Kraus Odell KPF-1676 User manual

Odell Single Handle
Pull-Down Kitchen Faucet
KPF-1676
TM
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2018 Kraus USA Inc. I REV. December 11, 2019
R
INSTALLATION MANUAL

Congratulations on the purchase of your new
Kraus plumbing fixture!
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance or have any problems with your product:
2
Please contact our Customer Service Team
1-800-775-0703 / [email protected]
Have the model number available and retain a copy of your
receipt with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE
STOP

Prior to Installation:
·Make sure you have all necessary parts by checking the diagram and
parts list. If any part is missing or damaged, please contact Kraus
Customer Service at 800-775-0703 for a replacement.
·Turn off the hot and cold water supply at the angle stops and turn on
the old faucet to release any built up pressure. Remove existing faucet.
Clean sink or countertop to remove any debris, plumber’s putty, or
silicone.
·Flush angle stops to release any debris prior to installation.
·Pre-drilled hole size requirement: 1 3/8" (min) - 1 1/2" (max)
·Max countertop thickness: 1 3/8”
·1 hole installation and 2 or 3 with optional deck plate (not included)
3
For technical assistance or replacement parts, please contact Kraus
Customer Service and one of our representatives will be happy to help:
Toll-Free: 800-775-0703 or [email protected]

44
Diagram and Parts List
1. Spray Head
2. Faucet Body
3. Hot and Cold Waterlines
A. Hot
B. Cold
4. Quick Connector
5. Mounting Hardware
A. Rubber Washer
B. Metal Washer
C. Mounting Nut
D. Mounting Screws
6. Spray hose
7. Weight
8. Hex Wrench
9. Base O-Ring
Adjustable Wrench Silicone Sealant
(optional) Phillips Screwdriver Safety Goggles
1
2
Tools you will need
3A
3B
4
5A
5C
5D
6
7
8
9
5B

55
Installer Tip:
Shut off main water supply before installing new faucet.
Faucet Installation Procedure
2-M10
9 3/8" (239mm)
9 3/4" (249mm)
15 3/4" (401mm)
10°
Ø2 1/4"
(57mm)
10 1/2" (266mm)
3 1/8"
(79mm)
5 7/8"
(150mm)
Ø1 3/8"~1 1/2"
(35mm~38mm)
MAX.
1 3/8"
(35mm)

66
Step 1A. Faucet installation - with deck plate
Step 1B. Faucet installation - without deck plate
For three-hole installation:
Deck plate, base plate
and silicone sealant
(optional) are required.
Note: Optional deck plate
not included.
For single-hole installation:
Deck plate, base plate and
silicone sealant are NOT
required.

7
Step 2. Install faucet and mounting hardware
Step 3. Secure mounting hardware
Insert faucet body (2) into
hole in countertop or deck
plate assembly. Install
mounting hardware (5A, B, C & D)
from underneath the
countertop.
Adjust direction of faucet
body (2) so that handle is on
right side of faucet. Tighten
mounting nut (5C) until snug.
Tighten mounting screws
(5D) to nut with a Phillips
screwdriver until snug.
5A
5C
5D
5D
5C
5B

8
Step 4. Attach spray hose and counterweight
Step 5. Connect waterlines
Connect spray hose (6)
to quick connector (4)
attached to supply line.
Install weight (7) on lowest
vertical point on spray
hose (6).
Connect waterlines (3) to angle
stops. Tighten both ends of
waterlines with a wrench
until snug. Turn on hot and
cold angle stops and check
for leaks.
4
6
7
3
NOTE: Make sure filter
washers are installed.

9
Step 6. Flush spray hose
Remove spray head (1) from
spray hose (6). Hold tip of
spray hose (6). Turn faucet on
and let the water run for 60
seconds to flush any debris.
Step 7. Check for leaks
Check for leaks at the
connections. Retighten if
necessary.
6
1

10
Replacement Parts
1. Spray Head
2. Check Valve
3. Spray Hose
4. Hose Guide
5. Plastic Clip
6. Handle Button
7. Set Screw
8. Metal Handle
9. Cartridge Cover
10. Locking Nut
11. Cartridge
12. Base O-Ring
13. Protective Sleeve
14. Check Valve
15. Quick Connector
16. Rubber Washer
17. Metal Washer
18. Mounting Nut
19. Mounting Screws
20. Filter Washers
21. EZ Weight
22. 2.5mm Hex Wrench
23. Mounting Hardware Kit
(includes KP06041,KP06028,
KP06067,KP06068)
Replacement Parts List Finish/Color Part #
KP06093
KP06104
KP06195
KP06196
KP06159
KP06030
KP06055
KP06192
KP06021
KP06018
KP06193
KP06194
KP06161
KP06104
KP06108
KP06041
KP06028
KP06067
KP06068
KP06185
KP06015
KP06050
KP06200
SFS*
*Denotes faucet component color options:
SFS - Spot Free Stainless Steel
BL- Black
GR- Grey
SFS*
SFS*
SFS*
SFS*
SFS*
13
14
15
17
18
16
19
20
1
2
3
4
5
6
7
8
9
10
11
22
21
4
12
BL, GR*

