Krell Industries 800 Series Quick start guide

B. BASIC INSTALLATION AND CONNECTIONS
I. Open the box and remove the top layer of foam. The following items
will now be visible:
I Bass Alignment Filter
1 AC power cord
1 packet containing ~the Owners Reference and Warranty Registration
Card
Note: If any of these items are not included please contact your
authorized dealer immediately for assistance.
2. Remove the unit from the box and and remove its protective plastic
wrap.
3. Set the internal switches for your B&W loudspeaker with the
instructions provided below.
The KRELL Bass Alignment Filter is adjustable for any B&W 800 Series
loudspeaker. Internal dip switches set the filtration network for
different models. A diagram describing the switch positions is
provided.
C. SETTING THE INTERNAL SPEAKER SELECTION SWITCHES
CAUTION: Make sure the power cord is not connected to the AC
receptacle.
The Krell B.A.F. is designed for B&W 800 series loudspeakers ~ and
will not operate properly if used with other loudspeaker systems.
i. Remove the I0 screws from the top cover and remove the cover.
2. LooMing down at the unit from the front, the adjustment switches
are located in the front-center and front-left corner of the PC
board.
Set the dip switch positions according to the supplied diagram for
your B&W loudspeaker. Make sure the switches are all the way over to
the selected side and not resting between the number and Open
positions.
3. Put the top cover back on the unit and insert the i0 screws.

Notes reqardinq balanced operation:
If you are using two B.A.F.s in balanced operation both units’
internal switch settings must be the same.
When two B.A.F. are connected for balanced operation they
automatically utilize the balanced circuitry without adjustment of
the units.
D. CONNECTIONS
Caution: When making connections to this component or any other
always make sure the power amplifier is OFF and the preamplifier is
in the Mute or standby mode.
Install the unit(s) on a clean, level surface away from excessive
heat or moisture.
The Krell B.A.F. can be connected to your system in four different
configurations. Connection details of the four options are presented
below. Follow the instructions that are appropriate for your system.
I. Sinqle unit, sinqle-ended between preamplifier and amplifier(s)
Connect the single-ended output of your preamplifier to the input of
the B.A.F. Connect the output of the B.A.F. to the single-ended input
on your power amplifier(s).
Operate your system in the same manner as before the B.A.F was
installed.
2. Sinqle unit, sinqle-ended, throuqh the preamplifier ~ape loop
Connect the Tape outputs of your preamplifier to the inputs of the
B.A.F. Connect the outputs of the B.A.F. to the Tape inputs of your
preamplifier. Be sure to maintain correct left and right channel
connections.
When listening to the B&W speakers, the Tape Monitor should be set to
the position corresponding to the output return from the B.A.F. The
Input Selector is used to select a source for listening.
Caution: In this configuration the Input Selector must not be set to
the input connected to the B.A.F. output. As with any tape recorder
or surround processor, this will create a feedback loop that can
cause a squeal. At high volume settings this could potentially damage
the loud speakers.

3. Dual units, balance.d, between p~eamplifier and amplifier(s)
Connect the left channel balanced output of your preamplifier to the
balanced input on the left channel B.A.F. Connect the balanced output
of the left B.A.F to the left balanced input of the power amplifier.
Do the same for the right channel.
Operate your system in the same manner as before the B.A.F.s were
installed. ~.~
4. Dual units, balanced or sinqle-~nded, throuqh the preamplifier
tape Ioo~
Connect the left channel Tape output of your preamplifier to the
input of the left channel B.A.F. Do the same for the right channel.
Connect the output of the left channel B.A.F. to the left channel
Tape i or 2 input of your preamplifier. Do the same for the right
channel.
When listening to the B&W speakers, the Tape Monitor should be set to
the position corresponding to the output return from the B.A.F. The
Input Selector is used to select a source for listening.
Caution: With this configuration the Input Selector must meve~ be set
to the input connected to the B.A.F. output. This will create a
feedback loop that can damage other system components.
5. After double-checking the input/output connections, connect the
power cord to the B.A.F.(s) and the other end to an AC outlet. The
unit(s) is now powered and operational.
There is no ON/OFF switch on the B.A.F. It was designed to be left on
at all times. The unit will draw less than i0 watts from the AC
powerline.
6. Turn the other system components on, remembering that the
amplifier is always the last component to be energized.
7. Enjoy

E. WARRANTY AND SERVICE INFORMATION
There are no user-serviceable parts inside the KRELL B&W 800 series
Bass Alignment Filter. The B.A.F. has a limited warranty of five
years parts and labor on electronic parts including return freight.
The warranty period begins on the date of purchase and is activated
with the return of the enclosed Warranty Card and a copy of the Sales
receipt. Please return the completed Warranty Card immediately after
successful installation and operation are completed.
The warranty for Krell products is valid only in the country to which
they were originally shipped and at the factory. If you think there
are problems with your unit please contact your dealer, distributor
or the factory immediately.
Please do not return any unit to KRELL for repair without first
calling to discuss the problem and to obtain a Return Authorization
number. Freight to the factory or distributor is your responsibility.
Return freight to you will be paid by the factory or distributor.
