connect to the right stereo analog audio acceptor
37
S/PDIF
Connect to a digital audio acceptor
38
ETHERNET Connector
Connects to the PC or other Serial Controller through computer networking
39
Power Connector with Fuse
AC connector, enabling power supply to the unit

8
VP-441 - Installing in a Rack
4 Installing in a Rack
This section provides instructions for rack mounting the unit.

VP-441 - Connecting the VP-441
9
9
5 Connecting the VP-441
Always switch off the power to each device before connecting it to
your VP-441. After connecting your VP-441, connect its power and
then switch on the power to each device.
You do not have to connect all the inputs and outputs, connect only
those that are required.
To connect the VP-441, as illustrated in the example in Figure 3, do the following:
1. Connect an HDMI source (for example, a DVD player) to the HDMI 1 VIDEO
INPUT connector.
Alternatively, you can connect the DVI connector on the DVD player to the HDMI
connector on the VP-441 via a DVI-HDMI adapter. When using this adapter, you can
connect the audio signal via the terminal block connector
2. Connect a computer graphics source to the VGA 15-pin HD VIDEO INPUT
connector.
3. Connect a composite video source (for example, a composite video player)
to the CV VIDEO INPUT RCA connector.
4. Connect an s-Video source (for example, an s-Video player) to the YC 4-pin
VIDEO INPUT connector.
5. Connect a component video source (for example, a component video player)
to the COMP 1 PR, PBand Y, VIDEO INPUT RCA connectors.
6. Connect the audio input signals to the AUDIO IN terminal block connectors,
as required (not shown in Figure 3).
7. Connect the RGBHV VIDEO OUTPUT BNC connectors to an RGBHV
acceptor (for example, an RGBHV display).
8. Connect the HDMI VIDEO OUTPUT connector to an HDMI acceptor (for
example, a plasma display).
!
i

10
VP-441 - Connecting the VP-441
9. Connect the VGA VIDEO OUTPUT 15-pin HD connector to a VGA acceptor
(for example, a projector).
10. Connect the audio output signals to the OUT stereo analog audio acceptor
and/or the digital audio acceptor, as required (not shown in Figure 3).
11. Connect the power cord (not shown in Figure 3).
12. If required, connect:
A PC via RS-232, see Section 6.3
The ETHERNET port, see Section 6.4
Figure 3: Connecting the VP-441 Presentation Switcher / Scaler

VP-441 - Controlling the VP-441
11
11
6 Controlling the VP-441
The VP-441 can be controlled via:
The front panel buttons (see Section 6.1)
The OSD menu (see Section 6.2)
RS-232 serial commands transmitted by a touch screen system, PC, or
other serial controller (see Section 6.3)
The ETHERNET (see Section 6.4)
The infrared remote control transmitter (see Section 6.5)
6.1 Controlling via the Front Panel Buttons
The VP-441 includes the following front panel buttons:
Input selector buttons for selecting the required input: CV, YC,
COMPONENT (1 and 2), VGA or HDMI (1 and 2)
BLANK, MUTE and FREEZE buttons
MENU, ENTER, and up, down, left and right arrow buttons
RESET TO XGA/720p and PANEL LOCK buttons
6.1.1 The Auto Adjust (Auto Tune) Feature
The auto adjust feature (applies only to the VGA input) automatically centers the
image on the screen when pressing the ENTER front panel button or the OK button
on the remote control transmitter (when not within the OSD menu).
You can also implement this feature every time the input is switched to VGA or
when the input resolution changes, via the FINETUNE menu (see Section 6.2.2).