11
Trouble-Shooting
If you have followed the instructions carefully and your faucet still does not work properly,
take the following corrective steps:
Leakage under faucet handle
PROBLEM CAUSE ACTION
Locking nut has come loose or
cartridge needs to be reseated.
Remove button located at top of handle.
Loosen set screw with hex wrench. Remove
handle and unscrew cartridge cover by
hand. Tighten locking nut with an
adjustable wrench.
Leaking between spray head
and the hose
Spray head may be loose or
washer is not seated correctly
in the hose connection.
Tighten spray head by hand until snug.
Make sure washer is seated correctly.
Care & Maintenance
To keep the product clean & shining, follow the steps below:
1. Rinse with clean water & dry with a soft cloth
2. Do not clean with soaps, acid, polish, abrasives or harsh cleaners
3. Do not use cloth with a coarse surface
4. Unscrew the aerator and clean when necessary
This installation manual is subject to change without further notice.
Water does not shut off
completely
Cartridge may need to be
adjusted or replaced.
Remove button located at top of handle.
Loosen set screw with hex wrench. Remove
handle and unscrew cartridge cover by
hand. Unscrew locking nut with an
adjustable wrench. Remove ceramic disc
cartridge.
Check for cracks, and if O-ring is seated
correctly. Reseat cartridge.
Hose does not retract Weight may be installed
incorrectly.
Readjust weight on hose.
Low flow Aerator may be clogged Unscrew aerator with aerator key. Hold tip
of spray head and turn on water to flush
debris.
ACID
The screen filter in the hose
connectors is dirty.
Turn off the water supply at water valve
and unscrew the hose connectors from
water supply lines. Clean the screen in the
water lines with hot water, removing any
debris or calcium build up.

12
Maintenance - Cartridge Replacement
Step 1: Remove button located
at the top of the handle. Loosen
the set screw with a hex
wrench. Remove the handle and
unscrew cartridge cover by
hand.
Step 2: Unscrew the locking nut
with an adjustable wrench.
Remove ceramic disc cartridge.
Step 3: Place the new cartridge
in the handle seat. Secure the
cartridge with the locking nut
and assemble the handle.

13
FAUCET WARRANTY
Kraus products are manufactured and tested to the highest quality standards by Kraus USA Inc. ("Kraus").
Kraus extends this warranty to the original purchaser for personal household use of the "Faucet" in its original location.
The warranty is non-transferable.
Kraus warrants the structure and finish of the product to be free from defects in material and workmanship under normal
usage for the lifetime of the product. The warranty commences from the initial date of purchase by the owner or trade
professional, from an authorized Kraus dealer, through the lifetime of the original owner or end-user.
Kraus warrants the mechanical components such as but not limited to sprayhead assembly (includes engine, aerators,
structure, restrictors, back flow preventers, sprayer hoses, braided supply line hoses which encompasses nylon, silicon and
stainless steel,etc) of the product to be free from defects in material and workmanship under normal usage for a period of
one (1) year. The warranty commences from the initial date of purchase by the owner or trade professional, from an
authorized Kraus dealer, through the one (1) year term of the original owner or end-user.
Kraus warrants the mechanical component (cartridge) of the product to be free from defects in material and workmanship
under normal usage for a period of five (5) years. The warranty commences from the initial date of purchase by the owner
or trade professional, from an authorized Kraus dealer, through the five (5) year term of the original owner or end-user.
Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or
replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and
is not transferable to a subsequent owner.
RESTRICTIONS
This warranty does not cover antediluvian, discontinued, or display products, whether such items are purchased at
discount outlets, unauthorized dealers, and/or sold on clearance.
This warranty does not cover instances of negligence, misuse, abuse, improper installation, carelessness, accident, hard
water or mineral deposits, exposure to corrosive materials, misapplication, damages caused by improper maintenance,
alteration of the product, or failure to follow care or installation instructions enclosed with your product. Avoid using
abrasive cleaners such as powders, bleach, ammonia, alcohol, or chlorine. Avoid using abrasive pads, steel wool, or wire
brushes, as these will damage and wear down the finish.
This warranty does not apply to Products that have not been installed or operated in accordance with instructions
supplied by Kraus and all applicable rules, regulations, and legislation pertaining to such installations.
This warranty does not apply unless the Kraus product is installed by a fully insured and licensed trade professional.
Kraus insists that such professionals have experience in the installation of bathroom and kitchen manufactured goods.
This warranty does not cover labor charges or costs of removal and reinstallation of said product. This warranty does not
allow recovery of incidental or consequential damages, such as loss of use, delay, property damage, or other
consequential damages, and Kraus accepts no liability for such damages.
This warranty does not cover Marine or Outdoor Installation.
Codes/Standards Applicable:
UPC
CR
UPC
CR
NSF/ANSI 372 NSF/ANSI 61-9
ASME A112.18.1
1.8GPM 6.8L/min maximum

14
Except as otherwise provided above, Kraus makes no warranties, expressed or implied, including warranties of
merchantability and fitness for a particular purpose, or compliance with any code.
Shipping charges will be covered for the first (1) year of the warranted replacement part or product (HI, AK, and Puerto
Rico shipping charges may apply). International shipping fees are not included.
COMMERCIAL WARRANTY
Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and
business use.
All incidental or consequential damages are specifically excluded. No additional warranties, express or implied, are given,
including but not limited to any implied warranty of merchantability or fitness for a particular purpose.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long
an implied warranty lasts, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
KRAUS USA has the right to change, modify, and/or update the warranty policy at any time. For the latest, most up to
date comprehensive warranty, go to www.kraususa.com/warranty
If you are a homeowner please contact a Kraus Customer Service Representative at:
Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
Toll-free 800-775-0703
[email protected]
If you are a plumbing contractor or trade professional please contact a Kraus Pro Representative at:
Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8955
[email protected]
If you are an Authorized Partner please contact a Partner Support Representative at:
Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8954
[email protected]
In requesting warranty service, please be ready to provide:
1. Proof of purchase.
2. A description of the problem.
Download the Kraus Care & Maintenance Guide at:
http://www.kraususa.com/maintenance

Register Your Kraus Product
Activate Your Warranty
Access Premium Customer Support
Get Product Information
REGISTER TODAY
http://www.kraususa.com/registration
R
www.kraususa.com
IMPORTANT
