Ksenia Lares 4.0 wls 96 User manual

Installation manual
www.kseniasecurity.com

All information in this document is subject to change without notice
and does not represent a commitment on the part of Ksenia Security

lares 4.0 Installation manual
3 R30024.120it
INTRODUCTION 5
Overview 5
Main functions 6
Compatibility 7
lares 4.0 versions and characteristics 7
lares 4.0 wls 96 and characteristics 8
Technical data 9
lares 4.0 control panel and its peripherals 9
INSTALLATION 11
lares 4.0 control panel description and connections details 11
Wall mounting instructions 12
lares 4.0 motherboard description 15
lares 4.0 wls 96 control panel description and connections details 16
Local or remote keypad description 17
Wall mounting instruction 18
lares 4.0 wls 96 motherboard description 19
Outputs section 20
Status LED 20
Maintenance operations 21
Add-On 3G module 22
Installation 22
Add-On 4G/LTE 23
Installation 23
Add-On PSTN module 24
Installation 24
Control panel power terminals 25
KS-BUS (RS485) connection diagram 25
KS-BUS Connection cable (section and characteristics) 25
Compatible BUS devices 26
Battery replacement 26
CONFIGURATION - LOGGING IN FOR THE FIRST TIME 27
Access to the portal Ksenia SecureWeb 27
Configuration from PC 28
Configuration from APP Ksenia PRO 30
Programming from keypad 31

lares 4.0 Installation manual
R30024.120it 4
How to read the control panel IP address from keypad 32
lares 4.0 Declaration of conformity 33
lares 4.0 wls Declaration of conformity 34

lares 4.0 Installation manual
5 R30024.120en
1. INTRODUCTION
Instruction for mounting and wall fixing the metal container, inside which the lares 4.0 control panel is housed, the
connections required and a brief mention about the different programming methods reserved to the installer,
including a quick overview of first access, are described in this manual.
The configuration of the control panel is the argument of "lares 4.0 Programming Manual".
The information described here is valid for all the models of lares 4.0 control panels.
1.1 Overview
lares 4.0 control panels represent the most advanced and reliable Solution in the Digital Revolution (IoT), in terms
of Physical Security (Intrusion, Video Verification, Access Control) and Home & Building Automation (lighting
control, heating/air conditioning, irrigation, roller shutters, automation and load control, access control, etc.).
All the models of lares 4.0 are hybrid (wired and wireless) and have a number of outputs equal to the number of
inputs for managing any type of automation. All of them can be managed by a single user APP (lares 4.0) and
programmed through the Ksenia Pro installer APP installed any mobile device, by the installer.
The Installer APP (Ksenia Pro) allows you to centralize and geolocalize all the installed units and therefore to offer
maximum assistance to the end customer by receiving push notifications also for technological alerts.
In fact, by implementing a web server inside the motherboard, you do not need any program to be installed on the
PC: it is possible to program the control panel, perform all the management operations available in the system
through the integrated installer WEB-SERVER, connecting to the Ksenia SecureWeb cloud for the remote
management and programming via mobile APP.
Regardless of the control panels size, the motherboard is native with Ethernet interface, 8 input terminals and 2
terminals that can be configured as inputs or outputs.
The control panel is available in 2 different versions: for smaller sizes the control panel has only one BUS
(compatible, except for some exceptions, with all existing BUS devices that can be updated by the control panels)
while for all the others it already integrates the double BUS and the 868MHz bi-directional wireless transceiver
(compatible with all existing Ksenia wireless devices).
Particular attention is always put to the ease of installation and for this reason all the connection terminals are
removable. On all versions and regardless of the control panel size, the cards have an SD card slot to expand the
available memory, in addition to receiving directly on board (without communication BUS to maximize the transit
speed of information and data ) both 3G or 4G/LTE module (or 4G-LTE/IP via gemino IoT communicator) and, where
necessary, the PSTN module. In any case, the sending of voice messages, emails, sms, push notifications, Contact ID
and SIA DC-09 level III protocol to the Surveillance Centers is guaranteed.
The control panel board can be installed inside existing metal containers of varying sizes. In addition to the control
panel motherboard with its add-on modules, it allows you to allocate up to 7 expansion modules, the 18Ah back-up
battery and a 50W switching power supply.

