Kronen KG-201 Quick start guide

Chocolate Heater
Translation of the
Original Instruction Manual
English

Manual Chocolate Heater
2
Instruction manual chocolate heater
Version: 1.2
Date of release: 22.04.2016

Manual Chocolate Heater
3
Contents
1. General Information.....................................................................................................4
2. Safety...........................................................................................................................8
3. Technical Characteristics...........................................................................................10
4. Installation and Function............................................................................................11
5. Transportation and Packaging...................................................................................14
6. Installation and Initial Operation.................................................................................15
7. Use and Operating.....................................................................................................16
8. Malfunctions...............................................................................................................18
9. Maintenance ..............................................................................................................19
10. Appendix....................................................................................................................20
11. Index..........................................................................................................................22

Manual Chocolate Heater
4
1. General Information
Always keep the instruction manual and all the other documents near the
chocolate heater. Before using the machine the first time, make sure that you
read the instruction manual first.
Explanation of the symbols used in the documents
Limitation of liability
If you do not follow the instruction manual, the manufacturer is not liable.
Manufacturer
Kronen Küchengeräte GmbH
Gewerbestr. 3
D-77731 Willstätt
Phone: [phone]
Fax: [phone]
[e-mail]
WARNING! Hot surface!
This symbol draws attention on the hot surface of the
device when in use. If not observed it may cause burns!
Attention, you have to follow the instructions to avoid
harm for you and the machine.

Manual Chocolate Heater
5
Defects and Claims
1. Claims based on material defects shall be subject to a limitation period of 2
years after surrender of the merchandise. The Seller does not assume any
liability for material defects in pre-owned merchandise.
2. We will, at our discretion, make new delivery for or subsequently improve any
and all rendered services which are verifiably determined to be defective as a
consequence of circumstances existing before the transfer of risk.
3. We reserve title to any and all parts which have been replaced.
4. In particular, no warranty will be assumed for damage or loss resulting from
the following causes, but for which we are not accountable:
Natural wear and tear, intervention or repair work improperly performed by
the Buyer or third parties, unsuitable or incorrect use, incorrect operation,
installation, commissioning, incorrect or negligent handling, improper main-
tenance, use of unsuitable operating materials and cleaning agents, chemi-
cal, electrochemical or electrical factors, any modifications of the merchan-
dise performed without our consent.
5. The Buyer shall allow the Seller the necessary time and opportunity to per-
form any subsequent improvement or substitute delivery which we regard, in
our reasonable judgment, to be necessary.
6. In the event of legitimate complaints, the Seller shall bear the immediate
costs of the subsequent improvement or substitute delivery. The total costs
which we must bear shall be limited to the value of the order in the event that
the places of delivery are outside the territory of Germany.
7. In cases in which the Buyer shares accountability for causing the defect, in
particular in the event of breach of the obligation to prevent and reduce loss or
damage, the Seller reserves the right to assert a corresponding damage com-
pensation claim.
8. The Buyer shall, at his discretion, have the right to cancel the contract if and
when –taking into account the statutory exceptions –a period which has been
set for us for subsequent improvement or substitute delivery due to material
defects has lapsed in vain.
9. The Buyer’s rights arising from the liability for material defects may not be
assigned without the Seller’s consent.