12
VP-441 - Controlling the VP-441
6.2 Using the OSD Menu
The control buttons let you control the VP-441 via the OSD menu. Press the:
MENU button to enter the menu
The default timeout is set to 10 seconds
ENTER button to accept changes and to change the menu settings
Arrow buttons to move through the OSD menu, which is displayed on the
video output
On the OSD menu, select EXIT to exit the menu.
6.2.1 The MAIN MENU
Mode
Function
CONTRAST
Set the contrast
The range and default values vary according to the input signal
BRIGHTNESS
Set the brightness
The range and default values vary according to the input signal
FINETUNE
Optimize the image quality (see Section 6.2.2)
COLOR
Setthe red,greenandblueshades (0to100,default48,48and 52respectively)
SIZE
Select the size of the display: FULL, OVERSCAN, UNDER1, UNDER2,
LETTER BOX, PANSCAN, BEST FIT (default, FULL)
UNDER1 refers to an underscan of 6%
UNDER2 refers to an underscan of 9%
SOURCE
Select the source: (default VGA)
Source input
Appears as:
Source input
Appears as:
CV
CVBS
VGA
PC
YC
SVIDEO
HDMI 1
HDMI1
COMP 1
YPBPR1
HDMI 2
HDMI2
COMP 2
YPBPR2
CVBS means Composite Video Baseband Signal
OUTPUT
Select the output resolution from the menu (default NATIVE):
Output resolution:
Appears as:
Output resolution:
Appears as:
1080i @60Hz
1080I60
800x600
SVGA
1080p @60Hz
1080P60
1024x768
XGA
576i
576I
1280x1024
SXGA
576p
576P
1600x1200
UXGA
720p @50Hz
720P50
480i
480I
1080i @50Hz
1080I50
480p
480P
1080p @50Hz
1080P50
720p @50Hz
720P60
1280x800
1280x800
1600x900
1600x900
1680x1050
WSXGA
2048x1080 @50Hz
2048x1080/50Hz
1920x1200
WUXGA
2048x1080 @60Hz
2048x1080/60Hz
1440x900
WSXGA+
[email protected]
480I59

VP-441 - Controlling the VP-441
13
13
Mode
Function
Output resolution:
Appears as:
Output resolution:
Appears as:
1400x1050
SXGA+
[email protected] Hz
480P59
1366x768
WXGA
[email protected]
720P59
NATIVE
[email protected]
1080I59
640x480
VGA
[email protected]
1080P59
NATIVE - Select NATIVE to select the output resolution from the EDID of the
connected HDMI monitor
AUDIO
Adjust audio parameters (see Section 6.2.3)
OSD
Set the OSD parameters: H POSITION, V POSITION, TIMER,
BACKGROUND and DISPLAY (see Section 6.2.4)
HDCP ON
INPUT
Set to ON or OFF.
HDCP support can be enabled (ON) or disabled (OFF) for each of the
HDMI inputs, allowing the source to transmit a non-HDCP signal if required
HDCP ON
OUTPUT
Select Follow Input or Follow Output to define whether the HDCP will follow
the input or the output
When Follow Input is selected, the scaler changes its HDCP output setting
(for the HDMI output) according to the HDCP of the input.
This option is recommended when the HDMI scaler output is connected to a
splitter/switcher
When Follow Output is selected, the scaler matches its HDCP output to the
HDCP setting of the HDMI acceptor to which it is connected.
FACTORY
RESET
Resets to the default parameters
If you cannot see the display after factory reset, use the front panel Res. button to
set the correct resolution: press continuously for 2 seconds to reset to XGA, or
continuously for 5 seconds to reset to 720p
INFORMATION
Displays the source, the input resolution, the output resolution and the
software version
AUTO SYNC
OFF
Turn the auto sync ON/OFF. When ON, a short period after not detecting a
valid video signal on the selected input, the unit will disable the H and V
syncs on the analog outputs until a valid input is again detected
EXIT
Select to exit the menu

