Kraus KPF-1612 User manual

Product Description and Measurements
Installation Instruction
Single Lever Pull Out Sink Mixer
MODEL-KPF-1612
Contact us toll-free at kraususa.com. 1-800-775-0703; or visit our website at www.
Prior To Installation Steps
1. Unpack your new product and ensure that all the parts are contained in the packaging.
Keep the product in its original box until you are ready to install it.
2. Shut off the water supply if replacing a previously-installed faucet.
3. Observe all plumbing and building codes in your area.
4. It is recommended that installation of the product be done by a professional plumber.
Thank You
Dear Valued Customer,
Kraus would like to take this opportunity to thank you for purchasing Kraus products. It is our sincere
hope that you are completely satisfied with your new purchase. We welcome any questions or comments
you may have and look forward to assisting you in the future.
Sincerely,
Kraus customer service department.
Installation Steps
1. Shut off all water supply prior to installation
2. Remove the metal spring (#14) by disassembling it from the hose.
3. Screw on the aerator head (#2) onto the spout (#3). Make sure that a black rubber washer is attached to the
end of the hose prior to attaching the aerator head.
4. Place the black rubber o-ring (#4) into the metal ring (#5).
5. Place the metal ring (#5) onto the faucet body (#1).
6. Unscrew the brass nut (#7) from the brass screw (#6).
7. Place the faucet on the countertop.
8. If the countertop is thin or the faucet is being mounted on the sink itself, place the countertop extender (#15)
from underneath the countertop and tighten it onto the brass screw. **Optional**
9. Place the rubber washer (#8) and then the metal washer (#9) onto the brass screw from underneath the
countertop.
10. Tighten the brass nut (#7) onto the brass screw (#6).
11. Place the plastic enclosure (#10) onto the hose and situate the smaller opening onto the brass screw (#6).
12. Place the spring (#14) onto the hose.
13. Place the red hard washer (#11) into the hose inlet (#13) and screw the hose (#12) (with the spring already
attached) onto the brass screw (#6).
14. Screw in the hot and cold waterlines (#16) and attach them to the water supply.

Contact us toll-free at kraususa.com. 1-800-775-0703; or visit our website at www.
Installation
Do not disassemble the main body, as it has been installed & commissioned
correctly & precisely before leaving the factory.
To avoid the faucet from jamming, DO flush the water pipe before installation.
After installation make sure every joint is safely sealed (NO LEAKAGE).
Make sure to connect the hot/cold inlet pipe correctly form front view hot water
pipe connecting to the left and cold water pipe connecting to the right .
MODEL-KPF-1612
5
4
6
8
9
7
10
11
13
14
12
16
15
Code Parts List Quantity
Faucet
Aerator Head
Spout
Rubber O-Ring
Metal Ring
Brass Screw
Brass Nut
Rubber Washer
Metal Washer
Plastic Enclosure
Red Hard Washer
Hose
Hose Inlet
Spring
Counter Top Extender (optional)
Hot & Cold Water Lines
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
2
3

Installation
Contact us toll-free at kraususa.com. 1-800-775-0703; or visit our website at www.
Usage, Cleaning & Maintenance
Usage
Cleaning & Maintenance
Make sure the installation holes are in the correct size.
Install the lavatory and pop-up waste as shown in the drawing.
Connect the main body and water supply pipe with water inlet pipe
To keep product clean and shiny follow the instruction below.
1. Flush with clean water and dry with soft cloth only.
2. Do not use any detergent, polisher, sane-cloth,or a scraper.
3. Do not use acid detergent.
How to operate the handle
1. Raise the handle lever up for opening water, push it down
for close.
2. Turn the handle lever to left to increase hot water flow for
higher water temperature by operating reversely.
3. The swivelling can be circled 360 .
MODEL-KPF-1612
9 ½’’
6.4’’ 6.1’’
19.8’’
Max 1.4’’
Max 1.4’’
Pull Out Hose