Manual Chocolate Heater
6
Terms and Conditions of Warranty
1. The Seller hereby grants to the end customer a warranty for newly manufac-
tured Kronen Küchengeräte GmbH appliances, provided that they remain in
Germany. The warranty period shall be 12 months as of the delivery of the
appliance to the end customer, but shall not exceed 18 months from the dis-
patch of the appliance from the works.
2. Kronen Küchengeräte GmbH will perform subsequent improvement or substi-
tute delivery of the defective parts within the scope of the warranty, provided
that the functional capability of the Kronen Küchengeräte GmbH appliance has
been significantly impaired. Further claims within the scope of the warranty are
excluded.
Following notification in due time of a warranty case, the Kronen Küchengeräte
GmbH service department will decide how the defect is to be remedied and will
discuss the subsequent actions with the customer, engaging an Kronen
Küchengeräte GmbH authorised customer service centre if necessary. If and
when the appliance must be shipped to a service centre for repair within the
scope of the warranty, shipment shall be made at the customer’s expense and
risk.
3. Warranty claims are excluded in the following cases:
- Normal wear and tear
- Incorrect installation of the appliance
- Wilful damage or incorrect operation
- Damage caused by calcium deposits
- Damage caused by inspection or repair by persons who are not authorised
by Kronen Küchengeräte GmbH
4. Kronen Küchengeräte GmbH restricts the terms and conditions of warranty
for appliances which are intended for sale abroad. In such cases, Kronen
Küchengeräte GmbH grants a warranty covering the original Küchengeräte
GmbH spare parts. This warranty covers the functional capability of the spare
parts, provided that they are installed correctly. Kronen Küchengeräte GmbH
shall provide a replacement part in the event of a functional defect. No installa-
tion or personnel expenses which may be incurred will be assumed.
The warranty in this case is limited to 12 months as of the transfer of risk.
5. The warranty services described above are subject to the condition that all
required maintenance and care work is carried out by a customer service
authorised by Kronen Küchengeräte GmbH and that any and all care and op-
erational instructions from Kronen Küchengeräte GmbH have been followed.
The warranty may not be transferred without the written consent of Kronen
Küchengeräte GmbH.

Manual Chocolate Heater
7
6. Kronen Küchengeräte GmbH grants a function warranty of 6 months for each
and every original Kronen Küchengeräte spare part, provided that it has been
installed correctly. Kronen Küchengeräte GmbH shall provide an original part in
the event of failure. No further claims, including claims for the cost of the re-
placement, can be acknowledged. Parts which are subject to above-average
wear and tear by the operator are excluded from the above warranty cover.
Copyright Protection
It is forbidden to copy all the documents delivered with the chocolate heater
partly or completely without the permission of the manufacturer.
Disposal of the Machine
The chocolate heater, respectively all the parts have to be disposed recycled
according to the local rules and laws. It is forbidden to dispose the chocolate
heater with the household garbage.
.

Manual Chocolate Heater
8
2. Safety
General Sources of Danger
That is why, we advise you to respect and follow the safety instructions.
-Make sure that unauthorized persons or untrained persons, especially
children, do not start and work with the chocolate heater.
-It is strictly prohibited to change or remove all the safety appliances on
the chocolate heater because this could result in serious danger for the
user.
-While you are using the machine stay concentrated and never get dis-
tracted.
-Always keep your working environment clean and dry to make sure
you don’t slip and fall.
-Don’t put objects on the chocolate heater which don’t belong there and
don’t use the machine as a storage place
Wrongful use or limited knowledge of the safety instruc-
tions could result in accidents and injuries on hands and
fingers.

Manual Chocolate Heater
9
Intended Use
The chocolate heater is a technical tool which exclusively should be used for its’
intended purpose.
Its only purpose is to warm chocolate into the designated containers.
Any different use of the machine is strictly forbidden.
The chocolate heater is intended for industrial use and only should be used by
trained workers of the company.
Personal protective equipment is not needed for the use of the chocolate heat-
er. Stricter company rules still apply.
It is strictly prohibited to make any reconstructions on the chocolate heater.
The full responsibility for the intended use and the compliance with safety in-
structions takes the operating company.