lares 4.0 Installation manual
R30024.120en 6
1.2 Main functions
Hardware
Power supply voltage 15 Vcc ± 1%
Central Power Consumption (max) 100mA
Temperature range +5 °C / +40 °C 23 °F / 131 °F
Degree of protection IP IP34

lares 4.0 Installation manual
7 R30024.120en
1.3 Compatibility
Content of this document is compatible with all lares 4.0 versions.
1.3.1 lares 4.0 versions and characteristics
• KSI1400016.300 - lares 4.0 - 16
• KSI1400040.300 - lares 4.0 - 40
• KSI1410040.300 - lares 4.0 - 40 wls
• KSI1410140.300 - lares 4.0 - 140 wls
• KSI1410644.300 - lares 4.0 - 644 wls
• KSI1400016.300 - lares 4.0 - 16:
up to 16 IN + 16 OUT with 6 partitions - native with Ethernet interface. (no wireless on board - requires a duo
transceiver). Dedicated APP for Installer (Ksenia Pro) and User (lares 4.0).
• KSI1400040.300 - lares 4.0 - 40
up to 40 IN + 40 OUT with 12 partitions - native with Ethernet interface. (no wireless on board - requires a duo
transceiver). Dedicated APP for Installer (Ksenia Pro) and User (lares 4.0).
• KSI1410040.300 - lares 4.0 - 40 wls
up to 40 IN + 40 OUT with 12 partitions native with Ethernet interface and 868 MHz bidirectional wireless
(DPMS technology - Dynamic Power Management System) and double BUS on board.
Dedicated APP for Installer (Ksenia Pro) and User (lares 4.0).
• KSI1410140.300 - lares 4.0 - 140 wls
up to 140 IN + 140 OUT with 20 partitions native with Ethernet interface and 868 MHz bidirectional wireless
(DPMS technology - Dynamic Power Management System) and double BUS on board.
Dedicated APP for Installer (Ksenia Pro) and User (lares 4.0)
• KSI1410644.300 - lares 4.0 - 644 wls
up to 644 IN + 644 OUT with 30 partitions (and beyond on specific project): native with Ethernet interface and 868
MHz bidirectional wireless (DPMS technology - Dynamic Power Management System) and double BUS on board.
Dedicated APP for Installer (Ksenia Pro) and User (lares 4.0).
(*) lares 4.0 - 644+ wls: it is possible to agree a customization of lares 4.0, for projects larger than 644 zones and/or
outputs already available.

lares 4.0 Installation manual
R30024.120en 8
1.3.2 lares 4.0 wls 96 and characteristics
• KSI1410096.30x - lares 4.0 wls 96 Kit (polycarbonate box and power supply)
• KSI1413096.30x - lares 4.0 wls 96 Kit (polycarbonate box, power supply and 3G module)
• KSI1410096.3xx - lares 4.0 wls 96 Kit (polycarbonate box, power supply and keypad)
• KSI1413096.3xx - lares 4.0 wls 96 Kit (polycarbonate box, power supply, keypad and 3G module)
• KSI1410096.30x - lares 4.0 wls 96 Kit
Able to manage up to 96 overall zonas including 40 wireless and 18 exits. Possible expansion wired on BUS: up to 3
user interfaces (to choose between ergo keypads and volo / volo-in proximity readers), 1 domus to manage to
manage the thermostat functions, 6 expansion modules (to choose between auxi and auxi-H), 2 between opis and
divide, 1 siren (imago or radius).
IP peripheral management (ergo-T, IoT geminium, port 4.0, cameras).
Supplied with white or black polycarbonate plastic box, 25W power supply and indoor siren.
• KSI1413096.30x - lares 4.0 wls 96 Kit
Same functions of the model described above with the 3G module and related antenna included.
• KSI1410096.3xx - lares 4.0 wls 96 Kit
Same features of the model described above with ergo S keypad included (same colour as box).
• KSI1413096.3xx - lares 4.0 wls 96 Kit
Same features of the model described above with the 3G module and related antenna included, ergo S keypad
(same colour as box).