14
VP-441 - Controlling the VP-441
6.2.2 The FINETUNE Menu
Input Signal
Parameter
Function
CV, YC,
COMPONENT
HUE
Set the color hue
SATURATION
Set the color saturation
SHARPNESS
Set the sharpness of the picture
NOISE
REDUCTION
Select the noise reduction: OFF, HI, LOW and MID
(middle)
COLOR FILTER
Set to ON to enable color filtering
VGA
PHASE
Set the clock phase
CLOCK
Set the clock frequency
H-POSITION
Set the horizontal position of the picture
V-POSITION
Set the vertical position of the picture
AUTO TUNE
When set to ON, auto adjusts the image (centers it
correctly on the screen) every time the input is
switched to VGA or when the input resolution changes
Alternatively, you can auto adjust the image by pressing
the ENTER button when not within the OSD menu
COLOR FILTER
Set to ON to enable color filtering
HDMI
COLOR FILTER
Set to ON to enable color filtering
DROP LINES
Set it to ON to eliminate the green line (default is OFF)
With some sources (mostly Apple devices) a green line
sometimes appears at the bottom of the display. By factory
default this option is set to OFF.
COLOR FILTER may improve the output image for certain graphic
cards where color fringing is seen.
6.2.3 The AUDIO Menu
Parameter
Function
OUTPUT
VOLUME
Set the output volume (from 0 to 100)
Not applicable for embedded HDMI inputs
INPUT VOLUME
Set the input volume (from 0 to 100)
Not applicable for embedded HDMI inputs
DELAY
Select the audio delay time: OFF, 40ms, 110ms and 150ms
SOUND
Select the sound options: ON, MUTE
MUTE FOLLOWS
Select the action that will be followed by mute:
INDEPENDENT: the audio muting is independent of the FREEZE and
BLANK functions
FREEZE
BLANK
FREEZE/BLANK: when freezing or blanking the video, the audio will be
muted (the MUTE function follows the FREEZE and the BLANK
functions)
i

VP-441 - Controlling the VP-441
15
15
Parameter
Function
HDMI AUDIO IN
Select:
AUTOMATIC: the embedded audio on the HDMI input is selected for an
HDMI signal, or the analog audio input is selected if the input is not
HDMI (for example, for a DVI input signal)
EMBEDDED: the embedded audio in the HDMI signal is selected
ANALOG: the analog audio input is selected
HDMI AUDIO IN is enabled only when one of the HDMI inputs is selected
6.2.4 The OSD Menu
Parameter
Function
H POSITION
Set the horizontal position of the OSD (from 0 to 100)
V POSITION
Set the vertical position of the OSD (from 0 to 100)
TIMER
Set the timeout period in seconds (from 5 to 100)
BACKGROUND
Set the OSD background between 0 (solid black) and 8 (transparent)
DISPLAY
Select the information shown on the screen during operation:
ON - the information is shown permanently
OFF - the information is not shown
INFO - the information is shown for a few seconds
6.3 Connecting to the VP-441 via RS-232
You can connect to the VP-441 via an RS-232 connection using, for example, a PC.
Note that a null-modem adapter/connection is not required.
To connect to the VP-441 via RS-232:
Connect the RS-232 9-pin D-sub rear panel port on the VP-441 unit via a
9-wire straight cable (only pin 2 to pin 2, pin 3 to pin 3, and pin 5 to pin 5 need
to be connected) to the RS-232 9-pin D-sub port on your PC
6.4 Connecting the VP-441 via the ETHERNET Port
To connect and configure the Ethernet port of the VP-441, refer to the ETHERNET
Configuration (Lantronix) GUIDE on our Web site:
http://www.kramerelectronics.com

16
VP-441 - Controlling the VP-441
6.5 Controlling via the Infrared Remote Control Transmitter
You can control the VP-441 from the infrared remote control transmitter:
Figure 4: Infrared Remote Control
Transmitter
Keys
Function
SIZE
Set the size of the image
displayed
POWER
Turn the VP-441 ON or OFF
(the outputs and the front-panel
are disabled)
FREEZE
Freeze/unfreeze the output
video image
BLANK
Toggle between a blank screen
(blue or black screen) and the
display
MUTE
Toggle between muting
(blocking out the sound) and
enabling the audio output
AV
Select the composite video
input
YC
Select the s-Video input
COMP1
Select the component video 1
input
COMP2
Select the component video 2
input
PC
Select the UXGA input
HDMI1
Select the HDMI1 input
HDMI2
Select the HDMI2 input
XGA Reset
Reset the resolution to XGA
720p Reset
Reset the resolution to 720p
INFO
Displays the selected input, the
input and output resolutions and
the firmware versions on the
OSD
NATIVE
Select the output resolution via
the EDID of the connected
HDMI monitor
Four navigation keys
When not in the OSD, the left and
right arrows also control the output
volume
For embedded HDMI inputs, this
does not affect the embedded
output
OK
Press to accept changes
Press also to auto adjust the
picture (see Section 6.1.1)
MENU
Enter the OSD menu
EXIT
EXIT the menu
