Kraus Allyn KPF-4100 User manual

AllynTM Single Handle Pull
Down Kitchen Faucet
KPF-4100
R
INSTALLATION MANUAL
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2021 Kraus USA Plumbing LLC I REV. December 7, 2021

2
Congratulations on the purchase of your new
Kraus plumbing fixture!
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance or have any problems with your product:
Please contact our Customer Service Team
1-800-775-0703 / [email protected]
Have the model number available and retain a copy of your
receipt with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE
STOP
R

3
Prior to Installation:
·Make sure you have all necessary parts by checking the diagram and
parts list. If any part is missing or damaged, please contact Kraus
Customer Service at 800-775-0703 for a replacement.
·Read all instructions and safety warnings and ensure you have all tools,
parts, and equipment necessary for a safe installation.
·Turn off the hot and cold water supply at the angle stops and turn on
the old faucet to release any built up pressure. Remove existing faucet.
Clean sink or countertop to remove any debris, plumber’s putty, or
silicone.
·Flush angle stops to release any debris prior to installation.
·Pre-drilled hole size requirement: 1 3/8" (min)
·Max countertop thickness: 2 1/4”
Care & Maintenance
* To keep the product clean & shining, follow the steps below:
1. Rinse with clean water & dry with a soft cloth
2. Do not clean with soaps, acid, polish, abrasives or harsh cleaners
3. Do not use cloth with a coarse surface
4. Unscrew the aerator and clean when necessary
* This installation manual is subject to change without further notice.
For technical assistance or replacement parts, please contact Kraus
Customer Service and one of our representatives will be happy to help:
Toll-Free: 800-775-0703 or [email protected]
ACID
R
STOP

44
Tools Required
Adjustable Wrench Phillips Screwdriver Silicone Sealant
Safety Goggles Pipe Tape

1
2
4
5
6A
6B
6C
7
8
9
3
55
Diagram and Parts List
1. Spray Head
2. Faucet Body
3. O-Ring
4. Waterlines
5. Quick Connector
6A. Metal Washer
6B. Mounting Nut
6C. Mounting Screws
7. Hex Wrench
8. Weight
9. Spray Hose

66
Faucet Dimensions
Installer Tip:
Shut off main water supply before installing new faucet.
5 3/4"
(147mm)
8 7/8"
(225mm)
4 5/8"
(118mm)
9"
(229mm)
17 1/2"
(445mm)
9 3/8"
(237mm)
Max.
2 1/4"
(57mm)
Ø1 3/8"
(35mm)
10 5/8"
(271mm)
3/8" Connection
5°

7
Step 1. Installing the O-Ring
Step 2. Install faucet and mounting hardware
Install the O-Ring (3).
Insert faucet body (2) into the hole
in the sink or countertop. Install
mounting hardware (6A, B & C)
from underneath the countertop.
3
6A
6B
6C

8
Step 3. Secure mounting hardware
Adjust direction of faucet body (2)
so that handle is on right side of
faucet. Tighten mounting nut (6B)
until snug. Tighten mounting
screws (6C) to nut with Phillips
screwdriver until snug.
Step 4. Attach spray hose and counterweight
Connect the spray hose (9) to
quick connector outlet (5)
attached to the supply line. Install
the weight (8) on the spray hose
where it is marked.
8
5
2
6C
6B

9
Step 5. Connect waterlines
Connect hot and cold copper lines
(4) to angle stops. Tighten both
ends of waterlines with a wrench
until snug. Turn on hot and
cold angle stops and check
for leaks.
4
Step 6. Flush spray hose
Remove spray head (1) from
spray hose. Hold tip of spray hose.
Turn faucet on and let the water
run for 60 seconds to flush any
debris.
NOTE: Please make sure filter
washers are installed before
connecting to the main valve.

10
Step 7. Check for leaks
Check for leaks at the connections.
Retighten if necessary.

11
1
2
3
Maintenance - Cartridge Replacement
Step 1: Loosen the set screw with a hex
wrench. Remove the handle and unscrew
the cartridge cover by hand.
Step 2: Unscrew the locking nut with an
adjustable wrench. Remove the
ceramic disc cartridge.
Step 3: Place the new cartridge in the handle
seat. Secure the cartridge with the locking
nut and assemble the handle.

10
11
12
13
14
15
16 17 18
1
2
3
5
6
7
8
9
4
12
Replacement Parts
Replacement Parts List Finish/Color Part #
KP06246
KP06247
KP06244
KP06240
KP06239
KP06241
KP06242
KP06243
KP06245
KP06041
KP06028
KP06067
KP06068
KP06161
KP06173
KP06174
KP06015
KP06050
KP06200
*Denotes spray hose assembly color options:
Spray hose assembly color options: Black
hose w/ Matte Black connector (BLMB),
Gray hose with Chrome connector (GRCH), Gray
hose with Spot-Free Stainless connector (GRSFS)
**Denotes faucet component color options:
CH - Chrome
SFS - Spot Free Stainless Steel
MB - Matte Black
BG - Brushed Gold
BL - Black
WH - White
GR- Grey
1. Spray Head
2. Spray Hose
3. Spout Clip
4. Set Screw
5. Faucet Handle
6. Cartridge Cover &
O-ring
7. Cartridge Nut
8. Cartridge
9. Base O-Ring
10. Rubber Washer
11. Metal Washer
12. Mounting Nut
13. Mounting Screws
14. Protective Sleeve
15. Quick Connector
Assembly
16. Flow Regulator
Assembly (1.8GPM)
17. EZ-Weight
18. Hex Wrench 2.5mm
19. Mounting hardware
kit (includes KP06041,
KP06028, KP06067,
KP06068)
20. Filter Washers
CH, SFS, MB, BG**
BLMB, GRCH,
GRSFS*
BL, GR**
WH**
CH, SFS, MB, BG**
CH, SFS, MB, BG**
KP06185
20

