Kraus Merlin KPF-1674 User manual

Merlin Single Handle
Pull-Down Kitchen Faucet
KPF-1674
TM
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2018 Kraus USA Inc. I REV. May 11, 2021
R
INSTALLATION MANUAL

Congratulations on the purchase of your new
Kraus plumbing fixture!
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance or have any problems with your product:
2
Please contact our Customer Service Team
1-800-775-0703 / [email protected]
Have the model number available and retain a copy of your
receipt with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE
STOP

Prior to Installation:
·Make sure you have all necessary parts by checking the diagram and
parts list. If any part is missing or damaged, please contact Kraus
Customer Service at 800-775-0703 for a replacement.
·Turn off the hot and cold water supply at the angle stops and turn on
the old faucet to release any built up pressure. Remove existing faucet.
Clean sink or countertop to remove any debris, plumber’s putty, or
silicone.
·Flush angle stops to release any debris prior to installation.
·Pre-drilled hole size requirement: 1 3/8" (min) - 1 1/2" (max)
·Max countertop thickness: 1 3/8”
·1 hole installation and 2 or 3 with optional deck plate (not included)
3
For technical assistance or replacement parts, please contact Kraus
Customer Service and one of our representatives will be happy to help:
Toll-Free: 800-775-0703 or [email protected]

44
Diagram and Parts List
1. Spray Head
2. Faucet Body
3. Hot and Cold Waterlines
A. Hot
B. Cold
4. Quick Connector
5. Mounting Hardware
A. Rubber Washer
B. Metal Washer
C. Mounting Nut
D. Mounting Screws
6. Spray hose
7. Weight
8. Hex Wrench
9. Base O-Ring
Adjustable Wrench Silicone Sealant
(optional) Phillips Screwdriver Safety Goggles
1
3A
3B
4
5A
5C
5D
26
7
8
Tools you will need
5B
9

55
Installer Tip:
Shut off main water supply before installing new faucet.
Faucet Installation Procedure
MAX.
1 3/8"
(35mm)
Ø1 3/8"
(35mm)
11 1/4" (284.7mm)
8 5/8" (218.5mm)
12°
9 1/8" (231.5mm)
5 7/8"
(149.8mm)
6 7/8" (175mm)
3 3/4"
(94.6mm)
1 1/8"
(30mm)
15 5/8" (396.4mm)

66
Step 1A. Faucet installation - with deck plate
Step 1B. Faucet installation - without deck plate
For three-hole installation:
Deck plate, base plate
and silicone sealant
(optional) are required.
Note: Optional deck plate
not included.
For single-hole installation:
Deck plate, base plate and
silicone sealant are NOT
required.
3A
3B

7
Step 2. Install faucet and mounting hardware
Step 3. Secure mounting hardware
Insert faucet body (2) into
hole in countertop or deck
plate assembly. Install
mounting hardware (5A, B, C & D)
from underneath the
countertop.
Adjust direction of faucet
body (2) so that handle is on
right side of faucet. Tighten
mounting nut (5C) until snug.
Tighten mounting screws
(5D) to nut with a Phillips
screwdriver until snug.
5C
5D
5A
5C
5D
5B

8
Step 4. Attach spray hose and counterweight
Step 5. Connect waterlines
Connect spray hose (7)
to quick connector (4)
attached to supply line.
Install weight (8) on lowest
vertical point on spray
hose (7).
Connect waterlines (3) to angle
stops. Tighten both ends of
waterlines with a wrench
until snug. Turn on hot and
cold angle stops and check
for leaks.
4
7
8
3NOTE: Make sure filter
washers are installed.

9
Step 6. Flush spray hose
Remove spray head (1) from
spray hose (7). Hold tip of
spray hose (7). Turn faucet on
and let the water run for 60
seconds to flush any debris.
Step 7. Check for leaks
Check for leaks at the
connections. Retighten if
necessary.
7
1

10
Replacement Parts
1. Spray Head
2. Check Valve
3. Washer
4. Spray Hose
5. Hose Guide
6. Plastic Clip
7. Handle Button
8. Set Screw
9. Metal Handle
10. Cartridge Cover
11. Locking Nut
12. Cartridge
13. Base O-Ring
14. Protective Sleeve
15. Rubber Washer
16. Metal Washer
17. Mounting Nut
18. Mounting Screws
19. Quick Connector
20. Flow Regulator (1.8gpm)
21. Check Valve
22. EZ Weight
23. 2.5mm Hex Wrench
24. Filter Washer
25. Mounting Hardware Kit
(includes KP06041,KP06028,
KP06067,KP06068)
Replacement Parts List Finish/Color Part #
KP06089
KP06107
KP06074
KP06097
KP06007
KP06168
KP06029
KP06054
KP06169
KP06171
KP06170
KP06103
KP06172
KP06161
KP06041
KP06028
KP06067
KP06068
KP06173
KP06174
KP06104
KP06015
KP06050
KP06185
KP06200
SFS,MB,BG*
*Denotes faucet component color options:
SFS - Spot Free Stainless Steel
MB - Matte Black
BG - Brushed Gold
WH - White
14
19
16
17
15
18
24
22
23
6
3
4
2
4
5
7
8
12 11 10
9
13
21
20 WH*
SFS,MB,BG*
SFS,MB,BG*
SFS,MB,BG*
SFS,MB,BG*