lares 4.0 Installation manual
9 R30024.120en
1.4 Technical data
1.5 lares 4.0 control panel and its peripherals
The following image offers a general overview of lares 4.0 and all the compatible peripherals that can be connected
via BUS - Wireless and IP.
lares 4.0 wls 96 16 40 40 wls 140 wls 644 wls
Power supply voltage 230 V~ -15/+10% 50 Hz 0.4A 230 V~ -15/+10% 50 Hz 0.8A
Power Supply Battery Charger
(Type A norm EN50131-6) 15V ± 1% 1.7A 15V ± 1% 3.5A
Current consumption (med./
stand-by)
50mA 40mA 40mA 60mA 60mA 60mA
Current consumption (max.) 80mA 70mA 70mA 100mA 100mA 100mA
Maximum current available for
external devices
160 mA grade 2 580 mA grade 2
230 mA grade 3
1500 mA grade 2
600 mA grade 3
Max. output voltage ripple 120 mV
Max. current for battery charging 800 mA
Maximum battery recharge
time to 80% 3 h 10 h 24 h
Deep discharge voltage
protection
10 V
Low battery threshold (restore) <11 V (13 V)
Low voltage threshold 12 V
Voltage below which the power supply output fault is signaled
Allocable batteries 2Ah 7Ah 18Ah
Maximum number of inputs 96 16 40 140 644
Built-in inputs (fixed +
programmable)
4 8 8 8 8
Maximum number of
outputs 18 16 40 140 644
Ethernet connectivity
management
YES
Power supply fault detection YES
Over voltage protection YES (17 V)
Combinations of Digital Key More than 4 billions
Alarm transmission system SP2, DP1, SP4, DP3
Time for generation and
transmission of alarm messages 3 sec.
Time for detection and
presentation failures 10 sec.
Protection class IP 34
Security grade 23
Environmental class II
Isolation Class I
Overall dimensions (WxHxD) 297x222x58 mm 255x295x80mm - 325x400x90 mm - 325x440x90 mm
Weight (with battery) 2.3 Kg (4.5 Kg) 4.2 Kg (10 Kg)
Operating range +5 / +40 °C
Humidity (not condensed) 95 %

FULL INSTALLATION CHART
KS-BUS 485
Universal
PoE / LAN
LAN
Wireless
Legend

lares 4.0 Installation manual
11 R30024.120en
2. INSTALLATION
Before starting with the installation, choose an appropriate site where to install the control panel, following the
recommendations below:
• Choose a vertical flat surface, with sufficient space around for installation and the opening operations.
• For an optimal wireless transmission, install the panel to an height of at least 150 cm from the floor, as much as
possible centrally located with respect to the peripherals. Avoid installations in cellars or in proximity of
obstacles that can disturb the propagation of radio waves, like huge metal or concrete beams, electrical
frames, big White Goods or large metallic masses.
• Choose a place difficult to reach by thieves and accessible by the user, better if protected by one or more
motion sensors.
• At the entrance, we suggest to consider the installation of just one keypad.
2.1 lares 4.0 control panel description and connections details
The main parts of the lares 4.0 system are identified below.
The image also shows the Power Supply connections: pay attention to the protection ground connection.
The large slot in the metal box bottom allows a convenient passing of cables for wiring the peripheral devices, even
in the case of large systems.
- Figure 1 -

lares 4.0 Installation manual
R30024.120en 12
2.1.1 Wall mounting instructions
In order to correctly install the metal cabinet and the components inside it, please follow the instructions here
below:
1. Fix the metal box on the wall, height ≤2mt, using screws Ø6mm (included).
2. Wire the cables as shown in picture “- Figure 1 -” page 11 .
3. Ensure the cables to the fixing holes (see “- Figure 1 -” page 11 ) using plastic clamps (Not included).
1. Large slot for passing cables.
2. Removable metal plate.
3. Bottom fixing holes.
4. Support for motherboard.
5. Support for motherboard expansion modules.
6. Tamper micro-switch.
7. 18Ah battery.
8. Cable Included for connecting the Power Supply and the Battery.
The two terminals without fastons are for the Power Supply (15Vdc), the two connectors
with fastons are for the Battery 12V.
9. lares 4.0 motherboard.
10. Connection terminals.
11. Battery terminals. If necessary use the included faston adapters (A).
12 Power Supply unit terminals.
13. 2A fuse.
14. Holes for cables fixing.

lares 4.0 Installation manual
13 R30024.120en
- Figure 2 -
- Figure 3 -
16. Metal box fixing holes. If necessary use the included 5 shims box (B).
17. Tamper micro-switch.
Removable metal plate

lares 4.0 Installation manual
R30024.120en 14
- Figure 4 -
4. Arrange outside the Panel an isolating device (e.g. Circuit Breaker Device 16A Curve C).
5. The Power Supply has an internal fuse (50W - F3.15AL). In case it should fail, its replacement requires the
opening of the Power Supply and must therefore be carried out by authorized personnel.
6. Wire the protection ground connection directly on the Power Supply unit.
7. The Power Supply conductors must be 1.5 mm² minimum section
8. Depending on the installed Control Panel, check the relative box in the label outside the metal cabinet, using a
petroleum solvent resistant pen.
15. Holes for front cover fixing. Use the included 4 screws. Aafter closing the cover of the
metal box, fix with the included screws at the indicated points 15.