Manual Chocolate Heater
10
3. Technical Characteristics
Weight: 8 kg
Dimensions: 545 x 334 x 225 mm
Connected load:
Line voltage 230 V
Mains frequency 50 Hz
Requirements for
intended place: - horizontal and flat
- Not slippery
- Table height between
600 and 900 mm
- No flammable surface
(e.g. table cloth, carpet,
etc.)
Performance data
and - limits : net power 1000 W
Recommended mains fuse 10 A
Non-ionizing radiation:
Non-ionizing radiation is not produced specific, but only technically limited by
the electrical equipment (e.g. electric motors, power lines, or magnetic coils)
delivered. In addition, the machine has no strong permanent magnets. In com-
pliance with a safety distance (distance to source field implant) of 30 cm, the
influence of active implants (e.g. pacemakers, defibrillators) can be excluded
with high probability.

Manual Chocolate Heater
11
4. Installation and Function
In the chocolate tempering can GN pans can be loaded. On a water bath, the
chocolate is heated in the GN shells.
Included in delivery
Delivery includes the fully assembled chocolate heater built of stainless steel.
Also in the box are all the documents including the instruction manual and two
GN containers.
Type Plate
The label is at the back of the chocolate heater.
It includes following information:
Manufacturer and Address
Type
Serial number
Year of construction
Nominal voltage
Line voltage
Mains frequency
Parts and Description
Body (1): built out of stainless steel.
Drain tap (2): Through the drain tap the water can be drained after
using.
Thermostat (3): With the thermostat the desired temperature can be
set.
Control lamp (4): The control lamp indicates when the chocolate
heater heats.
Main switch (5): With the main switch, the chocolate heater is
switched off and on.

Manual Chocolate Heater
12
Assembled Parts
1
Body
2
Drain tap
3
Thermostat
4
Control lamp
5
Main switch
1
2
5
4
3

Manual Chocolate Heater
13
Operating Elements
The chocolate heater has a main switch (5) to turn on the unit. If the main
switch on the chocolate heater is switched on, the button glows.
On the thermostat (3), the desired temperature can be set. The setting range is
from 0 to 100 ° C.
During the heating process, the indicator light (4) glows. This will turn off when
the thermostat set temperature is reached.
5 4 3

Manual Chocolate Heater
14
5. Transportation and Packaging
Always transport the chocolate heater in the intended box.
Always transport the machine upright and make sure it is secured.
In case there is more than one chocolate heater on the pallet do not put another
pallet on top of it.
Check the box of possible damages when the machine is shipped. In case of
damages, talk to the responsible shipping company.
Open the box by slicing the tape with a tape slicer. Do not use sharp knives.
Lift the chocolate heater out of the box and put it on the table.
Make sure that shipment consists out of the things you ordered. In case the
shipment is not complete talk to the responsible salesman.
There are no transportation devices installed on the chocolate heater.
Dispose or recycle the machine according to the local laws.
Always lift and hold the machine at the body.

Manual Chocolate Heater
15
6. Installation and Initial Operation
The chocolate heater is shipped ready for use. The installation and the initial
operation can be done by the user
The table has to fulfil certain requirements:
-Horizontal and flat
-Not slippery
-Table height between 600 and 900 mm
-No flammable surface (e.g. table cloth, carpet, etc.)
After you placed the chocolate heater on the table plug in the machine in the
intended outlet. The mains plug has to be viewed and easily accessible at any
time by the operator.
Before you do that, make sure that the required specifications on the label are
fulfilled. In case they don’t match don’t plug in the machine or turn it on. In this
case, call the responsible customer service.
The outlet has to comply with the CEE 7/7 standards.
Before the first use make sure you cleaned the chocolate heater. Follow the
instructions in chapter “7 Use and Operating” passage cleaning.

Manual Chocolate Heater
16
7. Use and Operating
Safety instruction for operating
“To-do-list” before operating the machine
Make sure the chocolate heater is clean especially in those areas that come in
contact with the food, for example: the GN container. In case it is necessary
clean those areas according to the instructions given in paragraph cleaning.
Working with the chocolate heater
Fill the chocolate heater for uniform heat distribution with water.
Note the filling capacity minimum / maximum.
Insert the GN containers and fill them with brown or white chocolate.
Turn on the machine with the main switch (5). The main switch is glowing
green. Next, set the thermostat (3) to the desired temperature. Once the set
temperature is reached, the light turns off (4). If the temperature in the tank
drops, it will light up again.
Note: Fill warm water into the device, it saves time and energy!
Make sure that the water level does not fall below the
"MIN" mark!
Check the water level periodically during the operation!
The device is not allowed to be operated without water in
the tank!
During operation some parts of the device are very hot.
To avoid burns, do not touch hot parts of the device!