13
Troubleshooting
If you have followed the instructions carefully and your faucet still does not work properly,
take the following corrective steps:
Leakage under faucet handle
PROBLEM CAUSE ACTION
Locking nut has come loose or
cartridge needs to be reseated.
Loosen set screw with hex wrench. Remove
handle and pull out cartridge cover by
hand. Tighten locking nut with an
adjustable wrench.
Leaking between spray head
and the hose
Spray head may be loose or
washer is not seated correctly
in the hose connection.
Tighten spray head by hand until snug.
Make sure washer is seated correctly.
Water does not shut off
completely
Cartridge may need to be
adjusted or replaced.
Loosen set screw with hex wrench. Remove
handle and pull out cartridge cover by
hand. Unscrew locking nut with an
adjustable wrench. Remove ceramic disc
cartridge.
Check for cracks, and if O-ring is seated
correctly. Reseat cartridge.
Hose does not retract Weight may be installed
incorrectly.
Readjust weight on hose.
Low flow Aerator may be clogged Unscrew aerator with aerator key. Hold tip
of spray head and turn on water to flush
debris.
The screen filter in the hose
connectors is dirty.
Turn off the water supply at water valve
and unscrew the hose connectors from
water supply lines. Clean the screen in the
water lines with hot water, removing any
debris or calcium build up.

Codes/Standards Applicable:
UPC
CR
UPC
CR
NSF/ANSI 372 NSF/ANSI 61-9
ASME A112.18.1
1.8GPM 6.8L/min maximum
Faucet - Lifetime Limited Warranty
Kraus USA Plumbing, LLC (“Kraus”) extends this warranty to the original purchaser for personal household use of the
Faucet when purchased from an authorized Kraus dealer and in the location of original installation. This warranty is
non-transferable.
Kraus warrants the structure and finish of the Faucet to be free from defects in material and workmanship under normal
usage for as long as the original purchaser resides in the residence in which the Faucet was first installed.
Kraus warrants the Faucet's sprayhead assembly (including the engine, aerators, structure, restrictors, back flow
preventers, sprayer hoses, braided supply line hoses which encompasses nylon, silicon and stainless steel) of the product
to be free from defects in material and workmanship under normal usage for a period of one (1) year from the date of
purchase.
Kraus warrants the Faucet's cartridge to be free from defects in material and workmanship under normal usage for a
period of five (5) years from the date of purchase.
Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired
or replaced with a product of equal value at the option of Kraus.
Commercial Warranty
Kraus USA Plumbing, LLC (“Kraus”) warrants its Products for a period of one (1) year to commercial purchasers of
Products used in industrial, commercial and business applications.
Care and Cleaning Instructions
Certain cleaning products may cause damage to a Product's finish and use of the following on the Product will void this
warranty:
·Abrasive cleaners such as powders, bleach, ammonia, alcohol or chorine
·Abrasive pads, steel wool or wire brushes
What is Not Covered
This warranty does not cover Products that were discontinued when purchased or display Products, whether such
Products were purchased at discount outlets, unauthorized dealers, and/or sold on clearance. This warranty does not
cover any free gifts included with purchase.
This warranty does not cover damage resulting from neglect, misuse (including use for an unintended application),
abuse, carelessness, accident, hard water or mineral deposits, exposure to corrosive materials, improper maintenance,
alteration of the Product, or failure to follow care, cleaning or installation instructions enclosed with your Product. Kraus
recommends that all Kraus Products be installed by a fully licensed and insured trade professional with experience in the
installation of bathroom and/or kitchen manufactured goods.
R
14

How to Make a Warranty Claim
If you are a consumer purchaser, please contact a Kraus Customer Service Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
Toll-free 800-775-0703
[email protected]
If you are a plumbing contractor or trade professional, please contact a Kraus Pro Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8955
[email protected]
If you are an authorized partner, please contact a Partner Support Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8954
[email protected]
In requesting warranty service, please be ready to provide your proof of purchase and a description of the problem.
Shipping charges will be covered for the first (1) year of the warranted replacement part or product (HI, AK, and Puerto
Rico shipping charges may apply). International shipping fees are not included.
Limitation on Duration of Implied Warranties
Please note that some states/provinces (including Quebec) do not allow limitations on how long an implied
warranty lasts, so the below limitations may not apply to you. TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, ANY IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
OF FITNESS FOR A PARTICULAR PURPOSE, IS LIMITED TO THE STATUTORY PERIOD OR THE DURATION OF THIS
WARRANTY, WHICHEVER IS SHORTER.
Limitation of Special, Incidental or Consequential Damages
Please note that some states/provinces (including Quebec) do not allow the exclusion or limitation of special,
incidental or consequential damages, so the below limitations and exclusions may not apply to you. TO THE
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND KRAUS USA
PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
(INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS PRODUCT), WHETHER ARISING
OUT OF BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE.
This warranty gives you specific legal rights, and you may also have other rights which vary from state/province to
state/province.
Download the Kraus Care & Maintenance Guide at:
http://www.kraususa.com/maintenance
R
15

Register Your Kraus Product
Activate Your Warranty
Access Premium Customer Support
Get Product Information
REGISTER TODAY
http://www.kraususa.com/registration
