Switching between the standard page and the shiftSwitching between the standard page and the shift page:page:
The control panels have additional keys available on a shift page. Any expansion panels connected to a control
panel also have a shift page.
Press the function key labeled “SHIFT“ to change to the shift page. A yellow LED next to the “Shift” key means that
the second page is being displayed.
Press the “Shift” key again to return to the standard page.
Headset Mode:Headset Mode:
Press the function key labeled “HS” in order to switch the control panel to headset mode. The LED next to the “HS”
key and the master volume display are green when the headset mode is active. The volume of the loudspeaker
and headset are saved in the control panel separately.
The gooseneck microphone and the loudspeaker are inactive and are switched over to the headset connection (4-
pin male XLR) when the panel is in headset mode. Please use only headsets with electret microphones. The power
for the headset microphone is provided by the panel. Avoid the closing of the headset connection pins with anyAvoid the closing of the headset connection pins with any
metal objects.metal objects.
Setting iSetting individual cross point volumes:ndividual cross point volumes:
The ARTIST intercom system is equipped with individual level control for each cross point. In addition to setting the
overall volume for a control panel with the master volume control you may also regulate each destination
separately.
Turn the level control next to a display key to the left to reduce the incoming audio from that destination. Turn the
knob to the right to increase the volume. The volume LED correspondingly moves to the left or right. Please note
that the volume change is finer than the change in the LED displays. The LEDs first move after several steps of the
knob.
Resetting all volume levels to the norm:Resetting all volume levels to the norm:
Double clicking on the master volume control sets all cross point levels back to the norm set in the configuration
software.
Resetting individual volume levels to the norm:Resetting individual volume levels to the norm:
To reset a single cross point level back to the norm, hold down the “NORM” function key while pressing the
display/key of the desired cross point.
Muting an audio source:Muting an audio source:
To mute an audio source press the level control next to its display key for approximately one second. The volume
display above the key turns red and jumps to the far left. This functions independently of whether or not audio is
active or not at the time of the muting. The call signaling above the keys remains unaffected.
Press the level control again for approximately one second to unmute the cross point. The volume and volume
display will return to the last setting before being muted
An alternative way to unmute the cross point is to simply press the display key. In this case the programmed audio
connection will be created AND the level control will return to the previous level.
Please note that ARTIST differentiates between conferences and group calls. You could, for example, mute all of
the active conferences on your panel and still be reachable through a group call.
