Wall Mount Pre-Rinse
Installation Manual
17-108WL, 17-109WL

Krowne • 100 Haul Rd. Wayne, NJ 07470 krowne.com
Wall Mount Pre-Rinse Installation Manual
Installation Instructions
1. Turn off water supply at main source before proceeding with installation.
2. Remove the two ½” threaded nipples (A) from the wall mount kit inside the box.
3. Apply thread sealant tape or pipe joint compound to one side of each of the two threaded
nipples (you will apply to the other side after step #4 is completed).
4. Install the threaded nipples with the sealant into the two ½” female threaded coupling
anges (B) and tighten properly. It is important to know that the coupling anges have
eccentric centers. This means that if the holes for the threaded nipples are not exactly 8” on
center, it allows you to adjust the center distance.
5. From the front of the sink, insert the threaded nipples into the faucet holes in the wall (C).
Make sure the coupling anges are turned so the brass nipples are at the 12 o’clock position.
This is necessary to make sure the faucet is level.
6. Apply thread sealant tape or pipe joint compound to the other side of each of the two
threaded nipples.
WARNING: Plumbing connections should be made by qualified personnel
who will observe all applicable plumbing, sanitary and safety codes.
Sink/Mounting
Surface
Black Rubber Washer
Rosette
Lock Nut
A
E
D
G
C
F
H
B
Figure 1
Note: For easy installation, we highly recommend using our E-Z Install Flexible Water Lines
(Model 21-443L). They include 1/2” NPT close elbows with swivel compression ttings on the
faucet side and 3/8” compression ttings on the water supply side. No thread sealant tape or
soldering required.

Krowne • 100 Haul Rd. Wayne, NJ 07470 krowne.com
Wall Mount Pre-Rinse Installation Manual
7. From the back of the sink, place the black rubber washer, rosette, and lock nut onto the
threaded nipples and tighten with a wrench.
8. From the front of the sink, insert the rubber washers (D) into the coupling anges (B).
9. Install the faucet body (E) onto the coupling anges and tighten properly with a wrench. If
the faucet does not t on the coupling anges, they will need to be rotated to t the faucet
as per step 4 above.
10. From the back of the sink install the water supply lines and tighten properly.
11. To assemble the pre-rinse with the add-on faucet, remove the riser pipe (G) and add-on
faucet assembly (H) from the box. Thread onto the faucet body and tighten.
12. Determine the correct length of the support rod (I) from the wall to the riser pipe (G). Cut the
support rod to size (Figure 2).
13. Determine the position on the wall for the wall bracket brace (J), making sure it is near the
top of the riser pipe (G).
14. Install the wall bracket brace on the wall with the included screws. Press the end of the
support rod into the bracket. Use allen wrench to tighten set screw in place.
15. Install the head of the support rod (K) around the riser with the two supplied screws.
16. The pre-rinse spray head (L), hose (M), and spring (N) have been assembled at the factory to
save time.
17. Install the complete assembly onto the top of the riser pipe, making sure you use the small
black washer supplied in the cardboard cylinder in the packaging. Tighten appropriately.
18. Loosen the spray head hook (O) and center it on the riser pipe. Tighten when it is in place.
19. Install faucet spout (F) onto add-on faucet body (H) (Figure 1).
I
J
O
G
K
L
M
N
Figure 2

Krowne • 100 Haul Rd. Wayne, NJ 07470 krowne.com
Wall Mount Pre-Rinse Installation Manual
Scan to view
aerator options.
1
8
7
2
3
20
4
10
11
12
15
19
17
18
9
16
13
5
14
6

Krowne • 100 Haul Rd. Wayne, NJ 07470 krowne.com
Wall Mount Pre-Rinse Installation Manual
Parts Guide
No. Model Description
1 21-138L Add-On Faucet with 6” Spout
1 21-149L Add-On Faucet with 8” Spout
1 21-139L Add-On Faucet with 12” Spout
1 21-140L Add-On Faucet with 14” Spout
1 21-141L Add-On Faucet with 16” Spout
2 21-308L Cold 1/4 Turn Ceramic Cartridge Valve
3 21-309L Hot 1/4 Turn Ceramic Cartridge Valve
4 21-333L Cold 1/4 Turn Ceramic Cartridge Valve, Less Handle
5 21-334L Hot 1/4 Turn Ceramic Cartridge Valve, Less Handle
6 21-306 Lever Handle Kit (includes hot & cold handles with color indicators)
7 21-401L Coupling Flanges (includes 2/ea)
8 21-194L Wall Mounting Kit (includes 2/ea: nipples, lock nut, rosette, washer)
9 21-108L 8” Center Wall Mount Pre-Rinse Base
10 21-137 Wall Bracket
11 21-168 Riser (12” Long, 3/8” male thread)
11 21-160L Riser (18” Long, 3/8” male thread)
11 21-160-24L Riser (24” Long, 3/8” male thread)
12 21-161L Spring Retainer
13 21-162 24” Spring
14 21-133L 44” Pre-Rinse Hose with Grip
14 21-134L 60” Pre-Rinse Hose with Grip
14 21-135L 72” Pre-Rinse Hose with Grip
14 21-136L 96” Pre-Rinse Hose with Grip
15 21-164L Grip (1/2” NPS Male)
16 21-165 Hook/Screw Assembly
17 21-171 Spray Head Handle
18 21-302L Button Valve
19 21-179L Spray Head Repair Kit - New Style (2007 to present)
20 21-129L 1.15 GPM Spray Head

Krowne • 100 Haul Rd. Wayne, NJ 07470 krowne.com
Wall Mount Pre-Rinse Installation Manual
Options and Accessories
Model Description
21-127L 0.65 GPM Spray Head
21-130L Shower Pattern Spray Head
21-131L Angled Pre-Rinse Spray Head
21-132L Pot Filer Spray Head
21-170 Ring (Optional)
21-311 Wrist Blade Handle Kit (includes hot and cold handles)
21-443L E-Z Install Flexible Water Line Kit
21-547L Swivel Pre-Rinse Hose Connector
25-150 Thread Sealant Tape
21-170
21-547L 21-311
21-130L21-129L
21-443L
21-131L
25-150
21-132L

Krowne • 100 Haul Rd. Wayne, NJ 07470 krowne.com
Wall Mount Pre-Rinse Installation Manual
Notes

Wall Mount Pre-Rinse Installation Manual
This Standard Warranty and Limitation of Liability (the “Warranty”) sets forth the warranty provided by Krowne Metal Corpora-
tion (hereinafter “Krowne”) with respect to the product purchased by Purchaser (the “Equipment). By accepting delivery of the
Equipment, Purchaser agrees to be bound by and accept these terms and conditions. All dened terms within the Warranty shall
have the same meaning and denition as provided elsewhere in the Warranty. Equipment covered by the Warranty shall only be
warranted in connection with its original installation only. Krowne will only be obligated to honor the warranty set forth in these
terms and conditions upon receipt of full payment for the equipment.
Please visit krowne.com/warranty for full terms and conditions regarding
the warranty on your new Royal Series product.
Warranty
WARNING: This product can expose you to chemicals including lead and lead compounds, which are known to the State of
California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
100 Haul Rd. • Wayne, NJ 07470
krowne.com
Product Description Warranty Period
Royal Series Plumbing 3 Year