lares 4.0 Installation manual
15 R30024.120en
2.1.2 lares 4.0 motherboard description
- Figure 5 -
Note1: Power Supply cable (n.8 in “- Figure 1 -” page 11 ) included for connecting the Power Supply and the Battery
is composed of four terminals: two terminals without fastons are for the Power Supply (15Vdc), the two connectors
with fastons are for the Battery 12V.
Note2: Inertial sensors and roller shutter sensors cannot be connected.
To install lares 4.0 on metal boxes code KSI7402117.010 or KSI7403130.010 adjust the Power Supply to 15V.
.
i1, i2, i3, i4, i5,i6, i7, i8 Input Terminals .
M1, M2 Input / Output Terminals (OC 500mA max).
+ P Positive Terminal of Power Supply (1.5A max).
- Negative Terminal of Power Supply.
+
KS-BUS
Serial BUS of
communication
Positive Terminal of BUS supply (15V 1,5 A Max).
AData
BData
-Negative Terminal of BUS supply.

lares 4.0 Installation manual
R30024.120en 16
2.2 lares 4.0 wls 96 control panel description and connections details
- Figure 6 -
To properly install the panel box to the wall, use the Ø 5mm screws (included).
1 GSMAntenna
2 GSM expansion module (optional)
3 Slot micro SIM Card
4 PSTN expansion module (optional)
5 Indoor siren
6 Condition LED
7LED
8 RF 868 Antenna
9 LINE /TEL: Connecting terminals to the telephone line
10 Power terminal block (220V)
11 BUS terminal block, removable inputs/outputs
12 Backup battery KSI7212020.000 (not included in the panels)
13 Fixing holes
14 Big openings for passing cable routing
15 Micro SD Slot for system upgrade and create/restore backup configuration (Micro SD not
included)
16 Fuse
17 Support screw tamper
18 Power Supply
19 Front cover
20 BUS connection terminal
21 Openings for passing speaker cables

lares 4.0 Installation manual
17 R30024.120en
2.2.1 Local or remote keypad description
- Figure 7 -
22 Integrate speaker
23 Ethernet Connector
24 QR-code label of control panel
25 Battery Connectors
S1 Switch (Reset / Data Factory)
S2 Switch (Secureweb Registration)
1 Soft Touch keypad
2ESCsofttouch
3ENTERkey
4 Soft touch Scroll for menu navigation:
4.1 Scroll to Sx
4.2 Scroll Down
4.3 Scroll to Dx
4.4 Scroll Up
5Dot-matrixdisplay
6 Bidirectional audio
7 Proximity Reader.

lares 4.0 Installation manual
R30024.120en 18
2.2.2 Wall mounting instruction
After removing the 2 fixing screws, open the box front as illustrated below (B):
1. push the plastic clips (A) with a screwdriver;
2. lift outward;
3. slide the cover downwards rotating outwards;
- Figure 8 -
4. drill the wall according to the fixing points and install the 5 mm screws included inside the package;
5. make sure to correctly position the panel box by using an air bubble level as indicated below (1).
- Figure 9 -
6. install and wire the 12V/2Ah battery as shown in the figure.

lares 4.0 Installation manual
19 R30024.120en
2.2.3 lares 4.0 wls 96 motherboard description
- Figure 10 -
Note1: Power Supply cable included for connecting the Power Supply and the Battery is composed of four
terminals: two terminals without fastons are for the Power Supply (15Vdc), the two connectors with fastons are for
the Battery 12V.
Note2: Inertial sensors and roller shutter sensors cannot be connected.
i1, i2, i3, i4 Input Terminals.
+ P Positive Terminal of Power Supply (1.5 A max).
- Negative Terminal of Power Supply.
o1 - o2 Output Terminals Open-Connector (OC 500mA max).
+
KS-BUS
Serial BUS of
communication
Positive Terminal of BUS supply (15V 1,5 A Max).
AData
BData
-Negative Terminal of BUS supply.

lares 4.0 Installation manual
R30024.120en 20
2.2.4 Outputs section
The motherboard of lares 4.0 wls 96 has 2 OC outputs of 500mA each one, programmable as you need:
polarities (normally open or normally closed), functions (bistable or monostable), activation times (ON time).
- Figure 11 -
2.3 Status LED
STATUS LED RD - L2
This LED blinks every time the Control Panel receives a valid radio packet.
STATUS LED - L3
The Control Panel has an RGB LED (L3) which, depending on the status, indicates some different information.
.
GREEN flashing Normal operation.
WHITE flashing Initialization phase.
PURPLE flashing NOR memory formatting.
RED flashing Firmware update in progress.
YELLOW flashing Data factory restore.
BLU flashing Reload backup of the configuration, following a firmware update with database
replacement.
FIXED YELLOW NOR memory access problems. execute Control Panel formatting.
FIXED RED Firmware problems. Contact Ksenia Security technical assistance.