Manual Chocolate Heater
17
Cleaning
Before you use the chocolate heater the first time make sure you clean it thor-
oughly. Also, clean the machine multiple times during the day after use.
Always use standard cleansers for cleaning the chocolate heater.
To clean the chocolate heater turn it off with the main switch (5) and disconnect
the mains plug.
Let the cooled water drain over the drain tap (2).
Clean now the chocolate heater and GN container with a common household
dish detergent and remove stubborn remaining product with a brush. Then rinse
thoroughly with clean water to remove any detergent residues and rub the
chocolate heater and GN Container dry with a dish towel
Advice: Do not use any hard items to clean the chocolate heater.
WARNING! Risk of scalding!
The water has to cool down before draining.
The chocolate heater is only protected against splash
water. Do not use high-pressure cleaner, steam cleaner or
similar methods.

Manual Chocolate Heater
18
8. Malfunctions
Safety instructions
Only costumer service should disassemble parts in case of malfunctions.
In case of reoccurring malfunctions call your customer service.
Error Correction
Error
Possible cause
Solution
Machine does heat. No
lamp is glowing.
Machine is not plugged
in
Main switch or mains
plug is defect
Plug in the machine
Those malfunctions
are to be fixed by
customer service
only.
Machine does heat. The
Main switch is glowing.
Thermostat is defect
Heating unit is defect
Those malfunctions
are to be fixed by
customer service
only.

Manual Chocolate Heater
19
9. Maintenance
Safety Instructions
Support / Customer Service / Hotline
Sales Department and customer service:
Kronen Küchengeräte GmbH
Gewerbestr. 3
D-77731 Willstätt
Phone: [phone]
Fax: [phone]
[e-mail]
Local Sales Department and customer service:
Partner
Street
Zip Code & Place
Tel.
Fax.
Service yes / no
To be filled out by local representative.
Maintenance, if not specifically mentioned, is not to be
done by the user. Maintenance is done by customer ser-
vice only.

Manual Chocolate Heater
20
10. Appendix
Declaration of Conformity
EG - LVD 2006/95/EG, EMC 2014/30/EC, (EC) VO 1935/2004, WEEE
2012/19/EC and RoHS 2011/65/EC.
Authorized Person: Christian Höltge
KRONEN Küchengeräte GmbH
Gewerbestraße 3
D-77731 Willstätt
Manufacturer: KRONEN Küchengeräte GmbH
Gewerbestraße 3
D-77731 Willstätt
declares that the following product:
Product name: Chocolate heater
Serial Number: ________________________
conform with the guideline mentioned on top - including the changes of
the statement at this point of time.
Following engineer standards apply:
EN 55011 Industrial, scientific and medical equipment - Radio-frequency
disturbance characteristics - Limits and methods of measurement
EN 55014-1 Electromagnetic compatibility - Part 1: Emission
EN 55014-2 Electromagnetic compatibility - Part 2: Immunity
EN 61000-3-2 Electromagnetic compatibility (EMC) - Part 3-2: Limits - Limits for
harmonic current emissions
EN 61000-3-3 Electromagnetic compatibility (EMC) - Part 3-3: Limits - Limitation of
voltage changes
EN 60335-1 Household and similar electrical appliances - Safety - Part 1: Gen-
eral requirements
EN 60335-2-50 Household and similar electrical appliances - Safety - Part 2-50:
Particular requirements for commercial electric bains-marie

Willstätt, the 22.04.2016
Place, Date Frank Förster
CEO
